KitchenAid KFP1333 Betriebsanleitung

W11036950

KitchenAid®Food Processor

Intended for Professional Service Technician Only

Service/Repair Manual

(Includes International model)

5KFP1333 (3.1L)

KFP1333, KFP1322, KFP1344, KFP1330, KFP1335,

KFP1356, (13 Cup)

KitchenAid®

Food Processor Service/Repair Manual

Intended for Professional Service Technician Only

Covers Domestic Model –13-cup: KFP1322ER, KFP1333WH, KFP1333OB, KFP1333ER, KFP1333CU,

KFP1333BD, KFP1333GC, KFP1333QG, KFP1333ACS, KFP1344CA, KFP1344ES, KFP1344MS, KFP1344ACS,

KFP1344ACS, KFP1344AES, KFP1344ACA, KFP1344AFPO, KFP130CU, KFP1330SPO, KFP1355WH,

KFP1355OB, KFP1355ER, KFP1355BU, KFP1355CU, KFP1355GC, KFP1356BU, KFP1356CU, KFP1356ER,

KFP1356GA, KFP1356WH, KFP1356TG, KFP1356OB

International Model –3.1L 5KFP1333GER

Table of Contents

Subject Page(s)

Important Service Workplace Safety Recommendations 1

Service Environment 2

Personal Protection 2

Electrical Considerations 2

Electrical Requirements 3

Important Safeguards 3

List of Tools Required 4

Testing the Food Processor 4

Service Procedures: 6

Component Access (Housing Base Removal) 6

Remove Power Cord 8

Remove Slicing Disc Adjusting Knob 9

Remove Motor 10

Remove Control Board 11

Re-Assembly of the Unit 11

Motor Replacement 12

Control Board Replacement 12

Cord Replacement 13

Clean and Test Unit 14

Appendix Subject Page(s)

A Tools Required for Food Processor Service 15

B Problem Guide 16

C 13-cup Food Processor Screw Torques 17

Motor And Housing Unit Parts

Illus. No. Part No. Description

1 W10407578 Use and Care Guide

2 W10451327 Bearing Support

3 W10451328 Ball Bearing

4 W10451326 Motor Adaptor

5 W10451325 Control Panel

6 W10451324 PCB Assembly

7 W10451323 Nameplate

8 W10451322 Terminal Block

9 W10451321 120V Housing Base

10 W10451320 Foot

11 W10451329 Power Cord (2 Prong)

W10451331 Power Cord (3 Prong)

Attachment Parts

Attachment Parts List

Illus. No. Part Number Description

1 W10451497 Shredding Adaptor

2 W10451487 Mini Blade

3 W10451463 Multi Purpose Blade

4 W10451466 Slicing Disc

5 W10451465 Shredding Disc

6 W10461927 Spatula

7 W10451494 Large Accessory Box

W10625740 Small Accessory Box

8 W10451493 Egg Whip

9 W10451489 Dough Blade

10 W10451495 Slicing Shaft Adapter

11 W10461962 Common Adaptor

12 W10461924 Round Pusher

13 W10461925 Regular Pusher

14 W10451469 Wide Mouth Pusher

15 W10451468 13 Cup Lid

16 W10451470 Mini Bowl

17 W10461926 Chef Bowl

18 W10451467 13 Cup Bowl Onyx Black

19 W10480168 Lid Gasket

20 W10761311 Dicing Kit used on KFP1355 & KFP1356

Not Pictured W10799255 Julienne Disc

Introduction

All KitchenAid Products are well designed. Normally they will give continual use year after year without service attention.

Records have been maintained to determine and correct, through improved design, any troubles that might possibly

develop. An effort has been made in preparation of this manual to cover them all.

IMPORTANT SERVICE WORKPLACE SAFETY RECOMMENDATIONS

The purpose of this manual is to familiarize the professional house wares technician with the techniques required to repair

the following:

Domestic 13-cup Food Processor

Model KFP1333

International 3.1L Food Processor

Model 5KFP1333

- 2 -

SERVICE ENVIRONMENT

The following Safety Guidelines should be adhered to when servicing this product.

The workplace should be dry and sanitary at all times and all units should be inspected for cleanliness before any

work is started.

Visually inspect the unit requiring service in a well illuminated area.

A mild, non-abrasive dishwashing soap solution and clean towel can be used to wash any unit requiring attention.

The hands of the service technician should be clean at all times during the service procedure.

PERSONAL PROTECTION

The Service Technician should wear Protective Eyewear at all times when conducting a repair on the unit.

Loose fitting sweaters, shirt sleeves or bracelets should not be worn while servicing any product with rotating

parts.

ELECTRICAL CONSIDERATIONS

The workplace for the food processor should have properly grounded AC outlets that adhere to all Local Electrical

Codes that are applicable at the time of repair.

The food processor Power Cord should always be inspected first before plugging the unit into an energized power

outlet.

Do Not run the food processor if the Power Cord is damaged - replace it.

ESD (Electro Static Discharge) protection should be provided when servicing the electronic components.

All disassembly and assembly procedures discussed in this manual should be conducted with the unit

disconnected from the AC power source.

Do Not leave the unit unattended while running it for inspection or for any other checks.

Do Not remove the work bowl cover from the work bowl or remove the work bowl from the processor base while it

is running.

Always unplug the food processor immediately after concluding all electrical tests.

- 3 -

Electrical Requirements

This food processor is designed for use with 120 VAC, 60 Hz (240 VAC, 50 Hz International) only. It has a grounded plug

and should not be modified in any way. Do not use an extension cord or an adapter with this food processor.

A short power supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer

cord. If the power supply cord is too short, have a qualified electrician or service technician install an outlet near the area

where the food processor will be used.

Important Safeguards

Ensure the KitchenAid®service technician is aware of the operating safeguards recommended to the customer:

1. Read all instructions in the KitchenAid®Food Processor Service Guide to Professional Results booklet.

2. Close supervision is necessary when any food processor is used by or near children.

3. The food processor has been U listed for household and commercial use.

4. To protect against electrical shock, do not immerse cord, plugs, or food processor housing in water or other liquid.

5. Do not operate any food processor with a damaged cord or plug or after the food processor has malfunctioned or has

been damaged in any manner.

6. Unplug the food processor from the outlet before cleaning.

7. Do not let the cord hang over the edge of a table or counter or touch hot surfaces.

8. Do not use an extension cord.

9. The use of accessories not recommended by KitchenAid®may result in fire, shock, or injury to persons.

10. Do not use the food processor outdoors.

11. Do not place the food processor on or near a hot gas or electric burner or on a heated oven.

12. Do not use the food processor for other than its intended use.

13. Do not use the food processor without the work bowl cover in place while in operation.

14. Do not clean the work bowl/cover with harsh cleaners, steel wool pads or other abrasive material.

- 4 -

List of Tools Required

The following tools are necessary to service the KitchenAid®Food Processor.

Dead Blow Hammer

Phillips Screw Driver

Large Flat Head Screw Driver

Small Flat Head Screw Driver

Soft Work Surface (soft towel or foam matting)

Volt/Ohm Meter or Digital Multi-meter

NOTE: Power drivers are not recommended for servicing the KitchenAid®Food Processor.

The following equipment will greatly assist the technician in servicing the KitchenAid®Food Processor:

Low pressure compressed air to remove debris from food processor/components.

Clean rags/shop towels

Cushion the service area to keep from scratching the food processor or damaging the controls. A clean shop

towel or a folded paper towel will usually work well for this purpose.

Testing the Food Processor

The service technician will have to test the performance of the food processor to identify and diagnose the problem.

Normal electrical testing techniques, using a volt/ohm meter, are sufficient to test the food processor electrical

components.

NOTE: Refer to the PROBLEM GUIDE in this manual while performing any test.

Review any documentation accompanying the faulty food processor.

Perform a ground continuity test and a hi-pot test prior to plugging the food processor into an electrical outlet.

Prior to disassembling the food processor, plug it into an electrical outlet and perform a function test. Test the

switches, speed selections, etc. for proper operation and to troubleshoot for the problem.

If the unit does not run when plugged in, make sure that the work bowl and lid are properly installed and that the

pusher is in place. Proper installation of the work bowl, lid and pusher are essential for the safety switch interlock

system to function. The work bowl interlock can be verified by assembly of the bowl, lid and pusher while off of the

base unit.
