Intermec EasyCoder PX4i Bedienungsanleitung

EasyCoder® Printer

RFID Kit

PX4i, PX6i

Installation

Instructions

ii EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions

Intermec Technologies Corporation

Worldwide Headquarters

6001 36th Ave.W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is provided solely for the purpose of allowing

customers to operate and service Intermec-manufactured equipment and is not to be

released, reproduced, or used for any other purpose without written permission of

Intermec Technologies Corporation.

Information and specifications contained in this document are subject to change

without prior notice and do not represent a commitment on the part of Intermec

Technologies Corporation.

The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook,

CrossBar, dcBrowser, Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, INCA

(under license), i-gistics, Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN,

Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan, Smart Mobile

Computing, SmartSystems, TE 2000, Trakker Antares, and Vista Powered are either

trademarks or registered trademarks of Intermec Technologies Corporation.

There are U.S. and foreign patents pending.

EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions 3

What Is the RFID Kit?

The RFID kit provides RFID functionality for the EasyCoder®

PX4i and PX6i printers. With this kit installed, the PX4i or PX6i

printer can read and write to RFID tags.

These instructions describe how to install these RFID kits:

•PX4i 915 MHz RFID Kit (P/N 270-153-001)

•PX4i 869 MHz RFID Kit (P/N 270-155-001)

•PX6i 915 MHz RFID Kit (P/N 270-154-001)

•PX6i 869 MHz RFID Kit (P/N 270-156-001)

For more information about using RFID features on the

PX4i or PX6i, see the EasyCoder Printer RFID User’s Guide

(P/N 934-041-xxx).

What You Get

•One of these I/O interface boards:

•I/O interface board with IM4 869 MHz radio module

•I/O interface board with IM4 915 MHz radio module

•One of these lower media guides:

•PX4i lower media guide with RFID antenna

•PX6i lower media guide with RFID antenna

•Dual slot I/O cable

•M3x5 screw (2)

•M4x5 screw

•Spacer screw

What You Need

•A PX4i or PX6i printer running Fingerprint v8.76.0 or later

or IPL v2.76.0 or later. You can download the latest version of

firmware from the Intermec web site at www.intermec.com.

•A #T10 and a #T20 Torx screwdriver.

•A slotted screwdriver.

4 EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions

Installing the RFID Kit

To install the RFID kit

1Open the front door and right side door.

The installation described in this section must only be

performed by an authorized service technician. Intermec

assumes no responsibility for personal injury or damage to

the equipment if the installation is performed by an

unauthorized person.

Follow standard ESD guidelines to avoid damaging the

equipment you are servicing.

Before you begin, turn off the printer and disconnect the

power cord and communication cables.

Note: This procedure applies to both the PX4i and PX6i. For

simplicity, the PX4i is depicted in the illustrations.

EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions 5

2Remove the eight #T10 Torx screws and remove the left side

door.

3Release the lower media guide latch.

Screw

(8 places)

Lower media

guidelatch

6 EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions

4Carefully remove the lower media guide and upper media

guide assembly.

5Remove the upper media guide from the lower media guide.

6Route the antenna cable from the RFID lower media guide

through the opening in the print engine base. Make sure to

route the cable in front of the label stop sensor (LSS) guide

bar.

Upper andlower media

guide assembly

EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions 7

7Slide the RFID lower media guide into the printer. Insert the

pins on the guide into the holes on the print engine base.

8Snap the RFID lower media guide into place.

9Insert the upper media guide.

10 On the back of the printer, remove the two screws that secure

the cover plate to slot 1 or slot 2, and remove the cover plate.

11 Connect the dual slot I/O cable to the main board.

RFID lower

media guide

Note: You need to use the first available slot on the printer

starting from the left (slot 1).

Screw

(2 places)

Slot 1 Slot 2

Dual slot I/O cable

8 EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions

12 Connect the dual slot I/O cable to the RFID interface board.

Use the connector 1 for slot 1 and connector 2 for slot 2.

13 Slide the RFID interface board into the printer.

14 Secure the RFID interface board with the two screws you

removed in Step 9 or with the two included M3x5 screws.

15 Secure the RFID interface board to the circuit board with the

M4x5 screw and spacer screw. For slot 1, use the spacer screw

on the main board. For slot 2, use the spacer screw in the kit.

16 Connect the antenna cable to the RFID interface board.

17 Attach the left side door to the printer.

18 Close the front and right side doors.

Connector 1

Connector 2

EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions 9

10 EasyCoder Printer (PX4i and PX6i) RFID Kit Installation Instructions
