Ingenico Tetra Move/5000 Bedienungsanleitung

Keyboard details and functionality

The functions key accesses

the different application menus

The red key cancels the procedure in

progress

The yellow key cancels the last

character

The green key validates input selections and

information. It is also used to switch on the

terminal.

The feed key will eject the thermal paper a

few centimeters over the tear line if pressed

for more than two seconds

The Move5000 device is equipped with a touch panel that allows you to capture functions and menus by

using your finger or a stylus.

Move5000

Quick Reference Guide

Move5000

Quick Reference Guide

(Terminal is touch-screen capable. All selections

are made by touching the options on screen).

Sale (Retail Merchant)

1. Press .

5. Input amount and press .

2. Once transaction is completed, ask

customer to sign on the screen or

press .

6. Terminal will prompt to print

customer’s copy.

3. Select SALE at main menu.

7. Insert/Swipe/Tap Card/Input Card#.

4. Terminal will print out merchant’s copy

receipt.

8. Press to print out the customer’s

copy or press to exit.

Sale (Tips Entry)

1. Press .

6. Once transaction is completed, ask

customer to sign on the screen or

press .

2. Select SALE at main menu.

7. Terminal will print out merchant’s copy

receipt.

3. Input amount and press .

8. Terminal will prompt to print

customer’s copy.

4. Input Tips or press to pass.

9. Press to print out the customer’s

copy or press to exit.

5. Insert/Swipe/Tap Card/Input Card#.

Sale (Restaurant Merchant)

1. Press .

6. Once transaction is completed, ask

customer to sign on the screen or

press .

2. Select SALE at main menu.

7. Terminal will print out merchant’s copy

receipt.

3. Input amount and press .

8. Terminal will prompt to print

customer’s copy.

4. Input Tips or press to pass.

9. Press to print out the customer’s

copy or press to exit.

5. Insert/Swipe/Tap Card/Input Card#.

Tips Adjustment

1. Press .

6. Input Tip Amount and press .

2. Select TIPS ADJUST at main menu.

7. Press to confirm amount.

3. Input amount and press .

8. Once transaction is completed,

terminal will print out the TIP Adjust

Sale receipt.

4. Select Search record method:

TRACE#/PAN/INVOIC#/TRANSACTI

ON AMOUNT.

9. Terminal will prompt to print

customer’s copy.

5. Press to confirm selection.

10. Press to print out the customer’s

copy or press to exit.

Void

1. Press .

5. Press to confirm amount.

2. Select VOID at main menu.

6. Once transaction is completed,

terminal will print out the merchant’s

copy receipt.

3. Input amount and press .

7. Terminal will prompt to print

customer’s copy.

4. Input Invoice#, then press.

8. Press to print out the customer’s

copy or press to exit.

Refund

(Refund function is only available for

selected merchants)

1. Press .

5. Once transaction is completed, ask

customer to sign on the screen or

press .

2. Select REFUND at main menu.

6. Terminal will print out merchant’s copy

receipt.

3. Input amount and press .

7. Terminal will prompt to print

customer’s copy.

4. Insert/Swipe/Tap Card/Input Card#.

8. Press to print out the customer’s

copy or press to exit.

Offline Sale

(Offline function is only available for

selected merchants)

1. Press .

7. Touch the screen to switch to # &

Alphabet keyboard.

2. Select OFFLINE at main menu.

8. Press.

3. Input password and press .

9. Once transaction is completed, ask

customer

to sign on the screen or press.

4. Input amount and press .

10.Terminal will print out merchant’s copy

receipt.

5. Insert/Swipe/Tap Card/Input Card#.

11.Terminal will prompt to print

customer’s copy.

6. Input the Auth code.

12.Press to print out the customer’s

copy

or press to exit.

Settlement

(Merchants are advised to choose

‘Settle all hosts’ for convenience)

1. Press .

5. (SETTLE ALL HOSTS selected) –

Terminal will print out the settlement

receipt for all card types.

2. Scroll and select SETTLEMENT.

6. SETTLE BY HOST selected) –Select

host type.

3. Input password and press .

7. Terminal will only settle and print out

the specific host settlement receipt.

4. Select SETTLE ALL HOSTS or

SETTLE BY HOST.

Pre-Auth

1. Press .

6. Once transaction is completed, ask

customer to sign on the screen or

press .

2. Select PRE-AUTH at main menu.

7. Terminal will print out merchant’s copy

receipt.

3. Select PRE-AUTH.

8. Terminal will prompt to print

customer’s copy.

4. Input amount and press .

9. Press to print out the customer’s

copy or press to exit.

5. Insert/Swipe/Tap/Input Card#.

Pre-Auth Completion (For Visa®/Mastercard®/JCB)

1. Press .

7. Input Invoice number and press .

2. Select PRE-AUTH at main menu.

8. Insert/Swipe/Tap Card/Input Card#.

3. Select PRE-AUTH COMP (VM/J/D/A).

9. Once transaction is completed, ask

customer to sign on the screen or

press .

4. Input the Pre-Auth amount and press

.

10.Terminal will print out merchant’s copy

receipt.

5. Input the new amount and press .

11.Terminal will prompt to print

customer’s copy.

6. Input the Auth code and press .

12.Press to print out the customer’s

copy or press to exit.

Pre-Authcomp (For CUP)

1. Press .

7. Input Invoice number and press .

2. Select PRE-AUTH at main menu.

8. Insert/Swipe/Tap Card/Input Card#.

3. Select PRE-AUTHCOMP CUP.

9. Once transaction is completed, ask

customer to sign on the screen or

press .

4. Input the Pre-Auth amount and press

.

10.Terminal will print out merchant’s copy

receipt.

5. Input the new amount and press .

11.Terminal will prompt to print

customer’s copy.

6. Input the Auth code and press .

12.Press to print out the customer’s

copy or press to exit.

Void Pre-Auth

1. Press .

7. Input Invoice number and press .

2. Select PRE-AUTH at main menu.

8. Insert/Swipe/Tap Card/Input Card#.

3. Select VOID PRE-AUTH.

9. Once transaction is completed, ask

customer to sign on the screen or

press .

4. Input the Pre-Auth amount and press

.

10. Terminal will print out merchant’s

copy receipt.

5. Input Auth code and press .

11. Terminal will prompt to print

customer’s copy.

6. Touch the screen to switch to # &

Alphabet keyboard. Press .

12. Press to print out the customer’s

copy or press to exit.

Instalment (IPP)

1. Press .

7. Insert/Swipe/Tap Card/Input Card#.

2. Select INSTALMENT at main menu.

8. Once transaction is completed, ask

customer to sign on the screen or

press .

3. Select INSTALMENT SALE.

9. Terminal will print out merchant’s copy

receipt.

4. Select the SCB PLANS/NON-SCB

PLANS.

10.Terminal will prompt to print

customer’s copy.

5. Select the month plan.

11.Press to print out the customer’s

copy or pressto exit.

6. Input the amount and press .

Reprint Last Transaction

1. Press .

5. Terminal reprint last transaction

receipt (merchant copy).

2. Scroll and select MERCHANT.

6. Terminal will prompt to print

customer’s copy.

3. Select REPRINT.

7. Press to print out the customer’s

copy or press to exit.

4. Select the LAST TRANSACTION.

Reprint Specific Transaction

1. Press .

5. Input Invoice # and press .

2. Scroll and select MERCHANT.

6. Terminal print selected transaction

receipt.

3. Select REPRINT.

7. Terminal will prompt to print

customer’s copy.

4. Select the ANY TRANSACTION.

8. Press to print out the customer’s

copy or press to exit.

Reprint Last Settlement Receipt

1. Press .

4. Select the LAST SETTLEMENT.

2. Scroll and select MERCHANT.

5. Terminal will print out the last

settlement.

3. Select REVIEW.

View Any Transaction (By Trace #)

1. Press .

6. Select the TRACE NUMBER.

2. Scroll and select REPRINT.

7. Input Trace Number (TRC Number) and

press .

3. Select REVIEW.

View Any Transaction (By Invoice #)

1. Press .

4. Select the INVOICE NUMBER.

2. Scroll and select MERCHANT.

5. Input Invoice Number (INV No.) and

press .

3. Select REVIEW.

View Any Transaction (By Amount)

1. Press .

4. Select the TRANSACTION AMOUNT.

2. Scroll and select MERCHANT.

5. Input amount and press .

3. Select REVIEW.

View Any Transaction (By Card #)

1. Press .

4. Select PAN.

2. Scroll and select MERCHANT.

5. Input card # and press .

3. Select REVIEW.

Print Out Detail Report

1. Press .

4. Select DETAIL.

2. Scroll and select MERCHANT.

5. Select the host at Select Host menu.

3. Select REPORT.

6. Terminal will print out detail Report.

Print Out Summary Report

1. Press .

5. Select the ALL HOSTS or BY HOST

at Select Report Option menu.

2. Scroll and select MERCHANT.

6. If select BY HOST, select the host at

Select Host menu.

3. Select REPORT.

7. Terminal will print out summary report

for all hosts or a specific host

(depending

on selection).

4. Select the SUMMARY.

Print Out Batch Total

1. Press .

4. Select HOST/GRAND TOTAL.

2. Scroll and select MERCHANT.

5. Press to print out or press to

exit.

3. Select BATCH TOTAL.

products referenced in this material may be trademarks or registered trademarks of their respective companies.

Andere Handbücher für Tetra Move/5000

Andere Ingenico Zahlungsterminal Handbücher

Ingenico

Ingenico Move 5000 Bedienungsanleitung

Ingenico

Ingenico Move/2600 Bedienungsanleitung

Ingenico

Ingenico FIT111 Bedienungsanleitung

Ingenico

Ingenico PAYZONE iCT250 Bedienungsanleitung

Ingenico

Ingenico icm122-01T2263A Bedienungsanleitung

Ingenico

Ingenico iCT2 Series Bedienungsanleitung

Ingenico

Ingenico FLEX IPP320 Bedienungsanleitung

Ingenico

Ingenico i8550 Bedienungsanleitung

Ingenico

Ingenico DESK/5000 Bedienungsanleitung

Ingenico

Ingenico iWL250 WIFI Bedienungsanleitung

Ingenico

Ingenico 7780 Bedienungsanleitung

Ingenico

Ingenico ISMP3- Bedienungsanleitung

Ingenico

Ingenico Lane/8000 Bedienungsanleitung

Ingenico

Ingenico M3500G Bedienungsanleitung

Ingenico

Ingenico Move3500 Bedienungsanleitung

Ingenico

Ingenico iUC150 Kurzanleitung zur Einrichtung

Ingenico

Ingenico iCT220, iCT250 Bedienungsanleitung

Ingenico

Ingenico PAYZONE iCT250 Bedienungsanleitung

Ingenico

Ingenico iCT220, iCT250 Bedienungsanleitung

Ingenico

Ingenico AXIUM DX4000 Portable Bedienungsanleitung

Ingenico

Ingenico DWM-55 Bedienungsanleitung

Ingenico

Ingenico iwl280 Bedienungsanleitung

Ingenico

Ingenico Telium Bedienungsanleitung

Ingenico

Ingenico iWL250 WIFI Bedienungsanleitung

Beliebte Zahlungsterminal Handbücher anderer Marken

PAX

PAX D180SRF Bedienungsanleitung

LinkPoint

LinkPoint AIO Bedienungsanleitung

Moneris

Moneris hispeed 6200 Bedienungsanleitung

Moneris

Moneris iWL220 Bedienungsanleitung

Optimum

Optimum M4230 Bedienungsanleitung

Triton

Triton RL5000 Bedienungsanleitung

Ingenico group

Ingenico group Lane/8000 Bedienungsanleitung

Gilbarco

Gilbarco FlexPay IV CRIND Installations- und Betriebshandbuch

Infinite Peripherals

Infinite Peripherals Infinea Tab Lite Bedienungsanleitung

PAX

PAX S920 Bedienungsanleitung

dejavoo

dejavoo Z Series Bedienungsanleitung

VeriFone

VeriFone VX 520 Series Bedienungsanleitung

Optomany

Optomany axept S900 Bedienungsanleitung

Skyzer

Skyzer iWL252 BLUETOOTH Bedienungsanleitung

Moneris

Moneris iWL220 Bedienungsanleitung

VeriFone

VeriFone HICAPS VX820 Bedienungsanleitung

Magtek

Magtek DYNAPRO Bedienungsanleitung

VeriFone

VeriFone UX401 Bedienungsanleitung
