Extron electronics MTPX Plus Series Bedienungsanleitung

Setup Guide

MTPX Plus Series

Category

Mini Twisted Pair Matrix Switchers

68-1560-01 Rev. C

08 19

Safety Instructions

Safety Instructions • English

WARNING:This symbol, , when used on the product, is intended to

alert the user of the presence of uninsulated dangerous voltage within the

product’s enclosure that may present a risk of electric shock.

ATTENTION: This symbol, , when used on the product, is intended

to alert the user of important operating and maintenance (servicing)

instructions in the literature provided with the equipment.

For information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the Extron Safety and

Regulatory Compliance Guide, part number 68-290-01, on the Extron

website, www.extron.com.

Sicherheitsanweisungen • Deutsch

WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer darauf

aufmerksam machen, dass im Inneren des Gehäuses dieses Produktes

gefährliche Spannungen herrschen, die nicht isoliert sind und die einen

elektrischen Schlag verursachen können.

VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in

der im Lieferumfang enthaltenen Dokumentation besonders wichtige

Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,

EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in

den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer

68-290-01) auf der Extron-Website, www.extron.com.

Instrucciones de seguridad • Español

ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,

avisa al usuario de la presencia de voltaje peligroso sin aislar dentro del

producto, lo que puede representar un riesgo de descarga eléctrica.

ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa

al usuario de la presencia de importantes instrucciones de uso y

mantenimiento recogidas en la documentación proporcionada con el

equipo.

Para obtener información sobre directrices de seguridad, cumplimiento

de normativas, compatibilidad electromagnética, accesibilidad y temas

relacionados, consulte la Guía de cumplimiento de normativas y seguridad

de Extron, referencia 68-290-01, en el sitio Web de Extron, www.extron.com.

Instructions de sécurité • Français

AVERTISSEMENT : Ce pictogramme, , lorsqu’il est utilisé sur le

produit, signale à l’utilisateur la présence à l’intérieur du boîtier du

produit d’une tension électrique dangereuse susceptible de provoquer

un choc électrique.

ATTENTION : Ce pictogramme, , lorsqu’il est utilisé sur le produit,

signale à l’utilisateur des instructions d’utilisation ou de maintenance

importantes qui se trouvent dans la documentation fournie avec le

matériel.

Pour en savoir plus sur les règles de sécurité, la conformité à la

réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets

connexes, lisez les informations de sécurité et de conformité Extron, réf.

68-290-01, sur le site Extron, www.extron.com.

Istruzioni di sicurezza • Italiano

AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad

avvertire l’utente della presenza di tensione non isolata pericolosa

all’interno del contenitore del prodotto che può costituire un rischio di

scosse elettriche.

ATTENTZIONE: Il simbolo, , se usato sul prodotto, serve ad avvertire

l’utente della presenza di importanti istruzioni di funzionamento e

manutenzione nella documentazione fornita con l’apparecchio.

Per informazioni su parametri di sicurezza, conformità alle normative,

compatibilità EMI/EMF, accessibilità e argomenti simili, fare riferimento

alla Guida alla conformità normativa e di sicurezza di Extron, cod. articolo

68-290-01, sul sito web di Extron, www.extron.com.



Trademarks

All trademarks mentioned in this guide are the properties of their respective owners.

The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or

ExtronElectronics (see the current list of trademarks on the Terms of Use page at www.extron.com):

Registered Trademarks (®)

Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, Flat Field, FlexOS, Glitch Free. Global

Configurator, GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink,

MediaPort, NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, Show Me, SoundField, SpeedMount, SpeedSwitch,

StudioStation, SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VideoLounge, VN-Matrix, VoiceLift, WallVault, WindoWall, XTP,

XTPSystems, and ZipClip

Registered Service Mark(SM) : S3 Service Support Solutions

Trademarks (™)

AAP, AFL (Accu-RateFrameLock), ADSP(Advanced Digital Sync Processing), Auto-Image, AVEdge, CableCover, CDRS(ClassD

Ripple Suppression), Codec Connect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator,

DSPConfigurator, DSVP(Digital Sync Validation Processing), eLink, EQIP, Everlast, FastBite, FOX, FOXBOX, IP Intercom HelpDesk,

MAAP, MicroDigital, Opti-Torque, PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger,

ShareLink, SIS, SimpleInstructionSet, Skew-Free, SpeedNav, Triple-Action Switching, True4K, Vector™ 4K , WebShare, XTRA, and

ZipCaddy

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause interference. This interference must be corrected at the expense of the user.

NOTE: For more information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the Extron Safety and Regulatory

Compliance Guide on the Extron website.

Conventions Used in this Guide

Notifications

The following notifications are used in this guide:

CAUTION: Risk of minor personal injury.

ATTENTION : Risque de blessuremineure.

ATTENTION:

• Risk of property damage.

• Risque de dommages matériels.

NOTE: A note draws attention to important information.

TIP: A tip provides a suggestion to make working with the application easier.

Software Commands

Commands are written in the fonts shown here:

^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0

[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]

E X! *X1&*X2)*X2#*X2! CE}

NOTE: For commands and examples of computer or device responses used in this

guide, the character “0” is the number zero and “O” is the capital letter “o.”

Computer responses and directory paths that do not have variables are written in the font

shown here:

Reply from 208.132.180.48: bytes=32 times=2ms TTL=32

C:\Program Files\Extron

Variables are written in slanted form as shown here:

ping xxx.xxx.xxx.xxx —t

SOH R Data STX Command ETB ETX

Selectable items, such as menu names, menu options, buttons, tabs, and field names are

written in the font shown here:

From the File menu, select New.

Click the OK button.

Specifications Availability

Product specifications are available on the Extron website, www.extron.com.

Extron Glossary of Terms

A glossary of terms is available at http://www.extron.com/technology/glossary.aspx.

Remote Control and Optimizing

the Video..................................................14

Selected SIS Commands................................... 14

Establishing a Network (Ethernet)

Connection................................................... 14

Establishing a USB Port Connection.............. 15

Host-to-switcher Instructions......................... 15

Command and Response Table......................... 16

Installing and Starting the Control Program........ 23

Installing the Program .................................... 23

First-time Connection Considerations ............ 23

Manually Setting the MTPX Level and

Peaking ........................................................ 26

Accessing the HTML Pages............................... 28

Conﬁguring for Network Communication ....... 29

Loading the Start-up Page............................. 30

Contents

Introduction ...............................................1

About this Manual................................................ 1

About the MTPX Plus Switchers .......................... 1

Twisted Pair (TP) Cable Transmission Distance .... 3

TP Skew Equalization .......................................... 4

Installation.................................................5

Rear Panel........................................................... 5

Inputs .............................................................. 6

RS-232 Output Inserts..................................... 6

Outputs ........................................................... 7

Remote Control ............................................... 8

Power.............................................................. 8

Front Panel.......................................................... 8

Front Panel Operation................................9

Creating a Tie ...................................................... 9

Saving or Recalling a Preset .............................. 10

Setting the Front Panel Locks (Executive

Modes)............................................................. 10

Selecting Lock Mode 2 or Toggling

Between Mode 2 and Mode 0 ...................... 11

Selecting Lock Mode 2 or Toggling

Between Mode 2 and Mode 1 ...................... 11

Deﬁning the Audio/RS-232 Wire Pair an

Conﬁguring the R

EMOTE Port............................12

Viewing and Adjusting the Audio Level............... 13

Viewing Ties and Muting Outputs ...................... 13

Video Adjustments ............................................ 13

viiMTPX Plus Series Setup Guide • Contents

MTPX Plus Series Setup Guide • Contents viii

MTPX Plus Series Setup Guide • Introduction 1

Introduction

Topics covered in this section are:

• About this Manual

• About the MTPX Plus Switchers

• Twisted Pair (TP) Cable Transmission Distance

• TP Skew Equalization

About this Manual

This setup guide allows you to easily and quickly set up and configure your Extron MTPX

Plus Twisted Pair (TP) Matrix Switcher. Step-by-step instructions show you how to connect

the hardware and then use the physical controls, Simple Instruction Set (SIS) commands,

the Matrix Switchers Control Program, and built-in HTML pages to optimize the video and

audio output for the best quality.

About the MTPX Plus Switchers

The MTPX Plus matrix switcher (see figure1) distributes signals that are compatible with the

Extron MTP and VTT/VTR product lines. The matrix switcher routes a TP input signal to any

combination of TP outputs. Depending on the MTP model, the routed TP signal can include

RGB or low resolution video and either mono audio or transmitter-to-receiver RS-232

serial communications. The matrix switcher can route multiple input/output configurations

simultaneously.

ETHERNET

ACT

INPUT

SELECT

LOCAL

RJ-45

LOCALINPUTS

12 3 4 5 67 8 9 10 11 12 13 14 15 16

17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

12 3 4 5 67 8 9 10 11 12 13 14 15 16

17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

21 3

4 5 6

RS-232OUTPUT INSERTION

LOCALOUTPUTS OUTPUTS

INPUTS

CONTROL

MONOAUDIO OUTPUTS

AUDIOINPUTS

LINK

RESET

1LR

2L R

3LR

4LR

5LR

6LR

1L R

2L R

3L R

4L R

5L R

6L R

7LR

TxRx

LISTED

1T23

I.T.E.

L R

INPUT

MTPT SV A

S-VIDEO OUTPUT

12V

0.5a MAX

DVD-RW/-RRECORDING

PrecisionCinemaProgressive

INPUT RGB

POWER

12V

0.5AMAX

MONOAUDIO

VID

Y/C

B-Y

R-Y

OUTPUTS

RS-232

TxRx SPACE

INPUT RGB

POWER

12V

0.5AMAX

VID

Y/C

OUTPUTS

MTP U R A

MONOAUDIO

COMPUTER IN

AUDIO IN

INPUT

AUDIO

MONITOR

POWER

12V

.5AMAX

OUTPUT

MTP T 1 5HD A

PRE-PEAK

OFF

TCP/IP

Network

Extr

MTP

X Plus 3232

isted Pair

Matrix

Swit

cher

Control

System

Extron

MTP T SV A

Transmitter

DVD

Sound System

Extron

MTP U R RSA SEQ

Universal Receiver

Extron

MTP U R

Universal

Receiver

Plasma / LCD

Display

Extron

MTP T 15HD A D

Transmitter

Extron

MTP T 15HD A

Transmitter

Rack

Mounted

LCD projecto

Monitor

Figure 1. Typical MTPX Plus Application

MTPX Plus Series Setup Guide • Introduction 2

NOTES:

• The receiver-to-transmitter serial communications and remote power capabilities

available with certain MTP models are not supported by this matrix switcher.

• For best results, use a cable length of at least 50 feet (15 m) between the TP inputs

and outputs and the transmitter and receiver.

The switcher inputs and outputs TP signals on RJ-45 connectors.

Three, four, or six (depending on the matrix size) 15-pin HD and 5-pole 3.5 mm direct

insertion input connectors are available for direct RGB (VGA) and stereo audio inputs

without an MTP transmitter.

NOTE: For most switchers, the available local inputs parallel the TP input of the same

number and either input can be used.

For the MTPX Plus 128, four inputs are local only and eight inputs are TP only.

Two, four, or eight (depending on the matrix size) 5-pole 3.5 mm captive screw ports are

available for direct mono audio outputs to an audio device without an MTP transmitter.

One or two (depending on the matrix size) 15-pin HD output connectors are available for

direct RGB (VGA) output to a video device without an MTP receiver.

NOTE:

• The direct input and direct output connectors can also support HD-YUV video, YUV

video, S-video, and composite video.

• For low resolution MTPs (S-video and composite video) on the TP inputs and

outputs, the MTPX Plus audio circuits are compatible only with the newer

generation, mono audio models. See the MTP transmitter/receiver manual to

determine which MTP models you have.

There are 4, 8, or 16 (depending on the matrix size) 3-pole 3.5 mm captive screw ports for

bidirectional RS-232 signal inserts. These signals, from a dedicated source (rather than from

the selected input), can be directly inserted into the signal set routed to the TP output.

The matrix switcher can be remotely controlled via an Ethernet LAN port, serial port, or USB

port (MTPX Plus 128 only) connection using either the Windows®-based Extron Matrix

Switchers Control Program or the Simple Instruction Set (SIS).
