Lantech IPGS-3 Series Bedienungsanleitung

IPGS-3XXX

IPGS-5XXX

IGS-3XXX

IGS-5XXX

IP30-rated Series

IP30-rated L2+Industrial Managed Switch w/Enhanced G.8032 Ring

User Manual (Hardware)

Nov. 2016

Recommendation for Shielded network cables

STP cables have additional shielding material that is used to reduce external interference.

The shield also reduces the emission at any point in the path of the cable. Our

recommendation is to deploy an STP network cable in demanding electrical environments.

Examples of demanding indoor environments are where the network cable is located in

parallel with electrical mains supply cables or where large inductive loads such as motors

or contactors are in close vicinity to the camera or its cable. It is also mandatory to use an

STP cable where the power device (like IP camera) is used outdoors or where the network

cable is routed outdoors.

Important Notice

Lantech Communications Global, Inc. reserves the right to modify the

equipment, its specification or this manual without prior notice, in the interest

of improving performance, reliability, or servicing. At the time of publication

all data is correct for the operation of the equipment at the voltage and/or

temperature referred to. Performance data indicates typical values related to

the particular product.

No part of this documentation or information supplied may be divulged to any

third party without the express written consent of Lantech Communications

Global Inc. Products offered may contain software which is proprietary to

Lantech Communications Global Inc. The offer or supply of these products

and services does not include or infer any transfer of ownership.

Interference Issues

This Equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a

commercial or industrial installation. This equipment generates, uses, and

can radiate radio frequency energy. It may cause harmful interference to

radio communications if the equipment is not installed and used in

accordance with the instructions.

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Content

Chapter 1 Hardware Features.................................1

Chapter 2 Hardware Description ............................4

2.1 IP Protection................................................... 4

2.2 LED Indicators................................................ 7

Chapter 3 Hardware Installation.............................9

3.1 Hardware installation ..................................... 9

3.2 DIN-Rail Mounting........................................ 10

3.3 Wall Mount Plate Mounting.......................... 12

3.4 Wiring the Power Inputs............................... 13

3.5 Wiring the Fault Alarm Contact.................... 14

3.6 Cabling......................................................... 15

3.7 USB Dongle ................................................. 18

Chapter 4 Network Application.............................19

ITU G.8032 Scheme.............................................. 19

Ring Coupling ........................................................... 19

Multiple Rings .......................................................... 20

Dual Homing ............................................................ 21

Chain....................................................................... 21

Chapter 5 Console Management ..........................23

5.1 Connecting to the Console Port................... 23

5.2 Login in the Console Interface..................... 24

Chapter 1 Hardware Features

Standard

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX

IEEE802.3z Gigabit fiber

IEEE802.3x Flow Control and Back Pressure

IEEE802.3ad Port trunk with LACP

IEEE802.1d Spanning Tree

IEEE802.1w Rapid Spanning Tree

IEEE802.1s Multiple Spanning Tree

IEEE 802.3ad Link Aggregation Control Protocol (LACP)

IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

IEEE 802.1X User Authentication (Radius)

IEEE802.1p Class of Service

IEEE802.1Q VLAN Tag

IEEE802.3at/af Power over Ethernet (PoE model)

Switch

Architecture

Back-plane (Switching Fabric): Depends on model

Packet throughput ability (Full-Duplex): Depends on model

Transfer Rate

14,880pps for Ethernet port

148,800pps for Fast Ethernet port

1,488,000pps for Gigabit Ethernet port

MAC Address

16K MAC address table

Connector

10/100/1000T: RJ-45 type connector

Mini-GBIC: 1000 SFP Sockets or 100/1000M SFP Sockets

100M fiber: SC/ST type connector for single-mode or multi-

mode type fiber cable

Power & P-Fail connector: 1 x 6-pole terminal block

Digital Input/Output: 1 x 6-pole terminal block

RS-232 connector: 1 x RJ-45 type connector

USB for automatic backup and configuration

Network Cable

10/100/1000T: 2-pair UTP/STP Cat. 5/ 5E / 6 cable

EIA/TIA-568 100-ohm (100m)

Protocol

CSMA/CD

LED

Per unit: Power 1 (Green), Power 2 (Green), P-Fail (Red)

Ethernet port: Link/Activity (Green), Speed (Green); Giga-T:

Link/Activity (Green)

PoE FWD: Green( IPGS)

DI/DO

1 Digital Input(DI):

Level 0: -30~2V/Level1: 10~30V

Max. input current:8mA

1 Digital Output(DO): open collector to 40VDC, 200mA

Power Supply

48 VDC for 802.3af (IPGS series)

54VDC for 802.3at (IPGS series)

24/48VDC (IGS-5XXX series, IGS-3408DSFP)

9.5~57VDC (IGS-3408GSFP series)

9.5~57VDC (IPGS series, 12V model)

90~305VAC/120~430VDC (HV model)

Power

Consumption

Depends on model

PoE Power

Budget

Depends on model (IPGS series)

Operating

Humidity

5% to 95% (Non-condensing)

Operating

Temperature

-40oC ~ 75oC

Storage

Temperature

-40oC ~ 85oC

Case Dimension

Metal case. IP-30, 74(W) x 105 (D) x 152 (H) mm

Metal case. IP-30, 96.3(W) x 105 (D) x 152 (H) mm

Metal case. IP-30, 74(W) x 135 (D) x 152 (H) mm

Installation

DIN rail and optional wall mount ear

EMI

FCC Class A, CE EN61000-4-2, CE EN61000-4-3, CE EN-

61000-4-4, CE EN61000-4-5,

CE EN61000-4-6, CE EN61000-4-8, CE EN61000-4-11, CE

EN61000-4-12, CE EN55022 Class A, CE EN55024

Stability Testing

IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),

IEC60068-2-6 (Vibration)

*For detail specifications, please refer to product datasheet.

**The revise authority rights of product specifications belong to Lantech Communications

Global, Inc. Lantech may make changes to specification and product descriptions at

anytime, without notice.

Chapter 2 Hardware Description

In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling

information, and wiring installation.

2.1 IP Protection

The IP Code, Ingress Protection Rating, sometimes also interpreted as International

Protection Rating, classifies and rates the degree of protection provided against the

intrusion (including body parts such as hands and fingers), dust, accidental contact, and

water in mechanical casings and with electrical enclosures. It is published by the

International Electrotechnical Commission (IEC)

Solid particle protection

The first digit indicates the level of protection that the enclosure provides against access

to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid

foreign objects.

Level

Object size

protected against

Effective against

—

No protection against contact and ingress of objects

>50 mm

Any large surface of the body, such as the back of a

hand, but no protection against deliberate contact

with a body part

>12.5 mm

Fingers or similar objects

>2.5 mm

Tools, thick wires, etc.

>1 mm

Most wires, screws, etc.

Dust protected

Ingress of dust is not entirely prevented, but it must

not enter in sufficient quantity to interfere with the

satisfactory operation of the equipment; complete

protection against contact

Dust tight

No ingress of dust; complete protection against

contact

Liquid ingress protection

The second digit indicates the level of protection that the enclosure provides against

harmful ingress of water.

Level

Protected

against

Testing for

Details

Not

protected

—

Dripping

water

Dripping water (vertically

falling drops) shall have no

harmful effect.

Test duration: 10 minutes

Water equivalent to 1 mm

rainfall per minute

Dripping

water when

tilted up to

15°

Vertically dripping water

shall have no harmful effect

when the enclosure is tilted

at an angle up to 15°from

its normal position.

Test duration: 10 minutes

Water equivalent to 3 mm

rainfall per minute

Spraying

water

Water falling as a spray at

any angle up to 60°from

the vertical shall have no

harmful effect.

Test duration: 5 minutes

Water volume: 0.7 litres per

minute

Pressure: 80–100 kPa

Splashing

of water

Water splashing against

the enclosure from any

direction shall have no

harmful effect.

Test duration: 5 minutes

Water volume: 10 litres per

minute

Pressure: 80–100 kPa

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Lantech Schalten Handbücher

Lantech

Lantech 5 10/100TX w/ 4 PoE Injector Industrial... Bedienungsanleitung

Lantech

Lantech IGS-L5408MGSFPR-AC Bedienungsanleitung

Lantech

Lantech IGS-0208GSFP Bedienungsanleitung

Lantech

Lantech IGS-2404 Bedienungsanleitung

Lantech

Lantech IES-5408T Bedienungsanleitung

Lantech

Lantech TGS-R6616XFT Bedienungsanleitung

Lantech

Lantech IPES-0008A-12V Bedienungsanleitung

Lantech

Lantech IPGS-0005T-4 Bedienungsanleitung

Lantech

Lantech IPGS-0005T-4-12V Bedienungsanleitung

Lantech

Lantech IPGS-5 Series Bedienungsanleitung

Lantech

Lantech IPES/IES-0008B Series Bedienungsanleitung

Lantech

Lantech Treo 500 Bedienungsanleitung

Lantech

Lantech IES-3 Series Bedienungsanleitung

Lantech

Lantech IGC-0101DSFP Bedienungsanleitung

Lantech

Lantech IES-2208C Bedienungsanleitung

Lantech

Lantech IES-2208CA Bedienungsanleitung

Lantech

Lantech LGS-1104 Bedienungsanleitung

Lantech

Lantech IES-2008 Bedienungsanleitung

Lantech

Lantech IES-5216DF Bedienungsanleitung

Lantech

Lantech TPGS-L6208XT Bedienungsanleitung

Lantech

Lantech IPES-5416T Series Bedienungsanleitung

Lantech

Lantech IPES-5408T-X-IGN Series Bedienungsanleitung

Lantech

Lantech IES-2208CA-DNV Bedienungsanleitung

Lantech

Lantech IPGS-0204DSFP Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
