JMC HDMI2SDI-S Bedienungsanleitung

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

HDMI2SDI-S

Scaling

User Manual

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Content

Feature ...................................................................................3

Front Panel...............................................................................4

Rear Panel................................................................................4

Side Panel ................................................................................5

Button/LED Indicate ....................................................................6

Installation ...............................................................................9

Package Contents .......................................................................9

Specifications.......................................................................... 10

Firmware Upload ...................................................................... 12

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Feature

SDI Supports HD formats :

720p50 & 60

1080i50 & 60

1080p24, 25, 30, 50 & 60

SDI Support 525i & 625i SD D1 format

Auto 3G/HD/SD-SDI detection

One HDMI input source can split to two 3G-SDI displays simultaneously.

Frame rate conversion(1.000/1.001)

External Button Configuration

Firmware is upgradable in the field using the integrated USB port

The converter is Plug-and-Play

Support VESA Mode

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Front Panel

Component

Function

SDI Output Port

From your SDI Display Device plug into

these ports ( Pass Through)

LEDs indicate

The LEDs is indicate Output Format

(SD/HD/3G/HDCP)

Mode Buttons

Select Format/TV Wall/TV Ratio

Rear Panel

Component

Function

Power Jack

The Power adapter plug into here.

HDMI Input Port

From your HDMI Source plug into these

ports

Power/Locked LED

The LEDs is indicate Signal indicate

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Side Panel

Component

Function

USB Connector

Upgrade Firmware/Control Box by PC

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Button/LED Indicate

1. Button Mode:

a. Format Mode:

Chick the button 1, the box will be setting to Output Format Mode and change

Frame Rate by button 2 and 3.

RES

FRAME RATE

FRACTION

By Pass

720x480

60i

59.94i

60p

59.94p

720x576

50i

50p

1280x720

60p

59.94p

50p

1920x1080i

60i

59.94i

50i

1920x1080p

60p

59.94p

50p

30p

29.97p

25p

24p

23.97p

: is default format at change button 1 after.

SD LED

HD LED

3G LED

BY PASS

●

720 x 480

○

●

720 x 576

○

●

○

1280 x 720

○

●

1920 x 1080i

●

○

1920 x 1080p

●

○

●

●: LED ON

○: LED OFF

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

b. TV Wall Mode:

Pull the button 2 , the box will be seting to TV Wall Mode and change viewer

window by button 3.

Turn OFF

Divide

Windows

To 2x2

Divide

Windows

To 3x3

Divide

Windows

To 4x4

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

c. Aspect Ratio Mode: Push Button 3 to change TV Ratio

↓：Display is 4:3

↑：Display is 16:9

2. LED Mode:

a. Output Mode:

Resolution

SD LED

HD LED

3G LED

HDCP LED

NTSC / PAL

●

○

720p / 1080i /

1080 [24p, 25p, 30p]

○

●

○

1080 [50p,60p]

○

●

○

HDCP Content

○

●

b. Input Singal Mode:

POWER/SIGNAL LED

SINGAL LOCKED

●

SIGNAL UN-LOCKED

●

3. FIRMWARE Mode:

Hold on the 3 and 2 button, the display is showed firmware version on display of

left upper.

4. DEFAULT Mode:

Pull all button (1, 2 and 3) at the same time, the box auto reset to default.

FIRMWARE VERSION

0.1.0.1

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Installation

HD2SDI-S installation consists of the following:

1. Disconnect +12DC adaptor to converter.

2. Connect Video Source (HDMI) to the HDMI Connector.

3. Connect SDI Equipment to the BNCs connector

4. Connect the +12DC adaptor to the converter.

Package Contents

The HD2SDI-S package contains the following items:

User Manual x 1

+12 DC Adapter x 1

HD2SDI-S Converter x 1

JMC Systems Engineering AB www.jmc.se +46-8-82 82 70

Specifications

DESCRIPTION

SDI Format

SD-SDI, HD-SDI & 3G-SDI

SDI Transition Rate

2.970Gb/s, 10485Gb/s and 270Mb/s

Audio Support

Stereo 2-Channel

Audio Sample

Auto Ra-sample to 48Khz (For Stereo)

Coaxial Cable Type

RG6/RG59(75Ω)

Cable Equalization

3G: 140m of RG6/ 100m of RG59

HD: 200m of RG6/ 140m of RG59

SD: 400m of RG6/ 280m of RG59

Firmware Updates

Via Mini-USB

Input

1 x HDMI

Output

2 x BNC [SDI]

BNC Connector

3G 75 Ωinter-locked socket

HDMI Connector

TYPE A [19-pin female]

USB Connector

Mini-USB

Bottom

Output Format/TV Wall/TV Ratio

Housing

SECC

Dimension

L:104mm x W:63.3mm xH:26mm

Power Source

Power Adapter: AC 100 ~ 240 V/DC (+6 ~ 15 V)

Operation Temperature

0~50°C [32~114°F]

Storage Temperature

-20~+60°C
