Intermec Sabre 1514 Bedienungsanleitung

P/N 063496-003

Decoding Laser Scanner

User’s

Manual

IntermecCorporation

6001 36th Avenue West

P.O. Box 4280

Everett, WA 98203-9280

U.S. service and technical support: 1-800-755-5505

U.S. media supplies ordering information: 1-800-227-9947

Canadian service and technical support: 1-800-688-7043

Canadian media supplies ordering information: 1-800-268-6936

Outside U.S. and Canada: Contact your local Intermec service

supplier.

The information contained herein is proprietary and is provided

solely for the purpose of allowing customers to operate and/or

service Intermec manufactured equipment and is not to be released,

reproduced, or used for any other purpose without written

permission of Intermec.

Information and specifications in this manual are subject to change

without notice.

1996 by Intermec Corporation

The word Intermec, the Intermec logo, JANUS, IRL, TRAKKER,

Duratherm, Precision Print, PrintSet, Virtual Wedge, and

CrossBar are trademarks of Intermec Corporation.

Throughout this manual, trademarked names may be used.

Rather than put a trademark () symbol in every occurrence of

a trademarked name, we state that we are using the names only

in an editorial fashion, and to the benefit of the trademark

owner, with no intention of infringement.

Manual Change Record

This page records the changes to this manual. The manual was

originally released as version 001.

Version Date Description of Change

002 6/96 Revised and reorganized to

include the 1551 scanners.

003 12/96 Revised to include international

keyboards, caps lock, remote

beep, and connecting to a

laptop or pen-based terminal.

Contents

Before You Begin ix

Warranty Information ix

Safety Summary ix

Warnings, Cautions, and Notes x

About This Manual xi

Connecting the Scanner

Getting Started 1-3

Unpacking the Scanner 1-3

Installation Equipment 1-4

Connecting the Scanner 1-4

15XXX02 Decoding Laser Scanner 1-5

15XXX03 Decoding Laser Scanner 1-6

15XXX07 Decoding Laser Scanner 1-9

Operating the Scanner

General Instructions 2-3

Scanner Light 2-3

Scanner Beeps 2-4

Operating the Scanner 2-4

Hand-Held Scanning 2-4

Hands-Free Scanning 2-6

Troubleshooting 2-7

Maintenance 2-8

Decoding Laser Scanner User’s Manual

Configuring the Scanner

About Configuring the Scanner 3-3

Configuring by Scanning Bar Codes 3-3

Configuring the Scanner From a Host Terminal 3-3

Waking Up the Scanner to Process Commands

3-5

Remote Beep 3-5

Acknowledging Commands Between Host and

Scanner 3-5

Displaying Current Configuration 3-6

Resetting Default Values 3-6

Configuring Bar Code Symbologies 3-7

UPC-A and UPC-E 3-8

UPC Number System Digit 3-9

UPC Check Digit 3-9

EAN/JAN 3-9

EAN/JAN Number System Digit 3-10

EAN/JAN Check Digit 3-10

Code 39 3-11

Standard 2 of 5 3-12

Interleaved 2 of 5 3-12

Code 128 3-13

Codabar 3-14

Code 93 3-15

Code 11 3-16

Configuring Bar Code Parameters 3-17

Prefix 3-17

Suffix 3-18

Terminal ID 3-19

Bar Code ID 3-19

Preamble and Postamble 3-20

Contents

vii

Configuring Operating Parameters 3-21

Power Consumption 3-21

Beep Volume 3-22

Laser Redundancy 3-22

Spotter Beam 3-23

External Trigger 3-23

Reading Uppercase Letters 3-24

Reading Symbols 3-25

International Keyboards 3-25

Configuring the 15XXX02 Serial Parameters 3-27

Baud Rate 3-27

Intercharacter Delay 3-28

Label Buffer 3-29

Setting Up the Bar Code Data String 3-29

Selecting a Protocol 3-31

Configuring the Scanner for Wand Emulation to Use With

a Portable Reader 3-33

Scanning Unreadable Symbologies 3-34

Configuring Bar Code Polarity 3-34

Configuring the Transmission Rate 3-34

Switching Back to a Terminal 3-35

Configuring the Scanner for Use With an Intermec 94XX

and 95XX Reader 3-36

Decoding Laser Scanner User’s Manual

viii

Hexadecimal Conversion Chart

Configuration Command List

Glossary

Index

Before You Begin

This section introduces you to standard warranty provisions,

safety precautions, warnings and cautions, document

formatting conventions, and sources of additional product

information.

Warranty Information

To receive a copy of the standard warranty provision for this

product, contact your local Intermec support services

organization. In the U.S. call 1-800-755-5505, and in Canada call

1-800-688-7043.

Safety Summary

Your safety is extremely important. Read and follow all

warnings and cautions in this book before handling and

operating Intermec equipment. You can be seriously injured,

and equipment and data can be damaged if you do not follow

the safety warnings and cautions.

Do not repair or adjust alone Do not repair or adjust energized

equipment alone under any circumstances. Someone capable of

providing first aid must always be present for your safety.

First aid Always obtain first aid or medical attention

immediately after an injury. Never neglect an injury, no matter

how slight it seems.

Resuscitation Begin resuscitation immediately if someone is

injured and stops breathing. Any delay could result in death. To

work on or near high voltage, you should be familiar with

approved industrial first aid methods.

Decoding Laser Scanner User’s Manual

Energized equipment Never work on energized equipment

unless authorized by a responsible authority. Energized

electrical equipment is dangerous. Electrical shock from

energized equipment can cause death. If you must perform

authorized emergency work on energized equipment, be sure

that you comply strictly with approved safety regulations.

Warnings, Cautions, and Notes

The warnings, cautions, and notes in this manual use the

following format.

Warning

A warning alerts you of an operating procedure,

practice, condition, or statement that must be strictly

observed to avoid death or serious injury to the

persons working on the equipment.

Avertissement

Un avertissement vous avertit d’une procédure de

fonctionnement, d’une méthode, d’un état ou d’un

rapport qui doit être strictement respecté pour éviter

l’occurrence de mort ou de blessures graves aux

personnes manupulant l’équipement.

Caution

A caution alerts you to an operating procedure,

practice, condition, or statement that must be strictly

observed to prevent equipment damage or

destruction, or corruption or loss of data.

Conseil

Une précaution vous avertit d’une procédure de

fonctionnement, d’une méthode, d’un état ou d’un

rapport qui doit être strictement respecté pour

empêcher l’endommagement ou la destruction de

l’équipement, ou l’altération ou la perte de données.
