12" x 20" WOOD LATHE

STOCK NO. 900493

10M 07/07

The latest addition to our line of JET®Woodturning Lathes is the model JWL-1220. This

new 3/4HP lathe supports stock up to 12" in diameter and 20" in length. A built-in work

light illuminates your work piece while turning and the spindle has a lock and indexing

capability for ﬂuting and veining applications. Integrated carry handles and a cord wrap

are added for portability.

708376.indd 1 7/3/07 6:42:06 AM

jettools.com

12"x 20" WOOD LATHE

•Heavy-duty cast-iron lathe bed adds stability while limiting vibration during operation

•Indexing mechanism which allows for ﬂuting and veining operations

•Self-ejecting tailstock for safe and easy removal of tooling

•Cam-lock mechanisms allow adjustments of headstock, tailstock and tool rest base

without having to use tools

•Hollow tailstock and removable tip on live center allows for hole boring through stock

•Convenient worklight allows better lighting right on the workpiece.

•6" and 10" toolrests

•Storage tray

•Cord wrap integrated

•3" face plate included

JWL-1220: 12"x 20" WOOD LATHE STOCK NUMBER 708376

Model Number JWL-1220

Net Weight (lbs.): 98

Swing Over Bed (in.): 12

Swing Over Tool Rest Base (in.): 9-1/2

Distance Between Centers (in.): 20

Speeds (RPM): Six, 500 to 3900

Headstock Taper: MT-2

Spindle Nose (in. x TPI): 1 x 8TPI

Tailstock Taper: MT-2

Hole Through Tailstock (in.): 3/8

Ram Travel (in.): 2

Spindle Taper: MT-2

Motor HP: 3/4HP

Motor Phase: 1Ph

Motor Voltage: 115V

Spindle

with

Indexing

Capability

3/4 HP Motor

Quick

Cam

Locks

Live

Center

Cast-Iron

Construction

6" Tool

Rest

Worklight

Chrome

Plated

Handwheel

708376.indd 2 7/3/07 6:42:08 AM
