Kramer VS-1616A Bedienungsanleitung

Kramer Electronics, Ltd.

USER MANUAL

Model:

VS-1616A

16x16 Balanced Stereo Audio Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

3Overview 2

4Your Balanced Stereo Audio Matrix Switcher 3

5Installing the VS-1616A in a Rack 6

6Installing the Balanced Stereo Audio Matrix Switcher 7

6.1 Connecting the Balanced/Unbalanced Stereo Audio Input/Output 7

6.2 Operating a Single Machine 8

6.3 Assembling a Multi-channel Audio Switcher 8

6.4 Assembling an Expanded Matrix Switcher 9

6.4.1 Assembling a 32x16 Switcher 10

6.4.2 Assembling a 32x32 Switcher 12

6.5 Assembling a System of Interconnected Switchers 14

6.6 Setting the DIP-switches 16

6.6.1 Setting the MACHINE # 16

6.6.2 Setting the MACHINE ADDRESS # 17

6.6.3 Understanding the SYSTEM Mode 17

6.6.4 Understanding the SLAVE Mode 18

6.7 Connecting a Control Interface 18

6.7.1 Connecting the RS-232 Control Interface 19

6.7.1.1 Connecting Two VS-1616As with a Null-modem Adapter 20

6.7.1.2Connecting Two VS-1616As without a Null-modem Adapter 20

6.7.1.3 Connecting to a 9-pin D-sub COM Port with a Null-modem Adapter 20

6.7.1.4 Connecting to a 9-pin D-sub COM Port without a Null-modem Adapter 21

6.7.1.5 Connecting to a 25-pin D-sub COM Port with a Null-modem Adapter 21

6.7.1.6 Connecting to a 25-pin D-sub COM Port without a Null-modem Adapter 21

6.7.2 Connecting the RS-485 Control Interface 22

6.8 Configuring the Sync 25

6.9 Connecting the KEYBOARD EXTENSION 25

7Operating Your Balanced Stereo Audio Matrix Switcher 26

7.1 Viewing the Startup Display 26

7.2 Using the Front Panel Buttons 27

7.2.1 Confirming the Settings 27

7.2.1.1 Toggling between the AT ONCE and CONFIRM Modes 28

7.2.2 Switching Inputs to Outputs 28

7.2.2.1 Switching One Input to One Output 28

7.2.2.2 Switching Several Inputs to Several Outputs 29

7.2.2.3 Switching One Input to All Outputs 30

7.2.3 Clearing Outputs 31

7.2.3.1 Clearing an Output 31

7.2.3.2 Clearing Several Outputs 32

7.2.3.3 Clearing All Outputs 33

7.2.4 Storing and Recalling Setups 33

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

7.2.4.1 Storing Setups 34

7.2.4.2 Recalling Setups 34

8Viewing the MENU Commands Sequence 35

8.1 Locking and Unlocking the Front Panel 37

8.2 Choosing the Follow-System or Breakaway-from-System Mode 38

8.3 Setting the MACHINE ADDRESS 40

8.3.1 Changing the MACHINE ADDRESS from Standalone to a Large Matrix 40

8.3.2 Changing the MACHINE ADDRESS from a Large Matrix to Standalone 42

8.3.3 Changing the a Large Matrix Setting MACHINE ADDRESS 42

8.4 Choosing the SWITCHING METHOD Setting 44

8.4.1 Understanding the SWITCHING METHOD Settings 44

8.4.2 Configuring a SWITCHING METHOD 45

8.5 Choosing the Extended Keyboard Setting 46

8.6 Setting the STORE/RECALL KEYBOARD Mode 46

8.7 Choosing What to INDICATE 47

8.8 Choosing the COMMUNICATION Setting 48

8.9 Setting the IR REMOTE Control 48

8.10 Choosing the AUTO STORE Current SETUP 50

8.11 Identifying the MACHINE 50

8.12 Choosing the Initial RESET 51

9Upgrading the Flash Memory 52

9.1 Connecting the PC to the RS-232 Port 52

9.2 Upgrading the Firmware 52

10 Technical Specifications 55

11 Communication Protocol 55

12 ASCII Protocol 57

12.1 Entering the ASCII Protocol 57

12.2 ASCII Command Description 57

Contents

iii

Figures

Figure 1: VS-1616A 16x16 Balanced Stereo Audio Matrix Switcher 4

Figure 2: Connecting the Balanced Stereo Audio Input/Output 7

Figure 3: Connecting the Unbalanced Stereo Audio Input 7

Figure 4: Connecting an Unbalanced Stereo Audio Output 7

Figure 5: DIP-Switch Setup on a Single Machine 8

Figure 6: Configuring a 4 Channel 16x16 Switcher with Two VS-1616A Switchers 9

Figure 7: MACHINE ADDRESS # Designation 10

Figure 8: The Principle of Assembling an Expanded Matrix Switcher 10

Figure 9: Connecting the 32x16 Switcher 12

Figure 10: Connecting the 32x32 Switcher 14

Figure 11: Assembling a System of Interconnected Switchers 15

Figure 12: Rear Panel DIP-switches 16

Figure 13: Connecting a PC to 4 VS-1616A Units 19

Figure 14: Connecting a PC (with a 25-pin connector) without a Null-modem Adapter 22

Figure 15: RS-485 Connector PINOUT 22

Figure 16: Connecting the RS-485 Connectors between 2 VS-1616A Units 23

Figure 17: An RS-485 Control Interface Setup 24

Figure 18: Keyboard Extension (EXT. KEYS) Connector 26

Figure 19: Default Startup Status Display Sequence 27

Figure 20: Sequence of MENU Commands 36

Figure 21: Choosing the MTX (SYNC from Matrix) Setting 45

Figure 22: Choosing what to INDICATE 47

Figure 23: Machine Identification 51

Tables

Table 1: Front Panel VS-1616A Features 5

Table 2: Rear Panel VS-1616A Features 5

Table 3: Quick Reference Operating Guide for a Single Machine 8

Table 4: DIP-Switch Definitions 16

Table 5: Machine # DIP-Switch Settings 17

Table 6: Summary of Basic RC-IR2 Setups 49

Table 7: Summary of Basic RC-IR2 Operations 49

Table 8: Technical Specifications of the VS-1616A Video Matrix Switcher 55

Table 9: Hex Table for the VS-1616A Video Matrix Switcher 56

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has

been providing a world of unique, creative, and affordable solutions to the

vast range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups1

Thank you for purchasing your Kramer VS-1616A 16x16 Balanced

Stereo Audio Matrix Switcher.

that are clearly

defined by function.

This product is ideal for the following typical applications:

•Professional display systems requiring audio signal routing

•Broadcast, presentation and production facilities

•Rental/staging applications

•Monitoring in large duplication systems

The package includes the following items:

•VS-1616A 16x16 Balanced Stereo Audio Matrix Switcher

•Power cord and “rack ears”

•Windows®-based Kramer control software

•Null-modem adapter

•This user manual2

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance high-resolution cables1

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The Kramer VS-1616A is a high-performance 16x16 Balanced Stereo

Audio Matrix Switcher for balanced audio stereo signals on detachable

terminal block connectors.

The VS-1616A forms part of the series of 16x16 matrix switchers that

includes the VS-162V(a 16x16 video matrix switcher).

In particular, the VS-1616A features:

•Balanced and unbalanced inputs and outputs

•True matrix operation, allowing the user to route any input to

any or all outputs simultaneously

•Excellent audio performance, which ensures that it remains

transparent in almost any audio application

In addition the VS-1616A:

•May be used as a single unit, or expanded to up to 96 x 96

inputs/outputs

•Can be configured into a Kramer multi-signal switcher system

including digital and analog video, digital and analog audio, and

RS-422 control switchers

•When integrated in a system, all units switch in true audio-

follow-video mode

•Recalls up to 99 configuration setups via the non-volatile

memory and provides for an unlimited quantity of setups when

using the Kramer control software on your PC

•Includes a user-friendly LCD display (making operation even

easier)

•With its FLASH memory, lets you upgrade to the latest Kramer

firmware version via Internet download

•Comes with a choice of protocol format: hexadecimal or ASCII

Control the VS-1616A:

•Using the front panel buttons

•Remotely, by RS-485 or RS-232 serial commands transmitted

by a touch screen system, PC, or other serial controller

•Remotely, from the Kramer RC-IR2 Infrared Remote Control

Transmitter

1 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Your Balanced Stereo Audio Matrix Switcher

•External IR receiver unit for controlling the machine via an IR

remote controller

•Via external contact closure push buttons

To achieve the best performance:

•Use only good quality connection cables1

•Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your

VS-1616A away from moisture, excessive sunlight and dust.

to avoid interference,

deterioration in signal quality due to poor matching, and

elevated noise levels (often associated with low quality cables).

4 Your Balanced Stereo Audio Matrix Switcher

Figure 1 illustrates the front and rear panels of the VS-1616A. Table 1

and Table 2 define the front and rear panels of the VS-1616A,

respectively.

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Balanced Stereo Audio Matrix Switcher

Figure 1: VS-1616A 16x16 Balanced Stereo Audio Matrix Switcher

Your Balanced Stereo Audio Matrix Switcher

Table 1: Front Panel VS-1616A Features

Feature

Function

1 IR Receiver The red LED is illuminated when receiving signals from the Kramer

Infra-red remote control transmitter

2 Power Switch Illuminated switch supplying power to the unit

3 ALL Button Pressing ALL followed by an INPUT button, connects that input to all

outputs

4 OFF Button An OFF-OUT combination disconnects that output from the inputs; an

OFF-ALL combination disconnects all the outputs

5 IN Buttons Select the input to switch to the output

6 OUT Buttons Select the output to which the input is switched

7 STO Button Stores the current setting in the non-volatile memory

8 RCL Button Recalls a setup from the non-volatile memory

9 LCD MATRIX Display1Displays the selected input(s) switched to the output(s) (above or below

the corresponding OUTPUT label) and user interface messages

10 LCD STATUS Display

Displays the matrix status

11 MENU Button Selects the programming commands to setup the switcher

12 TAKE LED Shows the current TAKE button mode aiding the completion of actions

13 TAKE Button Used to confirm and complete setup and switching

Table 2: Rear Panel VS-1616A Features

Feature

Function

14 IN Terminal Block Connectors Connect to the audio sources

15 OUT Terminal Block Connectors Connect to the balanced audio acceptors

16 EXTENSION / UNBALANCED OUT

Terminal Block Connectors Connect to the EXTENSION / UNBALANCED OUT

terminal block connectors on another unit, and/or to the

unbalanced audio acceptors

17 SYNC (IN and OUT) BNC Connectors Connect to daisy-chained video units for AFV setting

18 EXT. (extension) KEYS Terminal Block

Connectors Connects to an external keyboard (remote unit)

19 RS-485 Terminal Block Port Pins # 1 and # 2 are for vertical sync and Ground

connection, and Pins # 3 and # 4 are for RS-485

20 RS-232 IN 9-pin D-sub (F) Port Connects to the PC or the Remote Controller

RS-232 OUT 9-pin D-sub (M) Port Connects to the RS-232 IN 9-pin D-

sub (F) port of the next

unit in the daisy-chain connection

22 SETUP DIP-switches DIP-switches for setup of the unit

23 REMOTE IR 3.5mm Mini Jack Connect to an external IR receiver unit for controlling the

machine via an IR remote controller (instead of using the front

panel IR receiver)3

Power Connector with Fuse AC connector enabling power supply to the unit

1 In sections 7.2.4 and 8, the word “Displays” refers to the LCD MATRIX and STATUS Displays

2 If the unit is not the first unit in the line, connects to the RS-232 OUT 9-pin D-sub (F) port of the previous unit in the line

3 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the VS-1616A (only if the internal

IR connection cable has been installed)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Installing the VS-1616A in a Rack

5 Installing the VS-1616A in a Rack

This section describes how to install the VS-1616A in a rack.

Before Installing in a rack How to Rack Mount

Before installing in a rack, be sure that the environment is

within the recommended range: To rack-mount a machine:

1. Attach both ear brackets to the

machine. To do so, remove the

screws from each side of the

machine (5 on each side), and

replace those screws through the

ear brackets.

2. Place the ears of the machine

against the rack rails, and insert the

proper screws (not provided)

through each of the five holes in the

rack ears.

Note that:

•In some models, the front panel

may feature built-in rack ears

•Detachable rack ears can be

removed for desktop use

•Always mount the machine in the

rack before you attach any cables

or connect the machine to the

power

•If you are using a Kramer rack

adapter kit (for a machine that is not

19"), see the Rack Adapters user

manual for installation instructions

(you can download it at:

http://www.kramerelectronics.com)

Operating temperature range +5°to +45°C (41°to 113°F)

Operating humidity range 10 to 90% RHL, non-condensing

Storage temperature range -20°to +70°C (-4°to 158°F)

Storage humidity range 5 to 95% RHL, non-condensing

CAUTION!!

When installing on a 19" rack, avoid hazards by taking

care that:

1. It is located within the recommended environmental

conditions, as the operating ambient temperature of a

closed or multi unit rack assembly may exceed the

room ambient temperature.

2. Once rack mounted, enough air will still flow around

the machine.

3. The machine is placed straight in the correct

horizontal position.

4. You do not overload the circuit(s). When connecting

the machine to the supply circuit, overloading the

circuits might have a detrimental effect on overcurrent

protection and supply wiring. Refer to the appropriate

nameplate ratings for information. For example, for

fuse replacement, see the value printed on the

product label.

5. The machine is earthed (grounded) in a reliable way

and is connected only to an electricity socket with

grounding. Pay particular attention to situations where

electricity is supplied indirectly (when the power cord

is not plugged directly into the socket in the wall), for

example, when using an extension cable or a power

strip, and that you use only the power cord that is

supplied with the machine.

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer VS-44HDCP Bedienungsanleitung

Kramer

Kramer VP-1608 Bedienungsanleitung

Kramer

Kramer Sierra Video 4848V5SXL Bedienungsanleitung

Kramer

Kramer 88DE Bedienungsanleitung

Kramer

Kramer XL 1608V2S Bedienungsanleitung

Kramer

Kramer VS-2516 Bedienungsanleitung

Kramer

Kramer Sierra Video 1616V5S Bedienungsanleitung

Kramer

Kramer VS-66HDCPxl Bedienungsanleitung

Kramer

Kramer VS-84HN Bedienungsanleitung

Kramer

Kramer VP-8x8TP Bedienungsanleitung

Kramer

Kramer XL 1616V4 Bedienungsanleitung

Kramer

Kramer 88V5 Bedienungsanleitung

Kramer

Kramer AFM-20DSP-LE Bedienungsanleitung

Kramer

Kramer VP-27 Bedienungsanleitung

Kramer

Kramer XL 3216V2 Bedienungsanleitung

Kramer

Kramer VS-2042 Bedienungsanleitung

Kramer

Kramer VS-88HDCPxl Bedienungsanleitung

Kramer

Kramer VS-62HA Bedienungsanleitung

Kramer

Kramer Sierra Video 3232V3S Bedienungsanleitung

Kramer

Kramer VS-44H2 Bedienungsanleitung

Kramer

Kramer Sierra Video 3216V5 Bedienungsanleitung

Kramer

Kramer XL 1208V2S Bedienungsanleitung

Kramer

Kramer VS-4228 Bedienungsanleitung

Kramer

Kramer 3232S Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
