La Crosse CA79080 Bedienungsanleitung

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 1 | PAGE

WIRELESS WEATHER STATION

WITH BAROMETRIC PRESSURE & BONUS STATION

MODELS: CA79080 / 3081409TH / TX141THBV3

DC: 081820

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 2 | PAGE

TABLE OF CONTENTS

3. Power Up

3. Button Functions

4. Settings Menu

5. Adjustable Backlight

6. Auto Dim Backlight

6. Pressure History Graph & Number

7. Weather Forecast Icons

7. Temperature & Humidity Alerts

8. HI/LO Temperature & Humidity Records

9. Temperature & Humidity Trend Arrows

10. Sensor Search

10. Low Battery Indicators

10. Bonus Station Indoor/Outdoor Readings

10. Bonus Station Settings Menu

11. Bonus Station Battery Change

11. Bonus Station Sensor Search

12. Speciﬁcations

12. Care and Maintenance

13. Warranty Info

13. Canada Statement

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 3 | PAGE

POWER UP

1. Insert 2-AA batteries into your Outdoor Sensor.

2. Insert the 5 volt power cord into an outlet, then into your Weather Station.

Optional: Insert 3-AA batteries as backup.

3. Insert 2-AAA batteries into your Bonus Station.

4. Adjust time and date settings on each station.

5. Once the Outdoor Sensor is reading to each of your displays, place it outside in a shaded location.

Watch our sensor mounting video: bit.ly/TH_SensorMounting

Outdoor Sensor

TX141TH-Bv3

Bonus Station

308-1409TH

Weather Station

CA79080

BUTTON FUNCTIONS

ALERTS TEMP SENSOR

• Hold to enter Alert Settings • Press to view Temp History • Hold to search for sensor

+ (PLUS) - (MINUS) SET

• Press to increase settings • Press to decrease settings • Hold to enter Settings

• Press to arm/disarm alerts • Press to arm/disarm alerts

• Hold to delete Temp History

LIGHT ALERTS / LIGHT

• Press to adjust backlight • Hold together to reset station

• Hold to enter Auto-Dim Settings

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 4 | PAGE

SETTINGS MENU

It is best to press one button at a time when setting your station.

1. Hold the SET button to enter the Settings Menu.

2. Press the + or - button to adjust the values. Hold to adjust quickly.

3. Press the SET button to confirm and move to the next item.

4. Press the LIGHT button to exit.

Settings Menu Order:

• Language (English, Spanish, French)

• Beep ON/OFF

• 12/24 Hour

• Hour

• Minutes

• Year

• Month

• Date

• Celsius or Fahrenheit

• Pressure units: HPA or INHG

• Pressure number setting

Weekday: Your weekday will set automatically after year, month, and date are set.

Language: When Spanish (Español), or French (Français) are selected, the rest of the instructions will be in

that language.

Language 12 or 24 Hour FormatBeep ON/OFF

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 5 | PAGE

Hour Minutes

Year DateMonth

Celsius/Fahrenheit Pressure NumberPressure Units HPA/INHG

ADJUSTABLE BACKLIGHT

Your Backlight may be turned OFF or adjusted to 4 levels of brightness.

Intensity Levels: 0FF | 1.5% | 20% | 50% | 100%.

To adjust brightness:

1. Press and release the LIGHT button to adjust backlight brightness.

2. The word BACKLIGHT and the setting will show.

3. Once you have the desired backlight brightness, stop pressing buttons.

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 6 | PAGE

AUTO DIM BACKLIGHT

Program the station to automatically dim the backlight to its level 1 setting during preselected times. Use this

in coordination with your sleep schedule to avoid repeated manual adjustments.

Program Auto Dim (Hour setting only):

1. Hold the LIGHT button to set Auto Dim Start and Stop times.

2. Use the + or - button to turn the Auto Dim feature ON. Press the LIGHT button to conﬁrm and move to

next item.

3. START TIME will ﬂash. Use the + or - buttons to select your Auto Dimmer’s starting hour. Press the LIGHT

button to conﬁrm and move to next item.

4. STOP TIME will ﬂash. Use the + or - buttons to select your Auto Dimmer’s ending hour. Press the LIGHT

button to conﬁrm and exit.

Note: While the Auto Dim is active, if your press the LIGHT button, the backlight will change to the

brightness level selected and stay there. Auto Dim will resume at the next scheduled time.

PRESSURE HISTORY GRAPH & NUMBER

Read from left to right, the Pressure History Graph indicates the rise and fall in air pressure over the past 24

hours.

• The “0h” on the horizontal axis indicates the current hour, thus the current air pressure also.

• With each passing hour, the current air pressure is used as the basis for future graph trends.

• Air pressure trends can be determined by simply glancing at the bar graph.

A. If the bars are rising (higher on the right than the left) then the air pressure has a rising trend, and the

weather should improve.

B. If the bars are dropping (lower on the right than the left) then the air pressure has a falling trend, and

the weather should worsen.

• The bar chart will constantly scroll to provide visual interest. This cannot be turned o.

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 7 | PAGE

WEATHER FORECAST ICONS

• The Weather Forecast Icons are determined by the station’s barometric pressure reading. Please allow

7-10 days for barometric calibration.

• This represents the pressure at your home location, and may vary slightly from a local reporting news

outlet.

• Six Forecast Icons use changing atmospheric pressure to predict your weather conditions to come within

the next 12 hours. The accuracy of these icons should improve over time.

• When Outdoor temperature is below 0˚C (32˚F) and the forecast is RAIN or T-STORM, the station will

display SNOW.

SUNNY PARTLY SUNNY CLOUDY RAIN T-STORM SNOW

TEMPERATURE & HUMIDITY ALERTS

To set alerts:

1. Hold the ALERTS button to enter alert set mode.

2. Outdoor HI temperature alert OFF will show. If you wish to set this alert value, press the + or – button to

arm this alert (ON).

3. When the alert is armed (ON) the alert value will flash. Press the + or – button to change the alert value.

4. Press the ALERTS button to confirm and move to the next alert.

5. Press the LIGHT button to exit.

Note: If you do not wish to set an alert, press the ALERTS button again to move the next alert.

Outdoor HI Temperature Alert Outdoor LO Temperature Alert

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 8 | PAGE

Outdoor HI Humidity Alert Outdoor LO Humidity Alert

Indoor HI Temperature Alert Indoor LO Temperature Alert

HI/LO TEMPERATURE & HUMIDITY RECORDS

The HI & LO temperature and humidity readings are recorded with time and date of occurrence. This

provides a running history of records from when you ﬁrst powered up the station. Each time a new high or

low reading is recorded, that reading with time and date of occurrence will show.

Press and release the TEMP button to view:

• Outdoor HI Temperature with Time/Date

• Outdoor LO Temperature with Time/Date

• Outdoor HI Humidity with Time/Date

• Outdoor LO Humidity with Time/Date

• Indoor HI Temperature with Time/Date

• Indoor LO Temperature with Time/Date

When Alert Sounds:

• When armed alert value is reached, station will beep 5 times each minute, until out of alert range.

• The ﬂashing Alert Icon will indicate if it is a LO or HI alert.

• Press any button to stop the temp alert sound. The alert icon will ﬂash while value is in alert range.

Indoor HI Humidity Alert Indoor LO Humidity Alert

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 9 | PAGE

Outdoor HI & LO Temperature Records Outdoor HI & LO Humidity Records

Indoor HI & LO Temperature Records Indoor HI & LO Humidity Records

Heat Index & Dew Point

Reset:

• While viewing individual values, hold the MINUS

(-) button for 3 seconds to reset the individual

record.

• Value, time and date stamp will reset to current

values.

• Indoor HI Humidity with Time/Date

• Indoor LO Humidity with Time/Date

• Indoor/Outdoor Heat Index

• Indoor/Outdoor Dew Point

Note: Heat Index & Dew Point are current records.

TEMPERATURE & HUMIDITY TREND ARROWS

• The UP and DOWN arrows indicate changes in temperature and humidity over the past hour.

• The arrows will update every 15 minutes and compare data from exactly one hour prior.

Temperature: Arrows appear with changes of 1°C (2°F) or more.

Humidity: Arrows appear with changes of at least 3% RH.

WIRELESS WEATHER STATION WITH BAROMETRIC PRESSURE & BONUS STATION 10 | PAGE

LOW BATTERY INDICATOR

SENSOR SEARCH

• If the Outdoor Sensor loses connection to your Weather Station, the display will show dashes after 30

minutes.

• The weather station will search for 3 minutes every hour to try and reconnect with sensor.

• To search for the sensor, hold the SENSOR button for 3 seconds until the Sensor Reception Icon

starts to Animate.

• Sensor Reception Icon will be solid on screen when the connection is established.

• If no sensor connection is made, the icon will disappear after 3 minutes of searching.

• When the Low Battery Icon shows by the outdoor temperature, replace batteries in the sensor.

• When the Low Battery Icon shows by the indoor humidity, replace batteries in the station.

BONUS STATION INDOOR/OUTDOOR READINGS

Press and release the button to view Indoor Temp/Humidi-

ty or Outdoor Temp/Humidity.

BONUS STATION SETTINGS MENU

OUTDOOR INDOOR

OUTDOOR

1. Hold the button to enter the Settings Menu.

2. Press the button to adjust values. Hold to adjust quickly.

3. Press the button to confirm and move to the next item.

Setting order:

• 12/24 Hour Time

• Hour

• Minutes

• Celsius/Fahrenheit
