Installation

Instructions

Cutter Kit

(for EasyCoder PX4i,

PX6i, 501 XP, and

601 XP printers)

Intermec Technologies Corporation

Corporate Headquarters

6001 36th Ave. W.

Everett, WA 98203

U.S.A.

www.intermec.com

e information contained herein is proprietary and is provided solely

for the purpose of allowing customers to operate and service Intermec-

manufactured equipment and is not to be released, reproduced, or used

for any other purpose without written permission of Intermec.

Information and speciﬁcations contained in this document are subject to

change without prior notice and do not represent a commitment on the

part of Intermec Technologies Corporation.

e word Intermec, the Intermec logo, Norand, ArciTech, CrossBar,

Data Collection Browser, dcBrowser, Duratherm, EasyCoder, EasyLAN,

Enterprise Wireless LAN, EZBuilder, Fingerprint, i-gistics, INCA (under

license), InterDriver, Intermec Printer Network Manager, IRL, JANUS,

LabelShop, Mobile Framework, MobileLAN, Nor*Ware, Pen*Key,

Precision Print, PrintSet, RoutePower, TE 2000, Trakker Antares, UAP,

Universal Access Point, and Virtual Wedge are either trademarks or regis-

tered trademarks of Intermec Technologies Corporation.

roughout this manual, trademarked names may be used. Rather than

put a trademark (™ or ®) symbol in every occurrence of a trademarked

name, we state that we are using the names only in an editorial fashion,

and to the beneﬁt of the trademark owner, with no intention of infringe-

ment.

ere are U.S. and foreign patents pending.

Torx is a registered trademark of Camcar Division of Textron Inc.

EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions iii

Contents

1 Introduction

Description.................................................................................... 2

2 Installation

Step-by-step instructions................................................................6

3 Controlling the Cutter

Fingerprint................................................................................... 10

IPL...............................................................................................10

4 Maintenance and Troubleshooting

Cleaning.......................................................................................12

iv EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions

Contents

EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions 1

1 Introduction

is chapter describes the cutter kits for EasyCoder

PX4i, PX6i, 501 XP, and 601 XP printers.

2 EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions

Chapter 1 — Introduction

Description

e EasyCoder PX4i/PX6i and 501 XP/601 XP printers can easily

be ﬁtted with an optional cutter, provided the printer is not already

ﬁtted with an label-taken sensor. e cutters are almost identical with

exception for the width. Illustrations in this manual show EasyCoder

PX4i/PX6i printers, but the same principles apply to EasyCoder 501

XP/601 XP printers.

e cutter supports both Intermec Fingerprint and IPL.

e cutter unit is ﬁtted on the same hinges as the front door, which it

replaces, and is connected by a single cable to the DIN-connector on the

printer’s front.

e cutter is available both as a factory-installed option and as a ﬁeld-

installable upgrading kit. It can be installed by the operator.

e cutter is intended to cut through continuous non-adhesive paper

strip or through the backing paper between labels. It must not be used to

cut through any kind of adhesive or other soft material, that may stick to

the cutting parts and render the cutter inoperable and even damage the

electric motor by overheating.

Maximum paper thickness is 175 µm (≈175 grams/m2) for normal

paper-based materials.

Minimum practical copy length is 38.1 mm (1.5 inches)

e cutter increases the printer’s total weight and length as follows:

EasyCoder PX4i/501 XP:

Weight: 1.0 kg (2.2 lbs)

Length: 28 mm (1.1 inches)

EasyCoder PX6i/601 XP:

Weight: 1.65 kg (3.6 lbs)

Length: 28 mm (1.1 inches)

e cutter can be tilted forward in order to facilitate cleaning and paper

load.

e cutting edge will rotate to home position when the

power is turned on and when the printer is rebooted.

Always keep the cutter unit closed during operation.

EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions 3

Chapter 1 — Introduction

4 EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions

Chapter 1 — Introduction

EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions 5

2 Installation

is chapter describes how to install the cutter on an

EasyCoder PX4i/PX6i or 501 XP/601 XP printer. No

tools are required.

Install the cutter as follows:

• Switch oﬀ the power and remove the power cord.

• Open the printer’s front door.

• Hold the printer ﬁrmly and press the front door sideways to the left so

as to disengage the hinges.

• Remove the door completely.

• Fit the cutter unit to the vacant hinges. Make sure that the lock-

ing plate snaps into the groove of the right-hand hinge and that the

angled plate at the bottom of the cutter is inserted under the printer's

bottom plate.

• Fit the cable from the cutter unit into the DIN connector on the

printer's front.

0RESS

SIDEWAYS

6 EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions

Chapter 2 — Installation
