John Lewis Ridley Bedienungsanleitung

John Lewis Partnership

171 Victoria Street

London SW1E 5NN

johnlewis.com

Made in China 08/05/2018

We have taken great care to ensure that this product reaches you in perfect condition.

However, should any parts be damaged or missing please contact the Product Helpline on

(01202) 690945.

This symbol indicates that this product should not be treated as normal household waste

and it should be recycled. John Lewis do not operate instore take back, but as members of the

Distributor Trade Back scheme have funded the development and upgrade of recycling facilities

across the UK. Please take it to your nearest collection facility or for further details contact your

local council or visit www.recycle-more.co.uk.

User manual

Ridley

Floor lamp

Specifications

Max. power: 30W

Voltage: 240V, 50Hz

IP rating: IP20

Weight: 8.4kg

2400 lumen output

Colour temperature:Warm white (3000K)

Please retain these instructions for future reference.

Recommended bulb (included)

1 x 30 Watt energy efficient LED module

1 x 5 Watt energy efficient LED module

This product contains a non-replaceable LED Module. If the LEDs become damaged then the whole

product must be replaced.

When moving or cleaning, always switch off at the mains and allow the module to cool before

handling.

Assembly

Refer to assembly drawings. Carefully unpack the carton, making sure all the parts are present

before assembly.

Step 1

Do not attempt to plug in or use this product until it has been fully assembled. Disconnect from

mains during assembly or maintenance.

Step 2

Remove all packaging from the base, the central tubes and shade. Remove any cable protection

pieces in the ends of the tubes.

Thank you for purchasing this Ridley oor lamp. Please read the instructions carefully before use to

ensure safe and satisfactory operation of this product.

Care instructions

We recommend cleaning with a soft dry cloth. Do not use abrasive materials as these will damage

the nish.

Warnings!

This is a Class 1I product and must NOT be earthed.

Please read these instructions carefully before commencing any work.

Your standard lamp has been packaged as separate parts to prevent damage during transit.

When manoeuvring or assembling this product, it must be lifted from the bottom.

If you are in any doubt, please consult a qualied electrician.

For your safety, always switch off the supply before cleaning or adjusting.

This product is suitable for indoor use only

Parts list Image Qty

Light tting 1

Shade glass 1

Central tube 2

Shade xings 3

Base xings 1

Hex key 1

Spanner 1

Figure 1

Figure 2

Figure 3

Figure 4

Step 3

Fit the glass shade in place by placing the glass over the main light

and xing in place using the screws.

Step 4

Secure the upper tubes to the main light head using the hex key

provided, being aware of cross-threading, and ensuring no cables

are strained or trapped.

Step 5

Screw the two lower tubes into the central control unit, being

aware of cross-threading, and ensuring no cables are strained or

trapped.

Step 6

Fit the lower tubes to the base, by slotting through the plate

and into the base. Gently pull any excess cable through the base.

Secure the tubes in place using the base xings and spanner

provided.

Step 7

Stand the product upright and check the tightness of the joints.

Step 8

Your standard lamp is now ready to use. Plug in to the mains

supply, and switch on using the dimmer switches on the central

panel; the top switch (A) operates the main light, and the bottom

switch (B) operates the reading light.

Figure 5

Parts list
