Kettler TX1 Bedienungsanleitung

VERSO by Kettler™

TX1

Item# 7882-090 and Item # 7882-099 (230v)

TX3

Item# 7883-090 and Item# 7883-099 (230v)

Foldable Treadmill Owner’s Manual

Retain this owner’s manual for future reference.

Read and follow all instructions in this owner’s manual. Version B

TX3 #7882-090 & 7883-099

TX1 #7882-090 & 7882-099

KETTLER International Inc.

1355 London Bridge Rd.

Virginia Beach, VA 23453

Office Phone: 757-427-2400

Office Fax: 757-427-0183

Email: info@kettlerusa.com

Parts & Service Department:

Phone: 866-804-0440

Email: parts@kettlerusa.com

7883-090 & 7883-099

Version C

Owner’s Manual

TX1 INTRODUCTION:

Console with 5 LED windows

Water bottle holder and

accessory holder built into

the console.

Wide side landing to place

your feet before and after

your workout, or anytime

you feel like a rest during

the workout.

Running

belt

Safety key

–

treadmill will not

activate unless the safety key

is secured in place.

Motor cover

Horizontal bar with

foam grip

Handle bar with

foam grip

Upright post

Patented folding

lock release

Running belt adjustment to

adjust belt tension or to

center the running belt

Contact heart rate hand sensors

for quick check of your pulse.

Owner’s Manual

KEY FEATURES:

Congratulations on choosing a state-of-the-art treadmill.

You have taken the first step to a healthier and more rewarding lifestyle.

This treadmill has been especially designed to give you reliable performance and enjoyable

workouts in the comfort of your home. Please find below the features and benefits of this

treadmill.

Compact frame to take up less space and 78-degree-fold design is better for space saving.

The base frame is hidden below the main frame to maximize the running surface size.

Gas assisted lift makes folding and unfolding of the deck safe and easy.

The folding lock release mechanism is located at the end of the deck so that when folded,

only adults can access the release.

Built-in wireless pulse receiver compatible with Polar® and CardioSport ® chest straps to

monitor your heart rate during exercise. Wireless chest strap transmitter is optional.

Low impact design with cushions so that your joints are protected against injury.

Self-centering belt alignment helps to keep the running belt always tracked correctly in the

center.

CAUTION!

Before beginning any

exercise program,

always consult your

physician. If you

experience chest pains,

nausea, dizziness or

shortness of breath,

STOPexercising and

consult your physician

before continuing.

TX3 INTRODUCTION:

Console with text messages makes

customizing your workout easily.

Big LED and dot matrix display

windows for real time feed back of

all workout stats.

Safety key

–

treadmill will not

activate unless the safety key

is secured in place.

Contact heart rate hand sensors

for quick check of your pulse.

Owner’s Manual

KEY FEATURES:

Congratulations on choosing a state-of-the-art treadmill.

You have taken the first step to a healthier and more rewarding lifestyle.

This treadmill has been designed to provide you with reliable performance and enjoyable

workouts in the comfort of your home. Please find below the features and benefits of this

treadmill.

Compact frame to takes up less space and 78-degree-fold design is better for saving space.

The base frame is hidden below the main frame to maximize the running surface size.

CAUTION!

Before beginning any

exercise program,

always consult your

physician. If you

experience chest pains,

nausea, dizziness or

shortness of breath,

STOPexercising and

consult your physician

before continuing.

Horizontal bar with foam grip

Owner’s Manual

Gas assisted lift makes folding and unfolding of the deck safe and easy.

The folding lock release mechanism is located at the end of the deck so that when folded,

only adults can access the release.

Wireless pulse receiver compatible with Polar® and CardioSport® chest straps to monitor

your heart rate during exercise.

Low impact design with cushions so that your joints are protected against injury.

Self-centering belt alignment so that the running belt is always tracked correctly in the center.

SPECIAL FEATURES:

Model # TX3

Special

features

Message instructions

Direct speed control

Speed and elevation

adjust buttons at the

handlebar

Service notice

Extended handlebar

Back cover

TABLE OF CONTENTS:

Owner’s Manual

I. IMPORTANT SAFETY PRECAUTIONS……..……………………….……. 6

Grounding Instructions

Electrical Safety

Mechanical Safety

Appropriate Attire

Children and Pets

II. SETTING UP YOUR TREADMILL ……………………………………….…. 8

Placement in Your Home

Leveling the Base

Use Dedicated Circuit

III. HANDLING YOUR TREADMILL……………………….……………………. 9

Folding and Unfolding the Treadmill

Moving the Treadmill

IV. OPERATING THE TREADMILL……………………………………………… 10

Turn Power on

Safety Tether Key and Clip

Getting on and off the Treadmill

VI. OPERATING THE CONSOLE TX1…………………………………………

OPERATING THE CONSOLETX3………………………………………… 11

VII. EXERCISE TIPS AND GUIDELINES……………………………………….. 26

Stretch

Warm Up

Cool Down

How Often

How Long

How Hard

Target Heart Rate

VIII. MAINTENANCE…..………………………………………………………………. 28

Cleaning

Running Belt Centering Adjustment

Running Belt Tension Adjustment

Lubricating the Deck

IX. TROUBLE SHOOTING ………………………………………………………... 30

When to Call for Help

Trouble Shooting Guide

X. PART DESCRIPTION………………………………………………..…………. 31

XI.

XII. ASSEMBLY INSTRUCTION……………………………………….……

WARRANTY…………………………………………………………………..…... 32

XIII.

XIV. TX1 110V / 230V PART LIST………………………………………………….

TX3 110V / 230V PART LIST …………………………………………..………

Owner’s Manual

I.IMPORTANT SAFETY PRECAUTIONS:

When using an electrical product, basic precautions should always be followed. Read all

instructions before using this treadmill.

GROUNDING INSTRUCTIONS

This product must be grounded! If treadmill should malfunction or break down, grounding

provides a path of least resistance for electrical current to reduce the risk of electrical shock.

This product is equipped with a cord having an equipment-grounding conductor and a grounding

plug. This plug must be connected to an appropriate outlet that is properly installed and

grounded in accordance with local codes and ordinances.

DANGER!

Improper connection of the equipment-grounding conductor can result in a risk of electrical shock.

Check with a qualified electrician or service technician if you are in doubt as to whether the

product is properly grounded. Do not modify the plug provided with the product – if it will not fit

the outlet, have a proper outlet installed by a qualified electrician.

ELECTRICAL SAFETY

To reduce the risk of burns, fire, electrical shock or injury to persons, take the following

precautions.

DO NOT leave the treadmill unattended at any time when plugged in. Unplug the treadmill

from the power source when it is not in use.

DO NOT use the treadmill if the unit is wet or the plug or cable is damaged or the treadmill is

not working properly. DO NOT use damaged or defective equipment. Keep equipment

out of use until unit is repaired by trained technician.

Keep the power cable and plug away from heated surfaces.

NEVER place the power cord under carpeting or have any object on top of the power cord.

ONLY use the power cord provided with this treadmill.

To disconnect, turn the switch to the off position, then remove the plug from the outlet.

This exercise equipment is designed and built for optimum safety for the home use. However,

certain precautions always apply whenever you operate any exercise equipment. Be sure to

read the entire manual before assembly and operation of this machine. Also, please note the

following safety precautions.

WARNING!

Connect this unit to a

properly grounded

outlet only.

CAUTION!

STOPyour workout

immediately if you

feel any pain or

abnormal symptoms

and consult your

Owner’s Manual

MECHANICAL SAFETY

Before you start exercise, make sure the unit functions correctly. To maintain the safety level

of the exercise equipment, DO NOT use a faulty device.

Replace defective components immediately and/or keep the equipment out of use until repair.

Inspect the equipment prior to exercising to ensure that all nuts and bolts are fully tightened

before each use.

DO NOT use attachments not recommended by the manufacturer.

NEVER drop or insert any object into any opening.

ONLY one person may use the treadmill at a time.

NEVER activate the speed when someone else is standing on the treadmill.

APPROPRIATE ATTIRE

Always wear appropriate clothing. DO NOT wear clothing that might catch on any

part of the treadmill.

Always wear non-slippery shoes during workout with the treadmill. DO NOT wear

shoes with heels or leather soles. Check the soles of your shoes and remove any dirt and

embedded stones.

CHILDREN AND PETS

Most exercise equipment is not recommended for use by young children.

Children should not use the equipment unless they are under constant adult supervision.

To ensure safety, keep young children off the treadmill at all times.

■Exercise equipments have many moving parts. In the interest of safety, keep others

(especially children and pets) at a safe distance while you exercise.

Owner’s Manual

II. SETTING UP YOUR TREADMILL:

PLACEMENT IN YOUR HOME

To make exercise a desirable daily activity for you, the treadmill should be placed in a

comfortable and convenient setting. This treadmill is designed to use a minimal amount

of floor space and to fit nicely in your home.

zDO NOT place the treadmill outdoors.

zDO NOT place the treadmill near water or in high moisture content environment.

zMake sure power cord is not in the path of heavy traffic.

zIf your room is carpeted, check the clearance to make sure there is enough space

between the carpet fiber and the treadmill deck. If you are uncertain, it is best to

place a mat beneath your treadmill.

zLocate the treadmill at least 4 feet from walls or furniture.

zAllow a safety area of 5 feet X 3 feet behind the treadmill so that you can easily get

on and off the treadmill without being trapped during an emergency.

Occasionally after extended use you will find a fine black dust below your treadmill. This is

normal wear and DOES NOT mean there is anything wrong with your treadmill. This dust can

be easily removed with a vacuum cleaner. If you wish to prevent this dust from getting on your

floor or carpet, place a mat beneath your treadmill.

LEVELING THE BASE

It is important that you place the treadmill on a firm level surface.

Check the treadmill to ensure the frame is level once you have moved the treadmill into

the position of your choice.

USE DEDICATED CIRCUIT

The outlet selected should be a dedicated circuit. It is particularly important that NO

sensitive electrical equipments, such as computer or TV, share the same circuit.

CAUTION!

Make sure the

running deck is level

to the ground.

If the deck is

positioned on uneven

surface, it would

cause premature

damage to the

electronic system.

Owner’s Manual

III. HANDLING YOUR TREADMILL:

FOLDING THE TREADMILL

Folding and unfolding of this treadmill is made easy with the assistance of gas shock.After the

treadmill has come to a complete stop, it is important to make sure the elevation is lowered all

the way to the lowest level before folding the treadmill. The display console will indicate “0%

elevation” in the lower left window when positioned at the lowest level. With caution, fold up the

deck slowly with both hands. Fold the deck vertically upright until you hear a click, then the

folded deck is locked in place. Please note that if you failed to lower the elevation to the lowest

level (0% elevation) then the folding safety lock will not click nor lock in place. Be certain the fold

lock clicks and locks in place,

UNFOLDING THE TREADMILL

Pull out the lock pin on the upright post (L) with your left hand. At the same time, press the

deck slowly with right hand. Use both hands to bring the deck slowly to the ground. As the

deck gets closer to the ground, it will drop at a faster rate and feel heavier. Please handle with

caution.

MOVING THE TREADMILL

This treadmill is easy to move around safely.

To move the treadmill:

1. Turn power switch off.

2. Unplug the power cord.

3. Make sure the deck is at 0% grade elevation.

4. Fold the treadmill and make sure lock is engaged. You should hear a click to indicate

positive engagement.

5. Simply roll the treadmill on four wheels to the desired location.

STORING THE TREADMILL

For safety precaution, especially when you have children in the house, we recommend that you

follow these steps to keep the treadmill out of potential harm.

1. Turn off the power switch when you have finished workout.

2. Disconnect the plug from the wall socket.

3. Remove the safety tether key and store out of reach of children.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kettler Tretmühle Handbücher

Kettler

Kettler Pacer Bedienungsanleitung

Kettler

Kettler SPRINTER 5 07880-2 Series Bedienungsanleitung

Kettler

Kettler ALPHA RUN 600 Bedienungsanleitung

Kettler

Kettler GYMAHOME TRACK S6 Bedienungsanleitung

Kettler

Kettler Marathon TX 1 Bedienungsanleitung

Kettler

Kettler GYMAHOME SPRINTER 6 Bedienungsanleitung

Kettler

Kettler TRACK S6 Bedienungsanleitung

Kettler

Kettler Marathon TX 5 Stücklistenhandbuch

Kettler

Kettler TRACK EXPERIENCE Bedienungsanleitung

Kettler

Kettler Marathon TX 5 Bedienungsanleitung

Kettler

Kettler 07885-600 Stücklistenhandbuch

Kettler

Kettler ALPHA RUN 200 Bedienungsanleitung

Kettler

Kettler Marathon TX2 Stücklistenhandbuch

Kettler

Kettler Berlin S2 Bedienungsanleitung

Kettler

Kettler ALPHA RUN 400 Bedienungsanleitung

Kettler

Kettler TRACK SC Bedienungsanleitung

Kettler

Kettler ALPHA RUN 800 Bedienungsanleitung

Kettler

Kettler TRACK-5 Bedienungsanleitung

Kettler

Kettler Track-3 Bedienungsanleitung

Kettler

Kettler RUN-7 Bedienungsanleitung

Kettler

Kettler Olympic Bedienungsanleitung

Kettler

Kettler Track Performance 07885-300 Bedienungsanleitung

Kettler

Kettler MARATHON HS Bedienungsanleitung

Kettler

Kettler TRACK S10 Installationsanleitung

Beliebte Tretmühle Handbücher anderer Marken

Treadly

Treadly TREADLY 2 Bedienungsanleitung

HEALTH ONE

HEALTH ONE Walk Ro Bedienungsanleitung

NordicTrack

NordicTrack NTL12941 Bedienungsanleitung

NordicTrack

NordicTrack T7.5 S Bedienungsanleitung

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Bedienungsanleitung

Merax

Merax MS282992 Bedienungsanleitung

FYTTER

FYTTER RU-2SX Bedienungsanleitung

Precor

Precor 903 Bedienungsanleitung

FitLogic

FitLogic freewill d225 Bedienungsanleitung

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Bedienungsanleitung

Horizon Fitness

Horizon Fitness Adventure 5 Plus Bedienungsanleitung

Stamia

Stamia InMotion II Bedienungsanleitung

Smooth Fitness

Smooth Fitness EVO 3i Bedienungsanleitung

NordicTrack

NordicTrack NETL81810.0 Bedienungsanleitung

Schwinn

Schwinn 830/Journey 8.0 Bedienungsanleitung

Keys Fitness

Keys Fitness HealthTrainer HT-740T Bedienungsanleitung

Spirit

Spirit XT8 Bedienungsanleitung

NordicTrack

NordicTrack T 14.0 Treadmill Bedienungsanleitung
