5.1
DETAIL 5.1
4.1
DETAIL 4.1
CURVATURE AT
BOTTOM OF CAGE
RADIUS OF RING
6.1
d
d
DETAIL 6.1
INNER CAGE FACE
OUTER CAGE FACE
CHAIN RING
(CHAIN NOT SHOWN)
DRIVESIDE / OUTER
CAGE
3x M2.5 x 12mm SHCS
*APPLY BLUE LOCTITE*
0.88 N-m (+/- 0.09 N-m)
4.2
DETAIL 4.2
ENSURE THESE TWO FACES
ON INNER CAGE ARE 'IN-LINE'
WITH TEETH OF CHAINRING
7.1
7.2
AFTER ADJUSTMENT IS COMPLETE,
EQUALLY
TORQUE
'LOCKING-BOLTS' TO
2.00 N-m (+/-
0.20 N-m),
AND CONFIRM ALIGNMENT
+5°
-5°
DETAIL 7.1
ENSURE BOTTOM OF
CAGE IS FLUSH WITH
BOTTOM OF CHAIN
ENSURE REAR OF CAGE
ASSEMBLY IS
0.5-1.0mm
FROM TOP OF CHAIN
RING TEETH
+3°
-3°
DETAIL 7.2
EQUAL DISTANCE
BETWEEN CHAIN
AND CAGE FACES
NO CONTACT
BETWEEN CHAIN
AND CAGE FACES
38T w/ BRAZE-ON CLAMP ADAPTER SHOWN
46T w/ TRUE BRAZE-ON SHOWN
SETUP AND ADJUSTMENT: 4 > 5 > 6 > 7 > 8
5
INSTALL OUTER CAGE
4
ADJUST FOR HEIGHT
ADJUST FOR CHAINLINE DISTANCE
6
CHECK FOR FUNCTION AND BOLT TORQUE
8
ADJUST FOR PITCH AND YAW
7
SET THE HEIGHT OF THE ADAPTER:
'APPROXIMATELY' ALIGN THE CURVATURE AT BOTTOM OF
1.
THE CAGE TO THE RADIUS OF THE RING (SEE DIAGRAM 4.1)
SET 'APPROXIMATE' TOP-DOWN ALIGNMENT OF CAGE TO
2.
THE CHAIN RING (SEE DIAGRAM 4.2)
FINAL ADJUSTMENTS WILL BE MADE AT STEPS #6 - #7
ADJUST FOR CHAINLINE:
SET LATERAL ADJUSTMENT VIA THE COMBINATION OF THE
1.
'LOCKING-BOLTS' AND' BACK-BOLT'
ENSURE EQUAL SPACING BETWEEN THE CHAIN AND THE
2.
INSIDE OF THE INBOARD / OUTBOARD CAGE FACES. (SEE
DIAGRAM 6.1)
d = DISTANCE BETWEEN CAGE FACE AND CHAIN / CHAIN-RING
ADJUST FOR PITCH:
SET PITCH ANGLE VIA THE COMBINATION OF THE 'LOCKING-
1.
BOLTS' AND' BACK-BOLT' MOVEMENT
(MAX ANGLE = +/- 5
)
CONFIRM BOTTOM OF CAGE ASSEMBLY IS FLUSH WITH
•
THE BOTTOM OF THE CHAIN. (SEE DIAGRAM 7.1)
CONFIRM REAR OF CAGE ASSEMBLY IS
0.5-1.0mm
FROM
•
TOP OF CHAIN RING TEETH. (SEE DIAGRAM 7.1)
ADJUST FOR YAW:
SET YAW ANGLE VIA THE COMBINATION OF THE 'LOCKING-
2.
BOLTS' AND' BACK-BOLT' MOVEMENT
(
MAX ANGLE = +/- 3
)
CONFIRM FRONT OF CAGE ASSEMBLY IS EQUIDISTANT
•
FROM CHAIN AND CAGE FACES. (SEE DIAGRAM 7.2)
CONFIRM REAR OF CAGE ASSEMBLY IS NOT CONTACTING
•
CHAIN. (SEE DIAGRAM 7.2)
**IF APPLICABLE, INSTALL CHAIN PRIOR TO CAGE INSTALL**
STEPS TO CHECK FOR FUNCTION AND INSTALLATION INTEGRITY:
SHIFT TO BOTH ENDS OF THE CASSETTE AND CONFIRM
NO CONTACT
BETWEEN CHAIN AND THE CAGE
1.
IF
THERE IS CONTACT
•
CONFIRM STEPS #5-#7
•
IF
THERE IS NO CONTACT
•
PROCEED TO NEXT STEP
•
** CAUTION **
DERAILING TO THE OUTSIDE CAN/WILL DAMAGE THE FINISH OF THE CRANKSET -
USE WITH DISCRETION
BACK-PEDAL AND MANUALLY DERAIL THE CHAIN FROM THE BOTTOM - TO THE INSIDE AND/OR
**OUTSIDE**
OF THE RING
2.
IF
CHAIN SNAGS AND PREVENTS MOVEMENT OF THE CRANKSET
•
CHECK FOR HEIGHT (STEP #4)
•
CHECK FOR PITCH (STEP #7.1)
•
IF
CHAIN IS 'LIFTED' ABOVE THE TEETH AND ALLOWS BACK-PEDALING OF THE CRANKSET
•
PROCEED TO NEXT STEP
•
PEDAL FORWARD TO 'RE-ENGAGE THE' CHAIN ONTO THE CHAIN RING
3.
IF
CHAIN SLIPS BETWEEN THE CAGE AND THE CHAIN RING
•
CONFIRM STEPS #6-#7
•
IF
CHAIN RE-ENGAGES ONTO CHAIN RING AND FORWARD MOVEMENT IS RESTORED
•
PROCEED TO NEXT STEP
•
RE-CHECK THE FOLLOWING:
4.
-CAGE PITCH ANGLE
-CAGE YAW ANGLE
-REAR CAGE DISTANCE TO TOP OF TEETH
IF
MOVEMENT WAS DETECTED (i.e. NO LONGER IN PROPER ADJUSTMENT)
•
REPEAT STEPS #4-#7
•
RE-TORQUE ALL BOLTS IN THE SYSTEM REPEAT FUNCTION TEST
•
IF
NO MOVEMENT IS DETECTED
•
FUNCTION CHECK IS COMPLETE.
•
BOLT TORQUE SPECIFICATIONS:
CLAMP MOUNTING BOLT = 2.00 N-m (+/- 0.20 N-m)
•
BRAZE-ON MOUNTING BOLT = 4.00 N-m (+/- 0.50 N-m)
•
BACK-BOLT = N/A
•
LOCKING-BOLTS = 2.00 N-m (+/- 0.20 N-m)
•
DRIVESIDE CAGE BOLTS (M2.5 SHCS) = 0.45 N-m (+/- 0.09 N-m)
•
K-EDGE CX SINGLE-RING CHAIN GUIDE SPECIFICATIONS:
CHAIN RING SIZE CAPACITY = 38T - 46T
•
CHAINLINE DISTANCE = 45.5mm (+/- 2.50mm)
•
BRAZE-ON MOUNTING BOLT DISTANCE TO BB-AXIS = 133mm (+/-10mm)
•
CHAIN = 11SPD
•
NARROW-WIDE CHAIN RING COMPATIBILITY = YES
•
DESIGN FEATURES:
FEATURES OF THE K-EDGE CX SINGLE-RING CHAIN GUIDE:
MAXIMUM ADJUSTABILITY TO FIT VARYING FRAME GEOMETRY
•
MINIMAL CONTACT DURING NORMAL OPERATION
•
MINIMAL WEIGHT GAIN
•
ENHANCED 'TOP-SIDE' CHAIN GUIDANCE
•
ENHANCED 'TOP-OF-CHAIN CLEARANCE' TO ACCOUNT FOR F.O.D. (FOREIGN OBJECT DEBRIS)
•
ENHANCED MUD-CLEARANCE
•
ENHANCED '
BACK-PEDAL
DERAILMENT PROTECTION'
•
EASE OF INSTALLATION AND ADJUSTMENT
•
SLIM, SLEEK, AND APPEALING DESIGN
•
K13-050 - K-EDGE CX SINGLE RING GUIDE W/ O.L.S.- TECHNICAL INSTRUCTIONS
SUPPORT / CONTACT:
IF PROBLEM(S) STILL PERSIST AFTER TROUBLESHOOTING,
PLEASE CONTACT K-EDGE SUPPORT FOR FURTHER
BE SURE TO INCLUDE YOUR FULL NAME, PHONE NUMBER,
AND K-EDGE PRODUCT PURCHASED.
