System 9100 Technical Manual 636.4

Configuration Guides Section

Configuration Guide

Issue Date 0896

Code No. LIT-6364050

XT-9100 Extension Module/XP-910x Expansion Modules Page 3

•

Introduction 3

•

Hardware Configuration 4

•

Model Codes 4

Software Configuration 7

•

XT-9100 Type Settings 7

•

XT-9100 Configuration 9

•

Analog Input 10

•

Digital Input Configuration 15

•

Analog Output Configuration 16

•

Digital Output Configuration 19

•

Download/Upload 21

Appendix 1: SX Tool Item Description and Tables 23

•

General 23

•

Item Address 23

•

Item Type 23

•

Item Tag 24

•

Read/Write Data (R/W) 24

•

Floating Point Numbers 25

•

Item List 25

XT-9100 Configuration Guide

2 Configuration Guides—XT-9100 Configuration Guide

Configuration Guides—XT-9100 Configuration Guide 3

XT-9100 Extension Module/

XP-910x Expansion Modules

The XT-9100 Extension Module and its expansion modules have been

designed to provide additional input and output capacity within Metasys

Networks and specifically for the DX-9100 Extended Digital Controller.

The XT-9100 module provides the communication interface and the

XP modules provide the analog and digital inputs and outputs.

A Supervisory System communicates with an XT-9100 via the N2 Bus or

Bus 91*. Each XT-9100, depending on its expansion module combination,

can have up to 16 inputs/outputs, eight of which may be analog.

The DX-9100 communicates with the XT-9100 via the XT-Bus, and when

the DX-9100 is connected to an N2 Bus (or Bus 91), data from the

XT-9100 is available to a Supervisory System. Up to eight XT-9100

modules can be connected to the XT-Bus. Each XT-9100 provides,

depending on the type of the connected XP expansion modules, either

eight analog points or eight digital points, extending the input/output of a

DX-9100 by up to 64 remote input/outputs. Modules with 16

input/outputs may also be connected, provided that the total number of

remote input/output points on the DX-9100 does not exceed 64.

Configuration of the XT-9100 is achieved by using a personal computer

with GX-9100 Graphic Configuration Software (GX Tool) supplied by

Johnson Controls. When the serial interface of the XT-9100 is connected

directly to the N2 Bus (Bus 91), the GX-9100 will download and upload

configurations over the N2 Bus (Bus 91). When the serial interface of the

XT-9100 is connected to the XT Bus, the GX-9100 will download and

upload configurations via the N2 Bus (Bus 91) connected to the DX-9100

to which the XT-Bus is connected. The DX-9100 retransmits

configuration data to the XT-9100 on its XT-Bus.

XP9102

ADDRESS

A B CA B C

Power

RS485

FUSE

EXP

min

max

XT9100

max

AO7

AO8

min

xt910x

AI5 AI6 V AO7 AO8

24V

COM

+15V

AI1 AI2 AI3 AI4

EXP

Figure 1: XT-9100 Extension Module and XP-910x Expansion Modules

* The term “Bus 91” is not used in North America.

Introduction

4 Configuration Guides—XT-9100 Configuration Guide

For full details of the hardware configuration, refer to the XT-9100

Technical Bulletin (LIT-6364040).

An XT-9100 combined with expansion modules provides the following

configurations, either:

•eight analog inputs/outputs, or

•eight digital inputs/outputs, with digital counters associated with the

digital inputs, or

•eight analog inputs/outputs and eight digital inputs/outputs, or

•sixteen digital inputs/outputs, with digital counters associated with the

digital inputs within the first eight inputs/output points

The extension module address is set with the address switches on the

XT-9100. When connected to a DX-9100 controller, this address must

also be set in the DX-9100 software configuration. The address must be

unique not only on the XT-Bus, but also on the N2 Bus (Bus 91) to which

the DX-9100 is connected.

The XT-9100 must be supplied with a 24 VAC power source. All models

are suitable for 50 Hz or 60 Hz through software configuration.

For the analog inputs and outputs, the input and output type are set by

jumpers on the analog expansion module board. These settings must

comply with the software configuration settings.

Note: When an extension module is configured with 16 inputs/outputs,

the DX-9100 considers the single physical module as two logical

modules, each with eight inputs/outputs. A DX-9100 can

communicate with up to eight logical modules, with a maximum of

64 inputs/outputs.

Table 1: XT/XP/TR Model Codes

XT-9100-8004 Extension Module 24 VAC supply

XP-9102-8004 Expansion Module 6 analog inputs

2 analog outputs

XP-9103-8004 Expansion Module 8 digital outputs (triacs)

XP-9104-8004 Expansion Module 4 digital inputs

4 digital outputs (triacs)

XP-9105-8004 Expansion Module 8 digital inputs

XP-9106-8004 Expansion Module 4 digital outputs (relay)

TR-9100-8001* Transformer, 24V/12 VA Primary: 240 VAC

TR-9100-8002* Transformer, 24V/12 VA Primary: 220 VAC

* TR-9100 is not available in North America.

Hardware

Configuration

Model Codes

Configuration Guides—XT-9100 Configuration Guide 5

XP9103

DO1

DO2

DO3

DO4

DO5

DO6

DO7

DO8

XP9102

ADDRESS

A B CA B C

Power

RS485

FUSE

HOT GND NEUT

EXP

FUSE

min

max

XT9100TR9100

EXP

max

AO7

AO8

min

EXP

Bus Connector (provided)

emtxt-4

DO5 DO6 DO7 DO8

AI5 AI6 V

AO7

AO8

24VC

24V

COM

24V

COM

DO1 DO2 DO3 DO4

+15V

AI1 AI2 AI3 AI4

XT XP1 XP2TR

Figure 2: Typical XT-9100 Configuration

Table 2: XT Configurations

TR Transformer TR-9100 (optional)

XT Processor XT-9100

XP1 Analog

Digital

XP-9102

XP-9103

XP-9104

XP-9105

1 or 2 x XP-9106

(See Note 1.)

(See Notes 2 and 4.)

XP2 Digital XP-9103

XP-9104

XP-9105

1 or 2 x XP-9106

(optional)

(optional) (See Notes 2, 3, and 4.)

Notes:

1. The analog XP-9102 must be placed in position XP1.

2. Two XP-9106 modules are considered as one XP module when installed next to each

other in Position XP1 or XP2. When a single XP-9106 is installed in Position XP1 and

another type of XP module is installed in Position XP2, the total number of I/Os is

restricted to 12.

3. The XP-9106 can only be placed in Position XP2 when Position XP1 is filled by an

analog XP or two XP-9106 modules.

4. The first XP-9106 in position XP1 or XP2 controls points DO1-DO4 and the second

XP-9106 in either position controls points DO5-DO8.

5. Digital modules with counters must be in position XP1.

6 Configuration Guides—XT-9100 Configuration Guide

Configuration Guides—XT-9100 Configuration Guide 7

Software Configuration

Software configuration involves the setting of all the Items of the

extension module to values which correspond to the intended application.

Typically, use the GX Tool to configure a system, and the SX Tool to

troubleshoot. To use these tools, refer to the GX-9100 Software

Configuration Tool for Windows User’s Guide (LIT-6364060) and the

SX-9100 Service Module User’s Guide (LIT-6364070). Proceed in the

following order:

1. Define XT-9100 type settings.

2. Define XT-9100 configuration.

3. Define analog input characteristics.

4. Define digital input characteristics.

5. Define analog output characteristics.

6. Define digital output characteristics.

Via the GX Tool

Select DX-9100 and then Global. Enter the frequency as 50 or 60. The

XT frequency and the DX frequency are both defined here.

Via the SX Tool

Set Bit X1 of Item XTS (RI.69).

X1 = 0 50 Hz power line

X1 = 1 60 Hz power line

Via the GX Tool

First configure an XT Module. Select XTn, then Analog or Digital. Then

select the just configured XTn, XTn, and Data.

To set this flag, at the “Status on comm. fail” (communication failure)

field, enter 0 or 1.

When this bit is set to “0,” the digital outputs are switched off upon a

serial interface failure, and the corresponding Item values are reset to zero.

When set to “1,” the digital outputs hold their current state upon a serial

interface failure.

XT-9100 Type

Settings

Power Line

Frequency

(50 or 60 Hz)

Output

Hold/Reset on

Comm. Failure

Flag

8 Configuration Guides—XT-9100 Configuration Guide

Via the SX Tool

The “Output Hold/Reset on Communication Failure” flag is set at Bit X2

of Item XTS (RI.69).

X2 = 0 Output reset upon communication failure

X2 = 1 Output hold upon communication failure

When communication fails for the period set in this Item, the XT-9100

goes into “communication failure” state, indicated by a blinking power

LED on the front of the module. The default value is 60 seconds.

Via the GX Tool

First configure an XT Module. Select XTn, then Analog or Digital. Then

select the just configured XTn, XTn, and Data. At the “Comm. timeout

(sec)” field, enter the value in seconds.

Via the SX Tool

The “Maximum Time Between Communications” (in seconds) is entered

at Item MTBC (RI.86).

The operational mode of the XT-9100 can be seen at Item OPMO (RI.01)

with following status bits:

X8 = 1 PWR Power Failure. This bit is set when a XT is

powered up or when there is a serial interface

communication failure.

The setting in Item XTS (RI.69) Bit X2 (“Output Hold/Reset on

Communication Failure” flag) is repeated in Item OPMO (RI.01) Bit X7

so that it can be read by the DX-9100 or any other monitoring system.

Via the GX Tool

In order to download the XT-9100 devices it is necessary to enter the

XT addresses. These addresses will also be loaded into the DX-9100.

When performing a download through a DX-9100 Controller, the

controller only downloads the addresses of its own XT set. The

XT address is not stored in the XT-9100 but must be set on the address

switches on the module.

First configure an XT Module. Select XTn, then Analog or Digital. Then

select the just configured XTn, XTn, and Data. At the “Hardware

Address” field, enter the address (1-255) of the XT-9100 module.

Via SX Tool

Refer to the Extension Module Configuration section in the DX-9100

Configuration Guide (LIT-6364030).

Maximum Time

Between

Communications

Operational Mode

(SX Only)

XT Address

Configuration Guides—XT-9100 Configuration Guide 9

Via the GX Tool

The I/O type and map details are automatically generated by the GX-9100

Graphic Configuration Software when all I/O data for extension modules

has been entered. It is then downloaded into the XT-9100 directly or via

the DX-9100 and XT-Bus. (Refer to the Download/Upload section,

further in this document.)

When in the GX Tool, select the XT module, then define it as Analog or

Digital (if Digital, define it as 8 DI, 4DI/4DO, or 8DO). This defines

Module XP1. If an XT has 16 points (XP2 is connected), select the

XT box immediately to the right of the configured module, select

EXP.DIG and define it as 8DI, 4DI/4DO, or 8DO. “EXP” will appear in

the XT box. Then select XT (or EXP) again and define each point in the

selected configuration in the same way as when defining the points in the

DX-9100. The following pages describe how to define each of the points

individually.

Via the SX Tool

Each extension module configuration is defined by the I/O types and

map which are configured in Extension Module Items IOMAP (RI.77),

IOTYP (RI.78), and IOMOD (RI.79).

1. The I/O map (IOMAP) defines which inputs/outputs (in pairs) on the

extension module are used. Each extension module can be defined

with eight used points, which normally reside in the XP1 (first)

Expansion Module (points I/O1-I/O8), defined in bits X1-X4.

When an extension module has an XP2 (second) Expansion Module

with a further eight points, these points must be defined in bits X5-X8.

2. The I/O type (IOTYP) defines which inputs/outputs (in pairs) are

analog and which are digital. As the points on XP2 (if used) must be

digital, only bits X1-X4 can be configured.

3. The I/O mode (IOMOD) defines points as “input” or “output”

(in pairs). Only those points declared as “used” in Item IOMAP will

be monitored or controlled.

The combination of data in the Items IOMAP, IOTYP, and IOMOD

completely defines the configuration of an extension module. When

connected to a DX-9100 Controller, an identical set of data must be

entered into the Item data base in the DX-9100 Controller, so that,

when the DX-9100 and XT-9100 are connected and started up, the

DX-9100 will compare data bases and only send commands to the

extension module if the data is identical, thus avoiding incorrect

control actions.

XT-9100

Configuration

Settings

10 Configuration Guides—XT-9100 Configuration Guide

Note: The data base in the XT-9100 has been designed to accept most

configuration of inputs and outputs. All inputs and outputs

which are physically connected through expansion modules

must be configured, and only those points. If there is a

difference between the physical configuration and the software

configuration, the XT-9100 will signal an error condition to the

DX-9100 (XTnERR).

Each analog input is defined and configured by the following parameters:

•Tag name (optional, GX-only)

•Measurement units (for RTD inputs)

•Enable square root

•Alarm on unfiltered value

•Input signal range

•Alarm limits

•Filter time constant

The GX Tool determines the input signal range with a 2-stage process:

you must first decide if the input is active or passive; the remaining

options depend on this choice. With the SX Tool, this information is

entered into a number of Items.

Via the GX Tool

Select XTn, AIn, then either Active or Passive.

Note: All AI points must be configured even if not connected to a sensor

to enable the generation of a complete IO Map and to ensure

correct operation with the DX-9100 Controller.

Via the GX Tool

The selection of Celsius or Fahrenheit, is set in the Global data of the

DX-9100 (select DX-9100, then Global. At the “Temperature Units”

field, enter “C” for Celsius or “F” for Fahrenheit).

To determine the measurement units of active inputs, select XTn, AIn,

Data, and then enter in the “Measurement Units” field:

0 = None

1 = Temperature (“C” or “F” as entered in Global)

2 = Percent (%)

Note: The units of an active input are not read by the DX-9100

Controller, but are available to any other Supervisory System

which may be connected.

Analog Input

Configuration

AI Input Type:

Measurement

Units

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Johnson Controls Netzwerk-Hardware Handbücher

Johnson Controls

Johnson Controls NAE55 Series Bedienungsanleitung

Johnson Controls

Johnson Controls Metasys Intelligent Fire Network Bedienungsanleitung

Johnson Controls

Johnson Controls CK722 Bedienungsanleitung

Johnson Controls

Johnson Controls IQ WIFI Bedienungsanleitung

Johnson Controls

Johnson Controls Tyco exacqVision 2UA Bedienungsanleitung

Johnson Controls

Johnson Controls NIE55 Series Bedienungsanleitung

Johnson Controls

Johnson Controls S300 Series Handbuch

Johnson Controls

Johnson Controls Metasys NAE55 Bedienungsanleitung

Johnson Controls

Johnson Controls D Series Bedienungsanleitung

Johnson Controls

Johnson Controls EasyIO FW Series Bedienungsanleitung

Johnson Controls

Johnson Controls Facility Explorer Service-Handbuch

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
