J-Tech Digital JTECH-ex2 Bedienungsanleitung
160ft, 1080p hdmi extender over single cat5e/6
JTD-ID: 229 | Model Number: JTECH-ex2
USER MANUAL
J-TECH DIGITAL INC.
9807 EMILY LANE
STAFFORD, TX 77477
TEL: 1-888-610-2818
Page 2of 8
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
Notice
Our company reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
Page 3of 8
Table of Contents
1. Features............................................................................................................. 4
2. Specifications ................................................................................................... 4
3. Package Contents........................................................................................... 5
4. Panel Description ............................................................................................. 5
5. Connecting and Operating ........................................................................... 6
6. Maintenance.................................................................................................... 6
7. Warranty............................................................................................................ 6
8. Mail-In Service .................................................................................................. 6
9. Limited Warranty Limits and Exclusions ......................................................... 7
Page 4of 8
1. Features
•High-definition resolution up to Full HD 1080P 60Hz YUV 4:4:4
•Transmit over 160ft. CAT5E/6 without signal loss
•Supports 3D
•Supports LPCM up to 7.1 / 24bit / 192KHz
2. Specifications
Operating Temperature Range
0 - +40°C (32 0 +104°F)
Operating Humidity Range
5 –90% RH (No condensation)
Input Video Signal
0.5 –1.0 Volts P-P
Input DDC Signal
5 Volts P-P (TTL)
Video Formats
720P / 1080i / 1080P
Video Output
HDMI
Audio Formats
DTS-HD Master Audio, Dolby True-HD etc.
Transmission Distance
160ft. over single Cat5e/6
Power Consumption
2W (Maximum)
Dimensions (L x W x H)
TX: 79.3mm x 68mm x 16.5mm
RX: 79.3mm x 68mm x 16.5mm
Net Weight
232g / 0.5lbs
Page 5of 8
3. Package Contents
•(1) x Transmitter
•(1) x Receiver
•(1) x DC 5V/1A Power Adapter
•(1) x User Manual
4. Panel Description
1. Ethernet Port 2. DC 5V/1A Power Port 3. Power Indicator
4. HDMI Indicator 5. HDMI Input Port
Page 6of 8
1. Ethernet Port 2. Power Indicator 3. HDMI Indicator
4. HDMI Output Port
5. Connecting and Operating
•Connect an HDMI signal source to the transmitter via HDMI cable
•Connect a CAT5e/6 cable to both the ethernet port on the transmitter and the receiver
•Connect a display via HDMI to the HDMI port on the receiver
6. Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner, or benzine to clean.
7. Warranty
If your product does not work properly because of a defect in materials of workmanship, our
company (referred to as “the warrantor”) will, for the length of the period indicated as below, “Parts
and Labor (1) Year”, which starts with the date of original purchase (“Limited Warranty period”),
at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a
new or a refurbished product. The decision to repair or replace will be made by the warrantor.
During the “Labor” limited warranty period, there will be no charge for labor. During the “Parts”
warranty period, there will be no charge for parts. You must mail-in your product during the
warranty period. This Limited Warranty is extended only to the original purchaser and only covers
products purchased as new. A purchase receipt or other proof of original purchase date is required
for Limited Warranty service.
8. Mail-In Service
When shipping the unit, carefully pack and send it prepaid, adequately insured, and preferably in
the original carton. Include a letter detailing the complaint and provide a day time phone and/or
email address where you can be reached.
Page 7of 8
9. Limited Warranty Limits and Exclusions
This Limited Warranty ONLY COVERS failures due to defects in material or workmanship, and
DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO
DOES NOT COVER damages which occurred in shipment, or failures which are caused by
products not supplied by warrantor, or failures which result from accidents, misuse, abuse,
neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, mis-
adjustment of consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service center or other Authorized
Servicer, or damage that is attributed to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED
WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTAIL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR
ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes damages
for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to
and from the service, loss of or damage to media or images, data or other recorded content.
The items listed are not exclusive, but are for illustration only.) PARTS AND SERVICE, WHICH
ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY.
Page 8of 8
WWW.JTECHDIGITAL.COM
PUBLISHED BY J-TECH DIGITAL INC.
9807 EMILY LANE
STAFFORD, TX 77477
TEL: 1-888-610-2818
E-MAIL: [email protected]
