Ikan ELE-USB-DRGFLY Bedienungsanleitung

ELE-USB-DRGFLY

EV2 DragonFly with USB Control Grip QUICKSTART GUIDE

www.ikancorp.com

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

3903 Stoney Brook Dr. Houston TX 77063

1.713.272.8822

[email protected]

© 2010 ikan Corporation. All right reserved

What’s included

Checked by

 1 x ELE-DRGFLY

 1 x CTL-USB01

QuickStart Guide:

 ELE-DRGFLY

 CTL-USB01

ELE-USB-DRGFLY

EV2 DragonFly with USB Control Grip QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

PRODUCT ASSEMBLY

Assembling your DragonFly Handheld Rig with USB Control Grip is quick and easy,

since the majority of the rig has already been pre-assembled for you. Line up the

holes on the Handle Bars with the holes of the Handle Arm, insert the 1/4-20

Screws and tighten using the included Hex Key. Then, line up the holes on the

Handle Bars with the holes of the USB Control Grip and tighten with the D-Rings .

Next, attach your camera to the bottom Plate, using the D-Ring, and tighten securely.

ELE-USB-DRGFLY

EV2 DragonFly with USB Control Grip QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

PRODUCT ASSEMBLY

Assembling your DragonFly Handheld Rig with USB Control Grip is quick and easy,

since the majority of the rig has already been pre-assembled for you. Line up the

holes on the Handle Bars with the holes of the Handle Arm, insert the 1/4-20

Screws and tighten using the included Hex Key. Then, line up the holes on the

Handle Bars with the holes of the USB Control Grip and tighten with the D-Rings .

Next, attach your camera to the bottom Plate, using the D-Ring, and tighten securely.
