Intel SRPM8 Bedienungsanleitung

SRPM8

Server System

Quick Start Guide

Order Number: A27246-001

✏How to do basic set-up, boot from the configuration software CD, install the

optional slide rail kit, and access the Product Guide from the CD

form, or by any means without prior written consent of Intel.

Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may

appear in this document. Intel makes no commitment to update nor to keep current the information contained in this

document.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

†Third-party brands and names are the property of their respective owners.

SRPM8 Server System Quick Start Guide 3

Contents

Server Specifications............................................................................................................ 5

Select Site............................................................................................................................ 6

Optional Slide Rail Kit........................................................................................................... 7

Equipment Rack Precautions....................................................................................... 7

Prepare the Slide Assemblies...................................................................................... 8

Attach the Rail Slide Rail Brackets to the Equipment Rack........................................ 10

Attach the Center Bar and Large Outer Bar Assemblies to the Equipment Rack....... 11

Install the Server in the Rack..................................................................................... 12

Check Power Cord............................................................................................................. 13

Power Cord Requirements......................................................................................... 13

Connect Monitor, Keyboard, Mouse................................................................................... 14

Turn on Video Monitor and Server...................................................................................... 16

Run Power-on Self Test ..................................................................................................... 18

Boot from CD ..................................................................................................................... 19

Change Boot Device Priority...................................................................................... 20

The Server Product Guide.................................................................................................. 20

Using the Acrobat .PDF Files..................................................................................... 20

Copy Configuration Software to Diskettes.......................................................................... 21

Warnings............................................................................................................................ 22

WARNING: English (US) .......................................................................................... 23

AVERTISSEMENT: Français.................................................................................... 25

WARNUNG: Deutsch................................................................................................ 27

AVVERTENZA: Italiano ............................................................................................ 29

ADVERTENCIAS: Español....................................................................................... 31

4 SRPM8 Server System Quick Start Guide

WARNINGS

READ WARNINGS: Before operating this server, read the warnings

beginning on page 22.

AVOID INJURY: To avoid personal injury when unpacking the server, use

only a mechanical assist unit to lift it off the shipping pallet. The

minimum server configuration weighs 51 kg (113 lbs); the maximum

weighs 63.5 kg (140 lbs).

Do not attempt to lift or move the server by the handles on the power

supplies.

Use only a hand-truck or other mechanical assist unit to move the server

from one location to another.

SRPM8 Server System Quick Start Guide 5

Server Specifications

Table 1. SRPM8 Server Physical Specifications

Specification Value

Height 31.12 cm (12.25 inches, 7u)

Width 44.45 cm (17.5 inches)

Depth 71.12 cm (28.0 inches)

Weight 51.4 kg (113 lbs) minimum configuration

63.5 kg (140 lbs) maximum configuration

Required front clearance 10 inches (inlet airflow <35 °C / 95 °F)

Required rear clearance 8 inches (no airflow restriction)

OM08750

Figure 1. SRPM8 Server

6 SRPM8 Server System Quick Start Guide

Select Site

WARNING

The push-button on/off power switch on the front panel of the server

does not turn off the AC power. To remove AC power from the server,

you must unplug the AC power cord from the server or wall outlet.

CAUTION, ESD precautions

Electrostatic discharge (ESD) can damage disk drives, add-in boards, and

other parts. This server can withstand normal levels of environmental ESD.

However, we recommend doing all procedures in this guide only at an

ESD-protected workstation. If one is not available, you can provide some

ESD protection by wearing an antistatic wrist strap attached to chassis

ground of the server—any unpainted metal surface—when handling

components.

CAUTION, use grounded outlet

Make sure that the power service connection is through a properly grounded

outlet.

The server operates reliably within normal office environmental limits. Select a site that meets

these criteria:

•Near a properly earthed, grounded, three-pronged power outlet

In the United States and Canada: a NEMA 6-15R outlet for 200-240 V.∼

In other geographic areas: a properly earthed, grounded outlet in accordance with the local

electrical authorities and electrical code of the region.

•Clean and relatively free of excess dust.

•Well ventilated and away from sources of heat, with the ventilating openings on the server

kept free of obstructions.

•Away from sources of vibration or physical shock.

•Isolated from strong electromagnetic fields and noise caused by electrical devices such as

elevators, copy machines, air conditioners, large fans, large electric motors, radio and TV

transmitters, and high-frequency security devices.

•Access space provided so the server power cords can be unplugged from the power supply or

the wall outlet; this is the only way to remove AC power from the server.

•Clearance provided for cooling and airflow.

SRPM8 Server System Quick Start Guide 7

Optional Slide Rail Kit

If the SRPM8 Server is to be rack mounted the slide rail kit should be installed as follows before

proceeding.

Equipment Rack Precautions

WARNINGS

ANCHOR THE EQUIPMENT RACK: The equipment rack must be anchored

to an unmovable support to prevent it from falling over when one or

more servers are extended in front of it on slide assemblies. The

anchors must be able to withstand a force of up to 113 kg (250 lbs). You

must also consider the weight of any other device installed in the rack.

MAIN AC POWER DISCONNECT: You are responsible for installing an

AC power disconnect for the entire rack unit. This main disconnect

must be readily accessible, and it must be labeled as controlling power

to the entire unit, not just to the server(s).

GROUNDING THE RACK INSTALLATION: To avoid the potential for an

electrical shock hazard, you must include a third wire safety grounding

conductor with the rack installation. If a server power cord is plugged

into an AC outlet that is part of the rack, then you must provide proper

grounding for the rack itself. If server power cords are plugged into

wall AC outlets, the safety grounding conductor in each power cord

provides proper grounding only for the server. You must provide

additional, proper grounding for the rack and other devices installed

in it.

CAUTIONS

Temperature: The operating temperature of the server, when installed in an

equipment rack, must not go below 5 °C (41 °F) or rise above 35 °C (95 °F).

Extreme fluctuations in temperature can cause a variety of problems in your

server.

Ventilation: The equipment rack must provide sufficient airflow to the

front of the server to maintain proper cooling. It must also include

ventilation sufficient to exhaust a maximum of 4,100 Btu's per hour for the

server. The rack selected and the ventilation provided must be suitable to

the environment in which the server will be used.

8 SRPM8 Server System Quick Start Guide

Prepare the Slide Assemblies

1. Remove the slide assemblies from the kit.

2. Orient the slide assembly so that the arrow embossed on each rail assembly is facing toward

the front of the server as shown in Figure 2.

Figure 2. Slide Rail Orientation

3. Secure each slide rail to the server using 3 of the 8-32 csink screws as shown in Figure 3.

Figure 3. Slide Rail Mounting Screws

4. Fully extend the telescoping slide assembly until the center bar hits the safety latch on the

small outer bar (all three overlapping bars will be visible).

5. Grasp the small outer bar (attached to the server) with your right hand so that your thumb is on

the safety latch of the small outer bar.

SRPM8 Server System Quick Start Guide 9

6. Press and hold the safety latch down (see Figure 4), and at the same time, grasp the large outer

bar with your left hand.

Figure 4. Small Rail Extension Release

7. Pull the small bar (attached to the server) out of the center bar; this takes a little force to

separate them. Set the small bar aside to attach to the rack in a later step.

8. Orient the center bar and large outer bar assembly so that the center bar is facing up.

9. Grasp the center bar with your right hand and the large outer bar with your left hand so that

your left-hand thumb is on the safety latch of the center bar.

Figure 5. Center Rail Extension Release

10. Press the safety latch, and separate the bars. Set the center bar and large outer bar assembly

aside to attach to the equipment rack in a later step.

11. Prepare the other slide assembly by repeating steps 2–10 above.

10 SRPM8 Server System Quick Start Guide

Attach the Rail Slide Rail Brackets to the Equipment Rack

✏NOTE

Mounting holes in the vertical rails of equipment racks are commonly

spaced in a 5/8 x 5/8 x 1/2-inch sequence. Perform the following steps

carefully; brackets must be mounted with precision to allow room for the

next server you install in a rack.

See Figure 6.

1. Remove a right-angle extension bracket, two screws, and a bar nut from the kit.

2. While facing the front or back of the rack, orient the right-angle extension bracket so that the

short side with the four mounting holes is facing toward the outside edge of the vertical rail.

3. Position the bracket behind the mounting holes in the vertical rail.

OM05955

Figure 6. Right-angle Bracket and Vertical Rail

A. Screw

B. Vertical rail

C. Bar nut

D. Right-angle extension bracket

4. With a pencil, mark the top and bottom hole locations of the bracket on both sides of the

vertical rail; no hole numbers are printed on the rail.

5. Insert a screw through the marked top hole in the rail and through the top hole in the bracket.

Place a bar nut on the screw and loosely tighten it. Repeat for the marked bottom hole.

6. Install the three remaining right-angle extension brackets on the other three vertical rails by

repeating steps 1–5 above.

Inhaltsverzeichnis

Andere Intel Server Handbücher

Intel

Intel JBOD 2000 Family Bedienungsanleitung

Intel

Intel SC5650BCDP Sicherheitsleitfaden

Intel

Intel SR1600UR - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel S7000FC4UR - Server System - 0 MB RAM Konfigurationshandbuch

Intel

Intel SR1680MV - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SR1560SFHS - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel R1000WF Series Kurzanleitung zur Einrichtung

Intel

Intel OCPRF100 MP Bedienungsanleitung

Intel

Intel ISP4400 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SR1530AHNA Konfigurationshandbuch

Intel

Intel SR1630BC - Server System - 0 MB RAM Konfigurationshandbuch

Intel

Intel A1U2ULCP Konfigurationshandbuch

Intel

Intel SR2400SYS - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SC450NX - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SR2625UR - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel NSC2U - IP Network Server Bedienungsanleitung

Intel

Intel SC5650HCBRP Betriebsanleitung

Intel

Intel MFSYS35 Bedienungsanleitung

Intel

Intel SR6850HW4M Bedienungsanleitung

Intel

Intel STCK1A32WFC Bedienungsanleitung

Intel

Intel R2000WF series Konfigurationshandbuch

Intel

Intel SR1500 - AXXMINIDIMM DDR-2 RAID Controller Cache... Bedienungsanleitung

Intel

Intel R2000WF series Bedienungsanleitung

Intel

Intel SR2612UR - Server System - 0 MB RAM Betriebsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
