KNF SCC 950 Bedienungsanleitung

KNF 304771-304773 07/18

Translation of original Operating Instructions, English

Operating Instructions

Read and observe these Operating Instructions!

Vacuum pump system

SCC 950

KNF Neuberger GmbH

Alter Weg 3

79112 Freiburg

Germany

Tel. +49 (0)7664 / 5909-0

Fax +49 (0)7664 / 5909-99

E-Mail: inf[email protected]

www.knf.de

Translation of original Operating Instructions, English, KNF 304771-304773 07/18

Items included in delivery:

Vacuum pump system, including two hand terminals (bat-

teries included)

Separate charging station for second hand terminal

Bracket to attach the charging station and second hand

terminal to the vacuum pump system

Coated collection flasks (2 x)

Flask clips (2 x)

Power cable

USB cable for connecting vacuum pump system to PC

Power supply for hand terminal

Operating instructions

Abbreviated instructions

CD with digital operating instructions and software for op-

erating the vacuum pump system with a PC

Transportation protection

Hand terminal 1 of the vacuum pump system is secured at the

factory in order to prevent damage during transportation.

The transportation protection must be removed

before hand

terminal 1 can be removed. Refer to Chapter

6 Setup and

connection.

Hand terminal 2 is enclosed without a transport securing

device.

Vacuum pump system SCC 950 Table of Contents

Translation of original Operating Instructions, English, KNF 304771-304773 07/18

Content Page

1. About this document 4

1.1. Use of the Operating Instructions 4

1.2. Symbols and markings 4

2. Use 5

2.1. Intended use 5

2.2. Improper use 6

3. Safety 7

4. Technical data 9

4.1. Vacuum pump system 9

4.2. Hand terminal of the vacuum

pump system 11

4.3. Software 12

5. Assembly and functions 13

5.1. SCC 950 13

5.1.1.Assembly of the vacuum pump

system 13

5.1.2.Vacuum pump system functions14

5.1.3.Hand terminals 16

5.2. Pump 17

5.3. Gas ballast 18

6. Setup and connection 19

6.1. Installation 19

6.2. Connections 22

7. Operation 23

7.1. Initial start-up 23

7.2. Stopping operation 26

8. Operating the vacuum pump system27

8.1. Hand terminal 27

8.1.1.General functions and displays 27

8.1.2.Operation 29

8.1.3.Changing batteries on the hand

terminal 35

8.2. Operation without hand terminal 36

8.3. Software 36

9. Servicing 37

9.1. Servicing schedule 37

9.2. Cleaning 37

9.2.1.Rinsing the vacuum pump

system 37

9.2.2.Cleaning the vacuum pump

system 37

9.2.3.Emptying collection flask on the

suction and pressure sides 37

9.3. Replacing the diaphragms and

valve plates 39

9.3.1.Removing the pump 40

9.3.2.Overview of pump parts 41

9.3.3.Disassembling head connection42

9.3.4.Disassembling pump heads 42

9.3.5.Replacing the diaphragms and

valve plates 44

9.3.6.Assembling heads and head

connection 45

9.3.7.Final steps 46

10. Troubleshooting 47

11. Spare parts and accessories 52

11.1. Spare parts 52

11.2. Accessories 53

12. Returns 54

13. Health and safety clearance and

decontamination form 55

About this document Vacuum pump system SCC 950

4 Translation of original Operating Instructions, English, KNF 304771-304773 07/18

1. About this document

1.1. Use of the Operating Instructions

The Operating Instructions are an integral part of the vacuum

pump system.

Carefully study the Operating Instructions before operating the

vacuum pump system.

Always keep the Operating Instructions handy in the work

area.

Forward the Operating Instructions to any subsequent

owners of the vacuum pump system.

Customer-specific vacuum pump systems (model designations

which begin with "PJ" or "PM") may differ from the Operating

Instructions.

In the case of custom systems, take note of any additionally

agreed specifications.

Compliance with the Operating Instructions is essential for safe

and reliable operation of the vacuum pump system. Failure to

do so

may result in damage or injury.

1.2. Symbols and markings

Warning

WARNING

This symbol indicates a danger statement.

It also indicates the possible consequences of failure

to observe the warning. The signal word (i.e. “War

ing”) indicates the level of danger.



Here you will see actions for avoiding the danger

and potential consequences.

Danger levels

Signal word

Meaning

Consequences if not observed

DANGER

warns of immedi-

ate danger

Consequences include death or

serious injuries and/or serious

property damage.

WARNING

warns of potential

danger

Death or serious injuries and/or

serious property damage are

possible.

CAUTION

warns of a poten-

tially dangerous

situation

Minor injuries or damage to

property are possible.

Tab. 1

Other information and symbols

This indicates an activity (step) that must be carried out.

1. This indicates the first step of an activity to be carried out. Any

additional steps are numbered consecutively.

This symbol indicates important information.

Custom systems

Vacuum pump system SCC 950 Use

Translation of original Operating Instructions, English, KNF 304771-304773 07/18 5

2. Use

2.1. Intended use

The SCC 950 vacuum pump system is designed for use in chemi-

cal, pharmaceutical, and biological laboratories. It is designed

exclusively to transfer gases and vapors.

Make sure that the installation location is dry and that the system is

protected against water in the form of rain, spray, splashes and

drips.

The vacuum pump system is solely for use in indoor areas.

Owner's responsibility

Only install and operate the vacuum pump system under the

operating parameters and conditions described in Chapter 4,

Technical data.

Protect the vacuum pump system against humidity.

Before using a medium, check the compatibility of the materials of

the pump head, diaphragms, valves, seals and hoses with the

medium.

Before transferring a medium, check whether the medium can be

transferred safely.

Only transfer gases that remain stable under the pressures and

temperatures occurring in the vacuum pump system.

The high-performance condenser may be used only at the pump

outlet; there is a risk of implosion if it is used at the pump inlet.

Make sure the tubes for gas and cooling medium are correctly

assigned on the high-performance condenser. Inlets and outlets of

the gas connections must not be confused.

Laboratory equipment or additional components connected to the

vacuum pump system have to be suitable for use with the pneu-

matic capabilities of the vacuum pump system (see Chapter 4,

page 9).

Operating parameters and

conditions

Requirements for media

to be transferred

High-performance condenser

Accessories

Use Vacuum pump system SCC 950

6 Translation of original Operating Instructions, English, KNF 304771-304773 07/18

2.2. Improper use

The vacuum pump system must not be operated in potentially

explosive atmospheres.

The vacuum pump system is not suitable for transferring dust.

The vacuum pump system is not suitable for transferring liquids.

The vacuum pump system must not be used if the entry of air or

gas into the vacuum pump system during venting (ventilation

valve) or an open gas ballast valve could result in the creation of

reactive, explosive or otherwise hazardous mixtures (e.g. with the

medium).

The vacuum pump system must not be used to create vacuum and

pressure simultaneously.

Never apply positive pressure to the suction side of the vacuum

pump system.

Vacuum pump system SCC 950 Safety

Translation of original Operating Instructions, English, KNF 304771-304773 07/18 7

3. Safety

The vacuum pump system is built according to the generally rec-

ognized rules of technology and in accordance with the pertinent

occupational safety and accident prevention regulations. Neverthe-

less, potential dangers during use can result in injuries to the user

or others, or in damage to the vacuum pump system or other

property.

Only use the vacuum pump system in a good technical and proper

working order, in accordance with its intended use, with awareness

of safety and potential hazards, and observing the advice within

the Operating Instructions, at all times.

Make sure that only trained and instructed personnel or specially

trained personnel work on the vacuum pump system. This espe-

cially applies to assembly, connection and servicing work.

Make sure that the personnel have read and understood the Oper-

ating Instructions, especially the "Safety" chapter.

Ensure adherence to all pertinent accident prevention and safety

regulations when working on and operating the vacuum pump

system.

Do not subject parts of the body to vacuum.

Open housing parts with notice sticker (see Fig. 1) only after sepa-

rating mains plug from power source.

Ensure that personnel check before each use of the SCC 950

vacuum pump system that they have the correct hand terminal for

the vacuum pump system. The vacuum pump system is equipped

with a paging function for this purpose (see Paging the vacuum

pump system, page 34).

When transferring dangerous media, observe the safety regula-

tions for handling such media.

Be aware that the vacuum pump system is not designed to be

explosion-proof.

Make sure that the temperature of the medium is always sufficient-

ly below its ignition temperature in order to avoid ignition or explo-

sion. This also applies to unusual operating situations.

Note that the temperature of the medium increases when the pump

compresses the medium.

Hence, make sure that the temperature of the medium is sufficient-

ly below its ignition temperature, even when it is compressed to the

maximum permissible operating pressure of the vacuum pump

system. The vacuum pump system's maximum permissible operat-

ing pressure is specified in the Technical data (see Chapter 4,

page 9).

Personnel

Working in a

safety-conscious manner

Fig. 1: Notice sticker

Using the right

hand terminal

for the vacuum pump system

Handling dangerous media

Handling flammable

media

Safety Vacuum pump system SCC 950

8 Translation of original Operating Instructions, English, KNF 304771-304773 07/18

Consider any external sources of energy, such as sources of

radiation, that could additionally heat the medium.

In case of doubt, consult KNF customer service.

When ventilating the vacuum pump system with air or inert gas, be

sure to prevent the formation of reactive or explosive media. The

maximum permissible operating pressure at the ventilation connec-

tion (Fig. 2/18, p. 13) is 0.1 bar g.

All replacement parts should be properly stored and disposed of in

accordance with the applicable environmental protection regula-

tions. Ensure adherence to the pertinent national and international

regulations. This applies especially to parts contaminated with toxic

substances.

The SCC 950 vacuum pump system conforms to the Directive

2011/65/EU (RoHS2).

The SCC 950 vacuum pump system conforms to the safety regula-

tions of Directive 2014/30/EU concerning Electromagnetic Compat-

ibility and Directive 2006/42/EC concerning Machinery. The follow-

ing harmonized standards are met:

DIN EN 61010-1

DIN EN 61326-1 – Class A

DIN EN 50581

In accordance with IEC 664 the systems conforms to:

Overvoltage category II

Pollution degree 2

All repairs to the vacuum pump system must be carried out by the

responsible KNF Customer Service team.

Housings with live parts may be opened by technical personnel

only.

Use only genuine parts from KNF for servicing work.

Ventilating the vacuum pump

system

Environmental protection

Standards

Customer service and

repairs

Vacuum pump system SCC 950 Technical data

Translation of original Operating Instructions, English, KNF 304771-304773 07/18 9

4. Technical data

4.1. Vacuum pump system

Materials for parts in contact with the medium

Pump head

PPS

Interconnection parts

PPS

Diaphragms

PTFE-coated

Valve plates

FFPM

Flat seals

FFPM

O-rings, green

FPM

O-rings, black

FFPM

Hose connector gas inlet

PVDF

Hose connector gas outlet

PP/PVDF

Hose connector inert gas

connection

Brass, nickel-plated

Hoses

Norprene®

Adapter separator

Adapter control unit

PPS

Adapter connector

Pressure transducer

Ceramic / 1.4404

Ventilation valves/gas ballast

valve:

Anchor seal

O-ring

Tube

FFPM

FPM

1.4301

Vacuum valve

FFPM

Non-return valve

FFPM

Pneumatic performance

Max. permissible

operating pressure [bar g]

Ultimate vacuum [mbar abs.]

≤ 2 mbar

≤ 4 mbar with open gas ballast

Flow rate at atm. pressure

[l/min]*

Approx. 50 (adjustable)

Max. permissible pressure at

inert gas connection [bar g]

0.1

Ambient and media temperature

Permissible media and

ambient temperature

+10°C to + 40°C

* liters in standard state (1013 mbar at 0°C)

Tab. 2 (1st part)

Technical data Vacuum pump system SCC 950

10 Translation of original Operating Instructions, English, KNF 304771-304773 07/18

Other parameters

Vacuum connection and

gas outlet

For hose ID 10 mm

Ventilation connection

For hose ID 4 mm

Weight [kg]:

(including hand

terminals)

Approx.18.2

Dimensions W x H x D [mm]:

- with charging station at-

tached

- without charging station

attached

353 x 487 x 376

246 x 487 x 376

Maximum permissible ambient

relative humidity

(not condensing)

80% for temperatures up to

31°C, decreasing linearly to 50%

at 40°C

Maximum altitude of installa-

tion [m above sea level]

2000

Coolant supply parameters (high-performance condenser)

Permissible pressure [bar g]

Permissible temperature

- 15 °C to + 20 °C

Coolant connections on high-

performance condenser

For hose ID 8 mm

Coolant-coated surface [cm2]

Min. 470

Electrical data of vacuum pump system

Nominal voltage** [V]

100-240 +/- 10%

Frequency [Hz]

50-60

Maximum operating current [A]

1.7

Max. power consumption [W]

150

Protection class

IP20

Vacuum pump system fusing

[A]

2 x T2.5

Drive motor fusing

Electronic overcurrent protection

Tab. 2 (2nd part) ** Automatic mains power adjustment

The pump of the vacuum pump system is supplied by a univer-

sal power supply with integ

rated overload protection. It is

protected against overheating by a temperature sensor on the

motor board and equipped with overcurrent protection.

If one of these safety functions is triggered, the pump will be

shut down and must be manually reset, as fol

lows:



Separate vacuum pump system from the mains.



Remove the cause(s) of the fault before restarting.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere KNF Wasserpumpe Handbücher

KNF

KNF N680 EX Bedienungsanleitung

KNF

KNF N 143 AV.12 E Montageanleitung

KNF

KNF N 820.3 FT.40.18 Bedienungsanleitung

KNF

KNF UN 828 Bedienungsanleitung

KNF

KNF NF 1.100 EX Bedienungsanleitung

KNF

KNF NF 1.300 EX Bedienungsanleitung

KNF

KNF UNF 1.300 EX Bedienungsanleitung

KNF

KNF NF 1.30 Bedienungsanleitung

KNF

KNF Laboport N86 KN.18 Bedienungsanleitung

KNF

KNF N920 AP.18 Bedienungsanleitung

KNF

KNF FEM 1.02 Bedienungsanleitung

KNF

KNF FL 10 Bedienungsanleitung

KNF

KNF NMP850K DC-B HP Bedienungsanleitung

KNF

KNF N96 Bedienungsanleitung

KNF

KNF UFK 1.1100 EX Bedienungsanleitung

KNF

KNF N0150 EX Bedienungsanleitung

KNF

KNF N838 DC Series Bedienungsanleitung

KNF

KNF NF 300 Bedienungsanleitung

KNF

KNF N1200 Bedienungsanleitung

KNF

KNF N96 Verdrahtungsschema

KNF

KNF FK 1100 Bedienungsanleitung

KNF

KNF OEM Bedienungsanleitung

KNF

KNF N96K E-W Bedienungsanleitung

KNF

KNF Labor N035.18 Bedienungsanleitung

Beliebte Wasserpumpe Handbücher anderer Marken

Neptun

Neptun NPHW 5500 Bedienungsanleitung

Sensidyne

Sensidyne Gilian BDX-II Montage- und Bedienungsanleitung

Draper

Draper 47808 Bedienungsanleitung

Trolla

Trolla 12820 Bedienungsanleitung

Sunfab

Sunfab SVH Series Bedienungsanleitung

WilTec

WilTec 50740 Bedienungsanleitung

Fieldmann

Fieldmann FVC 5015 EK Bedienungsanleitung

Everbilt

Everbilt EFSUB5-122HD Bedienungsanleitung

Graco

Graco Husky 3300e Bedienungsanleitung

esotec

esotec 101018 Bedienungsanleitung

moyno

moyno 2000 CC Bedienungsanleitung

Becker

Becker BASIC VASF 2.80/1-0.AC230 Bedienungsanleitung

Sykes AmeriPumps

Sykes AmeriPumps GP100M Fehlerbehebungshandbuch

DUROMAX

DUROMAX XP WX Series Bedienungsanleitung

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Bedienungsanleitung

Franklin Electric

Franklin Electric IPS Bedienungsanleitung

Xylem

Xylem e-1532 Series Bedienungsanleitung

Milton Roy

Milton Roy PRIMEROYAL Bedienungsanleitung
