"On-Off": This mode requires a 2-channel Tx.
Channel 1 will always energize the relay
Channel 2 will always de-energize the relay
You must press both buttons at the same time during programming
(channelised code programming). Pressing one channel only will not
get the on/off function.
"On-Off": This mode requires a 4-channel Tx.
Channel 3 will always energize the relay
Channel 4 will always de-energize the relay
(Mode added November 2006)
"Test": Relay is energized, for test purpose only
Troubleshooting
This section contains helpful troubleshooting tips and solution.
Symptom Solution
Receiver not responding to transmitter after
programming.
Try to program the transmitter again, but this
time connect battery to the transmitter.
If transmitter only programs when the battery is
connected, return transmitter to Elsema.
Check if GIGALINK™cable is inserted
correctly
Transmitter activates wrong channel on a multi-
channel receiver.
Wrong dip switch setting while programming
the receiver. Use the dip switch table and
program again
Transmitter has short range. Check receiver antenna connection. If you are
using a shielded coax cable, check that the
shield and core are connected properly.
Led is flashing on the transmitter. Replace battery.
