IHome IBT90 Bedienungsanleitung

Color Changing Rechargeable

Bluetooth Speaker

with Speakerphone

instruction manual

Model: iBT90

CHARGE

BEFORE

USE

Introduction

Thank you for purchasing the iHome iBT90. This product is designed to

provide high quality wireless sound for your iPad, iPhone, iPod, computer,

PDA or other Bluetooth audio device.

This instruction booklet explains the basic operation and care of the unit.

Please read them carefully and keep for future reference.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or

excessive heat.

• Protect your furniture when placing your unit on a natural wood and

lacquered ﬁnish. A cloth or other protective material should be placed

between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water.

Stronger cleaning agents, such as benzene, thinner or similar materials

can damage the surface of the unit.

iBT90

What’s Included

• iBT90 speaker

• USB charging cable

iBT90

USB charging cable

iBT90

Back

Meet Your iBT90

Top

Red Charging Status

Indicator Light

Blue Bluetooth Status

Indicator Light

Power On/O button

Front

Microphone

Bluetooth/

Speakerphone

Button

Color Mode Button

(press and hold for

Battery Review)

Lower/Raise

Volume Buttons

USB Out Port

(charges other

devices)

USB In Port

(charges unit)

Aux-in Jack

Splashproof seal

(press on lower left corner of

seal ﬁrst for easiest seal closing)

Reset port

Charging the Unit

CHARGE UNIT BEFORE USE/KEEP UNIT OFF FOR FASTER CHARGING

1. Connect the micro USB plug on the included USB cable to the micro

USB In charging port on the back of the unit.

2. Connect the standard USB plug end of the cable to a powered USB

port on a computer, a USB AC adaptor or other USB charging device.

For ﬁrst time use, charge unit for about 4 hours. The red charging

status indicator LED on top of the unit turns solid while charging and

turns o once unit is fully charged. When unit is not connected to

charging source,indicator blinks when battery needs charging.

TIP: On some iOS (Apple)

devices, you can view the iBT90

battery status on your device’s

screen. When device is paired

and connected, look for a

vertical battery icon next to the

Bluetooth icon on the upper

right corner of the

device’s screen.

iBT90

Charge via computer USB port, USB AC adaptor or other powered USB port

iHome iBT90 USB port

Computer USB port

Computer

connected to

working outlet

iHome iBT90 USB port

USB AC adaptor

(not included)

USB AC adaptor

connected to working outlet

3. To review the charging status of the unit while it is charging, press and

hold the Color Mode Button. The cabinet lights will ﬂash green

from bottom to top for 5 seconds to show unit is charging.

Reviewing Battery Charge Level

(Charger is Disconnected and unit is ON)

1. Press and hold the Color Mode Button when unit is ON but not

charging (micro USB cable not connected) to enter Battery Review

Mode. The cabinet lights will blink and built-in voice will announce the

current battery level.

Charging Devices Via USB Out Port (Charger is Disconnected

and unit is ON)

NOTE: The iBT90 will only charge devices when operating on the

internal battery (when NOT connected to power source via the USB

POWER IN port).The unit must be powered ON to charge devices via the

USB Out Port. To charge devices via USB while operating on the internal

battery, we recommend that the unit be fully charged ﬁrst. The iBT84 will

not charge external devices via USB when internal rechargeable battery is

too low (red indicator is blinking). To save battery power, USB charging is

limited to 1 hour when no audio is playing.

1. Lift splashproof cover on the back of the unit to expose the USB Out

Port.

2. Connect the standard size end of a USB cable (not included) to the

USB Out Port and connect the other end to the charging port on your

device.

3. Press and hold the Power On/O Button for 2 seconds to turn the

unit ON.

4. Some devices require more power than the 1 Amp the USB Out Port

provides. Monitor the charging progress on your deivice. If your

device does not charge, use the charger that came with it.

iBT90

Pairing Your Device

Pairing is the set-up process to introduce your Bluetooth-capable device to

the iBT90. Once your device is paired, the iBT90 can recognize it and you can

play your audio through it.

1. Turn on your Bluetooth device and make it “discoverable”

by turning on Bluetooth mode (check in Options or

Settings).

2. Press and hold the Power On/O Button for 2 seconds to

turn on the iBT90. The ﬁrst time the unit is powered on,

it will enter auto-pairing mode and attempt to connect to

a Bluetooth device (see step 4). Otherwise, power on,

then follow step 3 to begin pairing.

3. Press and hold the Bluetooth/Speakerphone Button for

2 seconds. The iBT90 will beep and the Bluetooth status

indicator light on top of the unit will ﬂash quickly.

If Color Mode is on, the cabinet lights will ﬂash blue and

red.

4. “iHome iBT90” should appear in your device’s Bluetooth

menu. If “Not Paired”, “Not Connected” or similar

message appears, select “iHome iBT90” to connect it. If

prompted for a passcode, enter “1234” on your device’s

keypad.

5. If pairing is successful, 1 beep will sound and the Bluetooth status

indicator light will appear solid blue (in Color Mode, cabinet will ﬂash

blue twice), indicating the iBT90 is ready to play music. There should

also be an indication on your device. If no device is successfully paired

within 3 minutes the iBT90 will default to previous mode. Once the

iBT90 is paired to a device, it will attempt to autolink when the device

is within range (about 33 feet).

Using the iBT90

For iPhone

iHome iBT90 iHome iBT90

For other

Pairing with a Dierent Device

When you power ON the speaker, it will automatically link with the previously

paired Bluetooth device as long as that device is still within range (about 33 feet).

To pair with a dierent device follow steps 1 - 4 under ”Pairing Your Device” on

previous page.

Playing Audio Via Bluetooth

1. Press and hold the Power On/O Button for 2 seconds to turn on the unit. The

Bluetooth status indicator will glow solid blue when a linked device is in range

and detected. You can then listen to audio streamed wirelessly from your paired

Bluetooth device.

2. Use controls on your Bluetooth device to play, pause and navigate tracks.

3. Press the +or –Button to adjust the iBT90 volume. You can also adjust

volume on your device.

4. When done listening, press the Power On/O Button to turn the unit OFF.

Remember to turn o your device, too.

Speakerphone Operation

NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a

call.

1. When a call is received, playing music is muted to hear the ring tone and the

cabinet lights ﬂash green. Press the Bluetooth/Speakerphone Button to

answer the call. For call waiting function, press the button again to answer the

second call, and once more to return to the original call.

2. When a call is completed, press the Bluetooth/Speakerphone Button to

end the call and resume previous function.

Using the iBT90

Playing Audio via Aux In

1. Connect micro USB charging/audio cable to

the Charging/Aux-in USB Port on the side of

the unit and connect the 3.5mm audio plug end

to the headphone or line-out jack on your audio

device.

2. Press and hold the Power On/O Button for 2

seconds to turn the unit ON.

3. Power on the audio device and use the controls

on the device to play or pause audio and to

navigate tracks.

4. Press the –or +Button to adjust the system

volume. You can also adjust volume on your

device.

5. When done listening, slide the Power On/O

Switch to OFF turn the unit OFF. Remember to

turn o your device, too.

Using Color Modes

There are six color modes, which you cycle through in this order:

a. Slow Fade (colors slowly fade from one into the next

b. Fast Change (colors change rapidly)

c. One Color (select a favorite color)

d. Pulse to Music (lights ﬂash to the beat of the music)

e. Preset Pulsing (each light array pulses through its own preset pattern of colors)

f. O (no display)

1. Press and hold the Power On/O Button for 2 seconds to turn the unit ON.

2. Press the Color Mode Button repeatedly to cycle to the desired color

mode. For One Color mode, ﬁrst cycle to Fast Change mode and press the

Color Mode Button when the desired color appears. For Pulse to Music, make

sure the volume on your connected Bluetooth device is above 50%.

3. When done, slide the Power On/O Switch to OFF turn the unit OFF.

Using the iBT90

Unit doesn’t respond (no power)

• Make sure unit is completely charged.

• Check that all connections are correct and properly plugged in.

• Make sure your device is properly paired with the iBT90.

• Make sure the unit is on

Unit doesn’t respond (locked up/ “frozen”)

If the unit does not respond, try resetting the unit by inserting the end of a

paperclip or similar into the Reset Port located under the splashproof seal

on the back of the unit .

To clear Bluetooth settings, press and hold both the Bluetooth/

Speakerphone Button for about 10 seconds. Note that doing so will clear

settings, and any Bluetooth devices will need to be re-paired.

Trouble pairing device with iBT90

Bluetooth implementation varies depending on your device’s hardware and

operating system. Please see our website for updates on pairing.

• When you power ON the speaker, it will automatically link with the last

previously paired Bluetooth device if the device is still within range (about 33

feet). To pair with a dierent device you must turn o Bluetooth capability on

the already paired device, or take it out of range.

• If your device does not auto-link when within range, re-pair the device. To do so,

ﬁrst delete the iBT90 from your Bluetooth devices menu.

• Make sure your device is working properly. Check your device’s manual for

details on Bluetooth pairing and linking.

For further information and to see the latest instructions, visit

www.ihome.com/support

Troubleshooting

Inhaltsverzeichnis

Andere iHome Sprecher Handbücher

iHome

iHome Voice iGV1 Bedienungsanleitung

iHome

iHome iBT73 Bedienungsanleitung

iHome

iHome TIMEBOOST iBTW41 Bedienungsanleitung

iHome

iHome iHPA-1500LT Bedienungsanleitung

iHome

iHome Beauty iCVBT52 Bedienungsanleitung

iHome

iHome iH8 Bedienungsanleitung

iHome

iHome iBT374 Bedienungsanleitung

iHome

iHome iBT16 Bedienungsanleitung

iHome

iHome HW4 Bedienungsanleitung

iHome

iHome iBT61 Bedienungsanleitung

iHome

iHome iBT371 Bedienungsanleitung

iHome

iHome iHM78 Bedienungsanleitung

iHome

iHome B66 Bedienungsanleitung

iHome

iHome iBT60 Bedienungsanleitung

iHome

iHome iBT9 Bedienungsanleitung

iHome

iHome Star Wars MILLENNIUM FALCON iHome Li-B17E7 Bedienungsanleitung

iHome

iHome iBN27 Bedienungsanleitung

iHome

iHome iBT371 Bedienungsanleitung

iHome

iHome iM71 Bedienungsanleitung

iHome

iHome Beauty REFLECT TRIFOLD iCVBT4 Bedienungsanleitung

iHome

iHome iW3 air series Leitfaden

iHome

iHome iBN19 Bedienungsanleitung

iHome

iHome iBT371 Bedienungsanleitung

iHome

iHome iHRK-500S-PR Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung

iHome iBT90 Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken
