Kramer VS-44HDMI Bedienungsanleitung

Kramer Electronics, Ltd.

USER MANUAL

Model:

VS-44HDMI

4 x 4 HDMI Matrix Switcher

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

3.1

Defining the EDID 3

3.2

About HDMI 4

3.3

Terminology Used in this User Manual 5

Your VS-44HDMI 4 x 4 HDMI Matrix Switcher 5

Installing the VS-44HDMI in a Rack 8

Connecting the VS-44HDMI 4 x 4 HDMI Matrix Switcher 9

Operating the VS-44HDMI 4 x 4 HDMI Matrix Switcher 10

7.1

Routing Inputs to Outputs 10

7.2

Disconnecting the Outputs 10

7.3

Storing and Recalling a Setting 10

7.4

Acquiring the EDID 11

7.4.1

Acquiring an EDID from a Single Connected Output 11

7.4.2

Acquiring an EDID from Several Sets of Inputs and Outputs 12

7.4.3

Acquiring an EDID from Several Connected Outputs Automatically 13

7.4.4

Acquiring the Default EDID 13

7.5

Controlling via RS-232 (for example, using a PC) 14

7.6

Controlling via ETHERNET 14

7.6.1

Connecting the ETHERNET Port directly to a PC (Crossover Cable) 14

7.6.2

Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 16

7.6.3

Control Configuration via the Ethernet Port 16

Technical Specifications 17

Hex Table 17

Kramer Protocol 2000 18

Figures

Figure 1: VS-44HDMI 4 x 4 HDMI Matrix Switcher Front and Rear Views 6

Figure 2: Connecting the VS-44HDMI 4 x 4 HDMI Matrix Switcher 9

Figure 3: Connecting a PC without using a Null-modem Adapter 14

Figure 4: Local Area Connection Properties Window 15

Figure 5: Internet Protocol (TCP/IP) Properties Window 16

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Tables

Table 1: Terminology Used in this User Manual 5

Table 2: VS-44HDMI 4 x 4 HDMI Matrix Switcher Front Panel Features 7

Table 3: VS-44HDMI 4 x 4 HDMI Matrix Switcher Rear Panel Features 7

Table 4: VS-44HDMI Technical Specifications 17

Table 5: VS-44HDMI Hex Codes for Switching via RS-232/RS-485 17

Table 6: Protocol Definitions 18

Table 7: Instruction Codes for Protocol 2000 19

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, and presentation

professional on a daily basis. In recent years, we have redesigned and

upgraded most of our line, making the best even better! Our 500-plus

different models now appear in eight groups

that are clearly defined by

function.

Thank you for purchasing the Kramer TOOLS VS-44HDMI 4 x 4 HDMI

Matrix Switcher, which is ideal for conference room presentations and

advertising applications, aswell asforrentalandstaging.

Each package includes the following items:

The VS-44HDMI 4 x 4 HDMI Matrix Switcher

Power cord

and Null-modem adapter

Windows

-based Kramer control software

Windows

-based Ethernet Configuration Manager and Virtual

Serial Port Manager

Kramer RC-IR1/2Infra-Red Remote Control Transmitter

(including the required batteries and a separate user manual

)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 We recommend that you use only the power cord supplied with this device

3 Downloadable from our Web site at http://www.kramerelectronics.com

4 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

5 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The VS-44HDMI is a high-quality 4x4 matrix switcher for HDMI signals

that features the following:

Up to 1.65Gbps bandwidth per graphic channel

Four input selector buttons to switch to the four selectable outputs

Support for HDCP (High Bandwidth Digital Content Protection)

An OFF button to disconnect an output

A PANEL LOCK button to prevent unwanted tampering with the

buttons on the front panel

1U-high, 19” size for mounting in a professional rack enclosure

The VS-44HDMI can be controlled using the front panel buttons, or

remotely via:

RS-232 serial commands transmitted by a touch-screen system,

PC, or other serial controller

The Kramer infra-red remote control transmitter

The ETHERNET

To achieve the best performance:

Use only good quality connection cables

to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables).

Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

VS-44HDMI away from moisture, excessive sunlight and dust

3.1 Defining the EDID

The EDID (Extended Display Identification Data

) is a data-structure,

provided by a display, to describe its capabilities to an HDMI source. The

EDID enables the VS-44HDMI to “know” what kind of monitor is

connected to the output. The EDID includes the name of the manufacturer,

the product type, the timing data supported by the display, the display size,

luminance data and (for digital displays only) the pixel mapping data.

1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

3 Defined by a standard published by the Video Electronics Standards Association (VESA)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.2 About HDMI

HDMI (High-Definition Multimedia Interface) is an uncompressed

all-digital

audio/video interface, widely supported in the entertainment and

home cinema industry. It delivers the highest high-definition image and

sound quality. Note that Kramer Electronics Limited is an HDMI Adopter

and an HDCP Licensee

HDMI features:

A simple

interface between any audio/video source, such as a

set-top box, DVD player, or A/V receiver and video monitor, such

as a digital flat LCD / plasma television (DTV), over a single

long

cable

A standard, enhanced, high-definition video, and multi-channel

digital audio

on a single cable

8-channel digital audio, with spare bandwidth to accommodate future

enhancements and compliance with all ATSC HDTV standards

Superior, uncompressed digital video quality via a single cable

and user-friendly connector

Backward-compatibility with DVI (Digital Visual Interface)

Two-way communication between the video source (such as a

DVD player) and the digital television, enabling new functionality

such as automatic configuration and one-button play

Support for existing high-definition video formats (720p, 1080i,

and 1080p/60), standard definition formats such as NTSC or PAL,

as well as 480p and 576p

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 See http://www.hdmi.org/about/adopters_founders.asp

3 See http://www.digital-cp.com/list/

4 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

5 HDMI technology has been designed to use standard copper cable construction at up to 15m

6 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

7 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Your VS-44HDMI 4 x 4 HDMI Matrix Switcher

3.3 Terminology Used in this User Manual

Table 1 defines some terms that are used in this user manual.

Table 1: Terminology Used in this User Manual

Term Definition

802.3 The standard specification for ETHERNET that is maintained by the Institute of

Electrical and Electronics Engineers (IEEE).

Dynamic Host Configuration

Protocol (DHCP)

Allows the network administrator to distribute IP addresses from a central point

and automatically send a new IP address when an Ethernet point is plugged into

a different network location

Gateway A network position serving as an entry to another network. On the Internet, a

node or stopping point can be either a gateway node or a host (end-point) node.

IP Address A 32-binary digit number that identifies each sender or receiver (within a network

via a particular server or workstation) of data (HTML pages or e-mails) that is

sent in packets across the Internet. Every device connected to an IP network

must have a unique IP address. This address is used to reference the specific

unit.

Local Area Network (LAN) Computers sharing a common communications line or wireless link, which often

share a server within a defined geographic area.

Media Access Control

(MAC) Address

A computer's unique hardware number (or address) in a LAN or other network.

On an Ethernet LAN, the (MAC) address is identical to the Ethernet address.

Transmission Control

Protocol/Internet Protocol

(TCP/IP)

The basic communication language or protocol of the Internet that breaks the

message into appropriately sized packets for the network, and can be used as a

communications protocol in an intranet or an extranet.

4 Your VS-44HDMI 4 x 4 HDMI Matrix Switcher

Figure 1, Table 2, and Table 3 define the unit.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-44HDMI 4 x 4 HDMI Matrix Switcher

Figure 1: VS-44HDMI 4 x 4 HDMI Matrix Switcher Front and Rear Views

Your VS-44HDMI 4 x 4 HDMI Matrix Switcher

Table 2: VS-44HDMI 4 x 4 HDMI Matrix Switcher Front Panel Features

# Feature Function

1 IR Receiver LED The red LED is illuminated when receiving signals from the Infra-red

remote control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 ALL Button Use ALL to select all inputs or all outputs (see section 7.1)

4 OFF Button Use OFF to disconnect one or all outputs (see section 7.2)

5 IN Buttons Press an INPUT selector button to select an input (from 1 to 4)

6 OUT Buttons Press an OUTPUT selector button to select an output (from 1 to 4)

7 STO Button Press to store an input setting

8 RCL Button Press to recall an input setting

9 LOCK Button Press to toggle disengaging the front panel buttons and to acquire the

EDID (see section 7.4)

10 EDID Button

Press to acquire the EDID

11 7-segment Display Displays the selected input switched to the output (marked above

each input)

Table 3: VS-44HDMI 4 x 4 HDMI Matrix Switcher Rear Panel Features

# Feature Function

12 IN HDMI Connectors Connect to the HDMI sources (from 1 to 4)

13 OUT HDMI Connectors Connect to the HDMI acceptors (from 1 to 4)

14 RS-232 DB-9F Port Connects to the PC or the RS-232 Remote Controller

15 ETHERNET Connector Connects to the PC or other Ethernet Controller

16 RESET Button Press the reset button to reset to the ETHERNET factory default

definitions

IP number 192.168.1.39

Mask – 255.255.255.0

Gateway – 192.168.1.1

17 REMOTE IR Connector Connect to an external IR receiver unit for controlling the machine via

an IR remote controller (instead of using the front panel IR receiver)

18 Power Connector with

Fuse

AC connector enabling power supply to the unit

1 Illuminates when configuring the EDID

2 First disconnect the power cord and then connect it again while pressing the RESET button. The unit will power up and load

its memory with the factory default definitions

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer VS-66HDMI Bedienungsanleitung

Kramer

Kramer VP-12x8 Bedienungsanleitung

Kramer

Kramer LASSEN XL 3232S Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1208V3S Bedienungsanleitung

Kramer

Kramer MTX3-88-SE Bedienungsanleitung

Kramer

Kramer 3216HDS Bedienungsanleitung

Kramer

Kramer VS-3232V Bedienungsanleitung

Kramer

Kramer VS-88HDxl Bedienungsanleitung

Kramer

Kramer VS-48HDCPxl Bedienungsanleitung

Kramer

Kramer VS-84HN Bedienungsanleitung

Kramer

Kramer XL 1204VS Bedienungsanleitung

Kramer

Kramer VS-84H Bedienungsanleitung

Kramer

Kramer VS-44HDXI Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1204V5S Bedienungsanleitung

Kramer

Kramer VS-8FDxl Bedienungsanleitung

Kramer

Kramer XL 1608V2S Bedienungsanleitung

Kramer

Kramer 3232HDS Bedienungsanleitung

Kramer

Kramer VS-62HA Bedienungsanleitung

Kramer

Kramer VS-84HN Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1608V3 Bedienungsanleitung

Kramer

Kramer Sierra Video 1204V5S Bedienungsanleitung

Kramer

Kramer AFM-20DSP-AEC Bedienungsanleitung

Kramer

Kramer 1608HDS Bedienungsanleitung

Kramer

Kramer VS-1616D Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
