Lapierre SOUNDGEAR Bedienungsanleitung

OPERATIONS MANUAL

B 1

Overview

Features, Controls and Identiﬁcation ......... 2

Preparation

Batteries ............................... 4

Battery Indicator Tones ................... 6

Assembly .............................. 8

Insertion and Removal ....................10

SoundGear Care

Device Care ............................12

Troubleshooting Guide ...................13

Noise Protection Information

Required Information .....................14

Limited Warranty

Limited Warranty Information. . . . . . . . . . . . . . . 15

Contents

2 3

1. Microphone opening

2. Sound outlet (receiver)

3. Battery compartment

(on/off control)

4. Location of serial number

5. Removal handle

6. Large orange sleeves (shown)

Six additional sleeves (two small

black, two large black and 2 small

orange) also included in package

7. Battery removal tool

OverviewOverview

These are fully automatic devices designed to overcome the

sensation of wearing an earplug. Hassle-free operation eliminates the

need for a volume control by returning environmental sounds while

at the same time protecting your ears from loud blasts. This product

is not intended to overcome hearing impairment and should not be

worn as a hearing aid.

Features, Controls and Identiﬁcation

Your device controls include:

4 5

Batteries

Your device uses a battery as its power source. This battery size

can be identiﬁed by the yellow (10) color code on the packaging.

Your device powers on upon inserting the battery and powers off

upon removing the battery.

To insert or replace the battery:

1. Remove the sleeve.

2. Remove old battery using the battery removal tool or simply

push the battery out from the side with your ﬁngers.

3. Remove the tab from the new battery.

4. Place battery in device by lining up the battery’s “+” sign

(ﬂat side of the battery) with the “+” on the case. The “+” sign

is on the wider end of the device, which is engraved with

SoundGear.

Preparation

1 2

3 4

Preparation

6 7

Battery Indicator Tones

An indicator will sound when the battery voltage is low. You have

approximately 5 minutes* to replace the battery. An indicator will

sound just before the battery stops working.

* Actual time between low battery indicator and shut down will vary

depending on environmental noise levels and brand of battery used.

Helpful Hints

• Becauseoftheirsize,it’sagoodideatochangeandreplace

batteries above a table or desk to reduce the risk of dropping

the device or battery.

• Disposeofusedbatteriesimmediatelyintheproperwaste

or recycling container.

• Becausebatteriescanvaryinsizeandperformance,ahearingcare

professional is your best source for lifespan estimates and veriﬁcation

that you are using the proper size and type.

Warnings

Batteries are dangerous if swallowed. To help prevent the

accidental ingestion of batteries:

Keep out of reach of children and pets

Check your medications before taking them – batteries have

been mistaken for pills

Never put batteries in your mouth, as they can easily be

swallowed

National Button Battery Ingestion Hotline: 202-625-3333

Preparation Preparation

8 9

PreparationPreparation

Assembly

To assemble device:

1. Remove the sleeve.

2. Remove the tab from the new battery.

3. Place battery in device by lining up the battery’s “+” sign

(ﬂat side of the battery) with the “+” on the case. The “+” sign is

on the wider end of the device, which is engraved with SoundGear.

4. Insert device back into sleeve making sure the SoundGear label is

visible. The narrow end of the device should rest against the tip

of the sleeve.

1110

10 11

Preparation

Insertion and Removal

To insert the device:

1. SoundGear should sit in the outermost part of the ear canal.

Select the largest sleeve ﬁrst and only use the smaller sleeve if

the large sleeve is too large to seal the outer ear canal or causes

discomfort in the outer ear canal.

2. Gently insert the canal tip of the device into your ear canal.

Softly press the device into place with your ﬁnger until the ear

canal is completely sealed.

• Donotpushdeviceintoyourearwheretheremovalhandle

cannot be reached.

• Fitshouldbesnugtoensureproductisproperlysealingthe

ear canal and achieving listed NRR.

To remove the device:

Grasp the removal handle and gently remove from ear.

1 2

Preparation

Helpful Hints

• Ifthedevicewillnotgointoearcanal,changetothesmallsleeve

provided in the package.

• Minorirritationandinammationmayoccurasyourearbecomes

accustomed to having an object in it; if so, please contact a hearing

care professional.

• Ifanactualallergicreactionoccurs,contactahearingcareprofessional.

• Severeswelling,dischargefromtheear,excessivewax,orother

unusual conditions warrant immediate consultation with a physician.

1312

12 13

SoundGear Care

Device Care

Do your best to keep your devices clean at all times. Heat, moisture and

foreign substances can result in poor performance.

•Cleandailyoverasoftclothtopreventdamagefromafalltoahardsurface

•Removethesleeve,thenusecleaningbrushprovidedinthepackagetoclean

debris from around the microphone, receiver and battery compartment

•Neverusewater,solvents,cleaninguidsoroiltocleanyourinstrument

•Theplasticsleevecanbecleanedwithsoapywater

•Allowtheplasticsleevetodrycompletelybeforeinsertingthedeviceback

into sleeve

A hearing care professional can provide further information on additional

maintenance procedures for your devices if needed.

Helpful Hints

•Whennotinuse,removethebatteriescompletely;placeyourdevicesin

the storage container and store:

– In a dry, safe place

– Away from direct sunlight or heat to avoid extreme temperatures

– Where you can easily ﬁnd them

– Safely out of reach of pets and children

•Donottakeapartyourdevicesorinsertthecleaningtoolinsidethem

Troubleshooting Guide

SYMPTOM POSSIBLE CAUSES SOLUTIONS

Not Loud

Enough

Low battery Replace battery

Wax or debris in the

microphone or receiver

Clean both microphone and receiver

with brush. Remove and clean the

plastic sleeve.

Hearing change Contact a hearing care professional

Inconsistent

Performance Low battery Replace battery

Unclear,

Distorted

Performance

Low battery Replace battery

Defective device Contact via email:

[email protected]

Dead

Low battery Replace battery

Wax or debris in the

microphone or receiver

Clean both microphone and receiver

with brush. Remove and clean the

plastic sleeve.

SoundGear Care

1514

14 15

The level of noise entering a person’s ear, when hearing protector is worn as

directed, is closely approximated by the difference between the A-weighted

environmental noise level and the NRR.

Example

1. The environmental noise level as measured at the ear is 92 dB(A).

2. The NRR is 25 decibels (dB).

3. The level of noise entering the ear is approximately equal to

[92 dB(A) – 25 dB] dB(A).

Caution: For noise environments dominated by frequencies below 500 Hertz (Hz),

the C-weighted environmental noise levels should be used.

Improper ﬁt of this device will reduce its effectiveness in attenuating noise.

Consult the enclosed instructions for proper ﬁt.

Although hearing protectors can be recommended for protection against the

harmful effects of impulsive noise, the Noise Reduction Rating (NRR) is based on

the attenuation of continuous noise and may not be an accurate indicator of the

protection attainable against impulsive noise such as gunﬁre.

Noise Protection Information

This Limited Warranty provided by Starkey Hearing Technologies, to you, the original

purchaser of a SoundGear device, covers your new electronic hearing protection device

when sold by an authorized Starkey Hearing Technologies dealer or via the website,

www.soundgearhearing.com. The duration of this Limited Warranty begins when you ﬁrst

take delivery of your hearing protection device from an authorized dealer or via the above

website and ends twelve (12) months later (“warranty period”).

In order to be eligible for service under this Limited Warranty you MUST register your

device by emailing SoundGear at [email protected].

LIMITATION ON DURATION OF IMPLIED WARRANTIES:

IMPLIED WARRANTIES, IF ANY, ARISING BY WAY OF STATE LAW, INCLUDING ANY

IMPLIED WARRANTY OF MERCHANTABILITY AND/OR ANY IMPLIED WARRANTY OF

FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY

PERIOD. There is no warranty of any nature made by Starkey Hearing Technologies beyond

this Limited Warranty. No person has authority to enlarge, amend, or modify this Limited

Warranty. Starkey Hearing Technologies is not responsible for any undertaking, representation,

or warranty (written, express, or implied) made by any Starkey Hearing Technologies dealer

or other person beyond those expressly set forth in this Limited Warranty.

Some States do not allow limitations on how long an implied warranty lasts, so the above

limitation may not apply to you.

WHAT THIS LIMITED WARRANTY COVERS:

This Limited Warranty covers only a “defect” in the workmanship performed and/or

materials used to manufacture your hearing protection device. “Defect” means the failure

of the workmanship performed and/or materials used to conform the device to Starkey

Hearing Technologies design and manufacturing speciﬁcations and tolerances.

Limited Warranty

1716

16 17

Limited Warranty

Your authorized Starkey Hearing Technologies dealer may have issued a warranty or

service plan that goes beyond the provisions of this Limited Warranty. Please contact

him or her for further information.

Starkey Hearing Technologies will either replace the hearing protection device or repair

any covered defect in your device, provided that you deliver your device to one of Starkey

Hearing Technologies authorized dealers or directly to Starkey Hearing Technologies in

the manner described below. In addition, you must notify the authorized dealer or Starkey

Hearing Technologies of the defect during the warranty period and within thirty (30) days of

discovering the defect. There will be no cost to you for Starkey Hearing Technologies repair

or replacement of the device itself, but the dealer may charge a fee for services he or she

provides. Performance of warranty repairs on your hearing protection device shall not extend

the duration of the warranty period. Any repairs performed on your device after the warranty

period has expired shall be considered “good will” repairs, which shall not alter the terms of

this Limited Warranty.

HOW TO OBTAIN WARRANTY SERVICE:

Deliver your hearing protection device (at your expense) to the Starkey Hearing

Technologies authorized dealer from whom you purchased it, or to Starkey Hearing

Technologies, Repair Dept., 6700 Washington Ave. S., Eden Prairie, MN 55344.

For additionalinformation you may visit www.soundgearhearing.com or email

SoundGear at [email protected].

WHAT THIS LIMITED WARRANTY DOES NOT COVER:

Batteries; accessories; or damage to your hearing protection device caused by misuse

or neglect, accident, unauthorized alteration, or failure to provide reasonable and

necessary maintenance and cleaning.

Limited Warranty

DISCLAIMER OF CONSEQUENTIAL AND INCIDENTAL DAMAGES:

THE PURCHASER SHALL NOT BE ENTITLED TO RECOVER FROM STARKEY HEARING

TECHNOLOGIES ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES RESULTING FROM

ANY DEFECT IN THE HEARING PROTECTION DEVICE, INCLUDING BY WAY OF EXAMPLE

ONLY, EXPENSES TO DELIVER THE DEVICE TO AN AUTHORIZED STARKEY HEARING

TECHNOLOGIES DEALER OR TO STARKEY HEARING TECHNOLOGIES, HOTEL ROOMS,

OR LOST WAGES. THIS EXCLUSION AND DISCLAIMER OF CONSEQUENTIAL AND

INCIDENTAL DAMAGES SHALL BE DEEMED INDEPENDENT OF, AND SHALL SURVIVE,

ANY FAILURE OF THE ESSENTIAL PURPOSE OF ANY REMEDY OF THIS LIMITED

WARRANTY.

Some States do not allow the exclusion or limitation of consequential or incidental

damages, so the above exclusions may not apply to you.

YOUR LEGAL REMEDIES:

THIS LIMITED WARRANTY DOES NOT “EXTEND TO FUTURE PERFORMANCE.” ANY

ACTION TO ENFORCE THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTIES MAY

AND SHALL NOT BE COMMENCED MORE THAN 90 DAYS AFTER THE EXPIRATION OF

THE WARRANTY PERIOD. THE PERFORMANCE OF REPAIRS SHALL NOT SUSPEND THIS

LIMITATIONS PERIOD FROM EXPIRING. UNDER NO CIRCUMSTANCES SHALL STARKEY

HEARING TECHNOLOGIES BE OBLIGATED TO REFUND ALL OR ANY PART OF THE

PURCHASE PRICE OF THE HEARING PROTECTION DEVICE. Some States do not allow

the reduction in the limitation period, so the above reduction in the limitation period may

not apply to you.

This warranty gives you speciﬁc legal rights. You may also have other rights, which vary

from State to State.

This warranty is valid only in the United States.

Inhaltsverzeichnis

Andere Lapierre Fahrradzubehör Handbücher

Lapierre

Lapierre 3 FPS2 X-Control Bedienungsanleitung

Beliebte Fahrradzubehör Handbücher anderer Marken

Sigma

Sigma BC 16.16 Bedienungsanleitung

Playcore

Playcore Dero Setbacks Bedienungsanleitung

VDO Cyclecomputing

VDO Cyclecomputing x3dw Bedienungsanleitung

Cateye

Cateye RAPID X2 Bedienungsanleitung

buratti meccanica

buratti meccanica Clorofilla Trail Bedienungsanleitung

Shimano

Shimano SG-8R20 Betriebsanleitung

BOB

BOB YAK Bedienungsanleitung

APLIC

APLIC 303303/20190717TW012 Bedienungsanleitung

SRAM

SRAM AXS BlipBox Bedienungsanleitung

Garmin

Garmin EDGE 500 Bedienungsanleitung

Shimano

Shimano FD-RX810 Bedienungsanleitung

Cateye

Cateye V2C - Gebrauchsanweisung

KMART

KMART 43115907 Bedienungsanleitung

SIGMA SPORT

SIGMA SPORT Buster 2000 Bedienungsanleitung

NVO Components

NVO Components STEM Bedienungsanleitung

DAXYS

DAXYS BP188 Bedienungsanleitung

XLC

XLC BV-W17 Bedienungsanleitung

Deda Elementi

Deda Elementi SUPERBOX Bedienungsanleitung
