Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups1

1.1 About the VP-747

that are clearly defined by function.

The VP-747 Universal Presentation Matrix Switcher / Scaler is a true multi-

standard video to graphics scaler and seamless switcher with eight universal

inputs comprised of five BNC connectors each of which can accommodate a

composite video, s-Video (Y/C), component video (RGB/YUV), RGBS, or

RGBHV signal. Input 1 and input 2 also accommodate DVI / HDMI2

•Presentation applications that require a preview option

inputs. It

has dual scalers, one for the preview and the other for the program output. Dual

scalers are required to do "live" seamless transitions from one source to

another. It is ideal for these typical applications:

•Projection systems in conference rooms, board rooms, auditoriums,

hotels, and churches

•Presentations requiring seamless switching between inputs, using special

effects, cuts and fades

The package includes these items: VP-747 Universal Presentation Matrix

Switcher / Scaler,power cord3, infrared remote control transmitter (including

the required battery), null-modem adapter, and this user manual4

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables5

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 The HDMI connector connects to a DVD source via the Kramer ADC DM/HF adapter

3 We recommend that you use only the power cord that is supplied with the machine

4 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

5 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic steps when connecting a VP-747:

Overview

3 Overview

The VP-747 Universal Presentation Matrix Switcher / Scaler is a true

multi-standard video to graphics scaler and presentation switcher for a wide

variety of presentation and multimedia applications. It consists of a very high

quality scaler with many user-selectable graphics or HDTV output resolutions,

as well as a user definable output mode1

The VP-727A Audio Switcher and VP-727A-BA Balanced Audio Switcher

are audio companion switchers for the VP-747, and either can operate in

conjunction with it and the VP-727T Presentation Switcher Control Panel.

In particular, the VP-747:

•Features Silicon Optix HQV® Video Processing (Hollywood Quality

Video) which represents the state-of-the-art in video processing

technology, with the highest quality de-interlacing, noise reduction, and

scaling performance for both standard-definition and high-definition

signals

•Features eight sets of universal INPUT BNC connectors: R/PR, G/Y/CV,

B/PB/C, HS/CS, and VS.Each set can be programmed to operate as:

composite video, s-Video, component video2

•Includes two DVI / HDMI

, RGsB/YUV, RGBS, or

RGBHV 3inputs (for input 1 and input 2) that support up to

1.65 / 2.25Gbps bandwidth per graphic channel4

•Is HDTV Compatible and HDCP compliant

•Scales the selected sources to DVI / HDMI, RGBHV (Y, Pb, Pr) and

VGA outputs simultaneously

•Has dual scalers—for “live” seamless transitions from one source to

another—with two independent outputs: a PREVIEW OUT and a

PROGRAM OUT (see Section 8.2

1 Recommended for advanced users only – non-standard settings may not be recognized by the display device

). The PREVIEW output—including an

OSD menu for making adjustments—is for determining how the scaled

output will look before displaying live during a presentation, as well as for

setting the special effects that harmonize the transition when changing

between sources. Both outputs have separate sets of connectors for DVI /

HDMI, VGA (a 15-pin HD computer graphics video connector), and

RGBHV / YPbPr (on BNC connectors)

2 Sometimes called YUV, or Y, B-Y, R-Y, or Y, Pb, Pr. The component input type (HDTV or YCbCr) may be set as HD or SD

3 The HDMI connector connects to a DVD source via the Kramer ADC DM/HF adapter

4 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

5 The HDCP (High Definition Content Protection) license agreement allows copy-protected data on the HDMI input to pass

only to the HDMI output

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

•Features eight PREVIEW input buttons for switching a selected input to

the PREVIEW output and eight PROGRAM input buttons for switching a

selected input to the PROGRAM output

•Includes two transition modes (accessible via the OSD): the Swap mode

and the Follow mode. When pressing the TAKE button in the Swap mode,

the preview and program inputs switch positions; when pressing in the

Follow mode, the program input follows the preview input

•Scales and zooms (to up to 400% of the original size)

•Offers high quality de-interlacing 3:2/2:2 pull down1

•Features K-IIT XL™ Picture-in-Picture Image Insertion Technology with

ultra stable picture-in-picture, picture-and-picture, and split screen

capability for both the PREVIEW and the PROGRAM outputs. Any video

source can be inserted into or positioned next to a computer graphics

video source or vice versa with window positioning and sizing controls

•Saves all settings in non-volatile memory in the unit

•Supports firmware upgrade via USB

•Features a sophisticated front panel lockout3

•Features a Take button for executing preview to program switching (with

transition effects, which include cuts, fades, and wipes

•Has ProcAmp )

•Has multi-standard video support: PAL, SECAM, and NTSC (3.58/4.43)

controls for both outputs

•Has a built-in Time Base Corrector that stabilizes video sources with

unstable sync

•Features multiple color space, outputting RGB or YUV

•Supports embedded audio on the HDMI inputs and outputs

•Digitally reprocesses the signal to correct mastering errors, and

regenerates the video at a chosen line and pixel rate format, providing, for

example, native-resolution video for LCD, DLP and Plasma displays

•Facilitates scaling of graphics resolutions to other resolutions

•Incorporates a unique graphics-scaling engine with image enhancement

algorithms, which are built into the firmware

1 Accommodates the frame-rate of a converted movie (24 frames per second) to video frequencies (25 frames per second

(PAL); 30 frames per second (NTSC)

2 See Table 5

3 See Section 8.5

4 The direction of the wipe may be selected by the user. The speed of each transition can be adjusted

5 Processing amplification enables adjustment of different video and audio signal parameters

Overview

•Is specifically designed to improve video quality by reducing chroma and

temporal noise

•Reduces digital artifacts such as mosquito and block noise

•Comes in a rugged, professional 19" 3U rack-mountable metal enclosure

•Uses a universal 100-240VAC automatic power supply, and rear panel

power switch

Control the VP-747 via the:

•Front panel and a user-friendly menu-driven OSD (see Section 9.1

•High contrast LCD Display (see )

Section 9.2

•IR remote control transmitter (see )

Section 9.3

•ETHERNET/RS-232 (see )

Section 9.4

•Kramer VP-727T Presentation Switcher Control Panel

) 1

3.1 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital2

In particular, HDMI

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the highest high-definition image and sound quality. Note that

Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.

•Provides a simple:

4interface between any audio/video source, such as a

set-top box, DVD player, or A/V receiver and video monitor, such as a

digital flat LCD / plasma television (DTV), over a single lengthy5

•Supports standard, enhanced, high-definition video, and multi-channel

digital audio

cable

•Transmits all ATSC HDTV standards and supports 8-channel digital

audio, with bandwidth to spare to accommodate future enhancements and

requirements

on a single cable

1 See the separate user manual on our Web site at http://www.kramerelectronics.com

2 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

3 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

licensing LLC

4 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

5 HDMI technology has been designed to use standard copper cable construction at up to 15m

6 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-747 Universal Presentation Matrix Switcher / Scaler

•Benefits consumers by providing superior, uncompressed digital video

quality via a single cable1

•Is backward-compatible with DVI (Digital Visual Interface)

, and user-friendly connector

•Supports two-way communication between the video source (such as a

DVD player) and the digital television, enabling new functionality such as

automatic configuration and one-button play

HDMI has the capacity to support existing high-definition video formats

(720p, 1080i, and 1080p/60), standard definition formats such as NTSC or

PAL, as well as 480p and 576p.

Achieving the best performance means:

•Connecting only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching, and

elevated noise levels (often associated with low quality cables)

•Avoiding interference from neighboring electrical appliances, making

sure not to block the ventilation holes, and positioning your VP-747 away

from moisture, excessive sunlight and dust

4 Your VP-747 Universal Presentation Matrix Switcher / Scaler

Figure 1 and Table 1 define the front panel of the VP-747:

1 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Your VP-747 Universal Presentation Matrix Switcher / Scaler

Figure 1: VP-747 Universal Presentation Matrix Switcher / Scaler Front Panel

Andere Handbücher für VP-747

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer Sierra Pro XL 1608V5S Bedienungsanleitung

Kramer

Kramer 1616DS Bedienungsanleitung

Kramer

Kramer VS-4216 Bedienungsanleitung

Kramer

Kramer Sierra Video 3232V3S Bedienungsanleitung

Kramer

Kramer VS-626 Bedienungsanleitung

Kramer

Kramer VS-88UT Bedienungsanleitung

Kramer

Kramer MTX3-16-M Bedienungsanleitung

Kramer

Kramer VP-88ETH Bedienungsanleitung

Kramer

Kramer XL 1204V4S Bedienungsanleitung

Kramer

Kramer VS-84HDCPxl Bedienungsanleitung

Kramer

Kramer Sierra Video 3232V3 Bedienungsanleitung

Kramer

Kramer Sierra Video 3248V5Sxl Bedienungsanleitung

Kramer

Kramer VS-44UHD Bedienungsanleitung

Kramer

Kramer Sierra Video 1208V5S Bedienungsanleitung

Kramer

Kramer VS-2616 Bedienungsanleitung

Kramer

Kramer 88DEE Bedienungsanleitung

Kramer

Kramer VS-1616DN-MD Bedienungsanleitung

Kramer

Kramer VS-8 Series Bedienungsanleitung

Kramer

Kramer 3232HDS Bedienungsanleitung

Kramer

Kramer VS-88HC Bedienungsanleitung

Kramer

Kramer VP-8x8A Bedienungsanleitung

Kramer

Kramer 1616HDEE Bedienungsanleitung

Kramer

Kramer Sierra Video 6448V5xl Bedienungsanleitung

Kramer

Kramer 1616HD Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
