Intel® Entry Storage System

SS4200-E Active Directory

Implementation and

Troubleshooting

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Active Directory Overview

•SS4200-E Active Directory is based on the

Samba 3 implementation

•The SS4200-E will function as a native

domain member server

•Cannot function as an Active Directory

domain controller (Samba 3 limitation)

•Interdomain trusts are not supported

•NT domain is not supported

•The SS4200-E uses Kerberos, not NT

compatible authentication protocols

•Supports Active Directory organizational

units

•Organizational units act as a container for

objects. Objects can be arranged according to

security and administrative requirement in an

organization

•No setup/configuration is required on a

working domain controller, or DNS server

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Active Directory Features

•After Active Directory is enabled, Active

Directory credentials can be used to login to

the Storage Manager

•Only those Active Directory users who have

logged in to the Storage Manager or have

accessed the storage device from a client will

be considered “valid storage Active Directory

users”

•Only these valid storage Active Directory

users will be displayed on the users list in

the Storage Manager

•This avoids the unnecessary overhead if

only a few users out of thousands of

Active Directory users need to access the

storage device

•A hardware reset will return the SS4200-E to

the default Workgroup mode

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Active Directory Features

•Any Windows user in the same domain can

access the storage device with Active

Directory credentials

•Private folders will be automatically created

for each logged in user (to storage device) or

any user who accesses the storage device

from a Windows client

Configuring Active Directory

Mode

•To switch between Workgroup mode and

Active Directory mode:

•Use Storage Manager to switch between

Workgroup mode and Active Directory mode

(Settings > Network Services > Windows File

Sharing (CIFS))

(See the visual representation in following slides)

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

•Workgroup mode accounts will be disabled in

Active Directory mode

•Switching between Workgroup mode and

Active Directory mode will remove the

existing permissions setting of all private

folders

•After switching, a user with administrative

privilege can reassign permissions setting or

delete these private folders

•This is to enable the content of private folders

created under one mode to be accessible under

another mode

•In the case of permanent loss of the domain

controller, this feature provides a way to

recover/delete Active Directory folders under

Workgroup mode

Configuring Active Directory

Mode

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Join an Active Directory

Domain

Settings > Network Services > Network Settings

page of the Storage Manager

Add the domain DNS server IP

address(es)

This can be done manually or

automatically from a DHCP

server by selecting the

“Automatically configure all

network settings” box

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Joining an Active Directory

Domain

Settings tab > Network Services > Windows File

Sharing (CIFS) Settings page of the Storage Manager

After successfully joining the Active Directory domain, the SS4200-E

should appear on the network domain controller’s Active Directory

Users and Computers menu as a member server.

Set Security Mode to Active Directory Domain

Organizational

unit entry is

optional

Enter the fully qualified

name of the domain

controller and the

credentials of an Active

Directory domain

administrator account

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Manager

After joining the Active Directory

domain, the Active Directory credentials

can be used to login to the Storage

Manager

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Storage Manager

User Accounts tab of the Storage Manager

As noted earlier, only the users who have

logged in will be shown on the User

Accounts list

After a user logs in, a private folder will be

automatically created for the logged in

user on the storage system

Third

Third-

-party marks and brands are the property of their

party marks and brands are the property of their

respective owners. All products, dates, and figures are

preliminary and subject to change without notice.

Storage Manager

Shared Folder tab of the Storage Manager

The user folder “mike” is locked

and inaccessible to the

Administrator who is logged in

currently
