Kärcher HD 5 12 Bedienungsanleitung

New Unit Information

New Unit Information 02.2004

HD 5/12

1.514-101

5.905-972

New Unit Information 02.2004

Technicalfeatures HD 5/12

Page 2 / 12

Drive unit

– 2-pole, air-cooled electric motor.

Pump:

– 3-piston axial pump.

– Pistons made from stainless steel, Ø 12mm

(0.472 in), stroke 9.3mm (0.366 in).

– Cylinder head made from brass.

– Swash plate with thrust ball bearing.

– Pressure and suction valve made from

stainless steel and plastic.

– The pressure switch switches off the motor

when the handgun is closed.

– Injector.

– Non-return valve.

– No safety valve.

– No pressure gauge.

– No pressure and flow control valve.

– Water inlet with strainer.

Electrics:

– Unit switch with thermal motor protection.

– Pressure switch.

Cleaning agent:

– Without cleaning agent tank.

– Metering valve on the unit.

– Cleaning agent operation at low pressure.

Accessories:

– Standard gun.

– Curved spray lance.

– Triple nozzle.

New Unit Information 02.2004

HD 5/12 Unit functions

Page 3 / 12

View from the front

1 High-pressure hose

2 Handgun

3 Mains connecting plug

4 Spray lance

5 Wheel

6 Triple nozzle.

7 High-pressure connection

8 Water connection with strainer

9 Inspection window for oil level

10 Front cover

11 Unit switch

12 Retaining screw for front cover

13 Handle,heightadjustable

New Unit Information 02.2004

Unit functions HD 5/12

Page 4 / 12

Rear view

1 Handle,heightadjustable

2 Rear cover

3 Cleaning agent supply hose with filter

4 Wheel

5 Mains connection cable

6 Wheel

7 Cleaning agent metering valve

8 Clamping screw for adjusting handle

height

9 Handgun bracket

New Unit Information 02.2004

HD 5/12 Unit functions

Page 5 / 12

1 Electrical box

2 Unit switch

3 Cleaning agent hose

4 Mains connection cable

5 Cleaning agent connection with non-

return valve

6 High-pressure connection

View from the front, cover removed

7 Overflow valve

8 Pressure switch

9 Water connection with strainer

10 Cylinder head

11 Motor housing

12 Oil reservoir

New Unit Information 02.2004

Unit functions HD 5/12

Page 6 / 12

Electrical box

1 Unit switch

2 Cover

3 Capacitor

4 Connection cable with motor

Electrical box open

– Pull the retainer clips (arrows) outward and

remove the cover (2).

New Unit Information 02.2004

HD 5/12 Unit functions

Page 7 / 12

View from the rear, cover open

1 Rear cover

2 Bore markings

3 Screw holes

4 Clamping screw for adjusting handle

height

5 Mains connection cable

6 Cleaning agent supply hose

7 Cleaning agent metering valve

Rear cover open

– Pull the retainer clips (arrows) outward and

remove the cover (1).

Note:

If the retaining clips have broken repair as

follows:Drillthroughthetwoboremarkings

(2)inthecoverwithaØ5mmbit.Thecover

(1) can then be mounted with two screws

M5x20(7.303-108)inthescrewholes(3).

New Unit Information 02.2004

Unit functions HD 5/12

Page 8 / 12

View from below

1 High-pressure connection

2 Pressure switch

3 Cylinder head bolt

4 Suction cover

5 Cylinder head

6 Water connection with strainer

New Unit Information 02.2004

HD 5/12 Unit functions

Page 9 / 12

Motor

45789 11 12 13

1 Pressure switch

2 Pressure valve

3 Cleaning agent suction hose connection

4 High-pressure seal

5 Low-pressure seal

6 Oil seal

7 Piston

8 Swash plate with thrust ball bearing

9 Motor bearings

10 Shaft seal

123

610

11 Motor winding (stator)

12 Magnet (rotor)

13 Motor bearings

14 Fan wheel

15 Motor drive shaft

16 Motor housing

17 Piston housing

18 Water connection

19 Suction valve

20 Cylinder head

New Unit Information 02.2004

Unit functions HD 5/12

Page 10 / 12

1 Retainingplate

2 Pressure valve

3 Retainingplug

4 Non-return valve

5 Spring

6 Ball

7 Cleaning agent hose connection

8 Injector

9 High-pressure connection

10 Cylinder head

Cylinder head

11 Connection bore (pump pressure)

12 Connection bore (dynamic pressure)

13 Screw plug

14 Connection bore to pressure switch (only

indicated here)

15 Overflow valve

16 Valve seat

17 Water connection

18 Suction valves

19 Cylinder head screws

20 Piston

123 23 2 3

20 13

1516 14
