Kramer DigiTOOLS 6410N Bedienungsanleitung

Kramer Electronics, Ltd.

USER MANUAL







Models:

6410N,

Digital to Analog Audio Converter

6420N,

Analog to Digital Audio Converter

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

3.1

Digital Audio Inputs/Outputs on the 6410N and 6420N 3

3.2

About the 6410N 4

3.3

About the 6420N 5

3.4

Recommendations for Achieving the Best Performance 5

Your Audio Converters 5

4.1

Your 6410N Digital to Analog Audio Converter 6

4.1.1

The 6410N Underside 7

4.2

Your 6420N Analog to Digital Audio Converter 8

4.2.1

The 6420N Underside 9

Using the Audio Converters 10

5.1

Connecting the 6410N Digital to Analog Audio Converter 10

5.1.1

Using the INPUT SELECTOR Switches 11

5.2

Connecting the 6420N Analog to Digital Audio Converter 12

Technical Specifications 14

Figures

Figure 1: Professional and Consumer Inputs/Outputs on the 6410N / 6420N 3

Figure 2: 6410N Digital to Analog Audio Converter 6

Figure 3: 6410N Digital to Analog Audio Converter Underside 7

Figure 4: 6420N Analog to Digital Audio Converter 8

Figure 5: 6420N Analog to Digital Audio Converter Underside 9

Figure 6: Connecting the 6410N Digital to Analog Audio Converter 11

Figure 7: Connecting the 6420N Analog to Digital Audio Converter 13

Tables

Table 1: 6410N Digital to Analog Audio Converter Features 6

Table 2: Selecting the Input on the 6410N 6

Table 3: 6410N Digital to Analog Audio Converter Underside Features 7

Table 4: 6410N Input Signal and Gain 8

Table 5: 6420N Analog to Digital Audio Converter Features 8

Table 6: 6420N Analog to Digital Audio Converter Underside Features 9

Table 7: 6410N Digital to Analog Audio Converter Technical Specifications 14

Table 8: 6420N Analog to Digital Audio Converter Technical Specifications 14

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer DigiTOOLS 6410N Digital to

Analog Audio Converter and/or 6420N Analog to Digital Audio Converter.

These products are ideal for:

Audio broadcast and production studios

Non-linear editing studios

Multimedia and presentation format conversion

Diagnostics of audio equipment during field operation

The package includes the following items:

6410N Digital to Analog Audio Converter and/or 6420N Analog to

Digital Audio Converter

Power adapter(s)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

Both the 6410N Digital to Analog Audio Converter and the 6420N Analog to

Digital Audio Converter use digital audio transmission standards, as section

3.1 describes.

This section summarizes:

The 6410N (see section 3.2)

The 6420N (see section 3.3)

Recommendations for achieving the best performance (see section 3.4)

3.1 Digital Audio Inputs/Outputs on the 6410N and 6420N

Figure 1 illustrates the transmission standards for professional and consumer

formats, which can be translated via the 6410N/6420N.

AES 75



AES / EBU

Digital Audio Transmission Inputs/Outputs

Figure 1: Professional and Consumer Inputs/Outputs on the 6410N / 6420N

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.2 About the 6410N

The 6410N is a high performance format converter for digital audio signals. It

converts AES/EBU, AES-ID3, S/PDIF or Toslink® optical digital audio

signals simultaneously

to:

Analog balanced stereo on detachable terminal block connectors

Unbalanced stereo on a 3.5” jack, capable of driving a 32load

(headphones)

In particular, the 6410N:

Supports multi-standards - AES/EBU, IEC 958, S/PDIF and EIAJ

CP340/1201 professional and consumer formats with sampling

frequencies up to 96kHz

Provides automatic equalization and reclocking of the digital audio stream

coming from any digital input

Automatically detects the sample rate of the digital input, ranging from

32kHz to 96kHz

Features selectable conversion ratio (D/A) settings: 0dBFS to +12dB,

+16dB, +20dB or +24dB

Has an S/N Ratio of over 88dB

Has AES/EBU and AES-ID3 transformer coupled inputs

The 6410N is 12VDC fed and is housed in a DigiTOOLS enclosure.

1 As Figure 6 illustrates, the sound outputs from both the amplifier and the headphones simultaneously

Your Audio Converters

3.3 About the 6420N

The 6420N is a high performance format converter for balanced audio

signals. It converts two channels of balanced audio signals to AES/EBU,

AES-ID3, S/PDIF and TOSlink® optical digital outputs simultaneously.

In particular, the 6420N:

Supports multi-standards - AES/EBU, IEC 958, S/PDIF and EIAJ

CP340/1201 professional and consumer formats with sampling

frequencies up to 96kHz

With its analog balanced stereo audio input signal, splits to four digital

audio output signals

, available in all the possible digital audio interfaces

Features selectable sampling frequencies of 32k, 44.1k, 48k, or 96k

Features selectable gain ratio (A/D) settings: -12dB, -16dB, -20dB or -24dB

to 0dBFs

Features selectable digital audio system bits (professional or consumer)

Has AES/EBU and AES-ID3 transformer coupled outputs

The 6420N is 12VDC fed and is housed in a DigiTOOLS enclosure.

3.4 Recommendations for Achieving the Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise-

levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position your

Kramer 6410N/6420N away from moisture, excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

4 Your Audio Converters

Sections 4.1 and 4.2 define the 6410N Digital to Analog Audio Converter and

the 6420N Analog to Digital Audio Converter, respectively.

1 Functioning as a 1:4 DA

2 For example: model number AD2512C, part number 2535-000251

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Audio Converters

4.1 Your 6410N Digital to Analog Audio Converter

Figure 2 and Table 1 define the 6410N Digital to Analog Audio Converter:

Figure 2: 6410N Digital to Analog Audio Converter

Table 1: 6410N Digital to Analog Audio Converter Features

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 AES 75BNC Connector Connect to the digital audio source

3 AES / EBU Detachable

Terminal Block Connector

Connect to the digital audio source

4 S/PDIF RCA Connector Connect to the digital audio source

DIGITAL

INPUTS

OPTICAL Toslink® Optical

Connector

Connect to the digital audio source

6 ANALOG

OUT

LEFT and RIGHT

Detachable Terminal Block

Connectors

Connect to the analog audio acceptor

7 A Push Button

INPUT

SELECTOR

B Push Button

Press A and B buttons (as detailed on side panel) to

select the input (see Table 2)

9 LINK LED Illuminates when receiving the appropriate input signal

10 VOLUME Control Knob Rotate to adjust the headphones output signal level

11 PHONES Out Connector Connects to a headphone set

12 ON LED Illuminates when receiving power

Table 2: Selecting the Input on the 6410N

Press A and press B to select:

IN IN AES/EBU

OUT IN AES 75



IN OUT S/PDIF

OUT OUT OPTICAL

Your Audio Converters

4.1.1 The 6410N Underside

Figure 3 and Table 3 define the 6410N underside:

Figure 3: 6410N Digital to Analog Audio Converter Underside

Table 3: 6410N Digital to Analog Audio Converter Underside Features

Feature Function

Set the dipswitches as follows to determine the RIGHT channel

conversion ratio

(GAIN CONTROL):

Gain Control: DIP 1 DIP 2 DIP 3 DIP 4

+24dB ON OFF OFF OFF

+20dB OFF ON OFF OFF

+16dB OFF OFF ON OFF

RIGHT

+12dB OFF OFF OFF ON

Set the dipswitches as follows to determine the LEFT channel conversion

ratio

(GAIN CONTROL):

Gain Control: DIP 5 DIP 6 DIP 7 DIP 8

+24dB ON OFF OFF OFF

+20dB OFF ON OFF OFF

+16dB OFF OFF ON OFF

GAIN

CONTROL

Dipswitches

LEFT

+12dB OFF OFF OFF ON

1 From digital to analog

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Audio Converters

Table 4 shows an example of the relation between the input signal, the

selected gain and the THD + N.

Table 4: 6410N Input Signal and Gain

Vinput [vrms] Gain [dB] THD + N [dB] @1kHz

1 +12 -94

1 +16 -95

1 +20 -94

0.7 +24 -90

4.2 Your 6420N Analog to Digital Audio Converter

Figure 4 and Table 5 define the 6420N Analog to Digital Audio Converter:

Figure 4: 6420N Analog to Digital Audio Converter

Table 5: 6420N Analog to Digital Audio Converter Features

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 AES 75BNC connector Connect to the digital audio acceptor

3 AES / EBU Detachable

Terminal Block Connector

Connect to the digital audio acceptor

4 S/PDIF RCA Connector Connect to the digital audio acceptor

DIGITAL

OUTPUTS

OPTICAL Toslink® Optical

Connector

Connect to the digital audio acceptor

6 ANALOG

INPUTS

LEFT and RIGHT

Detachable Terminal Block

Connectors

Connect to the analog audio source

7 MODE SELECTOR Dipswitches Set a dipswitch to ON to choose the appropriate

sample rate frequency

8 ON LED Illuminates when receiving power

Andere Handbücher für DigiTOOLS 6410N

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kramer Medienkonverter Handbücher

Kramer

Kramer FC-331 Bedienungsanleitung

Kramer

Kramer VP-440H2 Bedienungsanleitung

Kramer

Kramer VP-425 Bedienungsanleitung

Kramer

Kramer KDS-EN6 Bedienungsanleitung

Kramer

Kramer VM-80VN Bedienungsanleitung

Kramer

Kramer FC-6801 Bedienungsanleitung

Kramer

Kramer DigiTOOLS 7508 Bedienungsanleitung

Kramer

Kramer FC-10 Bedienungsanleitung

Kramer

Kramer VM-2DVI Bedienungsanleitung

Kramer

Kramer VP-426C Bedienungsanleitung

Kramer

Kramer KDS-SW2-EN7 Bedienungsanleitung

Kramer

Kramer VP-419XL Bedienungsanleitung

Kramer

Kramer VM-2HDCPxl Bedienungsanleitung

Kramer

Kramer VM-4H Bedienungsanleitung

Kramer

Kramer VP-429H2 Bedienungsanleitung

Kramer

Kramer FC-321 Bedienungsanleitung

Kramer

Kramer DigiTOOLS VM-2HDCP Bedienungsanleitung

Kramer

Kramer VM-2DH Bedienungsanleitung

Kramer

Kramer FC-7402 Bedienungsanleitung

Kramer

Kramer KDS-100EN Bedienungsanleitung

Kramer

Kramer VP-460 Bedienungsanleitung

Kramer

Kramer VP-410 Bedienungsanleitung

Kramer

Kramer FC-69 Bedienungsanleitung

Kramer

Kramer VM-4UX Bedienungsanleitung

Beliebte Medienkonverter Handbücher anderer Marken

SoundTraxx

SoundTraxx Blunami BLU-2200 Bedienungsanleitung

SPROLINK

SPROLINK VA1 Bedienungsanleitung

Acclaim Lighting

Acclaim Lighting DDC-1-AC Bedienungsanleitung

Nikon

Nikon AF-S TC-20E III Bedienungsanleitung

Axis

Axis AXIS Q7406 Bedienungsanleitung

Omega

Omega TAC80B-J Bedienungsanleitung

Zoom

Zoom Thunderbolt TAC-2R Bedienungsanleitung

OST

OST iConverter 10/100M Bedienungsanleitung

Vertiv

Vertiv Netsure Bedienungsanleitung

birddog

birddog MINI Bedienungsanleitung

Roland

Roland GI-10 Bedienungsanleitung

Wallenstein

Wallenstein WX310 Bedienungsanleitung

Pace

Pace MSS 200-1 Bedienungsanleitung

Solar Converters

Solar Converters EQ 12/24-50 Bedienungsanleitung

CYP

CYP EL-7400V Bedienungsanleitung

TIE

TIE MIDI 1i1o Bedienungsanleitung

DCS

DCS Vivaldi Upsampler Bedienungsanleitung

Westermo

Westermo MCW-211 SERIES Bedienungsanleitung
