Kramer VS-169TP Bedienungsanleitung

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

VS-169TP

16x9 CAT 5 Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 2

2.4 Quick Start 3

3Overview 4

3.1 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 5

4Your VS-169TP 16x9 CAT 5 Matrix Switcher 5

4.1 Using the IR Transmitter 10

5Installing the VS-169TP in a Rack 11

5.1 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 12

6Connecting the VS-169TP 16x9 CAT 5 Matrix Switcher 12

6.1 Connecting the RS-232 Ports 15

6.1.1 Connect the Local RS-232 Ports 15

6.1.2 Connect the Control RS-232 Ports 15

6.2 Setting the DIP-switches 15

6.2.1 Setting the Machine # 16

7Control the VS-169TP 16x9 CAT 5 Matrix Switcher 17

7.1 Controlling via the RS-232 Interface 17

7.2 Controlling via the RS-485 Interface 18

7.3 Controlling via the ETHERNET 19

7.3.1 Connecting the ETHERNET Port directly to a PC (Crossover Cable) 19

7.3.2 Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 20

7.3.3 Control Configuration via the Ethernet Port 20

8Understanding the VS-169TP 16x9 CAT 5 Matrix Switcher 21

8.1 Transmitting the RS-232 Signal 21

9Operating the VS-169TP 16x9 CAT 5 Matrix Switcher 23

9.1 Switching Inputs #1 and #2 between local and remote 23

9.2 The STATUS 7-Segment Display 24

9.3 Switching an Input to an Output 24

9.3.1 Switching one Input to all Outputs 24

9.3.2 Clearing an Output 25

9.3.3 Clearing all the Outputs 25

9.4 Confirming Settings 26

9.4.1 Toggling between the At Once and Confirm Modes 26

9.4.2 Confirming a Switching Action 26

9.5 Storing/Recalling Input/Output Configurations 27

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

9.5.1 Storing an Input/Output Configuration 27

9.5.2 Recalling an Input/Output Configuration 27

9.6 Locking the Front Panel 28

9.7 Choosing the Follow or Breakaway Operation Mode 28

9.7.1 Follow Mode Operation 28

9.7.2 Breakaway Mode Operation 29

10 Flash Memory Upgrade 31

10.1 Switcher Firmware Upgrade 31

10.2 Ethernet Firmware Upgrade 31

10.2.1 Downloading from the Internet 31

10.2.2 Connecting the PC to the RS-232 Port 31

10.2.3 Upgrading Firmware 32

11 Technical Specifications 33

12 Hex Table 33

13 Kramer Protocol 2000 35

Figures

Figure 1: VS-169TP 16x9 CAT 5 Matrix Switcher Front Panel 6

Figure 2: VS-169TP 16x9 CAT 5 Matrix Switcher Rear Panel 8

Figure 3: CAT 5 PINOUT 12

Figure 4: Connecting the VS-169TP 16x9 CAT 5 Matrix Switcher 14

Figure 5: DIP-switch Settings 15

Figure 6: Controlling the VS-169TP via the RS-232 Interface 17

Figure 7: Controlling the VS-169TP via the RS-485 Interface 18

Figure 8: Local Area Connection Properties Window 19

Figure 9: Internet Protocol (TCP/IP) Properties Window 20

Figure 10: Switching an Input to an Output 22

Figure 11: Switching an Input to Several Outputs 22

Figure 12: MATRIX STATUS Display in the Follow Mode 23

Figure 13: 7-segment Display During Normal Operation 24

Figure 14: 7-segment Display Following Power ON 24

Figure 15: Operating in the RS-232 (Rx) Breakaway Mode 30

Figure 16: MATRIX STATUS Display in the RS-232 (Rx) Breakaway Mode 30

Figure 17: The KFR-Programmer Window 32

Tables

Table 1: VS-169TP 16x9 CAT 5 Matrix Switcher Front Panel Functions 7

Table 2: VS-169TP 16x9 CAT 5 Matrix Switcher Rear Panel Functions 9

Table 3: CAT 5 PINOUT 12

Table 4: DIP-switch Settings 15

Table 5: Machine # DIP-switch Settings 16

Table 6: VS-169TP Technical Specifications 33

Table 7: VS-169TP Hex Table 34

Contents

iii

Table 8: Protocol Definitions 35

Table 9: Instruction Codes for Protocol 2000 36

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups1

Thank you for purchasing the Kramer VS-169TP 16x9 CAT 5 Matrix Switcher.

This unique matrix switcher, which utilizes cheap twisted pair cabling often pre-

installed in buildings these days, routes and distributes signals both from a local

source and at extended ranges (via twisted pair). It is designed especially for

installations where a high level of control possibilities from extended distances is

required. Typical uses include presentation and multimedia applications, as well

as long-range graphics distribution and control for schools, hospitals, security,

and stores.

that are clearly defined by function.

The package includes the following:

•The VS-169TP 16x9 CAT 5 Matrix Switcher

•Kramer RC-IR2Infrared Remote Control Transmitter (including the

required battery and a separate user manual3)

•Windows®-based Kramer control software

•Power cord2, rack “ears”, and this user manual3

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Go to http://www.kramerelectronics.com to check for up-to-date user

manuals, application programs, and to check if firmware upgrades are

available (where appropriate).

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 We recommend that you use only the power cord supplied with this device

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality

•Position your VS-169TP away from moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be connected

to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution: There are no operator serviceable parts inside the unit

Warning: Use only the power cord that is supplied with the unit

Warning: Do not open the unit. High voltages can cause electrical

shock! Servicing by qualified personnel only

Warning: Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive

2002/96/EC aims to reduce the amount of WEEE sent for disposal to landfill

or incineration by requiring it to be collected and recycled. To comply with

the WEEE Directive, Kramer Electronics has made arrangements with the

European Advanced Recycling Network (EARN) and will cover any costs of

treatment, recycling and recovery of waste Kramer Electronics branded

equipment on arrival at the EARN facility. For details of Kramer’s recycling

arrangements in your particular country go to our recycling pages at

http://www.kramerelectronics.com/support/recycling/.

Getting Started

2.4 Quick Start

This quick start chart summarizes the basic setup and operation steps.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The VS-169TP is a high-performance matrix switcher for video signals up to

WUXGA/1080p, analog stereo / S/PDIF audio and bidirectional RS-232

signals, over twisted pair CAT 5 cable. The unit can route any input to any or

all outputs simultaneously.

More specifically, the VS-169TP features:

•Compatibility with most Kramer twisted pair transmitters/receivers

•16 inputs for remote connection to CAT 5 transmitters and eight outputs

for remote connection to CAT 5 receivers

•Two switchable local inputs (built-in transmitters) and one local output (a

built-in receiver) allowing direct connection of the signals (UXGA, audio

and RS-232) for the units located near to the switcher

•Follow or breakaway switching for all signals (UXGA, audio, RS-232)

•48kHz/24-bit analog/digital conversion for broadcast quality stereo audio

•Baud rate of up to 19,200 for full-duplex RS-232 together with audio; one

source to multiple destination for straight RS-232 signal and priority

system or user-defined destination for reply signal

•Four-line LCD display for separate route indication of video, audio, or

RS-232

•Control via front panel pushbuttons, RS-232, RS-485, IP and IR remote

control

•15 user-programmable presets for quick-change configurations

•Kramer 2000 communication protocol

•100-240V AC worldwide power supply

•Standard 19” rack mount size – 2U

Your VS-169TP 16x9 CAT 5 Matrix Switcher

3.1 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)

We recommend that you use shielded twisted pair (STP) cable. There are

different levels of STP cable available, and we advise you to use the best

quality STP cable that you can afford. Our non-skew-free cable, Kramer

BC-STP is intended for digital signals and for analog signals where skewing

is not an issue. For cases where there is skewing, our UTP skew-free cable,

Kramer BC-XTP, may be used. Bear in mind, though, that we advise using

STP cables where possible, since the compliance to electromagnetic

interference was tested using those cables.

Although unshielded twisted pair (UTP) cable might be preferred for long

range applications, the UTP cable should be installed far away from electric

cables, motors and so on, which are prone to create electrical interference.

However, since the use of UTP cable might cause inconformity to electromagnetic

standards, Kramer does not commit to meeting the standard with UTP cable.

4 Your VS-169TP 16x9 CAT 5 Matrix Switcher

Figure 1, Table 1, Figure 2and Table 2define the VS-169TP.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-169TP 16x9 CAT 5 Matrix Switcher

Figure 1: VS-169TP 16x9 CAT 5 Matrix Switcher Front Panel

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer VS-3232DVI Bedienungsanleitung

Kramer

Kramer 1608HDS Bedienungsanleitung

Kramer

Kramer VP-729 Bedienungsanleitung

Kramer

Kramer Sierra Video 1204V5S Bedienungsanleitung

Kramer

Kramer Sierra Video 1204V3 Bedienungsanleitung

Kramer

Kramer VS-88HDCPxl Bedienungsanleitung

Kramer

Kramer XL 1204V4S Bedienungsanleitung

Kramer

Kramer VS-48HDxl Bedienungsanleitung

Kramer

Kramer VS-808TP Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1616V3S Bedienungsanleitung

Kramer

Kramer LASSEN XL 3216S Bedienungsanleitung

Kramer

Kramer XL 1208V4S Bedienungsanleitung

Kramer

Kramer VS-44HDCP Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1616V5 Bedienungsanleitung

Kramer

Kramer VP-747 Bedienungsanleitung

Kramer

Kramer VS-3232DN Bedienungsanleitung

Kramer

Kramer VS-88DT Bedienungsanleitung

Kramer

Kramer VS-42HN Bedienungsanleitung

Kramer

Kramer VP-8x8TP Bedienungsanleitung

Kramer

Kramer Sierra Video 3264V5xl Bedienungsanleitung

Kramer

Kramer VS-8 Series Bedienungsanleitung

Kramer

Kramer VP-211DS Bedienungsanleitung

Kramer

Kramer Sierra Video 1608V3 Bedienungsanleitung

Kramer

Kramer Sierra Video 1616V5S Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
