Intermec EasyLAN 10I2 Bedienungsanleitung

EasyLAN™10i2

Ethernet Adapter

Quick Start Guide

ii EasyLAN 10i2 Ethernet Adapter Quick Start Guide

Intermec Technologies Corporation

Corporate Headquarters

6001 36th Ave. W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is proprietary and is

provided solely for the purpose of allowing customers to

operate and service Intermec-manufactured equipment and

is not to be released, reproduced, or used for any other

purpose without written permission of Intermec.

Information and specifications contained in this document

are subject to change without prior notice and do not

represent a commitment on the part of Intermec

Technologies Corporation.

rights reserved.

The word Intermec, the Intermec logo, Norand, ArciTech,

CrossBar, Data Collection Browser, dcBrowser,

Duratherm, EasyCoder, EasyLAN, Enterprise Wireless

LAN, EZBuilder, Fingerprint, i-gistics, INCA (under

license), InterDriver, Intermec Printer Network Manager,

IRL, JANUS, LabelShop, Mobile Framework,

MobileLAN, Nor*Ware, Pen*Key, Precision Print,

PrintSet, RoutePower, TE 2000, Trakker Antares, UAP,

Universal Access Point, and Virtual Wedge are either

trademarks or registered trademarks of Intermec

Technologies Corporation.

Throughout this manual, trademarked names may be used.

Rather than put a trademark (™or ®) symbol in every

occurrence of a trademarked name, we state that we are

using the names only in an editorial fashion, and to the

benefit of the trademark owner, with no intention of

infringement.

There are U.S. and foreign patents pending.

EasyLAN 10i2 Ethernet Adapter Quick Start Guide iii

Contents

Introducing the EasyLAN 10i2 Adapter......................5

Physical Description ...................................................6

Out of the Box ...........................................................8

Installing the EasyLAN 10i2 Adapter..........................8

Connecting the EasyLAN 10i2 Adapter to

Your Network..........................................8

Printing a Test Label ..................................10

Downloading the IP Address ......................10

Managing and Configuring the EasyLAN 10i2

Adapter................................................................12

iv EasyLAN 10i2 Ethernet Adapter Quick Start Guide

blank

EasyLAN 10i2 Ethernet Adapter Quick Start Guide 5

Introducing the EasyLAN 10i2 Adapter

The external EasyLAN™10i2 Ethernet adapter (P/N

072885) and the internal EasyLAN 10i2 Ethernet adapters

(P/N 072894 and P/N 072884) let you share your

available printer resources with everyone connected to your

Ethernet network. Throughout the guide, “EasyLAN 10i2

adapter” is used to refer to both the internal and external

adapter unless otherwise specified.

You can only connect the external EasyLAN 10i2 adapter

to these printers:

• EasyCoder 91* • EasyCoder 601XP

• EasyCoder 301/E4* • EasyCoder 4630*

• EasyCoder 401* and

401LL*

• EasyCoder 7421,

PC41, and 7422*

• EasyCoder 501*, 501E*,

501S*, and 501XP

• ColorCoder 901/V4*

• EasyCoder C4, PC4, and

PC41

*These printer models require an external power supply to run

the EasyLAN 10i2 adapter.

You can connect either the external or the internal

EasyLAN 10i2 adapter (P/N 072894) to these printers:

• EasyCoder 3240

• EasyCoder 3400D and earlier and EasyCoder 3440

• EasyCoder 3600

Note: To connect the external adapter, the

printers must have the parallel port option

installed.

You can connect the internal EasyLAN 10i2 adapter (P/N

072884) to these printers:

• EasyCoder 3400e

• EasyCoder 4420 and 4440

6 EasyLAN 10i2 Ethernet Adapter Quick Start Guide

Note: If you are using the internal EasyLAN 10i2

adapter, you cannot use the parallel port.

The EasyLAN 10i2 adapter uses a 10BaseT connection,

which has a network speed of 10 Mbps.

Physical Description

10BaseT

connecto

LED

Te s t

button

EL10i011.eps

Internal EasyLAN 10i2 Adapter

LED

External power

supply connector

10BaseT

connector

Test

button

Parallel port

connector

EL10i010.eps

External EasyLAN 10i2 Adapter

EasyLAN 10i2 Ethernet Adapter Quick Start Guide 7

Connectors, LED, and Button Table

Part Description

10BaseT connector Connects the EasyLAN 10i2

adapter to a 10 Mbps Ethernet

network via a 10BaseT cable.

External power supply

connector (external

adapter only)

Connects the external EasyLAN

10i2 adapter to a power source via

a power supply.

Parallel port connector

(external adapter only)

Provides the external EasyLAN

10i2 adapter with a single

high-speed parallel port that can

connect directly, without the need

of cabling, to an Intermec printer

with a parallel port installed.

LED The LED provides information

on power-up diagnostics and

network activity.

Test button Use the Test button to:

• Print a test label that shows

some of the EasyLAN 10i2

adapter’s settings. Printers that

do not use the Intermec

Printer Language (IPL) or

Direct Protocol (DP), such as

the EasyCoder 91, 7422, C4,

or PC4 or the ColorCoder V4,

cannot print a test label.

• Reset the EasyLAN 10i2

adapter’s settings to the factory

default settings.

For more help, see “Printing a

Test Label” on page 10.

8 EasyLAN 10i2 Ethernet Adapter Quick Start Guide

Out of the Box

Your printer with the EasyLAN 10i2 adapter installed

comes with the following:

• PrinterCompanion™CD-ROM, which includes the

EasyLAN 10i2 Ethernet Adapter User’s Manual (P/N

072889) in PDF format and the Intermec print

monitor

• This guide and Important EasyLAN 10i2 Information!

Installing the EasyLAN 10i2 Adapter

Before you install the EasyLAN 10i2 adapter, make sure

that you have the appropriate Ethernet cable and power

cable. Also make sure that you have loaded media and

ribbon into the printer. For help, see the quick start guide

for your printer.

Connecting the EasyLAN 10i2 Adapter to Your

Network

This section explains how to physically connect the

internal EasyLAN 10i2 adapter or the external EasyLAN

10i2 adapter to your network.

To connect the internal EasyLAN 10i2 adapter

1 Connect one end of a 10BaseT cable to the 10BaseT

connector on the adapter.

2 Connect the other end of the 10BaseT cable to an

Ethernet port for your network.

To connect the external EasyLAN 10i2 adapter

Note: Although you can connect the external

adapter to many different Intermec printers, the

illustrations in the next procedure show the 7421.

1 Note the MAC address found on the underside of the

EasyLAN 10i2 adapter. You need this address during

the configuration.

EasyLAN 10i2 Ethernet Adapter Quick Start Guide 9

2 Turn off the printer.

3 Plug the parallel port connector on the adapter into the

parallel port on the printer.

EL10i009.eps

10BaseT

connector

Parallel

port

Parallel port

connector

10BaseT

cable

4 Connect one end of a 10BaseT cable to the 10BaseT

connector on the adapter.

5 Connect the other end of the 10BaseT cable to an

Ethernet port for your network.

6 If necessary, plug in the external power supply.

EL10i008.eps

10BaseT

cable

External

power

supply

connector

External

power

10 EasyLAN 10i2 Ethernet Adapter Quick Start Guide

7 Turn on the printer. The LED on the adapter flashes

and then turns off.

When you turn on the printer with the EasyLAN 10i2

adapter, the adapter runs through a set of power-up

diagnostics for a few seconds. If the adapter is operating

properly, the LED blinks momentarily and then turns off.

The LED blinks whenever there is networking activity.

If you have a DHCP (Dynamic Host Configuration

Protocol) server on your network, the EasyLAN 10i2

adapter receives its TCP/IP settings, including an IP

address, when you plug in the adapter and turn on the

printer. You are now ready to print to your printer. If you

want to print a test label or set a static IP address for the

EasyLAN 10i2 adapter, see the next two sections.

Printing a Test Label

After the LED turns off, print a test label to make sure that

the EasyLAN 10i2 adapter is working. The test label shows

the current Ethernet and network settings of the adapter.

Note: Printers that do not use the Intermec

Printer Language (IPL) or Direct Protocol (DP),

such as the EasyCoder 91, 901, 7422, C4, or PC4

or the ColorCoder V4, cannot print a test label.

To print a test label

• Insert a small, straightened paper clip into the Test

button, and press and release the Test button.

Downloading the IP Address

If you have a DHCP server on your network, the EasyLAN

10i2 adapter automatically connects to the server and

receives its TCP/IP settings, including its IP address. If you

do not have a DHCP server or if you want to configure a

static IP address, you can use ARP (Address Resolution

Protocol) to assign an IP address to the adapter.
