Ikelite 6171.11 Bedienungsanleitung

ProductRegistration

Please register your product within 15 days of purchase. Our product

registration database is the quickest way for us to contact you in the

event of a product update.

To register, send a photo of the above registration label to us via

[email protected] along with your name, address, and phone

number.

UnderwaterTTL Housingfor PanasonicLumix LX100,

LX100II,Leica D-Lux (Typ109)

Product Number 6171.11

Introduction

Thank you for your purchase of Ikelite products.

Our primary focus is to provide quality, professional grade products

for use in and under water. Our products are designed, manufactured,

and distributed from our sole facility in Indianapolis, USA where we

started in 1962.

We are available if you have any questions or want photo advice.

Send us an email 24 hours a day to [email protected]. We strive to

reply within 1 business day.

An electronic version of this instruction manual is available for

download via the product page on our website:

https://www.ikelite.com

IntheBox

• Housing

• Main o-ring # 0110 (installed)

• Port cover # 0200.08 (installed)

• Waterproof bulkhead cap # 9104.7 (installed)

• .050” hex key # 0945.11

• 1/16” hex key # 0945.16

• 1/8” hex key # 0945.18

• Silicone lubricant 1cc tube

ImportantNotices

»A bulkhead cap or sync cord must be attached to the housing

bulkhead for waterproof operation. Never submerge the

housing in water without either a sync cord or bulkhead cap

attached.

»Do not pull the shutter trigger without a camera installed. You

may accidentally detach or damage the control spring.

»Never leave a housing in a rinse tank, even if it is the only

system in the tank. Accidental damage may occur when the

user walks away from a housing while it is in the rinse tank.

»Do not use alcohol, cleaning agents, spray lubricants, Rain-X,

or other solvents on the housing or lens port. Use of an

incompatible chemical compound can damage the plastic and

o-rings, and may result in leaking.

AccessoryPort

»Do not remove the Accessory Port Plug unless you are

installing a compatible accessory.

Your housing features one spare Accessory Port which may be used

for attachment of factory optional or aftermarket housing accessories.

The Accessory Port is 1/2-20 threaded.

Visit ikelite.com for information on optional accessories.

Contents

Product Registration 1

Introduction 2

In the Box 2

Important Notices 3

Accessory Port 3

Getting to Know Your Housing 6

Tray Mounts 8

Accessory Port 8

Trigger Extension 8

Lanyard Mount 8

Setting Up Your Camera 9

Pre-Installation Checklist 9

Camera Settings 9

Exposure Settings 9

Setting Up Your Housing 10

Opening the Housing 10

Inserting the Camera 10

Attaching the Hotshoe 12

Closing the Housing 13

Setting Up An External Strobe 13

TTL Strobe Compatibility 14

Attaching an Electrical Sync Cord 14

Taking your Housing in the Water 16

Final Check 16

Entering the Water 16

Shooting Underwater 17

Learning about Underwater Photography 17

Maintenance 18

Post-Dive 18

Lens Port 19

Storage 19

Servicing Recommendations 20

Lubricating Controls 20

Lubricating Push Buttons 20

Lubricating Control Shafts 21

Troubleshooting 23

Spare Parts 25

Limited Warranty 25

Service and Repairs 25

GettingtoKnow Your Housing

Shutter

Filter

Zoom

Shutter speed

Bulkhead

Lidsnap Lens Port

Tray mounts

Aperture

Fn3 Fn2

AE/FE

LOCK

Fn1 DISP

ISO

Fn3 Fn2

AE/FE

LOCK

Fn1 DISP

ISO

Accessory

port

Lid hook

O-ring

Camera mount

plate

Lanyard

Exposure

compensation

Rear * dial

ON/OFF

MENU/SET

White Balance

Playback

Drive Mode

Fn1/Delete

AF Mode

Tray Mounts

This housing features two 1/4-20 threaded tray mounts on the bottom

of the housing. The spacing between the tray mounts is 3” (76.2 mm).

Optional tray with handles and mounting hardware are sold separately.

It is recommended to detach and thoroughly rinse the tray mounts,

tray, and mounting hardware, with fresh water routinely during

continuous use and prior to storage.

Accessory Port

This housing features one spare accessory port which may be used

for the attachment of optional accessories. This port accepts ttings

designed for a 1/2” through or 1/2-20 threaded hole.

The optional Vaccum Kit # 47012 may be installed in this location. A

hand pump with gauge allows you to draw a vacuum on the house

to simulate water pressure and check for leaks prior to entering the

water.

Visit ikelite.com for an updated list of compatible products.

»Do not remove or loosen the accessory port plug unless you

are installing a compatible accessory.

Trigger Extension

The shutter lever may be extended to be closer to your hand when

using an optional tray with right-hand quick release handle. This

requires the Trigger Extension # 4077.93.

Trigger extension and tray with quick release handle are sold

separately.

Lanyard Mount

A lanyard with a thin cord may be attached to the housing using the

lanyard mount on back of the housing.

SettingUpYour Camera

Pre-Installation Checklist

1. Insert a fully charged camera battery.

2. Insert a properly formatted memory card.

3. Remove any attached lanyard or neck strap.

4. Remove the camera’s external ash if attached.

Camera Settings

• Set Red-Eye Removal to OFF.

• Set Shutter AF to ON.

• Set Half Press Release to OFF.

• Set Quick AF to ON.

• Set Eye Sensor AF to OFF.

• Set AF Assist Lamp to OFF.

• Set Focus/Release Priority to FOCUS.

• Set Filter Effects to OFF when using an external strobe.

Exposure Settings

Refer to the Cheat Sheets in the Photo School section of our website

for recommendations on exposure settings for a wide variety of

shooting situations:

https://www.ikelite.com/blogs/cheat-sheets

SettingUpYour Housing

Opening the Housing

1. Push the lid snap lock forward and start to lift the curved end away

from the housing.

2. Lid snaps are designed to provide enough force to compress the

o-ring for a proper seal. Keep rm pressure against the lid snap

while lifting it away.

Lid Snap Lock

3. Repeat with remaining lid snaps.

4. Remove the housing back.

Inserting the Camera

1. Remove any lanyard or neck strap which may be attached to the

camera.
