Kramer VSM-4x4X Bedienungsanleitung

P/N: 2900-301565 Rev 1 www.kramerAV.com

USER MANUAL

MODEL:

VSM-4x4X

4K 4x4 Seamless Matrix

Switcher/Multi-Scaler

Kramer Electronics Ltd.

VSM-4x4X –Contents
i

Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Defining VSM-4x4X 4
Mounting VSM-4x4X 6
Connecting VSM-4x4X 7
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor 8
Connecting to VSM-4x4X via RS-232 8
Operating VSM-4x4X Via the Front Panel Buttons 9
Storing and Recalling a Preset 9
Switching an Input to an Output in the Matrix Mode 10
Selecting a Multi-View Mode Configuration 10
Selecting a Video Wall Configuration 11
Operating via Ethernet 13
Using Embedded Web Pages 16
Defining AV Settings 17
Operating and Controlling in the Matrix Mode 22
Operating and Controlling in the Multi-View Mode 23
Operating and Controlling the Video Wall Mode 40
Managing EDID 44
Defining General Settings 45
Defining Interface Settings 48
Defining VSM-4x4X User Access 49
Viewing the About Page 51
Upgrading the Firmware 52
Technical Specifications 53
Default Communication Parameters 54
Default EDID 54
Protocol 3000 57
Understanding Protocol 3000 57
Protocol 3000 Commands 58
Result and Error Codes 76

Kramer Electronics Ltd.

VSM-4x4X –Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

•Review the contents of this user manual.

Go to www.kramerav.com/downloads/VSM-4x4X to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving Best Performance

•Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

•Do not secure the cables in tight bundles or roll the slack into tight coils.

•Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

•Position your Kramer VSM-4x4X away from moisture, excessive sunlight and dust.

Safety Instructions

Caution:

•This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

•For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

•There are no operator serviceable parts inside the unit.

Warning:

•Use only the power cord that is supplied with the unit.

•Disconnect the power and unplug the unit from the wall before installing.

•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified

personnel only.

•To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which is located on the bottom of the unit.

Kramer Electronics Ltd.

VSM-4x4X –Introduction

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce

the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected

and recycled. To comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN) and will cover any

costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on

arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular

country go to our recycling pages at www.kramerav.com/il/quality/environment.

Overview

Congratulations on purchasing your Kramer VSM-4x4X 4K 4x4 Seamless Matrix

Switcher/Multi-Scaler. The VSM-4x4X is a 4X4 seamless matrix switcher that can also be

used as a video wall driver (2X2 or 1X4), a quad-viewer, or a 4 picture multi-viewer. The unit

allows instantaneous switching between inputs (that is, with a clean, frame-to-frame video

cut). The VSM-4x4X supports HDMI 2.0 and HDCP 2.2, with resolutions up to 4K60 4:4:4,

per-port HDCP and EDID settings, passing of 4 channels of embedded audio, and analog

stereo de-embedded audio for each of the 4 outputs.

VSM-4x4X provides exceptional quality, advanced and user-friendly operation, and flexible

connectivity.

Exceptional Quality

•PixPerfect™Scaling Technology –Kramer’s precision pixel mapping and high quality

scaling technology.

•Matrix Switching Modes –Truly seamless switching mode (zero-time video cuts), or

fade-through-black mode (enabling independent output resolutions).

•Built-in ProcAmp –Color, hue, sharpness, noise, contrast and brightness.

•Multiple Aspect Ratio Selections –Full, 4:3, 16:9 and best fit.

•4 Preset Memory Locations –For each operation mode for quick access to common

IN-OUT configurations.

•Non-Volatile Memory –Saves final settings.

•Built-in noise reduction and picture enhancement features.

•HDMI Support –4K@60Hz, Deep Color, x.v.Color™, 7.1 PCM, Dolby TrueHD, DTS-HD,

as specified in HDMI 2.0.

Advanced and User-friendly Operation

•Selectable Operation Modes –4x4 matrix switcher, video wall (2x2 or 1x4 configuration),

multi-view display Split, Side-by-Side, PIP, POP, Stacked or Quad display.

•Bezel Correction Options –In video wall mode.

•Constant Output Sync –For all modes of operation.

•Multiple aspect ratio selections.

Kramer Electronics Ltd.

VSM-4x4X –Introduction

•STO, RCL and IDENTIFY buttons, a RESET TO XGA/1080P button (to hardware-reset

the output resolution) and a PANEL LOCK button.

•Built-in video Proc-Amp –color, hue, sharpness, contrast, and brightness are set

individually for each input.

•Firmware Upgrade –Ethernet-based, via a user-friendly software upgrade tool.

•Advanced EDID management per input.

•Includes non-volatile memory that retains the last settings, after switching the power off

and then on again.

Flexible Connectivity

•4 HDMI Inputs and 4 Scaled HDMI Outputs.

•4 balanced audio outputs with independent volume settings per output, embedded audio

on the HDMI inputs and outputs.

Typical Applications

VSM-4x4X is ideal for the following typical applications:

•Presentation and multimedia.

•Projection systems in conference rooms, boardrooms, auditoriums, hotels and churches,

production studios, rental and staging.

•Video wall: large signage applications in public places.

•Any application where high quality conversion and switching of multiple and different

video signals to graphical data signals is required for display or projection purposes.

Controlling your VSM-4x4X

Control your VSM-4x4X directly via the front panel push buttons (with on-screen menus, or:

•Via the Ethernet using built-in user-friendly Web pages.

•By RS-232 serial commands transmitted by a touch screen system, PC, or other serial

controller.

•Remotely, from the infrared remote control transmitter.

Kramer Electronics Ltd.

VSM-4x4X –Defining VSM-4x4X

Defining VSM-4x4X

This section defines VSM-4x4X.

Figure 1: VSM-4x4X 4K 4x4 Seamless Matrix Switcher/Multi-Scaler Front Panel

Feature

Function

IN SELECTOR

Buttons

Press to select an HDMI input (from 1 to 4) to switch to an output or a

window.

Press together with STO/RCL buttons to store a configuration and recall it

when required (see Storing and Recalling a Preset on page 9).

OUT SELECTOR

Buttons

In the MATRIX mode: select the output to which the input is switched (A, B,

C or D).

In the VIDEO WALL mode: not used.

In the MULTI-VIEW mode: select the input for each window on the display.

ALL Button

Press ALL followed by an INPUT button to connect that input to all the

outputs (not available for the video wall mode).

OFF Button

Press after pressing an output button to disconnect the selected output

from the inputs. To disconnect all the outputs, press ALL followed by OFF.

MATRIX Mode

Press to operate the system as a matrix switcher.

VIDEO-WALL Mode

Press to operate as a video wall.

2x2

Configure a 2x2 video wall.

1x4

Configure a 1x4 video wall.

MULTI-VIEW Mode

Press to operate in multi-view configurations:

Quad

4 windows filling the display.

PiP

1 window over a background image.

2 windows over a background image.

3 windows over a background image.

Stacked

4 images, overlapping (maintaining aspect ratio).

PoP

2 images, side-by-side (maintaining aspect ratio).

2 images, displayed as a split-screen (elongated

images).

1 large window and 3 smaller images on the side

(maintaining aspect ratio).

RCL Button

Press, followed by an input button, to recall a configuration.

STO Button

Press, followed by an input button, to store a configuration.

IDENTIFY Button

Press to indicate which input is displayed on each output or window.

RESET TO

XGA/1080p Button

Press and hold for about 5 seconds to toggle resetting the video resolution

to XGA or 1080p.

PANEL LOCK

Button

Press and hold for about 5 seconds to toggle locking the front panel

buttons.

Kramer Electronics Ltd.

VSM-4x4X –Defining VSM-4x4X

Figure 2: VSM-4x4X 4K 4x4 Seamless Matrix Switcher/Multi-Scaler Rear Panel

Feature

Function

HDMI INPUT Connectors

Connect to the HDMI sources (from 1 to 4).

HDMI OUTPUT Connectors

Connect to HDMI acceptors (from A to D).

AUDIO OUT 5-pin Terminal

Block Connector

Connect to a balanced audio acceptor (from 1 to 4).

RESET Recessed button

Press and hold while powering the device to reset to factory default

parameters.

ETHERNET Connector

Connect to the PC or other Serial Controller through computer

networking.

RS-232 3-pin Terminal Block

Connector

Connect to the PC or a remote controller.

Mains Power Connector,

Fuse and Switch

Connect to the mains supply and use the switch to turn the unit on

or off.

Kramer Electronics Ltd.

VSM-4x4X –Mounting VSM-4x4X

Mounting VSM-4x4X

This section provides instructions for mounting VSM-4x4X. Before installing, verify that the

environment is within the recommended range:

•Operation temperature –0to 40C (32 to 104F).

•Storage temperature –-40to +70C (-40 to +158F).

•Humidity –10% to 90%, RHL non-condensing.

Caution:

•Mount VSM-4x4X before connecting any cables or power.

Warning:

•Ensure that the environment (e.g., maximum ambient temperature & air flow) is

compatible for the device.

•Avoid uneven mechanical loading.

•Appropriate consideration of equipment nameplate ratings should be used for avoiding

overloading of the circuits.

•Reliable earthing of rack-mounted equipment should be maintained.

Mount VSM-4x4X in a rack:

•Attach both rack ears by removing the screws from each

side of the machine and replacing those screws through

the rack ears.

Kramer Electronics Ltd.

VSM-4x4X –Connecting VSM-4x4X

Connecting VSM-4x4X

Always switch off the power to each device before connecting it to your VSM-4x4X. After

connecting your VSM-4x4X, connect its power and then switch on the power to each device.

Figure 3: Connecting to the VSM-4x4X Rear Panel

To connect VSM-4x4X as illustrated in the example in Figure 3:

1. Connect up to 4 HDMI sources (for example, a Blu-ray player, a set top box, a work

station, and so on) to the HDMI INPUT connectors .

2. Connect the 4 HDMI outputs to up to four HDMI acceptors (for example, displays).

3. Connect the 4 AUDIO OUT 5-pin terminal block connectors to to up to 4 balanced

stereo audio acceptors (for example, Kramer active speakers).

4. Connect the ETHERNET RJ-45 port to a control system.

5. Connect the RS-232 3-pin terminal block connector to a laptop.

6. Connect the power to the mains electricity (not shown in Figure 3).

Kramer Electronics Ltd.

VSM-4x4X –Connecting VSM-4x4X

Connecting the Output to a Balanced/Unbalanced

Stereo Audio Acceptor

The following are the pinouts for connecting the output to a balanced or unbalanced stereo

audio acceptor:

Figure 4: Connecting to a Balanced Stereo Audio

Acceptor

Figure 5: Connecting to an Unbalanced Stereo Audio

Acceptor

Connecting to VSM-4x4X via RS-232

You can connect to VSM-4x4X via an RS-232 connection using, for example, a PC.

VSM-4x4X features an RS-232 3-pin terminal block connector allowing the RS-232 to control

VSM-4x4X.

Connect the RS-232 terminal block on the rear panel of VSM-4x4X to a PC/controller, as

follows:

From the RS-232 9-pin D-sub serial port connect:

•Pin 2 to the TX pin on the VSM-4x4X RS-232 terminal

block

•Pin 3 to the RX pin on the VSM-4x4X RS-232 terminal

block

•Pin 5 to the G pin on the VSM-4x4X RS-232 terminal block

RS-232 Device VSM-4x4X

Andere Handbücher für VSM-4x4X

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer VS-622DT Bedienungsanleitung

Kramer

Kramer ASPEN-32UFX Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1208V5 Bedienungsanleitung

Kramer

Kramer VS-1616DN-MD Bedienungsanleitung

Kramer

Kramer VP-4x8 Bedienungsanleitung

Kramer

Kramer AFM-20DSP-LE Bedienungsanleitung

Kramer

Kramer XL 1616V4S Bedienungsanleitung

Kramer

Kramer VS-4216 Bedienungsanleitung

Kramer

Kramer VS-48HN Bedienungsanleitung

Kramer

Kramer 3232DS Bedienungsanleitung

Kramer

Kramer 3232DEE Bedienungsanleitung

Kramer

Kramer VP-32XLN Bedienungsanleitung

Kramer

Kramer VS-66HDCPxl Bedienungsanleitung

Kramer

Kramer XL 3216VS Bedienungsanleitung

Kramer

Kramer Sierra Video 4864V5xl Bedienungsanleitung

Kramer

Kramer XL 1608V4 Bedienungsanleitung

Kramer

Kramer VS-44HDCP Bedienungsanleitung

Kramer

Kramer VS-44FO Bedienungsanleitung

Kramer

Kramer BC/VS-2216 Bedienungsanleitung

Kramer

Kramer Sierra Video 3216V3S Bedienungsanleitung

Kramer

Kramer VS-6464DN-EM Bedienungsanleitung

Kramer

Kramer Sierra Video 1616V3S Bedienungsanleitung

Kramer

Kramer Sierra Video 84V3 Bedienungsanleitung

Kramer

Kramer VS-6EIII Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
