Juniper M20 Bedienungsanleitung

M20 Internet Router

PIC Guide

Juniper Networks, Inc.

1194 North Mathilda Avenue

Sunnyvale, California 94089

USA

408-745-2000

www.juniper.net

Part Number: 530-022506-01, Revision 1

This guide provides an overview and description of the Physical Interface Cards (PICs)

supported by the Juniper Networks M20 Internet router. The PICs are described

alphabetically. Table 1 on page 3 lists the PICs supported by the M20 Internet router

by PIC family.

PICs provide the physical connection to various network media types. The PICs are

mounted on Flexible PIC Concentrators (FPCs), which are inserted into a slot in a

router. A PIC typically occupies a single slot on an FPC. PICs receive incoming packets

from the network and transmit outgoing packets to the network. During this process,

each PIC performs framing and high-speed signaling for its media type. Before

transmitting outgoing data packets, the PICs encapsulate the packets received from

the FPCs. Each PIC is equipped with a media-specific ASIC that performs control

functions tailored to the PIC's media type. For complete information about installing

PICs and transceivers, see the PIC and Transceiver Installation Instructions located at

http://www.juniper.net/techpubs/.

Blank PICs resemble other PICs, but do not provide any physical connection or

activity. When a slot is not occupied by a PIC, you must insert a blank PIC to fill the

empty slot and ensure proper cooling of the system.

The M20 router supports the Type 1 FPCs listed in “FPCs Supported”on page 5.

Table 3 on page 6 provides a PIC/FPC compatibility matrix for the current PICs

supported by the M20 router.

For a complete list of end-of-life FPCs and end-of-life Enhanced FPCs for M-series

and T-series routing platforms, see the M-series and T-series Routing Platforms

End-of-Life FPC Guide located at http://www.juniper.net/techpubs/.

2■

M20 Internet Router PIC Guide

Table 1: PICs Supported in the M20 Internet Router

Page

PIC

Slots RequiredFPC Support

First JUNOS

SupportPortsPIC Family and Type

ATM2 IQ

131 slotType 16.14ATM2 DS3 IQ

151 slotType 16.14ATM2 E3 IQ

171 slotType 15.52ATM2 OC3/STM1 IQ

201 slotType 15.51ATM2 OC12/STM4 IQ

Channelized

281 slotType 14.01Channelized OC12

Channelized IQ

221 slotType 15.64Channelized DS3 IQ

241 slotType 15.610Channelized E1 IQ

261 slotType 17.11Channelized OC3 IQ

301 slotType 15.61Channelized OC12 IQ

321 slotType 15.71Channelized STM1 IQ

341 slotType 17.410Channelized T1 IQ

DS3, E1, and T1

361 slotType 13.14DS3

381 slotType 14.14E1

661 slotType 14.14T1

E3 IQ

401 slotType 16.14E3 IQ

Ethernet

461 slotType 14.14Fast Ethernet

461 slotType 15.28Fast Ethernet

461 slotType 15.112Fast Ethernet

491 slotType 16.31Gigabit Ethernet with SFP

Ethernet IQ

511 slotType 16.01Gigabit Ethernet IQ with

SFP

Ethernet IQ2

■3

Table 1: PICs Supported in the M20 Internet Router (continued)

Page

PIC

Slots RequiredFPC Support

First JUNOS

SupportPortsPIC Family and Type

531 slotType 17.6R34Gigabit Ethernet IQ2 with

SFP

Services

81 slotType 16.40Adaptive Services II

101 slotType 17.50Adaptive Services II Layer

2 Services

441 slotType 15.20ES

561 slotType 15.60Link Services

671 slotType 13.30Tunnel Services

Serial

421 slotType 15.62EIA-530

SONET/SDH

571 slotType 13.14SONET/SDH OC3c/STM1

601 slotType 13.11SONET/SDH OC12c/STM4

63Entire FPC slotType 16.11SONET/SDH

OC48c/STM16 with SFP

4■

M20 Internet Router PIC Guide

FPCs Supported

The M20 router supports the Type 1 FPCs listed in Table 2 on page 5. Inserting a combination of PICs with an aggregate

higher than the maximum throughput per FPC is supported, but constitutes oversubscription of the FPC.

Table 2: FPCs Supported by the M20 Router

First JUNOS

Release

Maximum

Throughput per FPC

Maximum Number of

PICs Supported per

FPC

FPC Model NumberFPC Name

7.23.2 Gbps4M20-FPC1-EPEnhanced Plus FPC1

FPCs Supported ■5

FPCs Supported

PIC/FPC Compatibility

Table 3 on page 6 provides a PIC/FPC compatibility matrix for the current PICs supported by the M20 router. The table lists

the first JUNOS release in which the FPC supports the PIC. For example, JUNOS 7.2 is the first release in which the M20-FPC1-EP

supports the ATM2 OC3/STM1 IQ, 2-port PIC.

Table 3: M20 PIC/FPC Compatibility

M20-FPC1-EPNumber of PortsPIC Type

ATM2 IQ PICs

7.24ATM2 DS3 IQ

7.24ATM2 E3 IQ

7.22ATM2 OC3/STM1 IQ

7.21ATM2 OC12/STM4 IQ

Channelized PICs

7.21ChOC12

Channelized IQ PICs

7.24ChDS3 IQ

7.210ChE1 IQ

7.21ChOC3 IQ

7.21ChOC12 IQ

7.21ChSTM1 IQ

7.210ChT1 IQ

T1, DS3, E1, E3 PICs

7.24DS3

7.24E1

7.24T1

E3 IQ PIC

7.24E3 IQ

Ethernet PICs

7.24Fast Ethernet

7.28Fast Ethernet

7.212Fast Ethernet

6■PIC/FPC Compatibility

M20 Internet Router PIC Guide

Table 3: M20 PIC/FPC Compatibility (continued)

M20-FPC1-EPNumber of PortsPIC Type

7.21Gigabit Ethernet, SFP

Ethernet IQ PICs

7.21Gigabit Ethernet IQ, SFP

Ethernet IQ2 PICs

7.6R34Gigabit Ethernet IQ2, SFP

Services PICs

7.20Adaptive Services II

7.5

0Adaptive Services II (AS)

Layer 2 Services

7.20ES

7.20Link Services

7.20Tunnel Services

SONET/SDH PICs

7.24OC3c/STM1

7.21OC12c/STM4

7.21OC48c/STM16, SFP

PIC/FPC Compatibility ■7

PIC/FPC Compatibility

Adaptive Services II PIC

■JUNOS 6.4 and laterSoftware release

■Supports tunnel services. This feature is included with the PIC and does not require an

individual license.

■Individual licenses must be purchased for additional services.

■Power requirement: 0.4 A @ 48 V (19 W)

Description

■Support for up to 2000 service sets

■Active monitoring on up to 1 million flows

■Support for MTUs up to 9192 bytes for Gigabit Ethernet and SONET interfaces

Hardware features

Depending on your JUNOS release and individual licenses, software features for this PIC can

include the features listed in Table 4 on page 8. For more information about the software

features available for services PICs, see the JUNOS Services Interfaces Configuration Guide.

Software features

Status LED, one tricolor:

■Off—PIC is offline and it is safe to remove it from the chassis.

■Green—PIC is operating normally.

■Amber—PIC is initializing.

■Red—PIC has an error or failure and no further harm can be done by removing it from

the chassis.

Application LED, one bicolor:

■Off—Service is not running.

■Green—Service is running under acceptable load.

■Amber—Service is overloaded.

LEDs

Table 4: Adaptive Services PICs Software Features

Adaptive Services

II Layer 2 Services

PIC

Adaptive Services II

PIC

Software Feature

––GRE Key

––GRE dont-fragment

8■Adaptive Services II PIC

M20 Internet Router PIC Guide

Table 4: Adaptive Services PICs Software Features (continued)

–6.4Stateful firewall with packet inspection: detects

SYN attacks, ICMP and UDP floods, and ping of

death attacks

–6.4Network Address Translation (NAT) for IP

addresses

–6.4Port Address Translation (PAT) for port numbers

–6.4IP Security (IPSec) encryption

–7.0Active flow monitoring exports cflowd version

5 and version 8 records

–8.3Active flow monitoring exports version 9

records, based on RFC 3954 (IP v4 templates

only)

––Passive flow monitoring

––Passive flow collection

–8.1Flow-tap

––Dynamic flow capture

–8.3Real-time performance monitoring

7.57.3Link services

7.56.4Tunnel services:

■IP-IP unicast tunneling

■GRE unicast tunneling—Supports GRE

fragmentation

■Protocol Independent Multicast (PIM) sparse

mode unicast tunneling

–6.4Virtual tunnel interface for Layer 3 VPNs

––Layer 2 Tunneling Protocol (L2TP)

7.57.3Voice services:

■Compressed Real-Time Transport Protocol

(CRTP)

–6.4Encapsulations:

■Multilink Frame Relay (MLFR)

■Multilink Point-to-Point Protocol (MLPP)

Adaptive Services II PIC ■9

Adaptive Services II PIC

Adaptive Services II Layer 2 Services PIC

■JUNOS 7.5 and laterSoftware release

■Supports Layer 2 Service package only. Tunnel services are included with the PIC. Other

services require an individual license.

■Power requirement: 0.4 A @ 48 V (19 W)

Description

■Support for up to 2000 service sets

■Support for MTUs up to 9192 bytes for Gigabit Ethernet and SONET interfaces

Hardware features

Depending on your JUNOS release and individual licenses, software features for this PIC can

include the features listed in Table 5 on page 11. For more information about the software

features available for services PICs, see the JUNOS Services Interfaces Configuration Guide.

Software features

Status LED, one tricolor:

■Off—PIC is offline and it is safe to remove it from the chassis.

■Green—PIC is operating normally.

■Amber—PIC is initializing.

■Red—PIC has an error or failure and no further harm can be done by removing it from

the chassis.

Application LED, one bicolor:

■Off—Service is not running.

■Green—Service is running under acceptable load.

■Amber—Service is overloaded.

LEDs

10 ■Adaptive Services II Layer 2 Services PIC

M20 Internet Router PIC Guide
