USER GUIDE

4.3 Cubic Foot

Compact Refrigerator

NS-CF43SS6

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 1 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

Insignia 4.3 Cubic Foot Compact

Refrigerator

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Grounding requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Main components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setting up your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Before using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Providing proper ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Setting the thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Using the freezer compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Making ice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Defrosting your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Reversing the door position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Maintaining your refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Changing the interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Shutting down your refrigerator - long vacations (several months). . . . . .15

Moving Your Refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

ONE-YEAR LIMITED WARRANTY - INSIGNIA . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Introduction

Congratulations on your purchase of a high-quality Insignia product. Your

NS-CF43SS6 represents the state of the art in compact refrigerator design

and is designed for reliable and trouble-free performance.

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 2 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

Important Safety Instructions

WARNING

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this appliance near water.

6Clean only with damp cloth.

7Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

8Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

9Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched particularly

at plugs, convenience receptacles, and the point where they exit from

the appliance.

11 Do not attempt to modify or extend the power cord of this appliance.

12 Unplug this appliance during lightning storms or when it will not be

used for long periods of time.

13 Make sure that the available AC power matches the voltage

requirements of this appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage

constituting a risk of electric shock is present

within your compact refrigerator.

This symbol indicates that there are important

operating and maintenance instructions in the

literature accompanying your compact

refrigerator.

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 3 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

14 Do not handle the plug with wet hands. This could result in an electric

shock.

15 Unplug the power cord by holding the plug, never by pulling the cord.

16 Do not turn the appliance on or off by plugging or unplugging the

power cord.

17 Turn off the appliance before unplugging it.

18 Refer all servicing to qualified service personnel. Servicing is required

when the appliance has been damaged in any way, such as the

power-supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the appliance, the appliance has been exposed

to rain or moisture, does not operate normally, or has been dropped.

19 To reduce the risk of fire or electric shock, do not expose this appliance

to rain, moisture, dripping, or splashing, and no objects filled with

liquids should be placed on top of it.

WARNING

Electric Shock Hazard

Failure to follow these instructions can result in

electric shock, fire, or death.

1WARNING–Keep ventilation openings in the

appliance clear of obstruction.

2WARNING–Do not touch the interior of the

freezer compartment with wet hands. This could

result in frost bite.

3WARNING–Do not use mechanical devices or other means to

accelerate the defrosting process, other than those recommended by

the manufacturer.

4WARNING–Do not damage the refrigerant tubing when handling,

moving, or using the refrigerator.

5WARNING–Do not use electrical appliances inside the food storage

compartment of the refrigerator, unless they are of the type

recommended by the manufacturer.

6WARNING–DANGER—Never allow children to play with, operate, or

crawl inside the refrigerator.

Risk of child entrapment. Before you throw away your old refrigerator

or freezer:

1) Take off the doors

2) Leave the shelves in place so that children may not easily climb

inside

7Unplug the refrigerator before carrying out user maintenance on it.

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 4 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

8This appliance can be used by children age 8 years and older and

persons with reduced physical or mental capabilities or lack of

experience and knowledge if they are given supervision or instruction

concerning the use of the appliance in a safe way and understand the

hazards involved. Children should not play with the appliance.

Cleaning and maintenance should not be performed by children

without supervision.

9If a component part is damaged, it must be replaced by the

manufacturer, its service agent, or similar qualified persons in order to

avoid a hazard.

10 Please dispose of the refrigerator according to local regulations as it

contains flammable gas and refrigerant.

11 Follow local regulations regarding disposal of the appliance due to

flammable refrigerant and gas. All refrigeration products contain

refrigerants, which under the guidelines of federal law must be

removed before disposal. It is the consumer's responsibility to comply

with federal and local regulations when disposing of this product.

12 This appliance is intended to be used in household and similar

environments.

13 Do not store or use gasoline or any flammable liquids inside or in the

vicinity of this refrigerator.

14 Do not use an extension cord with this appliance. If the power cord is

too short, have a qualified electrician install an outlet near the

appliance. Use of an extension cord can negatively affect the

refrigerator’s performance.

Grounding requirement

This appliance must be grounded. This appliance is equipped with a cord

having a grounding wire with a grounding plug. The plug must be

inserted into an outlet that is properly installed and grounded.

Improper use of the grounding plug can result in a risk of electric shock.

Consult a qualified electrician or service person if the grounding

instructions are not completely understood, or if doubt exists as to

whether the appliance is properly grounded.

Features

Package contents

• 4.3 cubic foot compact refrigerator

•Icecubetray

•Icescoop

•UserGuide

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 5 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

Main components

Setting up your refrigerator

Before using your refrigerator

• Remove the exterior and interior packing.

• Let the refrigerator stand upright for approximately four hours before

connecting it to power. This reduces the possibility of a malfunction in

the cooling system from improper handling during transportation.

• Clean the interior surface with lukewarm water using a soft cloth.

Finding a suitable location

• This refrigerator is designed to be free standing only, and should not

be recessed or built-in.

• Place your refrigerator on a floor that is strong enough to support the

refrigerator when it is fully loaded.

• Allow five inches of space between the back and sides of the

refrigerator and any surrounding walls. This allows the proper air

ventilation. Adjust the feet to keep the refrigerator level.

Cabinet tabletop

Ice shovel

Ice tray

Thermostat

Interior light switch

Refrigerator section

shelves

Crisper

Leveling leg

Freezer door

Refrigerator door

Freezer shelf

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 6 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

• Locate the refrigerator away from direct sunlight and sources of heat

(stove, heater, radiator, and so on). Direct sunlight may affect the

acrylic coating and heat sources may increase electrical consumption.

Ambient temperature below 50°F (10°C) or above 85°F (29.4°C) will

hinder the performance of this refrigerator. This refrigerator is not

designed for use in a garage or any other outside installation.

• Avoid locating the refrigerator in moist areas.

Leveling your refrigerator

• It is very important for the refrigerator to be level in order to function

properly. If the refrigerator is not leveled during installation, the doors

may not close or seal properly, causing cooling, frost, or moisture

problems.

• To level your refrigerator, you may either turn the leveling foot

clockwise to raise that side to the refrigerator or turn it

counter-clockwise to lower that side.

Providing proper ventilation

Place the refrigerator at lease five inches from the wall to ensure proper

airflow to the compressor. Do not place the refrigerator near any heat

sources, such as a heater or stove, as this may put a strain on the

compressor.

Note

Having someone push against the top of the refrigerator helps to

take some weight off the leveling foot, making it easier to

adjust.

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 7 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

Providing a proper power supply

Check your local power source. This refrigerator requires a 110V-120V,

60Hz power supply.

Use a receptacle that accepts the grounding prong. The power cord o is

equipped with a 3-prong (grounding) plug which mates with a standard

3-prong (grounding) wall outlet to minimize the possibility of electric

shock hazard from this refrigerator.

Notes

• The refrigerator should always be plugged into its own

individual electrical outlet which has a voltage rating that

matches the rating plate.

• Never unplug your refrigerator by pulling on the power

cord. Always grip the plug firmly and pull straight out from

the outlet.

3-prong receptacle

Receptacle box cover

3-prong plug

Grounding lead

Grounding adapter Receptacle box cover

Screw

Receptacle

Using a 3-prong plug and outlet Using a grounding adapter

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 8 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

Setting the thermostat

1The first time you turn the refrigerator on, adjust the thermostat to “7”

and run for at least two hours before putting food in.

2After it is fully cooled, test it and adjust towards “4” to make less cool,

to best suit your needs. The “4” setting should be appropriate for

home or office refrigerator use.

Using the freezer compartment

The freezer compartment is designed for the long-term storage of frozen

foods.

The storage life of frozen foods varies and the recommended storage time

should not be exceeded.

• Place frozen food into the freezer as quickly as possible after purchase.

If there are instructions on the packet, carefully follow these

instructions regarding storage times.

Notes

• Turning the thermostat to the “0” position stops the cooling

cycle but does not shut off the power to the refrigerator.

• If the refrigerator is unplugged or loses power, you must

wait three to five minutes before restarting the it. If you

attempt to restart before this time delay, the refrigerator

will not start.

• Large amounts of food will lower the cooling efficiency of

the refrigerator.

• If you choose to change the thermostat setting, adjust it by

one increment at a time. Allow several hours for

temperature to stabilize between adjustments.

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 9 Friday, March 13, 2015 8:58 AM

Insignia 4.3 Cubic Foot Compact Refrigerator

www.insigniaproducts.com

Making ice

1Set the thermostat to “7”.

2Fill the ice cube tray (2/3 capacity) with cold water and place the tray

on the bottom of the freezer compartment to freeze properly.

3When the water in the ice cube tray has hardened, remove the ice tray

from the freezer, then twist slightly to eject the ice cubes from the tray.

4Re-set the thermostat to “4” when you are done making ice.

Defrosting your refrigerator

This refrigerator is not designed to defrost automatically. In order to

prevent damage to the interior liner of the refrigerator from excessive

frost build-up, defrost the refrigerator every three months or when ice or

frost is approximately ¼" thick inside the freezer compartment.

1Set the thermostat to “0”, then remove all contents from the freezer

compartment.

2Leave the freezer door open to allow accumulated ice and frost to

melt. Remove large pieces of ice as needed.

3After defrosting, remove accumulated ice and water, then wipe the

freezer compartment dry with a soft cloth.

4Even though ice is not visibly present in the freezer compartment,

allow the evaporator, located behind the freezer wall, to completely

defrost for approximately two hours before restarting the refrigerator.

5Restart following the instructions in “Setting the thermostat” on

page 9.

Reversing the door position

Your refrigerator is built with a reversible door. Based on the location

where you plan to use your compact refrigerator, you may find it more

convenient to reverse the position of the door, to have it open from right

to left instead of left to right.

Caution

Do not use hot water or electric heating devices to melt the

accumulated ice.

Caution

To avoid injury to yourself or your property, we recommend that

someone assist you during the door reversal process.

NS-CF43SS6_15-0265_MAN_V1_ENG.fm Page 10 Friday, March 13, 2015 8:58 AM

Inhaltsverzeichnis

Andere Insignia Kühlschrank Handbücher

Insignia

Insignia NS-RFD21SS7 Bedienungsanleitung

Insignia

Insignia NS-CFL45GP1 Bedienungsanleitung

Insignia

Insignia NS-BC1ZSS9 Bedienungsanleitung

Insignia

Insignia NS-RBM92WH9-C Bedienungsanleitung

Insignia

Insignia NS-RBM18SS0-C Bedienungsanleitung

Insignia

Insignia NS-RTM10BK8 Bedienungsanleitung

Insignia

Insignia NS-RFD21CXSS0 Bedienungsanleitung

Insignia

Insignia NS-RBM92BK9 Bedienungsanleitung

Insignia

Insignia NS-CF30SS9-C Bedienungsanleitung

Insignia

Insignia NS-CFBM41SS1 Bedienungsanleitung

Insignia

Insignia NS-CF30SS9 Bedienungsanleitung

Insignia

Insignia NS-RTM18WHD2 Bedienungsanleitung

Insignia

Insignia NS-CF33BK3 Bedienungsanleitung

Insignia

Insignia NS-EWF01-2 Bedienungsanleitung

Insignia

Insignia NS-RTM20SS3 Bedienungsanleitung

Insignia

Insignia NS-CF26PK7 Bedienungsanleitung

Insignia

Insignia NS-CF33SS8 Bedienungsanleitung

Insignia

Insignia NS-RTM18BS8 Bedienungsanleitung

Insignia

Insignia NS-OCF55SS2 Bedienungsanleitung

Insignia

Insignia NS-RSS26SS0 Bedienungsanleitung

Insignia

Insignia NS-RFD21CISS0 Bedienungsanleitung

Insignia

Insignia NS-RTM21SS7 Bedienungsanleitung

Insignia

Insignia NS-RFD21SS7 Bedienungsanleitung

Insignia

Insignia NS-RTM10BK2 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
