Ledj Archi BAR 48 Bedienungsanleitung

www.prolight.co.uk

(Order code: LEDJ222)

USER MANUAL

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

SAFETY INSTRUCTIONS

Every person involved with the installation, operation & maintenance of this

equipment should:

- Be competent

- Follow the instructions of this manual

CAUTION! TAKE CARE USING THIS EQUIPMENT!

HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!

Before your initial start-up, please make sure that there is no damage caused during

transportation. Should there be any, consult your dealer and do not use the

equipment.

To maintain the equipment in good working condition and to ensure safe operation, it is necessary

for the user to follow the safety instructions and warning notes written in this manual.

Please note that damages caused by user modifications to this equipment are not

subject to warranty.

ARCHI BAR 48 SAFETY

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused

by the non-observance of this manual or any unauthorised modification to the

equipment.

• Never let the power-cable come into contact with other cables. Handle the power-cable

and all mains voltage connections with particular caution!

• Never remove warning or informative labels from the equipment.

• Do not open the equipment and do not modify the equipment.

• Do not connect this equipment to a dimmer-pack.

• Do not switch the equipment on and off in short intervals, as this will reduce the

system’s life.

• Do not expose to flammable sources, liquids or gases.

• Always disconnect the power from the mains when equipment is not in use or before

cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the

power-cable.

• Make sure that the available voltage is between 220v/240v.

• Make sure that the power-cable is never crimped or damaged. Check the equipment and

the power-cable periodically.

• If the equipment is dropped or damaged, disconnect the mains power supply immediately.

Have a qualified engineer inspect the equipment before operating again.

• If your product fails to function correctly, discontinue use immediately. Pack the unit

securely (preferably in the original packing material), and return it to your Prolight dealer

for service.

• Only use fuses of same type and rating.

• Repairs, servicing and power connection must only be carried out by a qualified

technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.

• WARRANTY; One year from date of purchase.

OPERATING DETERMINATIONS

If this equipment is operated in any other way, than those described in this manual,

the product may suffer damage and the warranty becomes void.

Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,

lamp failure etc.

Do not endanger your own safety and the safety of others!

Incorrect installation or use can cause serious damage to people and property.

Setup

Operating Instructions

The Archi Bar 48 is a DMX-512 controllable unit made up of high efficiency and Ultra Bright

RGBW LEDs and will operate in stand alone, master/slave or DMX control modes.

ARCHI BAR 48 INTRODUCTION

Introduction

Features

• DMX channels: 4/6/19 selectable

• 48 x 3W Ultra Bright RGBW LEDs (R: 12, G: 12, B: 12, W: 12)

• 14 built-in programmes

• 4 push button LCD display

• Master/Slave functions

• Auto run mode

• Power in/out connections

• DMX in/out connections

• Consumption: 84W

• Beam 25 degrees

• IP Rating: IP65

• Power supply: 240V

• Dimensions: 1000 x 120 x 175mm

• Weight: 10.2Kgs

Overview

POWER

DMX

POWER

DMX

LCD DISPLAY

POWER

DMX

POWER

DMX

LCD DISPLAY

ARCHI BAR 48 OPERATION MODES

Operation modes

Dimming mode:

To activate the unit in dimming mode, press the “MODE” button to show “DIMMING” on the LCD

screen. Now press the “ENTER” button to set the brightness of the LEDs by using the “UP” and

“DOWN” buttons.

Press the “ENTER” button once for the Red LEDs, twice for Green LEDs, three for Blue LEDs

and four for the White LEDs. Each of the colours can be set from 00 - 99 by using the “UP” and

“DOWN” buttons. Press the “ENTER” button once more to select the desired flash value and

adjust by using the “UP” and “DOWN” buttons.

Brightness levels 00-99 (00 = low, 99 = high), Flash values: 00 - 99 (00 = slow, 99 = fast)

Auto run mode:

To activate the unit in auto run mode, press the “MODE” button to show “AUTO RUN” on the

LCD screen. Now press the “ENTER” button to select the desired frequency level by using the

“UP” and “DOWN” buttons.

“FQN” 01-99 (01 = low, 99 = high)

Note: In this mode, it will run 13 built-in programmes in a continious loop.

Slave mode:

To activate the unit in slave mode, first you must link multiple units together and press the

“MODE” button to show “SLAVE MODE” on the LCD screen. Now on the master unit press the

“MODE” button to select the desired mode and the slave units will now run in sequence with the

master unit.

Built-in programmes:

To activate the units built-in programmes, press the “MODE” button to show “01.DIMMING” on

the LCD screen. Press the “ENTER” button to choose between the 14 built-in programmes by

using the “UP” and “DOWN” buttons. Now press the “ENTER” button to select the desired speed

and adjust by using the “UP” and “DOWN” buttons. Press the “ENTER” button once more to

select the desired flash value and adjust by using the “UP” and “DOWN” buttons.

Speed values: 00 - 99 (00 = slow, 99 = fast), Flash values: 00 - 99 (00 = slow, 99 = fast)

For the 14 built-in programmes please see page 5.

DMX mode:

To activate the unit in DMX mode, press the “MODE” button to show “DMX MODE” on the LCD

screen. Press the “ENTER” button and select the desired DMX address setting by using the “UP”

and “DOWN” buttons. Then to select one of the 3 DMX modes 19, 6 or 4 channel,

press the “ENTER” button again to choose the desired DMX mode by using the “UP” and

“DOWN” buttons.

For the 4, 6, and 19 channel DMX address information please see pages 6 & 7.

NOTE: Once the desired settings have been selected in each of the above modes, ALWAYS

confirm the settings by pressing the “ENTER” button.

ARCHI BAR 48 BUILT-IN PROGRAMME CHART

14 Built-in programme chart

4 channel mode DMX chart 6 channel mode DMX chart

01. Dimming

Blackout - Full on

Flash 00 - 99

Red: 00-99, Green: 00-99, Blue: 00-99, White: 00-99

Flash adjustable

02. Colour Jump

Speed 00 - 99, Flash 00 - 99

7 colour change

Speed & Flash adjustable

03. Colour Fade

Speed 00 - 99, Flash 00 - 99

7 colour fade in, fade out

Speed & Flash adjustable

04. Dream

Speed 00 - 99, Flash 00 - 99

7 colour fade

Speed & Flash adjustable

05. Colour Flow

Speed 00 - 99, Flash 00 - 99

7 colour chase (forward & reverse)

Speed & Flash adjustable

06. Over Flow

Speed 00 - 99, Flash 00 - 99

7 colour chase in relay pattern (forward & reverse)

Speed & Flash adjustable

07. Colour Chase

Speed 00 - 99, Flash 00 - 99

7 colour chase (forward)

Speed & Flash adjustable

08. Multi-colour

Speed 00 - 99, Flash 00 - 99

Multi-colour relay chase

Speed & Flash adjustable

09. Fade Flow

Speed 00 - 99, Flash 00 - 99

7 colour fade relay chase

Speed & Flash adjustable

10. Two Flow

Speed 00 - 99, Flash 00 - 99

2 colour relay chase

Speed & Flash adjustable

11. One Way

Speed 00 - 99, Flash 00 - 99

7 colour relay chase

Speed & Flash adjustable

12. Two Way

Speed 00 - 99, Flash 00 - 99

7 colour relay chase (criss cross)

Speed & Flash adjustable

13. Two colour

Speed 00 - 99, Flash 00 - 99

7 multi-colour relay chase (criss cross)

Speed & Flash adjustable

CH4

0-255

CH1

0-255

CH2

0-255

CH3

0-255

CH4

0-255

CH1

0-255

CH2

0-255

CH3

0-255

CH5

Master

Dimmer

0-255

CH6

0-10 - On

11-255 - Flash

ARCHI BAR 48 DMX PROGRAMME CHARTS

19 channel mode DMX chart

CH4CH1 CH2 CH3 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12 CH13 CH14 CH15

0-5

black

out

6-10

dimmer

11-15

dimmer

16-20

Red

21-25

Green

26-30

Blue

31-35

White

36-40

R/W

41-45

R/G

46-50

R/B

51-55

G/B

56-60

W/B

61-65

W/G

66-70

R/G/B

71-75

R/G/W

76-80

R/B/W

81-85

G/B/W

86-90

R/G/B/W

91-100

R/G/B/W

Dimmer

0-255

Flash

0-255

Speed

0-255

Flash

0-255

101-110

Colour jump

111-120

Dream

121-130

Colour flow

131-140

Over Lap

flow

141-150

Colour

chase

151-160

Multi-colour

161-170

Fade flow

171-180

Two flow

181-190

One way

191-200

Two way

201-210

Two colour

211-255

N/A

CH16 CH17 CH18 CH19

0-255

11-15

dimmer

CH1

Dimmer

0-255

Flash

0-255

CH2 CH3

ARCHI BAR 48 DMX SET UP

DMX-512:

• DMX (Digital Multiplex) is a universal protocol used as a form of communication between

intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the

controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the

DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only

have a data “out” terminal).

DMX Linking:

• DMX is a language allowing all makes and models of different manufactures to be linked together

and operate from a single controller, as long as all fixtures and the controller are DMX compliant.

To ensure proper DMX data transmission, when using several DMX fixtures try to use the

shortest cable path possible. The order in which fixtures are connected in a DMX line does not

influence the DMX addressing. For example; a fixture assigned to a DMX address of 1 may be

placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a

fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to

address 1 to that unit, no matter where it is located in the DMX chain.

DATA Cable (DMX cable) requirements (for DMX operation):

• The Archi Bar 48 can be controlled via DMX-512 protocol. The DMX address is set on the

back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for

data input/output (figure 1).

Figure 1

Also remember that DMX cable must be daisy chained and cannot be split.

Further DMX cables can be purchased

from all good sound and lighting suppliers

or Prolight dealers.

Please quote:

CABL10 – 2M

CABL11 – 5M

CABL12 – 10M

Notice:

• Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield

conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer

casing. Grounding the shield could cause a short circuit and erratic behaviour.

Special Note: Line termination:

• When longer runs of cable are used, you may need to use a terminator on the last unit to

avoid erratic behaviour.

Using a cable terminator (part number CABL90) will decrease the possibilities of erratic

behaviour.

5-Pin XLR DMX Connectors:

• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin

XLR fixtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin

XLR connectors in to a 3-pin line a cable adaptor must be used. The chart below details the

correct cable conversion.

Termination reduces signal transmission problems

and interferance. it is always advisable to connect a

DMX terminal, (resistance 120 Ohm 1/4 W) between

pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.

ARCHI BAR 48 DMX SET UP

ARCHI BAR 48 TECHNICAL SPECIFICATIONS

Technical Specifications

Weight & Dimensions

• Length…............................................................1000mm

• Width..................................................................120mm

• Height……………………………………………...175mm

• Weight………………………………………..........10.2sKgs

Power

• AC input……………………………………..........240V/50hz

• Power consumption.........................................84W

• Fuse

• Main………………………………………………...F2A

Control & Programming

• Data input………………………………………....Locking 3-pin XLR male socket

• Data output………………………………………..Locking 3-pin XLR female socket

• Protocols………………………………………….DMX-512 USITT

• DMX channels…………………………………....19, 6 and 4

Inhaltsverzeichnis

Andere Ledj Beleuchtungsausrüstung Handbücher

Ledj

Ledj Spectra Par 15Q8 PRO Bedienungsanleitung

Ledj

Ledj LEDJ112 Bedienungsanleitung

Ledj

Ledj Mini Pix 9 Panel Bedienungsanleitung

Ledj

Ledj BlockBuster 6 Bedienungsanleitung

Ledj

Ledj LEDJ251 Bedienungsanleitung

Ledj

Ledj LED-56 Bedienungsanleitung

Ledj

Ledj RGB DMX Bedienungsanleitung

Ledj

Ledj STRATOS SPOT Bedienungsanleitung

Ledj

Ledj Libretto Mini WW Profile Bedienungsanleitung

Ledj

Ledj Pixel Bar LEDJ73A Bedienungsanleitung

Ledj

Ledj STAGE BAR 16 Bedienungsanleitung

Ledj

Ledj LEDJ387 Bedienungsanleitung

Ledj

Ledj LEDJ377 Bedienungsanleitung

Ledj

Ledj Spectra Flood 18HEX10 Bedienungsanleitung

Ledj

Ledj LEDJ188 Bedienungsanleitung

Ledj

Ledj Spectra Par LEDJ88 Bedienungsanleitung

Ledj

Ledj Stage Par CZ200 3200K Bedienungsanleitung

Ledj

Ledj LED RGB 252 Bedienungsanleitung

Ledj

Ledj Mini Pix 4 Batten Bedienungsanleitung

Ledj

Ledj FLEX30 Bedienungsanleitung

Ledj

Ledj Libretto Mini Bi-CCT Profile Bedienungsanleitung

Ledj

Ledj LEDJ255 Bedienungsanleitung

Ledj

Ledj Aspect XL Bedienungsanleitung

Ledj

Ledj Slimline CW Series Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
