Jacuzzi JS-1i Bedienungsanleitung
Jacuzzi®Full Spectrum Infrared Saunas
Please read this manual before using your Sauna for the first time.
Please keep this manual for future reference.
www.Jacuzzi.com
Owner’s Manual
Table of Contents
Installation ----------------------------------------04
01 | Jacuzzi®JS-1i and JS-2i ---------------------------05
Packaging ----------------------------------------06
Assembly Instructions --------------------------------07
02 | Jacuzzi®JS-3i ----------------------------------20
Packaging ----------------------------------------21
Assembly Instructions --------------------------------22
Enjoying Your Sauna ---------------------------------35
Using Your Sauna Control Panel--------------------------36
Tips for Use ---------------------------------------40
Safety Instructions- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 42
Important Safeguards --------------------------------44
* The information contained in this manual is subject to change without notice.
Installation
Choosing a Location
Place your sauna on a dry and level surface for best results.
Installation requirements for your sauna are as follows:
1. Your Jacuzzi®sauna is a self-contained and freestanding unit. It should not be built into any structure without prior
authorization.
2. Please maintain a minimum of 4-inch clearance on all sides of the unit to allow air to circulate while giving access
for the power cord.
Cleaning and Maintenance
1. Before using your sauna for the first time, clean the inside of the sauna with a damp cloth.
2. Place a towel on the floor and bench to absorb any perspiration. Wash these often to maintain a clean and pleasant
environment inside your sauna.
3. Perspiration may darken the wood over time. Refer to Varnish Instructions.
Please be careful when carrying and installing the glass pieces to avoid breakage. Make certain the
glass is securely fastened during installation before letting go of any individual piece that could break.
Jacuzzi®Saunas JS-1i and JS-2i
www.jacuzzi.com
5
01
Packaging - - - - - - - - - - - - - - - - - - - - - - - - 06
Assembly Instructions - - - - - - - - - - - - - - - - - - 07
Jacuzzi®Saunas JS-1i and JS-2i
6
www.jacuzzi.com
Packaging
.
Box 1 of 6 Box 2 of 6 Box 3 of 6 Box 4 of 6
Roof and Floor Panels Left Side Wall Front Wall Metal Threaded Rods
Installation Manual Right Side Wall Back Wall
Box 5 of 6 Box 6 of 6
Parts and Accessories 2 x Full Spectrum
Heaters
Right Side Wall
Contents of Boxes
Accessory Box Contents
Door Handle Wood piece
(2 pieces)
Front Heater
Mounting Screws
(4 sets)
Jacuzzi®Saunas JS-1i and JS-2i
www.jacuzzi.com
7
Assembly Instructions
Assembly of the sauna requires a minimum of two adults to complete. As noted, a third person is recommended when
installing the glass components. Please read the instructions thoroughly before and during assembly to ensure proper
installation of the unit. Wearing booties to cover your shoes will protect the wood from getting scuffed or stained.
When determining a location for your sauna, please keep in mind the following:
1. The main power cord on the sauna must be easily accessible.
2. The location must be dry and level.
3. Panels should be installed in the following order:
1) Floor 4) Right Side Wall 7) Roof
2) Back Wall 5) Under Bench Support 8) Front Wall Glass
1. Place the bottom floor panel on the ground
near the location you will be using the sauna.
Make sure the front of the floor is in the desired
location of the door. The metal threshold
indicates the front of the sauna.
1. Connect the back panel to the floor panel by lining up
the back panel on the groove of the floor panel.
1 - Location of Sauna and Installation Order
2 -Placing Floor Panel 3 - Connecting the Back Panel to
the Floor Panel
Jacuzzi®Saunas JS-1i and JS-2i
8
www.jacuzzi.com
Assembly Instructions Cont’d
1. Place the left side wall in the slot in
the floor positioned as in the drawing
below.
2. When the wall is in place, make sure
the metal rod is positioned in the
metal nut in the floor.
3. Screw the metal bolt from the top of
the panel into the metal nut in the
floor using your hand to twist the
metal rod.
4. Repeat this step installing the Right
Side Wall.
4 - Connecting Side Walls
Left Side Wall Installed Right Side Wall Installed
If the panels still seem too tight to come down all the way, try backing off the
bracket screws by one half turn with a Phillips head screwdriver.
Jacuzzi®Saunas JS-1i and JS-2i
www.jacuzzi.com
9
1. Insert the left side wall glass into the slot in the left side wall and make sure it’s well seated on the floor.
2. Repeat this step with the Right Side glass.
5 - Installing Side Wall Glass
When installing the glass panels, a third person is recommended to support the glass during installation..
Jacuzzi®Saunas JS-1i and JS-2i
Assembly Instructions Cont’d
10
www.jacuzzi.com
Assembly Instructions Cont’d
1. Located the two (2) front columns and the
corresponding metal rods.
3. Align one of the threaded columns with the left side
glass and position the metal rod over the metal nut in
the floor.
4 Hand screw the metal rod into the nut until it is tight.
5. Repeat this step for the Right Side Column.
2. Thread the rods through the columns.
6 - Install Front Columns
Note: Some of the rod will be exposed
at the top of the column.
Jacuzzi®Saunas JS-1i and JS-2i
