IKEA FRYSA Bedienungsanleitung

FRYSA

Please refer to the last page

of this manual for the full list

of IKEA appointed Authorized

Service Centre and relative

national phone numbers.

Gehen Sie dazu auf die letzte

Seite dieser Broschüre. Dort

nden Sie eine Übersicht mit den

entsprechenden Telefonnummern

und Kontaktdaten unserer

autorisierten Kundendienste.

Consultez la dernière page de ce

manuel pour la liste complète des

centre d’entretien et de réparation

agréés IKEA avec leur numéro de

téléphone respectifs.

Siete pregati di contattare il

numero del Centro Assistenza

Autorizzato incaricato da IKEA

riportato sull’ultima pagina di

questo manuale.

ENGLISH 5

DEUTSCH 19

FRANÇAIS 35

ITALIANO 56

min.

200 cm2

min.

200 cm

Before using the appliance, read

these safety instructions. Keep

them nearby for future reference.

These instructions and the

appliance itself provide important

safety warnings, to be observed

at all times. The manufacturer

declines any liability for failure to

observe these safety instructions,

for inappropriate use of the

appliance or incorrect setting of

controls.

SAFETY WARNINGS

Very young children (0-3

years) should be kept away from

the appliance. Young children

(3-8 years) should be kept

away from the appliance unless

continuously supervised. Children

from 8 years old and above and

persons with reduced physical,

sensory or mental capabilities

or lack of experience and

knowledge can use this appliance

only if they are supervised or

have been given instructions on

safe use and understand the

hazards involved. Children must

not play with the appliance.

Cleaning and user maintenance

must not be carried out by

children without supervision.

Children aged from 3 to 8 years

are allowed to load and unload

refrigerating appliances.

PERMITTED USE

CAUTION: The appliance is

not intended to be operated by

means of an external switching

device, such as a timer, or

separate remote controlled

system.

This appliance is intended

to be used in household and

similar applications such as: staff

kitchen areas in shops, ofces

and other working environments;

farm houses; by clients in hotels,

motels, bed & breakfast and other

residential environments.

This appliance is not for

professional use. Do not use the

appliance outdoors.

The bulb used inside the

appliance is specically designed

for domestic appliances and is not

suitable for general room lighting

within the home (EC Regulation

244/2009).

The appliance is designed

for operation in places where

the ambient temperature comes

within the following ranges,

Safety Information

Table of contents

Safety Information 5

Product description 10

Controls 10

First Use 11

Daily use 12

Helpful hints and tips 13

What to do if... 14

Technical data 15

Environmental concerns 16

IKEA GUARANTEE 17

ENGLISH

ENGLISH 6

according to the climatic class

given on the rating plate. The

appliance may not work properly

if it is left for a long time at a

temperature outside the specied

range.

Climatic class ambient

temperatures (°C)

SN: From 10 to 32

N: From 16 to 32

ST: From 16 to 38

T: From 16 to 43

This appliance does not

contain CFCs. The refrigerant

circuit contains R600a (HC).

Appliances with Isobutane

(R600a): isobutane is

a natural gas without

environmental impact, but is

ammable. Therefore, make

sure the refrigerant circuit

pipes are not damaged,

especially when emptying the

refrigerant circuit.

WARNING!: Do not damage

the appliance refrigerant circuit

pipes.

WARNING!: Keep ventilation

openings, in the appliance

enclosure or in the built-in

structure, clear of obstruction.

WARNING!: Do not

use mechanical, electric or

chemical means other than

those recommended by the

Manufacturer to speed up the

defrost process.

WARNING!: Do not use or

place electrical devices inside

the appliance compartments if

they are not of the type expressly

authorised by the Manufacturer.

WARNING!: Ice makers and/

or water dispensers not directly

connected to the water supply

must be lled with potable water

only.

WARNING!: Automatic ice-

makers and/or water dispensers

must be connected to a water

supply that delivers potable water

only, with mains water pressure

between 0.17 and 0.81 MPa (1.7

and 8.1 bar).

Do not store explosive

substances such as aerosol cans

and do not place or use gasoline

or other ammable materials in or

near the appliance.

Do not swallow the contents

(non-toxic) of the ice packs

(provided with some models).

Do not eat ice cubes or ice lollies

immediately after taking them

out of the freezer since they may

cause cold burns.

For products designed to use

an air lter inside an accessible

fan cover, the lter must

always be in position when the

refrigerator is in function.

Do not store glass containers

with liquids in the freezer

compartment since they may

break. Do not obstruct the fan (if

included) with food items. After

placing the food check that the

freezer door closes properly.

ENGLISH 7

Damaged gaskets must be

replaced as soon as possible.

Use the freezer compartment

only for storing frozen food,

freezing fresh food and making

ice cubes.

Avoid storing unwrapped

food in direct contact with

internal surfaces of the freezer

compartments.

C-Pentane is used as blowing

agent in the insulation foam

and it is a ammable gas.

The most appropriate

compartments of the appliance

where specic types of food are

to be stored, taking into account

different temperature distribution

in different compartments in the

appliance, are as follows:

4 star zone (****) compartment

is suitable for freezing foodstuffs

from ambient temperature

and for storing frozen food

as the temperature is evenly

distributed throughout the entire

compartment. Purchased frozen

food has the storage expiration

date stated on the packaging.

This date takes into account the

type of food being stored and

therefore this date should be

respected. Fresh food should

be stored for the following time

periods: 1-3 months for cheese,

shellsh, ice cream, ham/sausage,

milk, fresh liquids; 4 months for

steak or chops (beef, lamb, pork);

6 months for butter or margarine,

poultry (chicken, turkey); 8-12

months for fruits (except citrus),

roast meat (beef, pork, lamb),

vegetables. Expiration dates on

the packaging of foods in the

2-star zone must be respected.

To avoid food contamination,

please observe the following:

– Opening the door for long

periods can cause a signicant

increase of the temperature

in the compartments of the

appliance.

– Regularly clean surfaces that

may come into contact with

food and accessible drainage

systems.

– Clean water tanks if they have

not been used for 48 h; ush

the water system connected to

a water supply if water has not

been drawn for 5 days.

– Store raw meat and sh in

suitable containers in the

refrigerator, so that it does not

come into contact with or drip

onto other food.

– Do not freeze fresh food in one,

two or three-star compartments.

– If the refrigerating appliance

is left empty for long periods,

switch off, defrost, clean, dry,

and leave the door open to

prevent mould developing inside

the appliance.

ENGLISH 8

INSTALLATION

The appliance must be

handled and installed by two or

more persons - risk of injury. Use

protective gloves to unpack and

install - risk of cuts.

Installation, including

water supply (if any), electrical

connections and repairs must

be carried out by a qualied

technician. Do not repair or

replace any part of the appliance

unless specically stated in the

user manual. Keep children

away from the installation site.

After unpacking the appliance,

make sure that it has not been

damaged during transport. In the

event of problems, contact the

dealer or your nearest Aftersales

Service. Once installed, packaging

waste (plastic, styrofoam parts

etc.) must be stored out of reach of

children - risk of suffocation. The

appliance must be disconnected

from the power supply before

any installation operation - risk of

electric shock. During installation,

make sure the appliance does

not damage the power cable -

risk of re or electric shock. Only

activate the appliance when the

installation has been completed.

Be careful not to damage

the oors (e.g. parquet) when

moving the appliance. Install the

appliance on a oor or support

strong enough to take its weight

and in a place suitable for its size

and use. Make sure the appliance

is not near a heat source and

that the four feet are stable and

resting on the oor, adjusting

them as required, and check that

the appliance is perfectly level

using a spirit level. Wait at least

two hours before switching the

appliance on, to ensure that the

refrigerant circuit is fully efcient.

WARNING: When positioning

the appliance, ensure the supply

cord is not trapped or damaged.

WARNING: To avoid a hazard

due to instability, positioning

or xing of the appliance must

be done in accordance with the

manufacturer instructions. It’s

forbidden to place the refrigerator

in such way that the metal hose

of gas stove, metal gas or water

pipes, or electrical wires are in

contact with the refrigerator back

wall (condenser coil).

To guarantee adequate

ventilation, the distance between

the rear of the appliance and the

wall behind the appliance should

be 50 mm, to avoid access to

hot surfaces. A reduction of this

space will increase the Energy

consumption of product. Please

remove the power cord from

condenser hook during installation

before connecting product to

power supply.

ENGLISH 9

ELECTRICAL WARNINGS

It must be possible to

disconnect the appliance from the

power supply by unplugging it if

plug is accessible, or by a multi-

pole switch installed upstream of

the socket in accordance with the

wiring rules and the appliance

must be earthed in conformity

with national electrical safety

standards.

Do not use extension leads,

multiple sockets or adapters.

The electrical components must

not be accessible to the user

after installation. Do not use the

appliance when you are wet or

barefoot. Do not operate this

appliance if it has a damaged

power cable or plug, if it is not

working properly, or if it has been

damaged or dropped.

If the supply cord is damaged,

it must be replaced with an

identical one by the manufacturer,

its service agent or similarly

qualied persons in order to

avoid a hazard - risk of electric

shock.

WARNING: Do not locate

multiple portable socket-outlets

or portable power supplies at the

rear of the appliance.

Feets of the product: in Fs not

available; in built in - the “feet are

not adjustable - and the METOD

cabinet should be levelled with

spririt level.

ENGLISH 10

Product description

****

Controls

AOn/Stand-by

BTemperature display

CFast Freeze

DEco function

EBlack Out alarm

Turning Off the Sound

Alarm

GTemperature Setting

1Control panel

2NO FROST Module

3Flap Freezer

4Glass shelf

5Middle Drawer Freezer

6Small Drawer Freezer

7Big Drawer Freezer

8Lower Drawer Freezer

9Door magnet switch housing

Characteristics, technical data and images

may vary according to the model.

Accessories

Freezer block

Ice tray

A B C

D E F

On/Stand-by

Press for 3 seconds the Abutton to turn the

appliance off.

In Stand-by mode, two dashes light up on

the display and the light in the refrigerator

compartment does not turn on.

To turn the product on again, a brief press

on the button is sufcient.

Note: this procedure does not disconnect

the appliance from the electricity supply.

Temperature display

The display shows the freezer compartment

temperature (between -16°C and -24°C).

It is possible to set a different temperature

with the Gbutton.

Andere Handbücher für FRYSA

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere IKEA Kühlschrank Handbücher

IKEA

IKEA FROSTIG SC155 Bedienungsanleitung

IKEA

IKEA FROSTIG SC136 Bedienungsanleitung

IKEA

IKEA KÖLDGRADER Bedienungsanleitung

IKEA

IKEA STJARNSTATUS 204.621.51 Bedienungsanleitung

IKEA

IKEA TILLREDA Bedienungsanleitung

IKEA

IKEA SVALNA Bedienungsanleitung

IKEA

IKEA TILLREDA Bedienungsanleitung

IKEA

IKEA HUTTRA Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

IKEA

IKEA VINTERKALL Bedienungsanleitung

IKEA

IKEA FROSTIG BCF201/65 Bedienungsanleitung

IKEA

IKEA LAGAN Bedienungsanleitung

IKEA

IKEA ALINGSAS Bedienungsanleitung

IKEA

IKEA SMAFRUSEN Bedienungsanleitung

IKEA

IKEA ISC23CDEXB00 Bedienungsanleitung

IKEA

IKEA ISANDE Bedienungsanleitung

IKEA

IKEA MEDGANG FFRC MEDG 21976 BL Bedienungsanleitung

IKEA

IKEA NUTID Leitfaden

IKEA

IKEA TILLREDA Bedienungsanleitung

IKEA

IKEA FROSTIG BC155 Bedienungsanleitung

IKEA

IKEA FÖRKYLD Bedienungsanleitung

IKEA

IKEA Svalkas Bedienungsanleitung

IKEA

IKEA SMAFRUSEN Bedienungsanleitung

IKEA

IKEA RISNAS Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
