Icron VU5200 Bedienungsanleitung

VU5200 HDMI® + USB 2.0 Extender

HDMI® and USB 2.0 100m Cat 5e KVM Extender System

User Guide

Thank you for purchasing the VU5200 KVM Extender.

Please read this guide thoroughly.

FCC Radio Frequency Interference Statement Warning

This device complies with FCC Part 15 Subpart B.

CE Statement

The product meets European Standard EMC EN 55022 Class A, EN 61000, and EN 55024.

IC Statement

This Class A digital apparatus complies with Canadian ICES-003.

Information contained herein is subject to change without notice.

Document #90-01026-A05

Contents

Introduction...................................................................................................................... 4

Product Contents...........................................................................................................................................................................4

Requirements..................................................................................................................................................................................4

About the VU5200 KVM Extender............................................................................................................................................4

Compatibility and Recommended Setup ............................................................................................................................5

HDMI Compatibility ......................................................................................................................................................................5

Local Extender Description and Markings ...........................................................................................................................6

Remote Extender Description and Markings......................................................................................................................7

Installation Guide ............................................................................................................. 8

Installing the Local Extender Unit............................................................................................................................................8

Installing the Remote Extender Unit......................................................................................................................................8

Connecting the Local Extender to the Remote Extender...............................................................................................9

Connecting Power to the Local and Remote Extenders .................................................................................................9

Checking the Installation............................................................................................................................................................9

Connecting a USB Device...........................................................................................................................................................9

Troubleshooting Guide .................................................................................................. 10

Speciﬁcations.................................................................................................................. 12

Contacting Technical Support ....................................................................................... 13

Technical Glossary ......................................................................................................... 14

Introduction

The instructions in this guide assume a general knowledge of computer installation procedures, familiarity

with cabling requirements, and some understanding of USB devices.

NOTES provide additional useful and important information.

CAUTIONS provide important information about an operational requirement.

Product Contents

• Local Extender

• Remote Extender

• (2) 5V DC power adapter

• USB Cable

• HDMI Cable

• Quick Start Guide and Warranty Information

The product requires two power adapters, one for the local extender and one for the remote extender.

This product supports Cat 5e or better cabling (i.e. Cat 6, Cat 7, etc). All references to“Cat 5e”

should be read as“Cat 5e or better”.

Requirements

To complete the installation, you will require the following items that are not included with the product:

• A computer that is USB compatible (with USB compliant operating system) and has an HDMI port;

• USB 1.1 or 2.0 compatible device(s);

• A minimum of Cat 5e Shielded Twisted Pair (STP) cable with two Cat 5e RJ45 connectors (if using

surface cabling),

• A minimum of Cat 5e cabling with two information outlets and two Cat 5e patch cords with Cat 5e

RJ45 connectors (if using premise cabling).

While Cat 5e STP is the minimum category of twisted pair cabling, for the best experience, and to

minimize interference and cross-talk, Cat 6 STP or better is strongly recommended. When using

Cat 5e cabling, the layout and quality of your cable runs and connections becomes extremely

important. Please refer to the Cabling section on page 5 for more detailed information.

About the VU5200 KVM Extender

The VU5200 KVM Extender system incorporates ExtremeUSB®and HD Video technology, which enables users

to extend both HDMI video and USB 2.0 up to 100 meters (330 feet). The following ExtremeUSB features are

included:

• True Plug and play. No installation of software drivers required.

• Supports all major operating systems: Windows®, Mac OS X®, and Linux®

• Reliable operation with USB 2.0 and 1.1 devices and hubs

• Patented USB extension technology

note

Compatibility and Recommended Setup

The product is compatible with many graphics cards,operating systems and monitors, and supports

resolutions of up to 1080p, 1920 x 1200, and 4K. However, there is no guarantee that all devices will be

compatible with the product as there are a number of different factors that may impact the operation of this

KVM Extender.

This product supports both USB 1.1 and 2.0 devices.These devices include: keyboards, mice, ﬂash drives,

microphones, printers, and USB 1.1 web cameras. If uncertain whether your USB 2.0 device(s) can be

supported, please contact Technical Support.

USB 2.0 devices are limited to 30Mbps of throughput. Not all USB 2.0 devices will reach full

performance as a result.

HDMI Cables

Poorly terminated HDMI cables may result in damage to the devices they are connected to. Please ensure

that you use the HDMI cable provided with the product when connecting the local extender to the

host computer and high quality HDMI cables for all other HDMI connections.

Cabling

Solid core Category 6 STP cable with Category 6 RJ45 connectors is recommended for best

performance. Using Cat 5e or unshielded Cat 6 cabling may leave your signal more susceptible to

interference and noise which may result in poor video performance or reduced extension distance.

Cable Type Maximum Distance

Uncoiled Coiled

Notes

Solid Core Cat 5e UTP 100m (330 ft) 70m (229 ft) High susceptibility to electrical interference

Solid Core Cat 5e STP 100m (330 ft) 80m (262 ft) Moderate susceptibility to electrical interference

Solid Core Cat 6 UTP 100m (330 ft) 100m (330 ft) High susceptibility to electrical interference

Solid Core Cat 6 STP 100m (330 ft) 100m (330 ft) Recommended

Solid Core Cat 7 STP 100m (330 ft) 100m (330 ft) Recommended

Host Operating Systems

• Windows®

• Mac OS X®

• Linux®

USB Peripherals

• Keyboards • Mice

• MassStorageDevices • Printers

• USB1.1WebCameras • Microphones

HDMI Compatibility

The VU5200 KVM Extender supports the following HDMI features:

• Full uncompressed high deﬁnition 1080p, 1920 x 1200, and 4K video resolution

• Depth perception of 2D and 3D

• Deep Color and x.v. Color

• Lip Sync Pass-through

• CEC Pass-through

• HDCP Pass-through

note

Local Extender Description and Markings

The local extender connects to the host computer using the supplied HDMI and USB cable.

It’s important to use the HDMI cable supplied with the product when connecting the local extender to

the host computer to ensure proper operation.

ITEM TYPE DESCRIPTION

1 Power LED (Green) Green Light: The system is powered and ready to use.

No Light: The system does not have power.

2 Link LED (Green)

Green Light: The local and remote extenders are able to communicate with

each other across the link.

No Light: There is no communication between the local and remote

extenders.

3 USB LED (Green)

Green Light: The local extender and the host computer are communicating

with each other and working.

Blinking Green Light: The host has suspended communication with the

local extender.

No Light: The host and the local extender are not communicating or not

connected.

4 Video LED (Green)

Solid Green Light: HDCP (digital rights management) content is being

transmitted.

Blinking Green Light: Video (non-HDCP) content is being transmitted.

No Light: There is no video being transmitted.

5 Link Port (RJ45) Accepts RJ45 connector for Cat 5e cabling.

6 Config Reserved.

7 HDMI In Accepts HDMI connector for video input from the host computer.

8 Device Port (USB Type B) Connects the local extender to the host computer.

9 Power Port Connects to the 5V, 3A power adapter.

Front View

Rear View

1 2 3 4

Power

Link

USB

Video

HDMI InConfig 5V DCLink

Remote Extender Description and Markings

The remote extender provides HDMI output to a monitor and three USB Type A ports for standard USB

devices.Additional devices may be connected by attaching USB hubs.

ITEM TYPE DESCRIPTION

1 Power LED (Green) Green Light: The system is powered and ready to use.

No Light: The system does not have power.

2 Link LED (Green) Green Light: The local and remote extenders are able to communicate with

each other across the link.

No Light: There is no communication between the local and remote

extenders.

3 USB LED (Green) Green Light: The local extender and the host computer are communicating

with each other and working.

Blinking Green Light: The host has suspended communication with the

local extender.

No Light: The host and the local extender are not communicating or not

connected.

4 Video LED (Green) Solid Green Light: HDCP (digital rights management) content is being

transmitted.

Blinking Green Light: Video (non-HDCP) content is being transmitted.

No Light: There is no video being transmitted.

5 Link Port (RJ45) Accepts RJ45 connector for Cat 5e cabling.

6 HDMI Out Accepts HDMI connector to the remote monitor.

7 Conﬁg Reserved.

8 Device Port (USB Type A) Accepts USB device(s).

9 Power Port Connects to the 5V, 3A power adapter.

8 8 8

Front View

Rear View

1 2 3 4

HDMI Out Config 5V DCLink

Power

Link

USB

Video

Installation Guide

Before you can install the product, you need to prepare your site:

1. Determine where the computer is to be located and set up the computer.

2. Determine where you want to locate the remote desktop, including the monitor, keyboard, mouse

and any other USB device(s).

3. If you are using surface cabling, the product supports a maximum distance of 100m (330 ft).

If you are using premise cabling, ensure Cat 5e cabling is installed between the two locations,with

Cat 5e information outlets located near both the computer and the USB device(s), and the total

length, including patch cords, is no more than 100m.

Installing the Local Extender Unit

1. Place the local extender unit near the computer.

2. Connect the supplied USB cable to the USB port on the local extender, and an available USB 2.0/1.1

Type A Port on the computer.

3. Connect the supplied HDMI cable to the local extender (HDMI In), and an available HDMI Port on

the computer.

Installing the Remote Extender Unit

1. Place the remote extender unit near the monitor and USB device(s) in the desired remote location.

2. Connect an HDMI cable (not included) to the remote extender (HDMI Out) to the monitor.

3. Plug your USB Device(s) into the USB ports on the remote extender.

Local Extender

HDMI & USB

up to 100m Cat 5e

Remote Extender

Home Theater PC

(source)

HD TV/Monitor

(sink)

Connecting the Local Extender to the Remote Extender

With Surface Cabling

1. Plug one end of the Cat 5e cabling (not included) into the Link port (RJ45) on the local extender.

2. Plug the other end of the Cat 5e cabling into the Link port (RJ45) on the remote extender.

With Premise Cabling

1. Plug one end of a Cat 5e patch cord (not included) into the Link port (RJ45) on the local extender.

2. Plug the other end of the patch cord into the Cat 5e information outlet near the host computer.

3. Plug one end of the second Cat 5e patch cord (not included) into the Link port (RJ45) on the remote

extender.

4. Plug the other end of the second patch cord into the Cat 5e information outlet near the USB device(s).

Connecting Power to the Local and Remote Extenders

1. Plug the supplied 5V, 3A power adapter into a suitable AC outlet near the local extender.

2. Connect the power adapter to the local extender.

3. Plug the supplied 5V, 3A power adapter into a suitable AC outlet near the remote extender.

4. Connect the power adapter to the remote extender.

Use only the power adapters supplied with the product. Use of substitute adapters may cause permanent

damage to the system and will void the warranty.

Checking the Installation

1. On the local and remote extender units, check that the Power, Link, USB, and Video LEDs are on. If the

Link LED is off, then the cabling between the local and remote extenders is not installed properly or is

defective.

2. Check to see if the USB LED is on and the Video LED is blinking or on, if they are not, this indicates

there is no USB data or video data. Check the HDMI and USB connections to the host computer, and

the HDMI connection to the monitor. Check to see if any USB devices are connected to the remote

extender.

3. If the product is not displaying video or your USB device fails to be detected by your operating system,

consult the Troubleshooting section in this guide.

Connecting a USB Device

1. Install any software required to operate the USB device(s). Refer to the documentation provided for

your USB device(s), as required.

2. Connect the USB device to the device port on the remote extender.

3. Check that the USB device is detected and installed properly in the operating system.

Troubleshooting

The following table provides troubleshooting tips.The topics are arranged in the order in which they should

be executed,in most situations. If you are unable to resolve the problem after following these instructions,

please contact Technical Support for further assistance.

PROBLEM CAUSE SOLUTION

All LEDs on local

extender are off.

• The local extender is not

receiving power from the power

adapter.

1. Ensure that the power adapter is properly

connected to the local extender.

2.Check that the power adapter is connected to a

live source of electrical power.

All LEDs on

remote extender

are off.

• The remote extender unit is not

receiving power from the power

adapter.

1. Ensure that the power adapter is properly

connected to the local extender.

2.Check that the power adapter is connected to a

live source of electrical power.

Link LEDs on

local extender

and remote

extenders are

off.

•Thereisnoconnectionbetween

the local and remote extenders.

1. Ensure a Cat 5e cable is connected between the

local and remote extenders.Ensure Cat 5e STP or

better cabling with conductor RJ45 connectors is

used.

2.Connect a new short Cat 5e patch cord between

the local and remote extenders to determine if the

original Cat 5e cable is defective.

3. Ensure the Cat 5e cable is as straight as possible

(i.e. not coiled).

Link LED on

local extender is

on, USB LED on

local extender

is off.

• The host computer is not

powered on.

• The local extender is not

connected to the computer.

• The computer does not support

USB hubs.

• The USB cable is defective.

• The unit is malfunctioning.

1. Disconnect all USB devices from the remote

extender.

2.Disconnect the local extender from the computer.

3. Disconnect the local and remote extenders from

the power adapters.

4. Reconnect the local extender to the power

adapter.

5. Reconnect the remote extender to the power

adapter.

6. Reconnect the USB devices to the remote

extender.

7. Reconnect the local extender to the computer.

8.If the USB LED continues to stay off, contact

Technical Support.

Inhaltsverzeichnis

Andere Icron Extender Handbücher

Icron

Icron Raven 3204C Bedienungsanleitung

Icron

Icron USB 3.0 Spectra 3022 Bedienungsanleitung

Icron

Icron USB 2.0 RG2301 Bedienungsanleitung

Icron

Icron 422 Bedienungsanleitung

Icron

Icron Spectra 3022 Bedienungsanleitung

Icron

Icron USB 3.0 Spectra 3022 Bedienungsanleitung

Icron

Icron EL5353 Bedienungsanleitung

Icron

Icron USB 2.0 Ranger 2304 Bedienungsanleitung

Icron

Icron EL5200 Bedienungsanleitung

Icron

Icron USB Ranger 2212 Bedienungsanleitung

Icron

Icron USB 3-2-1 Starling 3251C Bedienungsanleitung

Icron

Icron USB 3-2-1 Raven 3124 Bedienungsanleitung

Icron

Icron USB 2.0 Ranger 2101 Bedienungsanleitung

Icron

Icron USB 2.0 Ranger 2104 Bedienungsanleitung

Icron

Icron USB Ranger 2211 Bedienungsanleitung

Icron

Icron USB 2.0 RG2304 Bedienungs- und Wartungsanleitung

Icron

Icron USB 2.0 Ranger 2204 Bedienungsanleitung

Icron

Icron USB 3-2-1 Starling 3251C Bedienungsanleitung

Icron

Icron 00-00437 Bedienungsanleitung

Icron

Icron Raven 3204C Pro Bedienungsanleitung

Icron

Icron EL5363 Bedienungsanleitung

Icron

Icron USB 2.0 Ranger 2312 Bedienungsanleitung

Icron

Icron USB 2.0 Ranger 2304 Bedienungsanleitung

Icron

Icron USB Rover 1850 Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung
