Jenn Air 3 Door Panel Installation Quick Guide

Model: JFC2089HT

Updated 09/14/06

Top Panels: Width   Height(ininches)

1/4”or3/8”backer*     1713/16*  421/16

*Recessedbackeroption:Thebackermaterialisexposedalongthehandlesideofbothupperdoors.The1713/16”width

dimensionprovidesboth1/4”and3/8”backerswitha3/16”recessesfromthebackeredgetothepaneledgealongthehandleside.

Seepg2.Theexposededgeofthebackermaterialcanbecoveredwithwoodveneer,melamineorpaintedtomatcheitherthe

panelorrefrigeratorcolor.Handlemountingscrewswillretainpanelstothehingesideofthepanelframe.Afulldimensionbacker

withoutanyrecesswouldmeasure1715/16”.Forafulldimensionbacker,readandunderstandtheinformationandnotesfor1/4”

veneeredpanels.

FramelessOverlay(panelcoversmetaltrim)  181/8   421/4

FramedInlay(paneldoesnotcovermetaltrim)  1713/16  415/8

FramedVeneer**     18**   421/16

**Note:anadditionalinstructionspecictoa1/4”veneeredbacker.Themetalframeisdesignedtotapanel1715/16”wide.

Cuttingan18”panelallowsfora1/4”spacebetweenupperpanelsandcoversthe1/16”edgeofthealuminumtrimatbothendsof

thehandlesideofthepanel.Detailedlingisneededatthetopandbottomofthehandlesideofbothupperdoorsforthepaneltot.

TESTFITBEFOREANDDURINGFILING.Carefullyleasmallnotchapproximate1/16”x7/32”atthebottomofthehandlesideofthe

paneltoallowthepanelbottomtotintothetopandbottomaluminumtrim.TESTFITBEFOREANDDURINGFILING.Carefullylea

similar1/16”x7/32”notchatthetoptoallowthetoptrimtotoverthetopofthepanel.

Bottom Panel:Width   Height (ininches)

1/4”or3/8”backermaterial    363/16  2313/16

FramelessOverlay(panelcoversmetaltrim)  361/2   24

FramedInlay(paneldoesnotcovermetaltrim)  353/4   233/8

FramedVeneer     363/16  2313/16

Nobackerinstructions:Millpanelorframematerialtoincludea1/4”x3/16”tongueonthetrimedge.Useappropriateinlayor

overlaydimensiontoconstructpanelswiththeproperoutsidedimensions.Seeillustrationsonpage4.

Note:Longerscrewsareneededtoattachthehandlemountingpostswhenoverlaypanelsareapplied.Foreaseandavailability,

considerusingKregpocketscrews:2-1/2”,#8Coarse,Washer-Head.Predrillpanelswitha5/32”pilothole.DONOTpredrillthe

refrigeratormetaldoor.DONOTovertighten.

3/8” Backer Edge Details:

Note: Lower backer panel has 5/16” x 1/8” rabbit cut into all four sides

0 1/8"

0 1/4"

0 1/8"

0 1/4"

BOTT OM PANEL BACKER

0 5/16" 0 5/16"

0 1/8"

0 1/4"

(1/4” minimum)

0 3/8"

0 1/8"

0 5/16"

0 1/4"

(1/4” minimum)

0 3/8"

RIGHT PANEL BACKER

0 5/16"

Metal of Door Metal of Door

LEFT PANEL BACKER

HandleEdge

(requiresnish)

HandleEdge

(requiresnish)

HingeEdgeHingeEdge

HingeEdge

LEFTTOP RIGHTTOP

Cross Section of Overlay and Inlay Panels:

0 7/32"

Metal of Door

Framed Inlay

0 5/16"

0 1/4"

0 1/8"

0 3/8"

0 5/32"

Metal of Door

Frameless Overlay

0 3/16"

01/4"

3/8”and1/4”Backers

LeftPanelShown

Panel With No Backer: TopViewCrossSectional

LeftPanelOnly

0 1/4"

0 3/16"

0 1/2"

Inlay Dimension

0 1/8"

0 5/16"

0 3/16"

0 1/4"

Overlay Dimension

0 1/8" Metal of Door

Metal of Door

NoBackerOverlayInstructions:Millallmoldingmaterialtofulldimension.

CutOnlytheframeedgestoproduce1/4”x3/16”tongueontheframeedges.

NoBackerInlayInstructions:Millallmoldingmaterialtoincludea1/4”x3/16”

tongueontheframeedge.Useappropriateinlaydimensionstoconstructpanels

withtheproperoutsidedimension.
