ICOquit Smokerlyzer Bedienungsanleitung

User Manual

iCOquit®®Smokerlyzer®

Important Information/Reminders

WARNING: The iCOquit® Smokerlyzer® device is for individual use. Do not share your device with

anyone to lower the risk of cross-contamination.

CAUTION: Never use alcohol or cleaning agents containing alcohol or other organic solvents as these

vapours will damage the carbon monoxide sensor inside the iCOquit®.

CAUTION: Do not use hand-sanitising products containing alcohol when using the device as this may

damage the sensors.

CAUTION: Use of accessories not approved by the manufacturer will invalidate the warranty and

may compromise the functionality of the device.

NOTE: Once the iCOquit® battery has become flat, the iCOquit® device will need to be disposed of,

please see disposal guidance in the ‘Disposal of Device’ section of this manual.

Contents

Important Information/Reminders ..................................................................................................... 1

About This Manual.............................................................................................................................. 3

Definitions........................................................................................................................................... 3

Warnings ............................................................................................................................................. 3

Cautions .............................................................................................................................................. 3

Contraindications................................................................................................................................ 3

Intended Use/Indications.................................................................................................................... 4

Instrument Layout............................................................................................................................... 4

Installation and Set-up........................................................................................................................ 4

User Interface ..................................................................................................................................... 5

Using the iCOquit® .............................................................................................................................. 8

Connecting to the iCOquit® .............................................................................................................. 14

Completing a Breath Test.................................................................................................................. 15

Interpreting Breath Test Result......................................................................................................... 17

Smoking Habits Questions ................................................................................................................ 18

Navigation Drawer Menu Options .................................................................................................... 20

Troubleshooting................................................................................................................................ 25

Cleaning............................................................................................................................................. 25

Technical Specification...................................................................................................................... 26

Safety Information ............................................................................................................................ 27

Warranty ........................................................................................................................................... 31

Disposal of Device ............................................................................................................................. 31

Responsible Manufacturer and Contacts.......................................................................................... 31

About This Manual

The User Manual provides instructions on how to operate iCOquit® Smokerlyzer® monitor and the

iCOquit® app. It contains relevant information about the monitor, its uses and its care, including

step-by-step instructions with screens and illustrations.

Definitions

WARNING: indicates a potentially hazardous situation, which, if not avoided, may result minor or

moderate injury.

CAUTION: indicates a potentially hazardous situation, which, if not avoided, may result in damage to

the device.

NOTE: used to call attention to notable information that should be followed during use.

Warnings

1. Hands should be washed regularly in accordance with infection control practice.

2. Please do not attempt to modify the equipment in any way or use accessories not specified

by the manufacturer. Any attempt to do so will invalidate the warranty and may

compromise the safety of the device.

3. The iCOquit® Smokerlyzer® is for indoor use only.

Cautions

1. Never use alcohol or cleaning agents containing alcohol or other organic solvents as these

vapours will damage the carbon monoxide sensor inside the iCOquit®.

2. Do not use hand-sanitising products containing alcohol when using the device as this may

damage the sensors.

3. Use of accessories not approved by the manufacturer will invalidate the warranty and may

compromise the functionality of the device.

Contraindications

There are no known contraindications.

Intended Use/Indications

The iCOquit® Smokerlyzer® breath carbon monoxide (CO) monitor is intended for single patient use

by cigarette smoking individuals, notifying the individual user of the amount of CO on their breath

produced as a consequence of smoking activity. The Device can be used in smoking cessation

programmes.

Instrument Layout

1. Breath sample port

2. On/pairing button

3. LED light ring/pairing light

4. Information label including serial

number

5. Breath exhaust

Installation and Set-up

Downloading the iCOquit® app

App can be downloaded from the App Store or Google Play.

Connecting the iCOquit® device

To connect the device to the app, push the pairing button when instructed to. A blue light will flash

once to show pairing is complete.

NOTE: This can take up to 5 seconds and will only pair once initiated from within the iCOquit® app.

The device automatically disconnects after 10 seconds of inactivity or when a breath test is

complete.

User Interface

Splash Screen

The splash screen shall display upon starting the

app. The splash screen shall disappear once the

app has successfully loaded.

1. Email Address field.

2. Password field.

3. Forgotten Password button, starts a new

forgotten password process.

4. Sign In Button, starts the authentication

process.

5. Register button, starts the user

registration process.
