King Industrial KC-895LS Bedienungsanleitung

INSTRUCTI N MANUAL

ODEL: KC-895LS

8” L W SPEED BENCH GRINDER

WITH LAMP

09/2016

2-YEAR

LI ITED WARRANTY

FOR THIS 8” BENCH GRINDER

KING CANADA T LS

OFFERS A 2-YEAR LI ITED WARRANTY

FOR CO ERCIAL USE.

PR F F PURCHASE

Please keep your dated proof of purchase for warranty and servicing purposes.

REPLACEMENT PARTS

Replacement parts for this product are available at our authorized King Canada service centers across Canada.

LIMITED T L WARRANTY

King Canada makes every effort to ensure that this product meets high quality and durability standards. King Canada warrants to the

original retail consumer a 2-year limited warranty as of the date the product was purchased at retail and that each product is free from

defects in materials. Warranty does not apply to defects due directly or indirectly to misuse, abuse, normal wear and tear, negligence or

accidents, repairs done by an unauthorized service center, alterations and lack of maintenance. King Canada shall in no event be liable

for death, injuries to persons or property or for incidental, special or consequential damages arising from the use of our products.

To take advantage of this limited warranty, return the product at your expense together with your dated proof of purshase to an authorized

King Canada service center. Contact your retailer or visit our web site at www.kingcanada.com for an updated listing of our authorized

service centers. In cooperation with our authorized serviced center, King Canada will either repair or replace the product if any part or

parts covered under this warranty which examination proves to be defective in workmanship or material during the warranty period.

N TE T USER

This instruction manual is meant to serve as a guide only. Specifications and references are subject to change without prior notice.

PARTS DIAGRAM & PARTS LISTS

Refer to the Parts section of the King Canada web site for the most updated parts diagram and parts list.

KING CANADA INC. D RVAL, QUÉBEC, CANADA H9P 2Y4

www.kingcanada.com

WARRANTY INF RMATI N

GENERAL SAFETY INSTRUCTI NS

F R P WER T LS

1. KN W Y UR T L

Read and understand the owners manual and labels affixed to

the tool. Learn its application and limitations as well as its spe-

cific potential hazards.

2. GR UND THE T L.

This tool is equipped with an approved 3-conductor cord and a

3-prong grounding type plug to fit the proper grounding type re-

ceptacle. The green conductor in the cord is the grounding wire.

NEVER connect the green wire to a live terminal.

3. KEEP GUARDS IN PLACE.

Keep in good working order, properly adjusted and aligned.

4. REM VE ADJUSTING KEYS AND WRENCHES.

Form habit of checking to see that keys and adjusting

wrenches are removed from tool before turning it on.

5. KEEP W RK AREA CLEAN.

Cluttered areas and benches invite accidents. ake sure the

floor is clean and not slippery due to wax and sawdust build-

up.

6. AV ID DANGER US ENVIR NMENT.

Don’t use power tools in damp or wet locations or expose them

to rain. Keep work area well lit and provide adequate surround-

ing work space.

7. KEEP CHILDREN AWAY.

All visitors should be kept a safe distance from work area.

8. MAKE W RKSH P CHILD-PR F.

-with padlocks, master switches or by removing starter keys.

9. USE PR PER SPEED.

A tool will do a better and safer job when operated at the

proper speed.

10. USE RIGHT T L.

Don’t force the tool or the attachment to do a job for which it

was not designed.

11. WEAR PR PER APPAREL.

Do not wear loose clothing, gloves, neckties or jewelry (rings,

watch) because they could get caught in moving parts. Non-slip

footwear is recommended. Wear protective hair covering to

contain long hair. Roll up long sleeves above the elbows.

12. ALWAYS WEAR SAFETY GLASSES.

Always wear safety glasses (ANSI Z87.1). Everyday eyeglasses

only have impact resistant lenses, thet are N T safety glasses.

Also use a face or dust mask if operation is dusty.

13. D N’T VERREACH.

Keep proper footing and balance at all times.

14. MAINTAIN T L WITH CARE.

Keep tools sharp and clean for best and safest performance.

Follow instructions for lubricating and changing accessories.

15. DISC NNECT T LS.

Before servicing, when changing accessories or attachments.

16. AV ID ACCIDENTAL STARTING.

ake sure the switch is ‘’OFF’’ before plugging in.

17. USE REC MMENDED ACCESS RIES.

Consult the manual for recommended accessories. Follow the

instructions that accompany the accessories. The use of im-

proper accessories may cause hazards.

18. NEVER STAND N T L.

Serious injury could occur if the tool tips over. Do not store ma-

terials such that it is necessary to stand on the tool to reach

them.

19. CHECK DAMAGED PARTS.

Before further use of the tool, a guard or other parts that are

damaged should be carefully checked to ensure that they will

operate pro- perly and perform their intended function. Check for

alignment of moving parts, breakage of parts, mounting, and any

other conditions that may affect its operation. A guard or other

parts that are damaged should be properly repaired or replaced.

20. NEVER LEAVE MACHINE RUNNING

UNATTENDED.

Turn power ‘’OFF’’. Don’t leave any tool running until it comes

to a complete stop.

SPECIFIC SAFETY INSTRUCTI NS

F R Y UR BENCH GRINDER

1. EYE PR TECTI N.

Grinding ejects small particles at a high rate of speed. ALWAYS

wear safety glasses when using this machine.

2. M UNTING T BENCH/STAND.

An unsecured grinder may become dangerously out of control dur-

ing operation. ake sure grinder is FIR LY secured to a

bench/stand before use.

3. WHEEL SPEED RATING.

Grinding wheels operated at a faster speed than rated may break

or fly apart. Before mounting a new wheel, be sure the wheel RP

rating is equal or higher than the speed of the grinder.

4. WHEEL FLANGES.

Only use the flanges included with the grinder when mounting

wheels. Other flanges may not properly secure the wheel and

cause an accident.

5. RING TEST.

Perform a "ring test" or “resonate test” on grinding wheels before

installation to ensure that they are safe to use. Tap the grinding

wheel and listen for a “ringing tone”, if you hear a thud and no ring-

ing tone the grinding wheel is not safe to use. A wheel that does

not pass the ring test may break or fly apart during operation.

6. STARTING GRINDER.

If a wheel is damaged, it will usually fly apart shortly after start-up.

To protect yourself, always stand to the side of the grinder when

turning it ON and allow it to run a full minute before standing in

front of it.

7. LUNG PR TECTI N.

Grinding produces hazardous dust, which may cause longterm

respiratory problems. Always wear a NIOSH –approved dust mask

or respirator when grinding.

8. SIDE GRINDING.

Do not grind on the side of the wheel. The wheels provided are

not designed for side grinding. Grinding on the side greatly

stresses the wheel and may cause it to shatter.

9. T P GRINDING.

Grinding on the top of grinding wheels greatly increases the risk

of workpiece kickback. Always grind on the downward part of the

wheel.

10. HAND/WHEEL C NTACT.

Grinding wheels can remove a lot of skin fast. Keep a firm grip

on the workpiece and position your hands a safe distance away

when grinding. DO NOT wear gloves as they may get caught in

the grinding wheel and cause even more serious injuries.

11. T L REST P SITI N.

If the tool rest is too far away from the wheel, the workpiece may

be pulled down, causing loss of control and pulling your hand into

the grinding wheel. Keep the tool rest within 1⁄8” from the grinding

wheel when operating.

12. CRACKED WHEEL.

Cracked wheels may break and fly apart during operation. Re-

place cracked wheels immediately!

13. WEAR THE PR PER PR TECTIVE CL THING.

Particles flying off of a grinding wheel will be traveling very fast,

prepare yourself for this. Wear safety glasses/face shield, a dust

mask, earplugs, a leather apron, and heavy leather boots.

14. GUARDS.

ake sure all guards are in place.

15. SPARKS.

Remember that grinding often produces sparks. Do not allow

anyone to stand in the path of the sparks. DO NOT grind near

flammable materials.

16. MAINTENANCE.

aintain proper care of your wheels.

17. SUPP RT W RKPIECE.

Grasp the workpiece firmly and properly support it on the tool

rest during grinding. aintain even pressure and control of the

workpiece when grinding.

18. C NCENTRATE.

Concentrate on the task at hand. STOP grinding if you are dis-

tracted.

19. GRINDING.

Do not grind workpieces that are heavier than the wheel itself.

This stresses the wheel. In these cases use a handheld grinder

instead.

ELECTRICAL INF RMATI N

WARNING!

ALL ELECTRICAL CONNECTIONS UST BE DONE BY A QUALIFIED ELECTRICIAN. FAILURE TO CO PLY AY RESULT IN SE-

RIOUS INJURY! ALL ADJUST ENTS OR REPAIRS UST BE DONE WITH THE ACHINE DISCONNECTED FRO THE POWER

SOURCE. FAILURE TO CO PLY AY RESULT IN SERIOUS INJURY!

P WER SUPPLY

WARNING: YOUR BENCH GRINDER UST BE CONNECTED TO A 110V-

120V, 15-A P CIRCUIT BREAKER. FAILURE TO CONNECT IN THIS WAY

CAN RESULT IN INJURY FRO SHOCK OR FIRE.

GR UNDING

This Bench Grinder must be grounded. If it should malfunction or breakdown,

grounding provides a path of least resistance for electric current, to reduce

the risk of electric shock. This Bench Grinder is equipped with a cord having

an equipment-grounding conductor and grounding plug. The plug must be

plugged into an appropriate outlet that is properly installed and grounded in

accordance with all local codes and ordinances.

Your Bench Grinder must be properly grounded. Not all outlets are properly

grounded. If you are not sure if your outlet is properly grounded, have it

checked by a qualified electrician.

WARNING: TO AINTAIN PROPER GROUNDING OF YOUR BENCH

GRINDER, DO NOT RE OVE OR ALTER THE GROUNDING PRONG IN

ANY ANNER.

WARNING: IF NOT PROPERLY GROUNDED, THIS BENCH GRINDER

CAN CAUSE ELECTRICAL SHOCK, PARTICULARLY WHEN USED IN

DA P LOCATIONS. TO AVOID SHOCK OR FIRE, IF THE POWER CORD

IS WORN OR DA AGED IN ANY WAY, HAVE IT REPLACED I EDI-

ATELY.

110V-120V PERATI N

As received from the factory, your Bench Grinder is ready to run for 110V-

120V operation. This Bench Grinder is intended for use on a circuit that has

an outlet and a plug which looks like the one illustrated in Fig.1.

WARNING: DO NOT USE A TWO-PRONG ADAPTOR FOR THEY ARE NOT

IN ACCORDANCE WITH LOCAL CODES AND ORDINANCES. NEVER USE

IN CANADA.

EXTENSI N C RDS

The use of any extension cord will cause some loss of power. Use the chart

in Fig.2 to determine the minimum wire size (A.W.G-American Wire Gauge)

extension cord. Use only 3-wire extension cords which have 3-prong ground-

ing type plugs and 3-hole receptacles which accept the tool’s plug.

For circuits that are further away from the electrical circuit box, the wire size

must be increased proportionately in order to deliver ample voltage to the

Bench Grinder motor. Refer to Fig.2 for wire length and size.

SAFETY SWITCH

This machine is supplied with a safety switch (A) Fig.3 equipped with a re-

movable safety key (B). To turn the machine ON make sure the yellow safety

key is inserted and pull the switch up, to the ON position. To turn the machine

OFF push the switch to the OFF position. To prevent unauthorized use of

your machine remove the safety key and store it in a secure location.

FIGURE 1

FIGURE 2

PR PERLY GR UNDED UTLET

CURRENT CARRYING PR NGS

GR UNDING PR NG

Tool’s

Amperage

Rating

3-6

6-8

8-10

10-12

12-16

Cord Size in A.W.G.

Cord Length in Feet

25 50 100 150

18 16 16 14

18 16 14 12

14 12 - -

FIGURE 3

GETTING T KN W

Y UR 8” BENCH GRINDER

Getting to know your 8” Low Speed

Bench Grinder

1) Adjustable eye shield (clear)

2) Grinding wheel guard

3) Work lamp ( ax. 40 W bulb)

4) Adjustable eye shield (magnifying)

5) 8” Grinding wheel (60 grit)

6) Grinding wheel guard

7) Tool rest

8) Tool rest bracket and lock knob (right)

9) Switch with safety key

10) Base with rubber feet

11) Tool rest bracket and lock knob (left)

12) Notched tool rest

13) 8” Grinding wheel (120 grit)

14) Diamond wheel dressing tool

Specifications

ODEL KC-895LS

Wheel size 8” x 1”

Arbor size 5/8”

otor 1/2 HP, 3 Amp.

RP 1,750

Voltage 120V, 1 phase, 60 Hz

Assembled dimensions (LxWxH) / weight 14-1/8” x 11-1/2” x 17” / 35 lbs

Packaging dimensions (LxWxH) / weight 21-1/8” x 12-3/4” x 10-7/8”/ 38 lbs

ASSEMBLY

Installing spark guards to wheel guards

1. Install the spark guard (A) Fig.4 to the front surface of the wheel guard (B)

using a pan head screw, spring washer and washer (C). Repeat for the other

side.

2. Adjust both spark guards (A) Fig.4 until they are 1/16” away from the grinding

wheel (D). Firmly tighten the pan head screws. As the grinding wheels are

worn down, re-adjust the spark guards to maintain the 1/16” distance from

the wheel.

Installing eye shields to wheel guards

1. Attach the eye shield (A) Fig.5 to the eye shield rod (B) using a carriage bolt

and hex. nut (C). Repeat for the other side.

2. Attach the curved end of the eye shield rod (B) Fig.5 to the grinding wheel

guard (D) using a hex. bolt (E), washer, clamp bracket (F). Screw the hex bolt

(E) into the threaded hole on the inside of the grinding wheel guard (D).

3. Secure the eye shield in place by tightening the hex. bolt (E) Fig.5 and car-

riage bolt and hex. nut (C).

Installing tool rests to wheel guards

The bench grinder comes with two adjustable tool rests which can be tilted de-

pending on the angle of grinding required. The left tool rest has a groove to

allow for sharpening drill bits, and the right tool rest is completely flat.

1. Install the right side tool rest support (A) Fig.6 to the grinding wheel guard (B)

using a carriage bolt, washer, spring washer and lock knob (C).

2. The lower slot on the tool rest support (A) Fig.6 fits around the small post (D)

that sticks out from the grinding wheel guard (B). The upper slot is used to

position the carriage bolt, washer, spring washer and lock knob.

3. Install the tool rest (A) Fig.7 to the tool rest support (B) with a washer and

lock knob (C) as shown.

4. Adjust the tool rest (A) Fig.7 to ensure the inner edge is 1/16” away from the

grinding wheel.

5. Repeat for the opposite left side tool rest.

FIGURE 4

FIGURE 5

FIGURE 6

FIGURE 7

ASSEMBLY & PERATI N

Mounting the bench grinder

This bench grinder comes with 2 mounting holes in its base. For safety reasons it is highly recommended to secure the bench grinder onto a solid

work surface, or stand. ( ounting hardware and stand not included.)

perating the bench grinder

The bench grinder is designed for hand held grinding, sharpening, and cleaning operations. ALWAYS WEAR EYE PR TECTI N! Hot sparks

are produced during grinding operations.

1. ake sure the switch is in the "OFF" position.

2. ake sure the spark guards and tool rests are set 1/16” from the grinding wheels. Before starting the grinder, turn the grinding wheel by hand

one full turn to make certain the wheels to do not come into contact with the spark guards or tools rests.

3. Stand to the side of the bench grinder and plug in the power cord into the correct power source.

4. Remain to the side of the bench grinder and lift the switch to the "ON" position.

5. Allow the grinding wheels to come up to a steady speed for at least one minute.

6. Adjust the eye shields as needed and place the workpiece on the appropriate tool rest for the desired operation.

7. Slowly move the workpiece towards the grinding wheel until it lightly touches. ove the workpiece back and forth across the front surface of the

grinding wheel removing the amount of material desired. NEVER GRIND N THE SIDES F THE GRINDING WHEELS.

8. When finished grinding turn off the machine by lowering the switch to the "OFF" position. CAUTI N: It will take a few minutes for the grinding

wheels to come to a complete stop.

Both wire wheels and buffing wheels can be used with this bench grinder. These

wheels may vary in thickness, and you may need to add spacers to ensure the

arbor hex. nut (A) Fig.8 tightens properly. The correct placement of the spacer(s)

(B) is shown in Fig.8.

N TE: The spacer(s) (B) should always go onto the arbor shaft first. Always use

the inner and outer flanges (C) that come with this bench grinder, even when using

wire or buffing wheels (D).

N TE: ake sure all wire wheels and buffing wheels installed on this bench

grinder are rated above the maximum RP rating of 1,750 RP .

Using the diamond wheel dressing tool

The diamond wheel dressing tool is used to remove imperfections and built up

materials from the grinding wheel, and to square the edges of the wheel.

N TE: The diamond wheel dressing tool D ES N T work on wire wheels or buff-

ing wheels.

1. Ensure the tool rest (A) Fig.9 is positioned horizontally, with a 1/16” distance

from the grinding wheel.

2. Remain to the side of the bench grinder and turn it “ON”. Allow the grinding

wheel to come up to a steady speed for at least one minute.

3. Firmly grip the diamond wheel dressing tool (B) Fig.9 and lay it flat on the tool

rest. Slowly move the diamond wheel dressing tool forward, until it begins to

touch the grinding wheel (C).

4. Once the head of the diamond wheel dressing tool begins to touch the grinding

wheel, move the head slowly from side to side (while keeping it flat on the tool

rest). Continue until the grinding wheel edges are square, and the surface has

been cleaned.

5. Turn the grinder “OFF” and allow the grinding wheel to come to a complete

stop.

N TE: Wait a minimum of 10 minutes before using the grinding wheel after it has been dressed. Inspect the grinding wheel for imperfections that

may require further wheel dressing, and for damage to the grinding wheel. If there are cracks or chips missing, REPLACE THE GRINDING

WHEEL IMMEDIATELY.

6. Dressing the grinding wheel can cause the diameter to shrink. Re-adjust tool rests and spark guards to maintain a 1/16” distance from the

wheel.

FIGURE 8

FIGURE 9

MAINTENANCE & TR UBLESH TING

Changing grinding wheels

WARNING: To avoid injury from accidental starting, always turn the switch off,

and unplug the machine from the power source before changing grinding wheels.

NOTE: Inspect new grinding wheels for cracks or other visible signs of damage.

Discard the grinding wheel immediately if any damage is found.

1. Remove the corresponding grinding wheel cover (A) Fig.10 by removing the

long screws (B). Removing the tool rest (C) will be necessary, reposition the

spark shield away from the grinding wheel.

2. Use a piece of wood to wedge the grinding wheel (A) Fig.11 against the grinding

wheel guard (B) to prevent the shaft (C) from rotating. Remove the arbor hex.

nut (D) using a 24 mm wrench.

N TE: The arbor hex. nut (D) Fig.11 on the left side of the bench grinder is left

hand threaded (rotate clockwise to loosen). The arbor hex. nut on the right side

of the bench grinder is right hand threaded (rotate counterclockwise to loosen).

3. Remove the outer flange (E) and slide off the old grinding wheel (A).

4. ake sure the inner flange is in position, then install the new grinding wheel.

Secure it with the outer flange (E) and arbor hex. nut (D).

N TE: Do not overtighten to avoid cracking the new grinding wheel. NEVER in-

stall a grinding wheel on the arbor without paper or fiber discs between the grind-

ing wheel and flanges. Not using the discs can put stress on the grinding wheel,

causing it to crack and possibly fall apart.

5. Reinstall the grinding wheel cover (A) Fig.10, and reposition the tool rest and

spark shield assemblies.

Problem

otor will not start.

otor overheats.

Wavy condition on surface

of workpiece.

Lines on surface of workpiece.

Burning spots or cracks in

the workpiece.

Probable cause

1. Low voltage.

2. Open circuit in motor or loose connections.

1. otor overloaded.

1. achine vibrating.

2. Workpiece not being held firmly.

3. Wheel face uneven.

4. Wheel is too hard.

1. Impurity on wheel surface.

2. Workpiece not being held tightly.

1. Improper type of grinding wheel.

2. Improper feed rate.

Probable solution

1. Check power line for proper voltage.

2. Inspect all lead connections on motor for

loose or open connections.

1. Reduce load on motor.

1. ake sure machine is securely mounted on a

solid surface.

2. Use a holding device to firmly retain the

workpiece.

3. Dress the grinding wheel.

4. Use softer wheel, or reduce the feed rate.

1. Dress the grinding wheel.

2. Use a holding device to firmly retain the

workpiece.

1. Try a wheel which is softer style or a coarser

grit.

2. Slow down the rate of movement of the

workpiece into wheel.

FIGURE 10

FIGURE 11

Inhaltsverzeichnis

Andere King Industrial Schleifer Handbücher

King Industrial

King Industrial KC-1295 Bedienungsanleitung

Beliebte Schleifer Handbücher anderer Marken

Parkside

Parkside PWS 230 C3 Bedienungsanleitung

SUHNER ABRASIVE

SUHNER ABRASIVE ASC 9 Technisches Handbuch

PTA

PTA P1322 Bedienungsanleitung

Crown

Crown CT13313 Bedienungsanleitung

Parkside

Parkside 280250 Bedienungsanleitung

Climax

Climax VM2150 Series Bedienungsanleitung

Jet

Jet JPSG-618M1 Service-Handbuch

Makita

Makita GA4030 Bedienungsanleitung

DeWalt

DeWalt DWEN202 Bedienungsanleitung

Grizzly

Grizzly G2790 Bedienungsanleitung

Fein

Fein MSf843-1a Bedienungsanleitung

Bosch

Bosch GWS 14,4 V PROFESSIONAL Bedienungsanleitung

RAMSET

RAMSET CBAGR18 Bedienungsanleitung

Bosch

Bosch 8-115 Z Bedienungsanleitung

STEELE PRODUCTS

STEELE PRODUCTS SP-PB008 Bedienungsanleitung

MW TOOLS

MW TOOLS ME15W Bedienungsanleitung

Caravaggi

Caravaggi SP 20 Betriebsanleitung

SUHNER ABRASIVE

SUHNER ABRASIVE UWK 10-R125 Technisches Handbuch
