Kramer VS-66H Bedienungsanleitung

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

VS-66H

6x6 HDMI Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 2

3Overview 3

3.1 Defining EDID 3

3.2 About HDMI 4

3.3 About HDCP 5

3.4 Recommendations for Best Performance 5

4Your VS-66H 6x6 HDMI Matrix Switcher 5

4.1 Using the IR Transmitter 8

5Installing the VS-66H on a Rack 9

6Connecting a VS-66H 6x6 HDMI Matrix Switcher 10

7Operating the VS-66H 6x6 HDMI Matrix Switcher 12

7.1 Switching an Input to an Output 12

7.2 Acquiring the EDID 12

7.2.1 Acquire an EDID from a Connected Output 12

7.2.2 Acquire an EDID from Several Sets of Inputs and Outputs 13

7.2.3 Acquire an EDID from Several Connected Outputs (Auto) 14

7.2.4 Acquire the Default EDID 14

7.3 Storing and Recalling a Setting 14

7.4 Connecting to the VS-66H via RS-232 15

7.5 Controlling via ETHERNET 15

7.5.1 Connecting the ETHERNET Port directly to a PC (Crossover Cable) 15

7.5.2 Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 17

8Technical Specifications 17

9Communication Parameters 17

10 Kramer Protocol 2000 18

Figures

Figure 1: VS-66H 6x6 HDMI Matrix Switcher 6

Figure 2: Connecting a VS-66H 6x6 HDMI Matrix Switcher 11

Figure 3: Local Area Connection Properties Window 16

Figure 4: Internet Protocol (TCP/IP) Properties Window 16

Tables

Table 1: VS-66H 6x6 HDMI Matrix Switcher Features 7

Table 2: Technical Specifications of the VS-66H 17

Table 3: Communication Parameters 17

Table 4: Protocol Definitions 18

Table 5: Instruction Codes for Protocol 2000 19

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1

Thank you for purchasing your Kramer VS-66H 6x6 HDMI Matrix Switcher.

that are clearly

defined by function.

Note, that the Kramer VS-66H is identical to the VS-66HDMI; just the

name has changed replacing the suffix “HDMI” by “H” (according to

the HDMI Guideline).

The VS-66H is ideal for conference room presentations and advertising

applications, as well as for rental and staging. Each package includes the

following items:

•VS-66H 6x6 HDMI Matrix Switcher

•Power cord and rack “ears”

•Windows®-based Kramer control software2

•Windows®-based Ethernet Configuration Manager and Virtual Serial

Port Manager

•Kramer RC-IR3Infrared Remote Control Transmitter (including the

required batteries and a separate user manual3)

•This user manual3

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables4

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Downloadable from our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Getting Started

KRAMER: SIMPLE CREATIVE TECHNOLOGY

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The VS-66H is a high quality 6x6 matrix switcher for HDMI signals.

In particular, the VS-66H features:

•Support for up to 1.65Gbps bandwidth per graphic channel1

•HDCP support (High Definition Digital Content Protection)

•I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent

EDID handling and processing algorithm that ensures Plug and Play

operation for HDMI systems

•An OFF button to disconnect an output

•A PANEL LOCK button to prevent unwanted tampering with the

buttons on the front panel

•12 preset memory locations for quick access to common configurations

•Installation into one vertical space of a standard 19” professional rack

enclosure

Control the VS-66H using the front panel buttons, or remotely via:

•RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

•The Kramer Infrared remote control transmitter

•The ETHERNET

•An external remote IR receiver (optional), see section 4.1

3.1 Defining EDID

The Extended Display Identification Data (EDID2

7.1

) is a data-structure,

provided by a display, to describe its capabilities to an HDMI source. The

EDID enables the VS-66H to “know” what kind of monitor is connected to

the output. The EDID includes the manufacturer’s name, the product type,

the timing data supported by the display, the display size, luminance data

and (for digital displays only) the pixel mapping data. See section for

details of how to acquire the EDID.

1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

2 Defined by a standard published by the Video Electronics Standards Association (VESA)

Overview

KRAMER: SIMPLE CREATIVE TECHNOLOGY

3.2 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all digital1

In particular, HDMI:

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the highest high-definition image and sound quality. Note

that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.

•Provides a simple2interface between any audio/video source, such as a

set-top box, DVD player, or A/V receiver and video monitor, such as a

digital flat LCD / plasma television (DTV), over a single lengthy3

•Supports standard, enhanced, high-definition video, and multi-channel

digital audio

cable

•Transmits all ATSC HDTV standards and supports 8-channel digital

audio, with bandwidth to spare to accommodate future enhancements

and requirements

on a single cable

•Benefits consumers by providing superior, uncompressed digital video

quality via a single cable5

•Is backward-compatible with DVI (Digital Visual Interface)

, and user-friendly connector

•Supports two-way communication between the video source (such as a

DVD player) and the digital television, enabling new functionality such

as automatic configuration and one-button play

HDMI has the capacity to support existing high-definition video formats

(720p, 1080i, and 1080p/60), as well as standard definition formats such as

NTSC or PAL.

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

3 HDMI technology has been designed to use standard copper cable construction at up to 15m

4 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

5 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Your VS-66H 6x6 HDMI Matrix Switcher

3.3 About HDCP

The High-Bandwidth Digital Content Protection (HDCP) standard

(developed by Intel), protects digital video and audio signals transmitted

over DVI or DVI connections between two HDCP-enabled devices to

eliminate the reproduction of copyrighted material. To protect copyright

holders (such as movie studios) from having their programs copied and shared,

the HDCP standard provides for the secure and encrypted transmission of

digital signals.

3.4 Recommendations for Best Performance

To achieve the best performance:

•Use only good quality connection cables1

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-66H

away from moisture, excessive sunlight and dust

to avoid interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables).

4 Your VS-66H 6x6 HDMI Matrix Switcher

Figure 1 and Table 1 define the VS-66H.

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

Your VS-66H 6x6 HDMI Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Figure 1: VS-66H 6x6 HDMI Matrix Switcher

Your VS-66H 6x6 HDMI Matrix Switcher

Table 1: VS-66H 6x6 HDMI Matrix Switcher Features

Feature

Function

1 IR Receiver The red LED lights when receiving signals from the Infrared remote

control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 ALL Button Pressing ALL before pressing an input button, connects that input to

all outputs1

OFF Button Pressing OFF after pressing an output button disconnects that output

from the inputs. To disconnect all the outputs,

press the ALL button and

then the OFF button

5 SELECT

Buttons2

OUT

Select the output to which the input is switched (from 1 to 6). The

selected button illuminates if an acceptor is connected

6 IN Select the input to switch to the output (from 1 to 6). The selected

button illuminates if a source is connected

7 STO Button Press to store an input setting (see section 7.3)

8 RCL Button Press to recall an input setting (see section 7.3)

9 LOCK Button Press to toggle disengaging the front panel buttons and to acquire

the EDID (see section 7.1)

10 EDID Button

Press to acquire the EDID (see section 7.1)

11 OUTPUT/ INPUT

LCD Display

Displays the selected input switched to the output (marked above

each input)

12 INPUT HDMI Connectors Connect to the HDMI sources (from 1 to 6)

13 OUTPUT HDMI Connectors Connect to the HDMI acceptors (from 1 to 6)

14 RS-232 9-pin D-sub Port Connects to the PC or other RS-232 Remote Controller

15 ETHERNET Connector Connects to the PC or other Ethernet Controller

16 RESET Button Press the ETHERNET factory reset button

to reset to the factory default

definitions 4

IP number −192.168.1.39

Mask – 255.255.255.0

Gateway – 192.168.1.1

17 REMOTE IR Opening

Connects to an external IR receiver unit

for controlling the machine via an

IR remote controller (instead of using the front panel IR receiver)

Power Connector with Fuse AC connector enabling power supply to the unit

1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

2 Are also used for storing machine setups (see section 7.3)

3 Illuminates when configuring the EDID

4 First turn the VS-66H OFF and then turn it ON again while pressing the RESET button. The unit will power up and load its

memory with the factory default definitions

5 Covered by a cap. The 3.5mm connector at the end of the internal IR connection cable fits through this opening

6 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the machine (only if the internal

IR connection cable has been installed)

Your VS-66H 6x6 HDMI Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

4.1 Using the IR Transmitter

You can use the RC-IR3IR transmitter to control the machine via the

built-in IR receiver on the front panel or, instead, via an optional external IR

receiver1. The external IR receiver can be located up to 15 meters away

from the machine. This distance can be extended to up to 60 meters when

used with three extension cables2

Before using the external IR receiver, be sure to arrange for your Kramer

dealer to insert the internal IR connection cable20F

3with the 3.5mm connector

that fits into the REMOTE IR opening on the rear panel. Connect the

external IR receiver to the REMOTE IR 3.5mm connector.

1 Model: C-A35M/IRR-50

2 Model: C-A35M/A35F-50

3 P/N: 505-70434010-S

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer VS-44HD Bedienungsanleitung

Kramer

Kramer 1608HDS Bedienungsanleitung

Kramer

Kramer XL 1616V Bedienungsanleitung

Kramer

Kramer VP-725DS Bedienungsanleitung

Kramer

Kramer Sierra Video 4864V5Sxl Bedienungsanleitung

Kramer

Kramer Sierra Video 1608V3S Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1208V3 Bedienungsanleitung

Kramer

Kramer VS-88UHD Bedienungsanleitung

Kramer

Kramer VS-48HN Bedienungsanleitung

Kramer

Kramer VP-8x4 Bedienungsanleitung

Kramer

Kramer VS-44DT Bedienungsanleitung

Kramer

Kramer VS-42H2 Bedienungsanleitung

Kramer

Kramer XL 3216VS Bedienungsanleitung

Kramer

Kramer VS-44UHD Bedienungsanleitung

Kramer

Kramer XL 1608V4 Bedienungsanleitung

Kramer

Kramer VS-88DVI Bedienungsanleitung

Kramer

Kramer VS-42H2 Bedienungsanleitung

Kramer

Kramer VS-3232D Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1208V3S Bedienungsanleitung

Kramer

Kramer Sierra Video 6448V5Sxl Bedienungsanleitung

Kramer

Kramer 88DS Bedienungsanleitung

Kramer

Kramer Sierra Video 3264V5xl Bedienungsanleitung

Kramer

Kramer VS-62H Bedienungsanleitung

Kramer

Kramer VS-44HN Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
