Technical data
Frequency HF: 869.2125 MHz
Range: Up to 500 m free range to an RX901B (1)
Battery: 2 pcs. 1.5V LR6/AA Alkaline (minimum 2000mA)
Battery time: About 12 months with 5 alarm calls per day depending on
settings.
Low battery indicator: Approximately 1/3 of the remaining capacity.
External power supply: 5-14V
Power consumption, off: < 200uA
Power consumption, RX/TX: < 100mA
Surrounding environment: Indoor use. ≤ 90% non-condensing
Ambient temperature: 0°C to +40°C
Cabinet type: Color RAL9002 ABS
Cabinet dimensions: W: 83mm, H: 57mm, D: 35mm.
Density: IP20
Weight: 130g
The right to make changes is reserved.
All rights reserved.
©KNOP Elektronik A/S
(1) Measured outdoors with an unobstructed view between transmitter and receiver. In buildings, the range is
reduced.
