Lenovo Type 8332 Bedienungsanleitung

Secure Managed Client

Storage Array User Guide

Machine Type 8332

Secure Managed Client - Storage Array

User Guide

Note

Before using this information and the product it supports, be sure to read the Safety and Warranty Guide that came with this

product.

First Edition (October 2008)

LENOVO products, data, computer software, and services have been developed exclusively at private expense and

are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted

rights to use, reproduction and disclosure.

LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are delivered

pursuant a General Services Administration ″GSA″ contract, use, reproduction, or disclosure is subject to restrictions

set forth in Contract No. GS-35F-05925.

Contents

Introduction . . . . . . . . . . . . .v

Product contents, order options, and accessories . .v

Chapter 1. Important safety information 1

Chapter 2. Features . . . . . . . . . .3

Enclosure subsystem . . . . . . . . . . . .4

Enclosure chassis . . . . . . . . . . . . .5

Server board subdivision . . . . . . . . . .6

Server board I/O panel . . . . . . . . . .6

Front operator's panel . . . . . . . . . . .7

Rear panel . . . . . . . . . . . . . . .8

Power supply unit . . . . . . . . . . . .8

Power supply output connectors . . . . . . .9

Cooling fans . . . . . . . . . . . . . .9

Drive carrier module . . . . . . . . . . .10

Drive status indicator . . . . . . . . . .11

Anti-tamper locks . . . . . . . . . . .11

Chapter 3. Getting Started . . . . . .13

Planning your installation . . . . . . . . .13

Drive bay numbering convention . . . . . . .13

Enclosure installation prerequisites . . . . . .14

Preparation of site and host server . . . . . .14

Unpacking the enclosure system . . . . . .14

Planning and configuring your installation . . .15

Rack installation prerequisites . . . . . . .15

Installing the enclosure in a rack . . . . . . .16

Rail kit assembly . . . . . . . . . . .16

Enclosure installation . . . . . . . . . .16

Power cord connection . . . . . . . . . .17

Grounding checks . . . . . . . . . . .17

Chapter 4. Operation . . . . . . . . .19

Power on . . . . . . . . . . . . . . .19

Power supply unit LED . . . . . . . . .19

Front operator's panel LEDs and switches . . . .20

Starting the drives . . . . . . . . . . . .21

Disk drive LEDs . . . . . . . . . . . .21

Engaging the drive module anti-tamper locks . .21

BIOS settings . . . . . . . . . . . . . .22

Turning off . . . . . . . . . . . . . .22

Chapter 5. Troubleshooting and

problem solving . . . . . . . . . . .23

Initial start-up problems . . . . . . . . . .23

Faulty cords . . . . . . . . . . . . .23

Alarm sounds and power up . . . . . . .23

Computer doesn't recognize the subsystem . . .23

LEDs . . . . . . . . . . . . . . . .23

Power supply units . . . . . . . . . . .23

Front operator's panel . . . . . . . . . .24

Cooling fan LEDs . . . . . . . . . . .25

Drive carrier module LEDs . . . . . . . .25

Rear panel LED . . . . . . . . . . . .25

Server board LEDs . . . . . . . . . . .25

Audible alarms . . . . . . . . . . . . .26

Alarm interpretation . . . . . . . . . . .26

Troubleshooting . . . . . . . . . . . . .28

System faults . . . . . . . . . . . . .28

Power supply unit faults . . . . . . . . .28

Cooling fan faults . . . . . . . . . . .29

Thermal cooling . . . . . . . . . . . .29

Drive carrier module faults . . . . . . . . .30

Dealing with hardware faults . . . . . . . .30

Continuous operation during replacement . . . .31

Chapter 6. Notices . . . . . . . . . .33

Trademarks . . . . . . . . . . . . . .34

iv User Guide

Introduction

The Secure Managed Client (SMC) - Storage Array is a 2U (rack space) disk drive

enclosure, currently housing 12 low-profile 2.54-cm (1-inch) high, 1.5/3.0 Gb/s,

8.89-cm (3.5-inch) form factor SATA disk drives. Each individual disk drive is field

replaceable.

This guide is written for system technicians who are responsible for setting up,

installing, and troubleshooting this storage system. This document provides a brief

overview of the features of this product, a list of accessories or other components

you may need, instructions on setting up the system, and troubleshooting

information.

Product contents, order options, and accessories

The SMC - Storage Array ships with the following items:

v Secure Managed Client (SMC) - Storage Array Setup Poster, in the product box

v AC power cord(s) (North America only)

v 50 Phillips head screws

v Resource CD

v Rail kit

v T10 TORX screwdriver

v 12 hard drive labels

For information about which accessories and third-party hardware have been

tested and can be used with your storage system, and for ordering information for

Lenovo products, visit http://www.lenovo.com.

vi User Guide

Chapter 1. Important safety information

CAUTION:

Before using this manual, it is important that you read and understand all the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading

and understanding this safety information reduces the risk of personal injury

and or damage to your product.

2 User Guide
