Front Panel

Front Panel Quick Reference

1-1

Chapter 1

Front Panel

Front Panel Quick Reference

This section describes features that, unless speciÞed otherwise, are common to both the rack

versions of the K2600 (K2600R and K2600RS) as well as the keyboard versions of the K2600

(K2600, K2600S, K2600X, and K2600XS). The buttons and sliders that are unique to the keyboard

models are described on page 1-4.

Navigation Data Entry

Mode Selection

Control

Navigation Data Entry

Mode Selection Audio Inputs

LCD contrast Disk Drive

Power switch MIDI LED

1-2

Front Panel

Front Panel Quick Reference

Volume Knob/ Slider

Controls mixed audio outputs and headphone jack only. Does not send MIDI Volume (MIDI 07).

Mode Buttons

Press any of these eight buttons to enter the corresponding mode.

Chan/Bank Buttons

Scroll through the layers of the current program while in the Program Editor. Scroll through the

zones in the current setup while in Setup mode. Scroll through the Quick Access banks while in

Quick Access mode.

Edit Button

Functional in most modes. Press

Edit

to modify the currently selected object or parameter. If itÕs

not editable, pressing

Edit

will do nothing.

There are editors available from every mode but Disk mode. The effect of pressing

Edit

in each

of the modes is listed below.

When in this

mode Pressing the Edit button…

Program mode …enters the Program Editor, where you can edit the currently selected

program.Chapter 6 in the

Musician’s Guide

covers the Program Editor.

Setup mode …enters the Setup Editor, where you can edit the currently selected setup.

Chapter 7 in the

Musician’s Guide

describes the Setup Editor.

Quick Access mode …enters the Quick Access Editor, where you can change the program or

setup assigned to the bank slot that was selected when you entered the

Quick Access Editor. See Chapter 8 in the

Musician’s Guide

Effects mode …if the Studio parameter is highlighted, enters the Studio Editor, where you

can edit the currently selected studio. Chapters 9 and 15 in the

Musician’s

Guide

explain studios, the Studio Editor, FX presets, and the FX Preset

Editor.

MIDI mode …enters the Velocity Map or Pressure Map Editor if the Velocity or

Pressure Map parameter is selected on either the TRANSMIT page or the

RECEIVE page.See Chapter 18 in the

Musician’s Guide

.Takes you to the

Program Editor if the Program parameter is selected on the CHANLS page.

See Chapter 6 in the

Musician’s Guide

Master mode …enters the Velocity Map, Pressure Map, or Intonation Table Editor if the

VelTouch, PressTouch, or Intonation parameter is selected.See

Chapter 18 in the

Musician’s Guide

Song mode …enters the Song Editor.The Song Editor is discussed in Chapter 12 in the

Musician’s Guide

.Takes you to the Program Editor if the Program

parameter is highlighted when

Edit

is pressed.

Disk mode …has no effect.

Table 1-1 Navigating with the Edit Button

Front Panel

Front Panel Quick Reference

1-3

Soft Buttons

Functions change depending on current display page. Function of each button is displayed on

bottom line of display.

Exit Button

Press to leave various editors. If youÕve made any changes while in the editor, you will be

prompted to save them.

Cursor Buttons

Press the corresponding button to move the cursor up, down, left, or right in the display.

Different parameter values will be highlighted as buttons are pressed.

AlphaWheel

For data entry. Rotate clockwise to increase value of currently selected parameter,

counterclockwise to decrease.

Plus / Minus Buttons (- and +)

Under the Alpha Wheel. Press to increase or decrease the value of the currently selected

parameter by the smallest possible amount. DonÕt confuse this with the

+/-

button on the

alphanumeric buttonpad.

Alphanumeric Buttonpad

For Numeric Characters

Enter the value numerically instead of using the Alpha Wheel or

Plus

Minus

buttons. Press

Enter

when Þnished. Press

Cancel

to restore a parameter to its previous value. Pressing

Clear

equivalent to pressing

without pressing

Enter

For Alphabetic Characters

When naming objects, you can use the alphanumeric pad to enter letters instead of numbers. If

youÕre renaming a program, for example, just position the cursor under the character you want

to change, then press the corresponding numeric button, as labeled. Press the button as many

times as necessary to enter the desired character. Pressing

Clear

will enter a space before the

selected character. The

button will enter the numerals 0Ð9 when pressed repeatedly.

HereÕs an example. To enter the letter

in a blank space, press

three times. You can press the

+/-

button before or after entering the letter.

The

Cancel

button is equivalent to the

>>>

soft button, and

Enter

is the same as

. The

Clear

button replaces the currently selected character with a space. The

+/Ð

button toggles between

uppercase and lowercase letters.

When you press the

+/Ð

button on the alphanumeric pad, the currently selected character (the

one with the cursor under it) will switch from upper case to lower case, and vice versa. The

+/Ð

button is a toggle; that is, if you switch from lower to upper case, all further entries will be in

upper case until you press the

+/Ð

button again.

1-4

Front Panel

Special Keyboard Functions

There are several punctuation characters available as well, but they can be entered only with the

Alpha Wheel or

Plus/Minus

buttons. The punctuation characters are between

(lower case)

and

Special Alphanumeric Buttonpad Functions

When youÕre in Quick Access mode, the Alphanumeric buttonpad can be used to select the

entries in the current Quick Access bank. The layout of the alphanumeric buttonpad

corresponds to the layout of Quick Access bank entries as seen on the Quick Access-mode page.

ThereÕs also a shortcut for selecting different QA banks while in QA mode. Just press the

+/Ð

Clear

button on the alphanumeric pad, and youÕll be prompted to enter a bank number. Type

the desired number on the alphanumeric pad, then press

Enter

. The bank will be selected, and

youÕll return to the Quick Access page.

You can also use the alphanumeric pad to select strings to search for in the currently selected list

of objects, and to enter new strings to search for. The search function is described fully on

page 3-8 of the

MusicianÕs Guide

Lastly, rack users can play notes from the numeric keypad by holding down the

Cancel

button

while pressing alphanumeric buttons. This is described fully on page 3-10 of the

MusicianÕs

Guide

The Display

You may want to adjust the contrast of the display for different lighting conditions. On keyboard

models, the adjustment knob is on the rear panel, between the MIDI ports and the continuous

controller pedal jacks. On rack models, itÕs on the front panel, above the power switch.

MIDI LED (Rack Models Only)

Lights when the K2600 is receiving MIDI information at its MIDI In port.

Special Keyboard Functions

This section describes the buttons and sliders that are unique to the keyboard models of the

K2600. Features common to both rack and keyboard models are described starting on page 1-1.

Programmable controllers:

Sliders A–H, and the buttons

above them,

Pitch Wheel and Mod Wheel

Panel switches (Buttons 9 and 10)

Large and small ribbons

Two continuous control pedals (or

one pedal and one breath

controller)

Four foot switches

Front Panel

Special Keyboard Functions

1-5

Solo Button

Mutes all zones in setup except the current one. The button of the zone being soloed glows red.

Mixdown Button

Brings up the Mixdown page, as shown in the following diagram. From this page you can

choose how the K2600Õs physical sliders function during MIDI mixdown. In the example below,

Sliders A-H will control the volume level of MIDI channels 1-8. By pressing the

Pan

soft button,

you would change the function of the sliders to control panning for channels 1-8; or, you could

press the

9-16

soft button to have the sliders affect channels 9-16.

You can also use the cursor buttons to highlight the pan or volume control for a channel and use

the Alpha Wheel or

Plus/Minus

buttons to change the pan or volume level. In the screen below,

for example, you could use the Alpha Wheel to control panning on channel 9 at the same time

that you are using the sliders to control volume on channels 1-8.

Figure 1-1 Mixdown Control

MIDI Faders button

When you press the

MIDI Faders

button, the K2600Õs sliders take on the functions assigned on

the current MIDI Faders page. From the MIDI Faders display you can deÞne four different pages

that deÞne how the K2600Õs physical sliders will work. In the display shown below, for example,

the eight sliders are each deÞned to send MIDI 6 (Data) on Channels 9 through 16. Press one of

the

Page

soft buttons to use (or create) a different page of MIDI fader assignments. Use the

Send

soft button to transmit values without moving the faders.

The MIDI Faders pages is saved as part of the Master table object.

Mixdown||||<>Prog:|36|DuckWalk||||||||||

|||WXWXWXWX|WXWXWXWX|WXWXWXWX|WXWXWXWX||

|||wxwxC{wx|wxwxwxwx|wxwxwxwx|wxwxwxwx||

>>||z|z}~|z||z|z|z|z||z|z|z|z||z|z|z|z||

||||_|_|_|_||_|_|_|_||_|_|_|_||_|_|_|_||

||||||||||||||||||||||||||||||||||||||||

|||*****************||||||||||||||||||||

|Pan|||Volume|Ch|1-8|Ch9-16|||||||||Done

Shows which channels are affected

by physical sliders. Soft buttons for indicating

which channels are affected

by physical sliders.

Shows whether

physical sliders

control pan or

volume.

MIDI|Faders:Page2|||||||||||||||||||||||

Chan|:|9|||10||11||12|||13|||14||15||16|

Ctl||:|6|||6|||6|||6||||6||||6|||6|||6||

Value:|0|||0|||0|||0||||0||||0|||0|||0||

||||||||||||||||||||||||||||||||||||||||

||||||\]||}~||\]||}~||||\]||}~||\]||}~||

|||||||_|||_|||_|||_|||||_|||_|||_|||_||

Page1||Page2||Page3||Page4|||Send|||Done

1-6

Front Panel

Special Button Functions

Assignable Controllers (Buttons 1–8 and Sliders A–H)

The function of these controllers will depend on how theyÕve been deÞned within a setup.

Buttons 1Ð8 control either zone muting or KB3 features, depending on the value of the value of

the Mutes parameter on the COMMON page in the Setup Editor. The SLIDER and SLID/2 pages

conÞgure the functions of Sliders AÐH.

PSw1, PSw2 (Buttons 9 and 10)

The function of these controllers depends on how theyÕve been deÞned on the SWITCH page in

the Setup Editor.

Record, Play/Pause, Stop

These buttons duplicate the functions of the corresponding soft buttons in Song mode, allowing

you to conveniently record, play, pause, and stop the current song.

Special Button Functions

The Mode buttons and the Chan/Bank Down button have additional functions, depending on

the mode or editor youÕre in. When youÕre in the Program or Setup Editor, they function

according to the blue labeling under each button. They also work as track mutes on the MIX

page of Song mode.

When youÕre in the Sample Editor, the Program, Setup, Q Access, MIDI, Master, and Song

mode buttons function according to the orange labeling near each button. Table 1-2 describes all

of the special button functions. This table also appears as Table 5-1 on page 5-8 of the MusicianÕs

Guide.

Button Mode or Editor

White

Blue

Orange Program Editor (Blue) Setup Editor (Blue) Song Mode Sample Editor

(Orange)

Program

Mute 1

Zoom-

Mutes Layer 1 of current program, or

mutes current layer of current drum

program

Mutes Zone 1 of current

setup if 3 or fewer zones;

mutes current zone of

current setup if more than 3

zones

OnMIXpage,

mutesTrack1

or 9

On TRIM and LOOP

pages, decreases

horizontal dimension of

current sample in

display

Setup

Mute 2

Zoom+

Mutes Layer 2 of current program, or

solos current layer of current drum

program

Mutes Zone 2 of current

setup if 3 or fewer zones;

solos current zone of

current setup if more than 3

zones

OnMIXpage,

mutesTrack2

or 10

On TRIM and LOOP

pages, increases

horizontal dimension of

current sample in

display

Q Access

Mute 3

Samp / Sec

Mutes Layer 3 of current program, or

solos current layer of current drum

program

Mutes Zone 3 of current

setup if 3 or fewer zones;

solos current zone of

current setup if more than 3

zones

OnMIXpage,

mutesTrack3

or 11

Toggles between units

used to identify location

within sample— either

numberofsamplesfrom

start, or time in seconds

from start

Effects

FX Bypass Bypasses (mutes) current program’s FX

preset (plays program dry) Bypasses (mutes) current

setup’s studio (plays studio

dry)

OnMIXpage,

mutesTrack4

or 12

Table 1-2 Special Button Functions

Front Panel

Special Button Functions

1-7

MIDI

Previous Pg

Gain -

Successive presses take you back to

four most recent editor pages;5th press

takes you to ALG page

Successive presses take

you back to four most

recent editor pages; 5th

presstakesyou to CH/PRG

page

OnMIXpage,

mutesTrack5

or 13

On TRIM and LOOP

pages, decreases

vertical dimension of

current sample in

display

Master

Mark

Gain +

“Remembers” current editor page, so

you can recall multiple pages with Jump

button;asterisk appears before page

name to indicate that it’s marked;

unmark pages by pressing Mark when

page is visible

Same as for Program

Editor; pages common to

both editors are marked or

unmarked for

both

editors

OnMIXpage,

mutesTrack6

or 14

On TRIM and LOOP

pages, increases

vertical dimension of

current sample in

display

Song

Jump

Link

Jumps to marked pages in order they

were marked Jumps to marked pages in

order they were marked OnMIXpage,

mutesTrack7

or 15

Preserves interval

between Start, Alt,

Loop, and End points of

current sample; press

again to unlink

Disk

Compare Negates effect of unsaved edits and

plays last-saved (unedited) version of

object being edited

Same as for Program

mode; display reminds you

that you’re comparing;

press any button to return

to edited version

OnMIXpage,

mutesTrack8

or 16

Chan / Bank

Layer / Zone In Program Editor, these two buttons scroll through layers of current

program;in Effects Editor, scroll through FX presets; in Keymap Editor,

scroll through velocity levels of current keymap; in Setup Editor, scroll

through zones of current setup; in Quick Access mode, scroll through

entries in current Quick Access bank

Change

recording

track

Edit Whenever cursor is highlighting an editable object or parameter, takes you to corresponding editor or programming page

Button Mode or Editor

White

Blue

Orange Program Editor (Blue) Setup Editor (Blue) Song Mode Sample Editor

(Orange)

Table 1-2 Special Button Functions (Continued)

1-8

Front Panel

Special Button Functions: Double Button Presses

Pressing two or more related buttons simultaneously executes a number of special functions

depending on the currently selected mode. Make sure to press them at exactly the same time.

The following table also appears as Table 3-1 on page 3-6 of the MusicianÕs Guide.

In this

mode or

editor…

…pressing these buttons

simultaneously… …does this:

Program

mode

Octav-, Octav+ Reset MIDI transposition to 0 semitones.Double-press again to

go to previous transposition.

Chan–, Chan+ Set current MIDI channel to 1.

Plus/Minus Step to next Program bank (100, 200, etc.)

Master mode Chan/Bank Enables Guitar/Wind Controller mode.

Song mode Left/Right cursor buttons Toggle between Play and Stop.

Up/Down cursor buttons Toggle between Play and Pause.

Chan/Bank Select all tracks on any TRACK page in Song Editor.

Disk mode

2 leftmost soft buttons Issue SCSI Eject command to currently selected SCSI device.

Chan/Bank Hard format SCSI device. List selected objects when saving

objects.

Left/Right cursor buttons Select all items in a list. Move cursor to end of name in naming

dialog.

up/down cursor buttons Clear all selections in a list. Move cursor to beginning of name

in naming dialog.

Program

Editor Chan/Bank Select Layer 1.

Keymap

Editor

Plus/Minus With cursor on the Coarse Tune parameter, toggles between

default Coarse Tune of sample root and transposition of sample

root.

Sample

Editor

2 leftmost soft buttons Toggle between default zoom setting and current zoom setting.

Plus/Minus buttons Set the value of the currently selected parameter at the next

zero crossing.

Any Editor

Plus/Minus Scroll through the currently selected parameter’s list of values in

regular or logical increments (varies with each parameter).

2 leftmost soft buttons Reset MIDI transposition to 0 semitones.Double-press again to

go to previous transposition.

Center soft buttons Select Utilities menu (MIDIScope, Stealer, etc.).

2 rightmost soft buttons Sends all notes/controllers off message on all 16 channels

(same as Panic soft button).

Left/Right cursor buttons Toggle between Play and Stop of current song.

Up/Down cursor buttons Toggle between Play and Pause of current song.

Save Dialog Plus/Minus buttons Toggle between next free ID and original ID.

Table 1-3 Double Button Presses

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kurzweil Elektronische Tastatur Handbücher

Kurzweil

Kurzweil K2600 V4 GM MODE - REV B Bedienungsanleitung

Kurzweil

Kurzweil MPS10 Bedienungsanleitung

Kurzweil

Kurzweil PC3 Bedienungsanleitung

Kurzweil

Kurzweil K2600 - MUSICIANS GUIDE REV A PART NUMBER 910330 CHAP... Bedienungsanleitung

Kurzweil

Kurzweil K2600 BEST OF VAST - REV A Fehlerbehebungshandbuch

Kurzweil

Kurzweil K2000R Bedienungsanleitung

Kurzweil

Kurzweil KP30 Bedienungsanleitung

Kurzweil

Kurzweil K2600 BEST OF VAST - REV A Bedienungsanleitung

Kurzweil

Kurzweil K2600 BEST OF VAST - REV A Bedienungsanleitung

Kurzweil

Kurzweil M-1 Bedienungsanleitung

Kurzweil

Kurzweil PC2 - MUSICIANS GUIDE REV A Bedienungsanleitung

Kurzweil

Kurzweil K2661 Bedienungsanleitung

Kurzweil

Kurzweil K1200 PRO 76 - PERFORMANCE GUIDE Bedienungsanleitung

Kurzweil

Kurzweil K1200 PRO EXPANDER MUSICIANS Bedienungsanleitung

Kurzweil

Kurzweil Forte SE Bedienungsanleitung

Kurzweil

Kurzweil K2600 V2.0 - MUSICIANS GUIDE SUPPLEMENT REV... Bedienungsanleitung

Kurzweil

Kurzweil K2600 - MUSICIANS GUIDE REV A PART NUMBER 910330 CHAP... Bedienungsanleitung

Kurzweil

Kurzweil PC2 V3.0 - MUSICIANS GUIDE SUPPLEMENT REV A Bedienungsanleitung

Kurzweil

Kurzweil KME-61 VERSION 2 SOFTWARE Betriebsanleitung

Kurzweil

Kurzweil K2600 - MUSICIANS GUIDE REV A PART NUMBER 910330 CHAP... Bedienungsanleitung

Kurzweil

Kurzweil K2600 ROM - INSTALLATION REV E Bedienungsanleitung

Kurzweil

Kurzweil K2600 BEST OF VAST - REV A Referenzhandbuch

Kurzweil

Kurzweil EP Series EP-400 Bedienungsanleitung

Kurzweil

Kurzweil K2600 BEST OF VAST - REV A Bedienungsanleitung

Beliebte Elektronische Tastatur Handbücher anderer Marken

Casio

Casio LK-50 Konfigurationshandbuch

Casio

Casio VZ-1 Fehlerbehebungshandbuch

Casio

Casio Privia PX-100 Bedienungsanleitung

Yamaha

Yamaha PortaTone PSR-225GM Bedienungsanleitung

Behringer

Behringer U-CONTROL UMX49 Bedienungsanleitung

Yamaha

Yamaha Portatone X2500 Bedienungsanleitung

Yamaha

Yamaha Portatone PSR-100 Bedienungsanleitung

Casio

Casio WK-1600 Bedienungsanleitung

Keith McMillen Instruments

Keith McMillen Instruments K-Board Pro 4 Technisches Datenblatt

Yamaha

Yamaha PortaSound PCS-30 Bedienungsanleitung

Roland

Roland Juno-6 Bedienungsanleitung

McGrey

McGrey 6170 Bedienungsanleitung

Yamaha

Yamaha PortaTone PSR-41 Bedienungsanleitung

HDC

HDC Kurzweil KP300X Bedienungsanleitung

Casio

Casio Celviano AP-45 Bedienungsanleitung

Akai

Akai MPK88 Bedienungsanleitung

Waldorf

Waldorf IRIDIUM Bedienungsanleitung

Yamaha

Yamaha NP-30 Montageanleitung
