LELY COSMIX P Einrichtungshandbuch

innovators in agriculture

www.lely.com

Lely Industries N.V.

Installation and Operator Manual

5.2308.8512.0 B

EN –English Original

LELY COSMIX P

Concentrate Feeder

INTENTIONALLY BLANK

5.2308.8512.0 B

innovators in agriculture

5.2308.8512.0 B

TRADEMARKS, COPYRIGHT AND DISCLAIMER 3

TRADEMARKS, COPYRIGHT AND DISCLAIMER

Lely, Astronaut, Astri, Atlantis, Attis, AWS, C4C,Calm, Caltive, Capsule,

Commodus, Compedes, Cosmix, Dairywise, Discovery, F4C, Fertiliner,

Gravitor, Grazeway, Hibiscus, Hubble, I-flow, InHerd, Juno, L4C, Lely

Center, Lelywash, Lotus, Luna, Nautilus, Orbiter, Quaress, Qwes, Shuttle,

Splendimo, Storm, T4C, Tigo, Vector, Viseo, Voyager, Walkway and

Welger are registered trademarks of the Lely Group.

Lely reserves all rights with respect to its trademarks. Any unauthorized

use of any Lely-owned trademark or any use of a trademark that is

confusingly similar to, or likely to cause confusion with a Lely-owned

trademark, would constitute infringement of Lely’s exclusive rights. All

rights reserved.

The information given in this publication is provided for information

purposes only and does not constitute an offer for sale. Certain products

may not be available in individual countries and products supplied may

differ from those illustrated.

No part of this publication may be copied or published by means of

printing, photocopying, microfilm or any other process whatsoever

without prior permission in writing by Lely Holding S.à.r.l. Although the

contents of this publication have been compiled with the greatest

possible care, Lely cannot accept liability for any damage that might arise

from errors or omissions in this publication.

Lely Industries N.V.

Cornelis van der Lelylaan 1

3147 PB Maassluis

the Netherlands

Phone: +31 (0)88 1228221

Fax: +31 (0)88 1228222

Website: www.lely.com

innovators in agriculture

INTENTIONALLY BLANK

5.2308.8512.0 B

4 TRADEMARKS, COPYRIGHT AND DISCLAIMER

innovators in agriculture

5.2308.8512.0 B

LIST OF INCLUDED AMENDMENTS 5

LIST OF INCLUDED AMENDMENTS

No:

Issue Date

(yy/mm) Chapter(s) Remarks

3 16/08 4,5 •Lifting mechanism of the M-box changed.

•Air pressure ON / OFF valve added.

2 15/08 4,5,7 •Long distance (LD) tag functionality added: machine

5.2309.0040.X.

•Adjustment of the photocell (Qwes IR models) added.

•Feed presence sensor removed.

•Pressure reducer added to control box.

•Several other minor updates.

111/02 Initial issue.

innovators in agriculture

INTENTIONALLY BLANK

5.2308.8512.0 B

6 LIST OF INCLUDED AMENDMENTS

innovators in agriculture

5.2308.8512.0 B

WARRANTY RESTRICTIONS 7

WARRANTY RESTRICTIONS

Excluded from this warranty are any cost or expenses due to:

•Abnormal use of the equipment which is not according to the

specifications stated in the Operator Manual or handled during the

Operators Service and Maintenance Certification program.

•The result of any intervention by technicians other than Lely service

technicians or technicians who have Lely’s approval to perform certain

duties.

•Incidents such as freezing, ice, fire, flood, inundation or any other

form of excessive water, lightning.

•Defect of the electrical system or grounding.

•Use of compressed air that does not meet the quality standards set by

Lely Industries.

•Damage to the electrical system as a result of vermin or the like.

•For USERS that have followed the Operators Maintenance and Service

Certification: Any damage resulting from abnormal use of the

equipment which is not according to the specifications stated in the

Operator Technical Training Manual is not covered by the warranty

scheme.

Warranty does not apply to consequential damage which does not

involve the machine itself.

All systems are tested. However in the event of a malfunction Lely cannot

be held responsible for consequential damage.

innovators in agriculture

INTENTIONALLY BLANK

5.2308.8512.0 B

8 WARRANTY RESTRICTIONS

innovators in agriculture

5.2308.8512.0 B

PREFACE 9

PREFACE

Manual Contents

This manual contains the information necessary for the correct

installation and operation of a LELY COSMIX P Concentrate Feeder.

Study and understand this information thoroughly before configuration

of the concentrate feeder. Failure to do so could result in damage to

equipment. Please consult your local Lely service provider if you do not

understand the information in this manual, or if you need additional

information.

All information in this manual has been compiled with care. Lely shall not

be liable for errors or faults in this manual. The recommendations are

meant to serve as guidelines. All instructions, pictures and specifications

in this manual are based on the latest information that was available at

the time of publication. Your concentrate feeder may comprise

improvements, features or options that are not covered in this manual.

Applicability

The table below shows the type numbers of concentrate feeder for which

this manual is applicable.

Model designation

Model Type number

LELY COSMIX P Concentrate Feeder with Qwes ISO

neck identification

5.2308.0000.X

LELY COSMIX P Concentrate Feeder with Qwes IR

identification

5.2308.0010.X

LELY COSMIX P Concentrate Feeder with Qwes ISO

leg identification

5.2308.0020.X.

LELY COSMIX P Concentrate Feeder with Qwes LD

identification

5.2308.0040.X

Software version

The description, operation and procedures in this manual are based on

the following software versions:

•T4C version 3.1.3 or higher.

•E-Link version 1.08R or higher.

•ADS3830 PCB; 01.09.0 or higher.

innovators in agriculture

5.2308.8512.0 B

10 PREFACE

Standard Torque Loading of Parts

All the nuts, bolts and screws used on the machine are torque tightened

to standard torque loadings applicable to the construction materials

used.

If a part has a non-standard torque loading, it is specified in the

applicable part of the manual.

Registration

The Type and Serial Number Plate is attached to the control box of the

concentrate feeder, on the top. Always include the type and serial

number of your concentrate feeder when you contact your local Lely

service provider or order spare parts.

Figure 1. Type and Serial Number Plate

We suggest you complete the table below with the type and serial

numbers of your concentrate feeder. This makes sure you can easily find

the information.

Type number

Serial number

Maintenance Authorization

Only technicians certified by Lely Industries are authorized to do

maintenance on the concentrate feeder, except for the

maintenance done by the operator as indicated in the Operator

Manual.If people who are not certified by Lely Industries do

maintenance on the concentrate feeder, the warranty on the

concentrate feeder becomes invalid.

Contact Number Local Service Provider

We suggest you write the telephone number and email address of your

local service provider contact in the table below. This makes sure you can

easily find the information.
