Laerdal SimMan 3G Bleeding Module Handbuch

SimMan 3G Bleeding Modules

Directions for Use

www.laerdal.com

Items Included

The following items are included with this kit:

– Amputated Arm SimMan 3G

– Gunshot Arm SimMan 3G

– Amputated Leg SimMan 3G

– Gunshot Leg SimMan 3G

– Hardware kit

– Directions for Use

– Warranty booklet

Contents

Removing SimMan 3G Left Arm 4

Attaching SimMan 3G Amputation or Shotgun Arm 5

Replacing SimMan 3G Left Leg with Trauma Leg 6

Spare Parts 7

Introduction

The SimMan 3G Bleeding Module kit includes trauma modules which can be ﬁtted to SimMan 3G

to simulate bleeding patient cases. After the simulation is completed, leave the trauma modules

connected, and perform the cleaning instructions as stated in SimMan 3G Directions for Use.

3 4

Removing SimMan 3G Left Arm

LA PULSES BP

LA CONV

PULSES

1. Unzip the clothing zippers on the right

side. Remove the shirt.

2. Unzip the zippers on the left side of the

torso. Open the Torso Skin to one side.

3. Open the Stomach Foam to one side. 4. Lift the hinged chest plate to access the

arm bolt.

5. Unscrew the left Arm screw with the

allen key and disconnect all Arm cables.

Note: Do not unscrew the Arm Screw fully.

6. Remove the arm with cables from the

arm socket.

Attaching SimMan 3G Amputation or Shotgun Arm

LA PULSES BP

LA CONV

A PULS

A PU

2 3

The Arm Adapter and Adapter Screw

are designed to attach an Amputation or

Gunshot Arm to the SimMan 3G manikin.

1. Fit the Arm Adapter into the hole in the

arm bracket from inside of the torso.

Ensure that the ﬂat edge of the adapter

is facing the chest hinge.

2. The Adapter is now in place and the

Trauma Arm can now be connected

with the Adapter Screw.

3. Thread the Adapter Screw through the

Amputation Arm and align the screw with

the hole in the Arm Adapter.

4. Secure the Adapter with one hand from

inside the torso. Screw the Adapter Screw

using the Phillips screwdriver.

Note:Tighten screw as desired to simulate

more or less Arm Range of Motion.

5. Connect the red tube from the

Amputation Arm to the nearest blood

port on the torso.

Caution: Do not over rotate arm. Over rotating

the Arm may cause the red vinyl tubing to

disconnect.

1 2

3 4

Replacing SimMan 3G Left Leg with Trauma Leg

1. Remove the SimMan 3G default leg.

Open Torso skin and stomach foam as

shown in steps 1-3, page 4.

2. Unscrew hip joint connector. Remove

the leg cables/tubes from the connector.

3. Carefully remove the left leg with cables

and tubes.

4. Insert the Amputation or Gunshot leg

with blood tube into the leg socket.

5. Insert the blood tube into the side

slot of the connector. Screw the

connector in place with one hand.

6. Connect the leg tube to the

corresponding tube, as labelled inside

the torso.

7. Close the stomach foam and zip the

torso skin back into place.

Spare Parts

Items listed below are replacements parts for the SimMan 3G Bleeding Module kit.

212-07850 Amputated Arm SimMan 3G

212-07950 Gunshot arm SimMan 3G

212-08150 Amputated Leg SimMan 3G

212-08250 Gunshot Leg SimMan 3G

212-08350 Hardware Kit

212-08450 SimMan 3G Bleeding Trauma Directions for Use

212-07650 Arm Adapter Screw

212-14250 Arm Adapter

20-02373 Rev B
