Konica Minolta FLEXDR C30 Bedienungsanleitung

DIGITAL RADIOGRAPHY

Distributed by：

KONICA MINOLTA MEDICAL & GRAPHIC, INC.

No.1, Sakura-machi, Hino-shi, Tokyo, 191-8511, Japan

Providingbothsafety

andoperability

ManualmovementoftheunitemploystouchSW.

Theunitcanberaised/loweredandfine-adjusted

smoothlywithalightholdingofahandle,provid-

ingbothsafetyandoperability(timesaving).The

unitcanbeloweredto465mm(frompanels

centertofloor),allowingawiderangeofimage

captureincludinglowerlimbs.

Easygridexchange

Gridcanbeselectedaccording

toimagingregionandparam-

eters.Imagequalityisenhanced

byanoptimumanti-scattering.

Gridexchangeissimpleand

speedy.

F L E X D R C 3 0

FlexDR C30 achieves more comfortable

workflow with excellent operability,

uncompromising usability and rapidimage

acquisition(5secondsafterexposure).

It also provides a state-of-the-art, high

levelofdiagnosticimage,bycombininga

highqualityFPD(FlatPanelDetector) and

theimageprocessingtechnologywhich

KonicaMinolta has developed for its

REGIUSsystem.

FlexDRC30deliversusabilitytomeettheneedsandexpectationsofimaging.

Contributingtolowerdose

andhigherresolution

FPD(FlatPanelDetector)employsanindirectconversion

systemwithCsI(cesiumiodide)columnarcrystal.Itprovidesa

state-of-the-art,highlevelofdiagnosticimage,bycombining

theimageprocessingtechnologywhichKonicaMinoltahas

developedovertheyears.Inaddition,thehighqualityFPD

hasahigherDQEenablinglowerdose.

Excellinginrealtimeperformance,

efficientimagingandsafety

Imageisacquiredinabout5secondsanddisplayedsimultaneouslyon

bothworkstationscreenandLCDsubpanelintheexaminationroom.The

subpanelallowsimagechecking,patientIDconfirmationandvarious

otheroperationsintheexaminationroom,providingaworkflowthat

enhancestherealtimeperformanceofFPD,streamlinedimaging,andless

burdenonpatients.

<Mainfeaturesofsubpanel>

■Large-scale(10.4inches)

touchscreenLCDmonitor.

■Patientinformationcanbe

checkeduponpositioning.

■Imagingparameters(image

size,direction,position)canbe

modifiedintheexamination

room.

■Displayhasafamiliaritywith

previousconsoledisplays,

keepingthesameusability.

X-ray

photodiode

X-ray

scintillator

light

Thoughtfulandeasytouse

■Statusindicationlights:

Operationalstatusoftheunitisindicatedbycolour-

codedindicatorlights.Readinessforimagecapture

anderroroccurrencecanbeimmediatelychecked

fromadistance.

■3DshapedholdbarsforPA/APexamination:

Holdbarsaredesignedforallsubjectsandallbody

types,providingbothfunctionalityandsafety.

Provisionofreal-timeoperation

H Y B R I D-W S C S-3

DiagnosticImagingWorkstationCS-3

isaconsolefordualusewithFlexDR

and REGIUS series. Touch screen

LCDmonitorwith wide viewingangle

hasbeenintroducedtoa simpleand

intuitive user interface. Reliable

image checking feature follows the

samelineofthatinFlexDRseries.

The system provides total manage-

ment from input of patient/order

informationreceivedfromHIS/RISall

the way through to image checking,

as well as more comfortable and

efficient image acquisition environ-

ment.

Equippedwithpatientinformation

registrationfunction

■Searchscreen:

Onthisscreen,patientinformationcanbesearchedbyIDnumber.

Suitableforoperationwithpatientcheck-inateachimagingroom.

■Orderlistscreen:

Registered orders are displayed sequentially in the combined

use of patient check-in terminal.  Suitable for operation with

separatepatientcheck-in.

Variousoptionalfunctions

thatenhanceusefulnessandconvenience.

■Arbitraryannotationfunction:

This function allows text editing and

layout at any positions on the image.

Annotations can be reflected in the

output(tohostorprinter).

■Inter-consoleimagesharing:

Thisfunctionallowsimagedatasharing

among CS-3 consoles on a single

network.

HybridDevice

WorkflowConsole

Thesystemcentralizesworkflowfromorderinformation

managementtoimageoutputingeneralX-rayimagingby

theuseofFlexDRandREGIUSsystem.Changeinto

Uniformityofhandling(includingconsoleoperations)and

consistencyofimagequalityisachievedwithsimultane-

ousCRandDRimagingforasinglepatient.

DeliveringUncompromisingRealTimeperformance.

CentralizedcontrolofDRandCRcreates

acomfortableworkenvironment.

★Screendesignissubjecttochangewithoutnoticeforthepurposeofperformanceimprovement.

■HybridDevice

NetworkSystem

REGIUS

19 0 FlexDR

C30

FlexDR

C30

CS-3

REGIUS

110

Viewer

HIS/RIS

Server

DRYPRO873

FlexDR

series

REGIUS

series

CS-3

Patientselection

FlexDRimagingselection

Imageacquisition

Imagechecking

REGIUSimagingselection

Imageacquisition

Imagechecking

Imageadjustment

▲Searchscreen ▲Orderlistscreen ▲Arbitraryannotationfunction ▲Inter-consoleimagesharingscreen

■Subpanel

■CS-3

Basedonthereviewofimageacquisitionworkflow,KonicaMinoltaoffersanadditionaltouchscreenLCDmonitor(sub

panel)withFlexDRmodel,providingimagedisplayandvariousotheroperationsintheexaminationroom toachievea

workflowwithimprovedreal-timeperformance.UpperlineshowsCS-3displayandlowerlineshowssubpaneldisplay.

Imagedata

sharing

CS-3

*Tobereleasedsoon

Simultaneous

display

inexaminationroom

SinglePC!

savingspace

Nomovement

between

consoles!

DigitalRadiographyFlexDRC30

OuterDimension

Unit:mm

DiagnosticWorkstationCS-3OuterDimension

Unit:mm

S P E C I F I C A T I O N S

★Thespecificationsabovearesubjecttochangewithoutpriornoticeforthepurposeofperformanceimprovement.

■Elevationrange

465〜1565ｍｍ(center)

■OuterDimension/Weight

W 9 9 6×D 5 2 0×H 187 8 mm/430kg

■Powerconsumption

240VAmax.

■OperatingConditions

Temperature:15-30℃/Humidity:30%-80%RH

■Accessory

Powercable

■Options

Heighttrackingcable,Centersynchronizationcable,

Collimationsynchronizationcable

Multiplefunctionsandanexcellentspecificationcontainedinacompactbody

1023

635

466

2345

2911

1878

640

731

997 257

DigitalRadiographyFlexDRC30Specification DiagnosticWorkstationCS-3Specification

■Detector

Flatpaneldetector

Scintillator(Csl)

■Exposuresize

6types ( 1 7 × 1 7 ,  1 4 × 1 7 ,  1 4 × 1 4 ,  1 1 × 1 4 ,  1 0 × 1 2 ,  8 × 1 0  )

■Samplingpitchsize

13 9μm×13 9μm

■Exposureresolution

3072×3072

■Effectiveresolution

3052×3052

■Gradationlevel

4096levels（12bit）

■OutputFormat

1×1,2×1,1×2

■MainOptions

・Hardwareoption

BarCodeReaderforCassetteRegistration

CS-1PDA

CS-1PDACRADLE

IDSWW

・Softwareoption

CS-3MWM/FTP/DETACHEDOption

CS-3MPPS/DETACHEDOption

CS-3HQMammographyOption

CS-3DICOMOutputAdditional#1

CS-3DICOMOutputAdditional#2

CS-3DICOMOutputAdditional#3

CS-3DICOMOutputAdditional#4

CS-3DICOMOutputPackage

CS-3StitchingOption

CS-3ImageSharingOption

CS-3DataAnalysisOption

■ImageProcessing

AutomaticGradationProcessing(GProcessing)

FrequencyProcessing(FProcessing)

EqualizationProcessing(EProcessing)

HybridProcessing(HProcessing)

■ImageOutput

・Maximum

Host:3chforRoutine,1chforbackup

Printer:2chforRoutine,1chforbackup

・CS-3StandardSoftware

HostorPrinter:1chforRoutine,1chforbackup

■DICOMSupport

BasicGrayscalePrintManagement(SCU)

Storage(SCU)

ModalityWorklistManagement

ModalityPerformedProcedureStep

GrayscaleStandardDisplayFunction(printoutput)

■MaximumDevicetoaCS-3

REGIUS170/19016unitsandREGIUS3701unit

346

135

54.5

301

369

356

317

341

157
