Icron RG2304-LAN Bedienungsanleitung

USB 2.0 RG2304-LAN

4-Port USB 2.0 Ethernet LAN

Extender System

Quick

Start

Guide

Before you get started, ensure that all the drivers required for your USB device(s) are installed.

Connect the Remote Extender to

the AC adapter and a power source.

Connect the Local Extender to the

computer using the included USB

cable.

Attach USB device(s) to the Remote

Extender.

Computer

Max 100m (Cat 5e cable not included)

1Place extenders where desired and connect

the Cat 5e extension link cabling to the

Link ports (RJ45) on the Local and Remote

Extender.

Direct Connect

Connect the Local Extender to the

computer using the included USB

cable.

Place the Remote Extender where desired.

Connect the Cat 5e patch cable from the

Link port (RJ45) to a network switch or wall

network port connected to a switch and

connect the Remote Extender to a power

source.

1Place the Local Extender where desired

and connect the Cat 5e patch cable from

the Link port (RJ45) to a network switch or

wall network port connected to a switch.

Network Connect

Attach USB device(s) to the Remote

Extender.

Link

Pair Config

Host

Activity

Link

Power

Link

Pair Config

Link

Pair

DC IN 24V@1A Config

Link

Pair

DC IN 24V@1A Config

Link

Pair Config

Host

Activity

Link

Power

Computer

Link

Pair Config

Link

Pair

DC IN 24V@1A Config

Max 100m between network devices

Local Extender (back view)

Remote Extender (back view)

Remote Extender (front view)

90-01048-A04

FCC Radio Frequency Interference Statement Warning

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received including interference that may cause undesired operation.

CE Statement

We, declare under our sole responsibility that the product, to which this declaration relates,is in conformity with European Standard EN 55022,

EN 61000 and EN 55024.

IC Statement

This Class B digital apparatus complies with Canadian ICES-003.

Certiﬁcation and Compliance

Information contained herein is subject to change

without notice. 90-01048-A04
