Interlogix UVP-M1120P-18X-N Bedienungsanleitung

UVP 1.3 MPX HD 18X

PTZ C

amera User Manual

P/N 1072601A-EN • REV 1.0 • ISS 23NOV12

2012 UTC Fire & Security Americas Corporation, Inc.

Interlogix is part of UTC Climate Controls &

Security, a unit of United

Technologies Corporation.

Trademarks and

patents

The

UltraView name and logo are trademarks of

UTC

Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the

manufacturers or vendors of the

respective products.

Manufacturer

UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA.

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6

003 DH Weert, The Netherlands

Certification

N4131

FCC compliance

Class A

: This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in

a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at his own

expense.

ACMA compliance

Notice!

This is a Class A product. In a domestic environment this

product may cause radi

o interference in which case the user may be

required to take adequate measures.

Canada

This Class A digital apparatus complies with Canadian ICES

-003.

Cet appareil numérique de la class A conforme à la norme NMB

003

du Canada.

European Union

directives

2004/108/EC (EMC directive)

: Hereby, UTC Fire & Security

Americas Corporation, Inc.,

declares that this device is in compliance

with the essential requirements and other relevant provisions of

Directive 2004/108/EC

2002/96/EC (WEEE directiv

e): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated col

lection points. For more information see:

www.recyclethis.info.

Contact information

www.interlogix.com or

www.utcfssecurityproducts.eu

Customer support

www.interlogix.com/customer

-support

UVP 1.3 MPX HD 18X PTZ Camera User Manual i

Content

Chapter 1 Introduction 1

Product description 1

Features 1

Chapter 2 Installation 3

Installation environment 3

Before you begin 4

Camera description 4

Specifications 5

System requirements 5

Installing the camera 6

Accessing the SDHC card 10

Connections 10

Chapter 3 Using the Web browser 13

Checking your Web browser security level 13

Accessing the camera over the internet 14

Overview of the camera Web browser 15

Configuring the camera 17

Chapter 4 Network setup 23

Chapter 5 Camera setup 27

Camera information 27

DST time 27

Camera configuration 28

Display information 29

Video recording parameters 30

Camera tamper alarm 34

Adding extra text on-screen 36

Camera image settings 37

Reset camera settings 39

Restore camera settings to default 39

Chapter 6 Motion setup 41

PTZ channel 41

Park action 42

Home preset position 43

Preset position 43

Limit PTZ movement 45

Preset tour settings 47

Shadow Tour settings 49

Privacy masking 51

Time task 53

ii UVP 1.3 MPX HD 18X PTZ Camera User Manual

Clearing customized settings 54

Chapter 7 Alarm setup 55

Motion detection 55

Event schedule for alarms 57

Alarm set up 58

Chapter 8 Camera management 61

User management 61

Format the SDHC card 64

Firmware upgrade 64

Restore default settings 64

Reboot the camera 65

Chapter 9 Camera operation 67

On-screen display 67

Live mode 67

Searching recorded video for playback 68

Playing back recorded files 70

Viewing logs 70

Searching for logs 71

Archiving recorded files 72

Using predefined presets 73

Appendix A Pin definitions 75

Index 77

UVP 1.3 MPX HD 18X PTZ Camera User Manual 1

Chapter 1

Introduction

Product description

The UVP 1.3 MPX HD 18X PTZ Camera features integrated network remote

monitoring capability with the functions of a high speed dome. It is easy to install

and operate.

The dome camera is ideal for all surveillance requirements in a wide variety of

locations such as roads, airports, railway stations, harbors, stadiums, scenic

areas and parking lots.

This is the user manual for UVP 1.3 MPX HD 18X PTZ Camera models:

UVP-M1120P-18X-N

UVP-M1120P-18X-P

UVP-M1120F-18X-N

UVP-M1120F-18X-P

UVP-M1120S-18X-N (North America only)

UVP-M1120S-18X-P (North America only)

Features

This section describes the UVP 1.3 MPX HD 18X PTZ Camera features.

Built-in Web server

One channel of compressed video stream transmitted via network and

decoded for local display

Supports up to six connections via the network

Supports multiple network transmission protocols

Web access for WAN applications

Management of dome configuration and user permission administration via

Ethernet

Chapter 1: Introduction

2 UVP 1.3 MPX HD 18X PTZ Camera User Manual

IP address dynamic allocation

Built-in driver/receiver

Integrated design ensures high reliability

256 presets and 8 tours programmable, each tour with a maximum of 32

configurable presets

Supports up to four shadow tours with a recording time of up to 10 minutes

Up to 24 programmable privacy mask areas (depending on camera models)

Built-in pan/tilt

High-precision motor drive, stable operation, sensitive reaction and precise

positioning

Integrated design with compact construction

360° continuous rotation

Low-speed movement ensures high image stability

Preset positioning tolerance less than 0.1°

Built-in zoom lens

High sensibility and high resolution

Auto focus

Automatic gain control

Auto white balance

Auto IR cut filter

UVP 1.3 MPX HD 18X PTZ Camera User Manual 3

Chapter 2

Installation

This chapter provides information on how to install the dome camera.

Installation environment

When installing your product, consider these factors:

• Handling: Handle the camera carefully. Avoid striking, shaking, etc. Improper

handing or storage could damage the camera.

• Electrical: Install electrical wiring carefully. It should be done by qualified

service personnel. The input electricity to the unit has a tolerance of 24 VAC ±

10%. Do not overload the power cord or adapter.

• Ventilation: Ensure that the location planned for the installation of the

camera is well ventilated.

• Temperature: Do not operate the camera beyond the specified temperature,

humidity or power source ratings. The operating temperature of the indoor

camera is between -10°C to 50°C (14°F to 122°F) and that of the outdoor

camera is between -30°C to 60°C (-22°F to 140°F). Humidity is below 90%.

• Moisture: Do not expose the indoor camera to rain or moisture, or try to

operate it in wet areas. The indoor camera is designed for indoor use or

locations only where it is protected from rain and moisture. Turn the power off

immediately if the camera is wet and ask a qualified service person for

servicing. Moisture can damage the camera and also create the danger of

electric shock.

• Cleaning: Clean only with a dry cloth. If the dirt is difficult to remove, use a

mild liquid non-abrasive detergent and wipe gently.

• Protect from strong light: Never face the camera towards the sun. Do not

aim the camera at bright objects. Whether the camera is in use or not, never

aim it at the sun or other extremely bright objects. Otherwise, the camera may

be smeared or damaged.

• Servicing: Do not attempt to service this camera yourself. Any attempt to

dismantle or remove the covers from this product will invalidate the warranty

Chapter 2: Installation

4 UVP 1.3 MPX HD 18X PTZ Camera User Manual

and may also result in serious injury. Refer all servicing to qualified service

personnel.

Before you begin

When you receive the product, check the package and contents for damage, and

verify that all items are included. If any of the items are damaged or missing,

please contact your local supplier. If you need to return the unit, you must ship it

in the original box.

The camera is shipped with the following items:

Dome camera

User manual

Quick start guide

Camera description

Figure 1: Camera dimensions

Pendant-mount camera

Flush-mount camera

Chapter 2: Installation

UVP 1.3 MPX HD 18X PTZ Camera User Manual 5

Figure 2: Overview of the dome camera

1. Ethernet RJ-45 connector.

Connect to the network devices.

2. Video output.

Connect the BNC connector to a CCTV

monitor. Optional.

3. Power supply cord.

Connect +24 VAC power supply.

4. Housing.

5. PTZ module.

6. Bubble.

Specifications

Operating temperature

Pendant housing: -10 to +50 °C (-14 to +122 °F)

Flush housing: -30 to +65 °C (-22 to +149 °F)

Power supply

24 VAC +/- 4 VAC

Power consumption

30 W (heater on), 15 W (heater off)

Dimensions (mm)

Pendant housing: Ø 220 × 261 mm (Ø 8.66 ×10.27 in.)

Flush housing: Ø 206 × 241 mm (Ø 8.11 × 9.49 in.)

Environmental

Pendant housing: IP66

Flush housing: IP54

Weight

5 kg (11 lb.)

System requirements

For proper operation, adhere to the following operational, cable, and power

requirements for the dome camera.

Cable requirements

Table 1 on page 6 lists the requirements for the cables that connect to the dome

camera.

Chapter 2: Installation

6 UVP 1.3 MPX HD 18X PTZ Camera User Manual

Table 1: Recommended cable requirements

Operation

Cable requirement Max. length

feet meters

Data (RS

-485) Not used

Video

75 ohm RG-59 coaxial cable with BNC ends. 750 228

Alarm

Cat 5 cable (recommended) 1250 381

Network

Cat 5 cable (recommended) 492 150

Power

24 VAC cable. To determine the size of cable needed for individual

applications, see “Power cable size and length requirements” below.

Power cable size and length requirements

Use the proper gauge of power cable to ensure proper operation and to avoid

voltage drops. See Table 2 below for the recommended cable gauge for varying

maximum cable lengths and power draws.

Table 2: Recommended power cable gauges based on maximum lengths for an operating

voltage of 24 VAC (±10%)

Wire gauge

mm² Power

30 W 40 W

Distance

(feet) Distance

(m) Distance

(feet) Distance

(m)

0.80 94 28 70 21

1.00 150 45 112 34

1.25 238 72 179 54

2.00 603 183 452 137

Installing the camera

For basic operation, you need to connect Ethernet, power and video output

cables to the components in the dome shown in Figure 2 on page 5. For

advanced operation, you can also connect any combination of alarm, relay, or

audio cables to the dome.

A qualified service person, complying with all applicable codes, should perform

all required hardware installation.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Interlogix Sicherheitskamera Handbücher

Interlogix

Interlogix TruVision Line Bedienungsanleitung

Interlogix

Interlogix TruVision TVB-5702 Merkblatt

Interlogix

Interlogix UVD-XP3DNR Montageanleitung

Interlogix

Interlogix UVD-XP4DNR Bedienungsanleitung

Interlogix

Interlogix TVB-2201 Bedienungsanleitung

Interlogix

Interlogix TruVision TVC-7120-1-N Bedienungsanleitung

Interlogix

Interlogix TruVision HD-TVI 3MPX Merkblatt

Interlogix

Interlogix UVP-N120P-36X(-P) Bedienungsanleitung

Interlogix

Interlogix TruVision TVB-2401 Bedienungsanleitung

Interlogix

Interlogix TruVision TVW-2401 Merkblatt

Interlogix

Interlogix TVD-5110-3 Bedienungsanleitung

Interlogix

Interlogix TruVision 4 IP Series Merkblatt

Interlogix

Interlogix UltraView UVC-6130-1-N Bedienungsanleitung

Interlogix

Interlogix TruVision TVD-2401 Bedienungsanleitung

Interlogix

Interlogix UVC-XP4DN-HR-P Bedienungsanleitung

Interlogix

Interlogix TruVision TVP-5104 Merkblatt

Interlogix

Interlogix TruVision TVB 2102 Bedienungsanleitung

Interlogix

Interlogix TruVision TVB-2402 Bedienungs- und Wartungsanleitung

Interlogix

Interlogix TruVision TVD-2404 Bedienungsanleitung

Interlogix

Interlogix TruVision PTZ 36X Bedienungsanleitung

Interlogix

Interlogix PIR Bedienungsanleitung

Interlogix

Interlogix MobileView MVC-7100-29-BL Bedienungsanleitung

Interlogix

Interlogix Ultra View UVD-6120VE-2 Bedienungsanleitung

Interlogix

Interlogix TruVision Line Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
