128958_V01_QSG_D-ONE_EN.docx 1/3

Quick Start Guide D-ONE Single Channel Pipetting Module

This quick start guide is intended to provide a quick overview of your D-ONE single

channel pipetting module’s key features. For detailed information, please refer to the

latest operating instructions of D-ONE and ASSIST PLUS

that can be found at

www.integra-biosciences.com in different languages.

Intended Use

This is a general-purpose laboratory instrument for use in research only. D-ONE is used on the

ASSIST PLUS pipetting robot for aspirating and dispensing aqueous liquids in the volume range of

0.5 –1250 μl using GripTip™ pipette tips only, see www.integra-biosciences.com. D-ONE provides

pressure-based liquid level detection and is compatible with two different GripTip sizes.

Safety information

Regardless of the listed safety notes, all locally applicable regulations must be observed.

1) This product may only be operated in a secure, protected network with trustworthy clients.

2) The pipette may only be used by properly trained personnel in a manner specified by INTEGRA

Biosciences.

3) Use only an INTEGRA battery and charging device.

4) Do not expose the battery to heat over 60 °C or mechanical stress.

5) Replace battery if the charging intervals are unusually short or if the charging takes much

longer than 4 hours.

6) Do not use or charge the instrument near flammable material or in an atmosphere with danger

of explosion.

7) Servicing work and repairs may only be performed by INTEGRA Biosciences or an authorized

after-sales service member.

Battery Charge

Charge the Li-ion battery completely before first use

with an INTEGRA stand, cable or on ASSIST PLUS.

The supply voltage must meet the requirements of the mains

adapter: 100–240 VAC, 50/60 Hz.

Low Battery

Recharging Battery

Fully Charged Battery

~ 2.5 h

Blinking red

Blinking bars

Three solid bars

Getting Started

1. Battery charge indicator on display

2. Back button, to navigate backward

3. Touch wheel, spin to scroll the cursor

4. OK button, to make a selection

5. Arrow buttons, for selections

6. Purge button, to empty tips

7. RUN button, to start operations

8. Tip ejector

Turn on:

Press and release RUN.

Turn off:

Press and hold the Back button for 3 seconds.

2/3 128958_V01_QSG_D-ONE_EN.docx

Language Selection

From the Main Menu, use the Touch Wheel to scroll to the Toolbox and press OK. Use the

“Language” option to select the desired language.

Pipette’s Toolbox

The Toolbox provides a variety of options, as setting personal preferences like the Touch wheel

spin sensitivity, computer connectivity and device information.

Creating a Pipetting Program

Use the VIALAB software to create multi-step programs on a PC and transfer them to the D-ONE,

see VIALAB operating instructions.

Starting a Pipetting Program

Use the communication module or the communication cable to connect D-ONE with ASSIST PLUS.

The following GripTips for benchtop pipetting systems can be attached:

D-ONE 0.5–300 μl (# 4531): 12.5 µl (pink) and 300 µl (green).

D-ONE 5–1250 μl (# 4532): 125 µl (yellow) and 1250 µl (blue).

Please visit the GripTip Selector Guide to find the correct GripTips.

From the Main Menu, select ASSIST PLUS. Press OK to enter the list of

VIALAB programs.

Select a program and press RUN.

Maintenance

Clean the outer surface with a lint-free cloth lightly soaked with mild soap solution in distilled water

or with a 70 % dilution of Isopropyl or Ethanol. Never use Acetone or other solvents.

D-ONE cannot be disassembled or autoclaved. Decontaminate D-ONE in accordance with good

laboratory practice.

If you intend to ship D-ONE to be periodically calibrated, the original packaging can be stored and

reused for this purpose.

Equipment Disposal

Electronic pipettes must not be disposed of with unsorted municipal waste.

Dispose of electronic pipettes in accordance with the regulations in your area governing

disposal of devices. In certain regions and countries, e.g. in all EU member states, the

distributor is obliged to take back this product free of charge at the end of life. Please

contact your local distributor for more details.

Manufacturer

INTEGRA Biosciences AG

CH-7205 Zizers, Switzerland

T +41 81 286 95 30

F +41 81 286 95 33

info@integra-biosciences.com

www.integra-biosciences.com

INTEGRA Biosciences Corp.

Hudson, NH 03051, USA

T +1 603 578 5800

F +1 603 577 5529

128958_V01_QSG_D-ONE_EN.docx 3/3

Declaration of conformity

INTEGRA Biosciences AG – 7205 Zizers, Switzerland

declares on its own responsibility that the devices

Description

Models

D-ONE Single Channel

Pipetting Module

4531, 4532

comply with:

EU Directives and Regulations

2014/35/EU, 2014/30/EU, 2012/19/EC, 2011/65/EC, 2006/66/EC, 1907/2006, 1103/2010

GBR Regulations

S.I. 2016/1101, S.I. 2016/1091, S.I: 2008/2164, S.I. 2013/3113, S.I. 2012/3032

Zizers, December 14, 2021

Urs Hartmann

CEO

Thomas Neher

Quality Manager

For detailed CE declaration with regulations of other countries, please refer to the D-ONE

operating instructions.
